Code CR4900Android User Manual page 21

13 ‐ BarcodeReading
13.1 – Scanning
13.2 –SupportedSymbologies
13.3 – Reading Ranges
Test Barcode
3 mil Code 39
7.5 mil Code 39
10.5 mil GS1 DataBar
13 mil UPC
4.2 mil Data Matrix
5 mil Data Matrix
6.3 mil Data Matrix
10 mil Data Matrix
20.8 mil Data Matrix
Note: working ranges are a combination of both the wide and high density fields. All samples were high quality barcodes and were read along a physical center line
at a 10° angle. Default AGC settings were used. Accuracy= +/‐ 10%.
D006791_CR49XX_User_Manual
CR4900 Performance
Min Inches (mm)
3.1" (80 mm)
1.3" (33 mm)
0.8" (20 mm)
1.1" (28 mm)
1.9" (48 mm)
1.7" (43 mm)
1.3" (33 mm)
0.8" (20 mm)
1.1" (28 mm)
FPO
10 c m
Max Inches (mm)
4.0" (102 mm)
7.2" (182 mm)
8.7" (220 mm)
11.0" (280 mm)
4.3" (110 mm)
4.5" (115 mm)
5.9" (150 mm)
7.1" (180 mm)
13.5" (343 mm)
2
