INSTALLATION INSTRUCTIONS FOR PART CHTO-013
Chrysler vehicles
KIT FEATURES
• Provides accessory (12-volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in amplified, non-amplified systems, or digital amplified systems
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• ASWC-1 harness included (ASWC-1 sold separately)
• Adjustable gain control for overall volume (on amplified systems)
• Retains blind spot detection system (if equipped)
• High level speaker input
• Micro "B" USB updatable
• Retains balance and fade
METRA. The World's best kits.™
CHTO-013
2004-up
APPLICATIONS
See inside front cover
INTERFACE COMPONENTS
• CHTO-013 Interface • 16-pin harness with
stripped leads • 10-pin harness to 22-pin Chrysler
harness with stripped leads (A) • 10-pin harness to
22-pin Chrysler harness with stripped leads (B) •
4-pin harness with stripped leads
TOOLS REQUIRED
• Cutting tool • Tape • Crimping tool • Connectors
(example: butt-connectors, bell caps, etc.)
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CHTO-013 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Axxess CHTO-013

  • Page 1 INSTALLATION INSTRUCTIONS FOR PART CHTO-013 CHTO-013 INTERFACE COMPONENTS • CHTO-013 Interface • 16-pin harness with Chrysler vehicles stripped leads • 10-pin harness to 22-pin Chrysler harness with stripped leads (A) • 10-pin harness to 2004-up 22-pin Chrysler harness with stripped leads (B) • 4-pin harness with stripped leads APPLICATIONS See inside front cover TOOLS REQUIRED KIT FEATURES • Cutting tool • Tape • Crimping tool • Connectors (example: butt-connectors, bell caps, etc.) • Provides accessory (12-volt 10 amp) • Retains R.A.P. (retained accessory power) • Used in amplified, non-amplified systems, or digital amplified systems • Provides NAV outputs (parking brake, reverse, and V.S.S.) • ASWC-1 harness included (ASWC-1 sold separately) CAUTION: Metra recommends disconnecting the •...
  • Page 2 CHTO-013 Applications Connections to be made From the 16-pin harness HaRnESS (a) - LD-CHTO-31 CHRYSLER DODGE JEEP • Connect the (2) Red wires to the ignition/accessory wire of the aftermarket radio. (continued) (continued) 300 2005-2007 Magnum 2005-2007 Grand Cherokee • Connect the Orange/White wire to the illumination wire of the aftermarket Ram 1500 2006-2008 2005-2007 Aspen 2007 radio. If the aftermarket radio does not have an illumination wire, tape off the DODGE Ram 2500/3500 Patriot 2007-2008 Orange/White wire. Caliber...
  • Page 3 CHTO-013 Connections to be made • Connect the Gray wire to the right front positive speaker output of the • Connect the Green wire to the radio’s left rear positive speaker output. aftermarket radio. • Connect the Green/Black wire to the radio’s left rear negative speaker output. • Connect the Gray/Black wire to the right front negative speaker output of the • Connect the Purple wire to the radio’s right rear positive speaker output. aftermarket radio. • Connect the Purple/Black wire to the radio’s right rear negative • Connect the Green wire to the radio’s left rear positive speaker output. speaker output. • Connect the Green/Black wire to the radio’s left rear negative speaker output. Tip: If you are unsure if your vehicle is amplified or not, note that these following •...
  • Page 4 INSTALLATION INSTRUCTIONS FOR PART CHTO-013 Installing the CHTO-013 • With all connections completed to the aftermarket radio, plug the 22-pin harness into the vehicles wiring harness. • Reconnect the negative battery terminal. • Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to test the radio. Testing the CHTO-013 • Turn the ignition on if not already, and then turn the radio on to verify that the radio works. Check balance and fader controls for proper operation. For amplified models only: • To adjust the overall volume of your audio system rotate the potentiometer, which is located on the 16-pin side of the interface clockwise. Our installation parts and kits make aftermarket stereo and video installation a breeze.
