Ethernet Web-Smart Switch Quick Installation Guide Unpacking Information Thank you for purchasing the D316S 16-Ports/D324S 24-Port Fast Ethernet Web Smart Switch. Before you start, please verify that your package contains the following items: 1. One 16/24-Ports Fast Ethernet Web Smart Switch 2. - Page 3 D326S Front Panel The front panel of the switch is shown as below D316S 16-Port D324S 24-Port LED Definition Status Operation Steady The switch is powered on Green Power The switch is powered off Green The port is connected LINK/...
- Page 4 10/100Mbps(copper) Full Duplex 100Mbps Half Duplex Installation of D316S 16-Port/D324S 24-Port Fast Ethernet Web Smart Switch This switch can be placed directly on your desktop, or mounted in a rack. After completing the device installation and you can immediately use the switch simply by attaching the cables and turning the power on.
-
Page 5: Desktop Installation
Desktop Installation 1. Install the switch on a level surface that can support the weight of the unit and the relevant components. 2. Plug the switch with the female end of the provided power cord and plug the male end to the power outlet. Rack-mount Installation The switch may be standalone, or mounted in a rack. - Page 6 The factory default value of User Name and Password is “admin”. After authentication procedure, the home page shows Now, you can start to manage D316S/D324S Switch. For any advanced configurations setup such as VLAN and QoS, please refer to the Manual within the CD-ROM.
