SEI Martinique HE4292R0TX Assembly Instructions Manual

Entry bench/storage

Advertisement

Quick Links

HE4292R0TX
Martinique Entry
For assistance with assembly contact:
Bench/Storage
Southern Enterprises Inc.
Customer Service 1-800-633-5096
Assembly Instruction
service@seidal.com
www.seidal.com
Max weight capacity: 250 lbs.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Martinique HE4292R0TX and is the answer not in the manual?

Questions and answers

Summary of Contents for SEI Martinique HE4292R0TX

  • Page 1 HE4292R0TX Martinique Entry For assistance with assembly contact: Bench/Storage Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instruction service@seidal.com www.seidal.com Max weight capacity: 250 lbs.
  • Page 2 HE4292R0TX Martinique Entry Bench/Storage Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
  • Page 3 HE4292R0TX Martinique Entry Bench/Storage Assembly Instructions 1 screw MUST BE directly mounted into a wall stud. Wall anchor is not needed when mounting into a wall stud. Step 1: Attach left leg (3), right leg (4) to seat frame (1) and bottom shelf frame (2) by using screw (A), screw (B) and washer (D) as shown.
  • Page 4 Step 3: Attach back top frame (8) to wooden support panel (9) by using screw (B) & washer (D) as shown. Then attach it to top shelf (10) by using screw (C), (H) as shown. Figure 3 Step 4: Inserting back top frame (8) into back panel (6) as shown.
  • Page 5 Step 5: Put cushion seat (12) on the seat frame (1) and fix by using screw (E) as shown. Figure 5 Step 6: Locate the bench at a comfortable place, measure the wall and mark the width and height as shown. Measure the wall and mark the location of the center of each of wall mounting holes...
  • Page 6 Step 7: Insert plastic anchors ( G ) into the holes of wall as shown. (When doing this, you will need a hammer help you). Using the phillips head screwdriver, install screw (F) into each of the anchors (G) as shown.
  • Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
