System Sensor ExitPoint PF24VA Installation And Maintenance Instructions page 2

The same number of devices using 12 AWG wire will pro-
duce only a 2 volt drop. The same number of devices using
18 AWG wire will produce an 8 volt drop. Consult your panel
manufacturer's specifications, as well as the sounder's op-
erating voltage to determine the acceptable voltage drop.
NOTE: If class "A" wiring is installed the wire length may
be up to 4 times the single wire length in this calculation.
Table 1. Current Draw Measurements and
Sound Output Guide:
Speed Selection
DIP Switch Power
Speed Selection Setting
FAST (exit) 10 High
FAST (exit) 10 Med-High
FAST (exit) 10 Med
FAST (exit) 10 Med-Low
FAST (exit) 10 Low
MED-FAST 9 High
MED-FAST 9 Med-High
MED-FAST 9 Med
MED-FAST 9 Med-Low
MED-FAST 9 Low
MED-SLOW 8 High
MED-SLOW 8 Med-High
MED-SLOW 8 Med
MED-SLOW 8 Med-Low
MED-SLOW 8 Low
SLOW 7 High
SLOW 7 Med-High
SLOW 7 Med
SLOW 7 Med-Low
SLOW 7 Low
NOTE 1: Sound output measured in an anechoic room at 10
feet.
NOTE 2: Sound output measured in a reverberant room
at 10 feet.
Installation
Consult the Directional Sound Applications Guide (A05-
1048-XXX) for information regarding the appropriate
mounting locations of directional sounders.
DIP Switches for Speed Settings
DIP switch positions 7-10 are used to select the speed set-
ting of the sounder. Switch 10 is the fastest speed and is
used to mark perimeter exits and stairwells. The remain-
ing settings are used for egress guidance to the perimeter
exits. The egress route would begin with the slow setting
(switch 7) and follow medium fast (switch 9) and medium
slow (switch 8) and finally the fast setting (switch 10). If
more than one switch is selected the sounder will default to
the fastest setting.
D690-06-00
Maximum DC Audibility Audibility
Operating (dBA) (dBA)
Current (16 to (16 to
(mA RMS) 33V) 33V)
(16 to 33V) Note 1 Note 2
185 98 75
131 95 72
78 92 69
76 89 66
64 86 63
170 98 74
124 95 71
75 93 68
73 90 65
62 87 62
160 97 73
104 95 70
76 92 67
65 89 64
57 87 61
163 98 72
103 95 69
76 92 66
61 89 63
61 86 60
DIP Switch Settings for Alerting Messages
DIP switch positions 5 and 6 are used to select additional
tone pulses that can be inserted between bursts of direc-
tional sound pulses. These messages are used to give
building occupants instructions. There are four messaging
options to choose from. "Stairs Up" (Switch 5 off, Switch 6
on) will notify occupants that they are approaching a stair-
well and will need to go up. "Stairs Down" (Switch 5 on,
Switch 6 off) will notify occupants that they are approach-
ing a stairwell and will need to go down. "Area of Refuge"
(Switches 5 & 6 on) alerts people who need to find these
areas of refuge in a building. "Exit Here" (Switches 5 & 6
off ) notifies occupants that they have reached the perim-
eter exit.
Table 2. Additional Tone Selection Guide:
DIP Switch DIP Switch
Position 5 Position 6
Setting Setting
on
on
off
off
DIP switch setting 4 enables a directional sound device to
become disabled when used in conjunction with devices
with dry contacts such as heat sensors or control modules.
The sounder has a set of input terminals that can be con-
figured for an "active open" or "active closed" state. When
the switch is in the "on" position, the sounder is "on" when
the disable connection is closed. When the switch is in the
"off" position, the sounder is "on" when the disable connec-
tion is open. See Table 3 for operation modes.
Table 3. Enable/Disable Function Logic Table:
DIP Switch
Position 4
Setting
on
on
off
off
There are five different power settings for the sound output
pressure. Switch settings 1, 2, and 3 set the power set-
ting for the sounder. Switch 1 selects the Med-High setting,
switch 2 selects the Medium setting, switch 3 selects the
Med-Low setting. If all three switches are "off" this selects
the High setting and if all three switches are "on" this se-
lects the Low setting.
Directional Characteristics are as follows:
-3dBA angles- 40, 130 horizontal and vertical
-6dBA angles- 15, 160 horizontal and vertical
2
Sound Output
on Area of Refuge
off Stairs DOWN
on Stairs UP
off Exit Here
Wiring
Sound
Terminals
Output
3 & 4
open disabled
closed enabled
open enabled
closed disabled
I56-3071-000
