Summary of Contents for Studebaker SB6077
-
Page 2: Important Safety Instructions
WARNING TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. - Page 3 consult your product dealer or local power company. 19. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
- Page 4 The serial number of this product is found on its bottom cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: SB6077 Serial Number: __________________ PROTECT YOUR FURNITURE!! The Turntable and Speakers of this system are equipped with non-skid rubber „feet‟...
- Page 5 LOCATION OF CONTROLS TURNTABLE UNIT (TOP VIEW) PART NAME DESCRIPTIONS 45 RPM ADAPTER Use this Adapter when playing vintage 45RPM records with a 1.5” (38mm) center opening. PLATTER This is the rotating part of the Turntable. CENTER SPINDLE The center hole of the vinyl record to be played should align with this SPINDLE. PLATTER FELT MAT This is for covering the platter and on which the vinyl record is placed.
-
Page 6: Control Panel
CONTROL PANEL PART NAME DESCRIPTIONS 15 STANDBY / FUNCTION Press it once to turn ON the Turntable unit. Press it repeatedly to cycle through BUTTON the PHONO, BLUETOOTH and USB functions. Corresponding LED indicators will light. 16 PLAY PAUSE / In BT pairing mode, press it for fast pairing. - Page 7 TURNTABLE UNIT (REAR VIEW) PART NAME DESCRIPTIONS 27 DETACHABLE This cover should be installed before first use. It should be kept closed to keep out DUST COVER dust and foreign objects from falling onto the record surface and cartridge while the record is playing.
- Page 8 PART NAME DESCRIPTIONS 33 VOLUME The VOLUME CONTROL is normally flush with the top panel of the RIGHT CONTROL SPEAKER. Press it once to eject and expose the VOLUME CONTROL knob. Rotate (HIDE & EJECT the VOLUME CONTROL clockwise to increase the audio output level and STYLE) counterclockwise to decrease the audio output level.
- Page 9 ANTI-SHOCK LOCK DOWN SCREW The turntable on this unit features a built in Anti-Shock system. The turntable is locked down when shipped from the factory. Turn the ANTI-SHOCK LOCK DOWN SCREW in a clockwise direction to release the turntable and activate the anti-shock feature before operating the turntable. ACTIVE SPEAKER OPERATION 1.
-
Page 10: Pitch Control
STYLUS onto the record to start playing. Adjust the audio output level using the VOLUME CONTROL to obtain a comfortable listening level. 10. Thanks to the auto return feature, the Turntable will automatically stop and return to the TONEARM HOLDER when the last track of the record has finished playing. 11. - Page 11 Press the FUNCTION BUTTON to select the “BLUETOOTH” function. The SB6077 unit will start searching for a previously paired device that is active and in range. If no active device is found within 15 seconds, the Speakers will emit a low level alert beep tone.
- Page 12 Press RECORD BUTTON to set up the MP3 encoding process. When the RECORD INDICATOR lights, the system is ready to start MP3 encoding. Play the selected song at maximum undistorted volume in order to keep the encoded song loud and clear. When the end of the current song is reached, press the RECORD BUTTON to stop encoding and the RECORD INDICATOR will turn OFF.
- Page 13 Use a good quality record cleaner and brush set to keep your records clean. Studebaker models SB450 and SB445 are available online. Other carbon fiber brushes, velvet pads and record cleaning kits are available online or in local record stores.
- Page 14 You need to turn off the Bluetooth function of new Bluetooth device is already connected the currently connected external Bluetooth enabled device to SB6077 system. device so as to release the SB6077 system for a new pairing and connection. - 13 -...
- Page 15 SPECIFICATIONS TURNTABLE SECTION Cartridge Audio Technica AT3600LA (Moving Magnet type) Replacement Stylus ATN3600 Turntable Speed 2 speeds: 33 and 45 RPM Pitch Control Approx. +/-8% (with center click) Input Modes Phono / Bluetooth / USB Bluetooth Version Bluetooth v2.1+EDR AC Adapter : Input: AC 120V~ 60Hz Output: DC9V 1.5A...
- Page 16 90 DAY LIMITED WARRANTY AND SERVICE VALID IN THE U.S.A. ONLY SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from defective materials or factory workmanship for a period of 90 days from the date of original customer purchase and provided the product is utilized within the U.S.A.
