BEFORE YOU BEGIN

Thank you for selecting the new PROFORM
stepper. The 225c blends advanced engineering with
contemporary styling to provide you with a low-impact
workout in the convenience and privacy of your own
home.
For your benefit, read this manual carefully before
using the 225c. If you have additional questions,
please call our toll-free HELPLINE at 1-800-736-6879,

PART IDENTIFICATION CHART

Use the drawings below to identify the small parts used in assembly. The number in parenthesis below each
drawing refers to the key number of the part, from the PART LIST on page 10. The second number refers to the
quantity used in assembly. Note: If a part is not found in the parts bag, check to see if it has been
preassembled.
M10 Locknut (15)Ð8
M8 x 19mm Button
Head Bolt (21)Ð2
M4 x 12mm Console
Screw (22)Ð4
¨ 225c Monday through Saturday, 7 a.m. until 7 p.m. Central
Time (excluding holidays). To help us assist you,
please note the product model number and serial
number before calling. The model number is
831.285820. The serial number can be found on a
decal attached to the PROFORM
the front cover of this manual).
M8 Lock Washer (23)Ð2
M10 x 82mm Carriage Bolt (24)Ð2
M4 x 10mm Screw (28)Ñ8
3
¨ 225c stepper (see
M10 x 40mm Bolt (25)Ð2
M4 x 16mm Screw (27)Ñ4
