Page 1 Solution 862 Installation Manual ISSUE 1.30...
Page 3 MA406I Solution This page has been included for you to cut out and insert into the spine of the folder Installation Manual ISSUE 1.30 (61-2) 9672 1233...
Page 5: Installation Manual
Solution 862 Installation Manual Copyright  2001 by Electronics Design and Manufacturing Pty Limited, SYDNEY, AUSTRALIA Document Part Number MA406I DOCUMENT ISSUE 1.30 Printed 10 May 2001 This documentation is provided to suit Control Panel (CC406) Solution 862 Firmware Revision 1.00 – 1.09 Hardware Revision A - J Alarm Link required = 2.74 or higher...
Page 7 Table Of Contents Introduction _____________________________________________________________________ 15 Introduction __________________________________________________________________________ 16 Features _____________________________________________________________________________ 17 Quick Start___________________________________________________________________________ 18 Zone Defaults ________________________________________________________________________________ 20 Zone Types __________________________________________________________________________________ 20 Programming____________________________________________________________________ 21 Programming_________________________________________________________________________ 22 Programming With The Remote Codepad _________________________________________________ 23 Programming With The Hand Held Programmer___________________________________________ 25 Programming With The Programming Key________________________________________________ 27 Programming Option Bits ______________________________________________________________ 28 Installer’s Programming Commands _____________________________________________________ 29...
Page 8 Arming The System In STAY Mode 1 _____________________________________________________________ 54 Entry Guard Timer For STAY Mode ____________________________________________________________ 54 Forced Arming _____________________________________________________________________________ 55 Disarming The System From STAY Mode 1 ________________________________________________________ 56 Arming The System In STAY Mode 2 _____________________________________________________________ 57 Entry Guard Timer For STAY Mode ____________________________________________________________ 57 Forced Arming _____________________________________________________________________________ 57 Disarming The System From STAY Mode 2 ________________________________________________________ 58 Codepad Duress Alarm_________________________________________________________________________ 59...
Page 9 Master Code Functions_________________________________________________________________ 89 Reserved __________________________________________________________________________________ 89 Changing and Deleting User Codes _____________________________________________________________ 90 Changing and Deleting Remote Radio User Codes__________________________________________________ 92 Changing Domestic Phone Numbers ____________________________________________________________ 94 Change Telco Arm/Disarm Sequence ____________________________________________________________ 96 Setting STAY Mode 2 Zones _________________________________________________________________ 101 Turning Outputs On/Off _____________________________________________________________________ 102 Setting The Date and Time ___________________________________________________________________ 104 Walk Test Mode ___________________________________________________________________________ 105...
Page 10 Dialler Information ______________________________________________________________ 129 Dialler Information ___________________________________________________________________ 130 Primary Telephone Number For Receiver 1 ________________________________________________________ 131 Secondary Telephone Number For Receiver 1 ______________________________________________________ 131 Handshake Tone For Receiver 1_________________________________________________________________ 132 Transmission Format For Receiver 1 _____________________________________________________________ 133 Subscriber ID Number For Receiver 1 ____________________________________________________________ 133 Primary Telephone Number For Receiver 2 ________________________________________________________ 134 Secondary Telephone Number For Receiver 2 ______________________________________________________ 134 Handshake Tone For Receiver 2_________________________________________________________________ 135...
Page 11 Connections Of Split EOL Resistors Using N/O Contacts _____________________________________________ 160 Zone Programming ___________________________________________________________________ 161 Zone Operating Information ____________________________________________________________________ Zone Options________________________________________________________________________________ Zone Reporting Information ____________________________________________________________________ Solution 862 Zones Defaults ____________________________________________________________________ Zone Types _________________________________________________________________________________ Instant Zone_______________________________________________________________________________ Handover Zone ____________________________________________________________________________ Delay-1 Zone______________________________________________________________________________ Delay-2 Zone______________________________________________________________________________...
Page 12 System Reporting Information _____________________________________________________ 175 Reporting Information_________________________________________________________________ 176 Zone Status – Bypass Reports __________________________________________________________________ 176 Zone Status – Trouble Reports __________________________________________________________________ 177 Zone Status – Sensor Watch Reports _____________________________________________________________ 178 Zone Status – Alarm Restore Code_______________________________________________________________ 178 Zone Status Reporting Options__________________________________________________________________ 178 Open/Close Reports __________________________________________________________________________ 179 Open/Close Reporting Options__________________________________________________________________ 179 Codepad Duress Report _______________________________________________________________________ 180...
Page 13 Optional Equipment _____________________________________________________________ 223 Optional Equipment __________________________________________________________________ 224 Terminals and Descriptions _______________________________________________________ 229 Terminal Definitions and Descriptions ___________________________________________________ 230 Glossary Of Terms ___________________________________________________________________ 231 Solution 862 Wiring Diagram __________________________________________________________ 234 Solution 862 Component Overlay _______________________________________________________ 235 Telecom Connection Diagrams _________________________________________________________ 236...
Page 14 Appendices _____________________________________________________________________ 237 Appendix A __________________________________________________________________________ 238 Telephone Anti-Jamming ______________________________________________________________________ 238 Appendix B __________________________________________________________________________ 239 Test Reports Only When Armed ________________________________________________________________ 239 Specifications ___________________________________________________________________ 241 Warranty Statement___________________________________________________________________ 242 Year 2000 Compliance _________________________________________________________________ 242 Specifications ________________________________________________________________________ 243 Software Version Number _____________________________________________________________________ 243 Advice To Users _____________________________________________________________________________ 243 New Zealand Telepermit Notes _________________________________________________________________ 244 Programming Sheets _____________________________________________________________ 245...
Page 15: Introduction
Introduction This section includes the following; • Introduction • Features • Quick Start • Zone Defaults • Zone Types...
Page 16: Introduction
Installation Manual Solution 862 Introduction Congratulations on selecting the control panel for your installation. So that Solution 862 you can obtain the most from your unit, we suggest that you take the time to read through this manual and familiarise yourself with the numerous outstanding operating and installation features of this system.
Page 17: Features
Introduction Features security system uses the very latest in microprocessor technology to Solution provide you with more useful features and superior reliability and performance. Following is a list of the main features that the control panel will provide. ‹ Eight Programmable User Codes (1 – 8) ‹...
Page 18: Quick Start
Installation Manual Solution 862 Quick Start The following steps will allow you to use the control panel with the factory Solution 862 default values. The default values allow the control panel to communicate in the Contact ID format. If you are not familiar to programming the...
Page 19 Introduction How To Set The Date and Time 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Enter the day, month, year, hour and minute using the (DD, MM, YY, HH, MM) format (i.e.
Page 20: Zone Defaults
Handover 24 Hour Fire Handover 24 Hour Tamper Table 1: Zone Defaults For Solution 862 Zone Types There are thirteen different zone types to choose from when programming zones. These thirteen different zone types are available for all control panels. Refer to Solution 862 Zone Programming on page 161 for more information on programming zones.
Page 21: Programming
Programming This section includes the following; • Programming • Programming With The Remote Codepad • Programming With The Hand Held Programmer • Programming With The Programming Key • Programming Option Bits • Installer’s Programming Commands • Disable Factory Default • Defaulting The Control Panel...
Page 22: Programming
Installation Manual Solution 862 Programming The programming options of the control panel are stored in a non-volatile EPROM. This memory will hold all the relevant configuration and user specific data even during a total power loss. The data retention time is as long as ten years without power; therefore, no reprogramming will be required after powering the control panel down.
Page 23: Programming With The Remote Codepad
Programming Programming With The Remote Codepad When programming the control panel via the remote codepad, the system must be in the disarmed state with no alarm memory present. To access the Installer’s Programming Mode, enter the four digit followed by 1234 button.
Page 24 Installation Manual Solution 862 To change data in the current location, enter the new value (0 – 15) followed by the button. This will store the new data into the location and still leave you positioned at the same location. You will notice that the new information programmed will be displayed on the codepad indicators (e.g.
Page 25: Programming With The Hand Held Programmer
Programming Programming With The Hand Held Programmer The Hand Held Programmer (CC814) has five, seven segment displays. The three seven segment displays on the left display the current location number and the two seven segment displays on the right display the data for the location currently being displayed. To connect the hand held programmer, locate the socket marked PROGRAMMING KEY found at the top of the PCB (printed circuit board) next to the Auxiliary Module socket.
Page 26 Installation Manual Solution 862 To exit the Installer's Programming Mode, enter command followed by the button. Two beeps will be heard and the system will return to the disarmed state. Refer to Installer’s Programming Commands on page 29 for further information on commands that can be performed during access of the Installer's Programming Mode.
Page 27: Programming With The Programming Key
Programming Programming With The Programming Key The Programming Key (CC891) is a unique device that will allow you to store or copy programming information from your control panel. Once the programming key has information stored in the microprocessor, the programming key may be used to easily program other existing control panels with the same programming data, or be Solution...
Page 28: Programming Option Bits
Installation Manual Solution 862 Programming Option Bits When programming these locations, you will notice that there are four alternatives per location. You may select one, two, three or all of these alternatives for each location, however, only one number is required to be programmed. This number is calculated by adding the option bit numbers together.
Page 29: Installer's Programming Commands
Programming Installer’s Programming Commands There are ten different commands that can be used to perform various functions once the Installer's Programming Mode has been entered. To issue the command required, enter the corresponding numerical code followed by the button. Command Description Page Enable/Disable Zone Status Mode...
Page 30: Command 958 - Enable/Disable Zone Status Mode
Installation Manual Solution 862 Command 958 - Enable/Disable Zone Status Mode This function enables and disables the zone status display mode when using the hand held programmer. The hand held programmer will display the zones on the seven-segment display from left to right. If there is a dash illuminated on the display of the hand held programmer, the corresponding zone is unsealed and if the display is blank, the zone is sealed.
Page 31: Command 959 - Test Programming Key
Programming Key (CC891) may be used with the control panel. Solution 862 The programming key test is non-destructive and any data in the programming key will remain intact after the test has been completed. One long beep indicates that the programming key test has failed and two beeps indicates a successful test.
Page 32 Installation Manual Solution 862 How To Test The Programming Key Using The Hand Held Programmer 1. Before connecting the hand held programmer onto the pins marked PROGRAMMING KEY, make sure that the switch on the hand held programmer is in the EXT position and that no external key has been plugged onto the hand held programmer.
Page 33: Command 960 - Exit Installer's Programming Mode
Programming Command 960 - Exit Installer's Programming Mode This command is used to exit the Installer's Programming Mode after you complete programming the control panel. You may exit Installer’s Programming Mode from any location by entering command followed by the button.
Page 34: Command 962 - Copy Control Panel Memory To Programming Key
Installation Manual Solution 862 Command 962 - Copy Control Panel Memory To Programming Key This command is used to copy the control panel memory to the programming key. Only the Programming Key (CC891) may be used with the control panel.
Page 35: Command 963 - Copy From Programming Key To Control Panel
This command is used to copy data from the programming key to the control panel. Only the Programming Key (CC891) may be used with the control panel. Solution 862 How To Copy The Programming Key Memory To The Control Panel 1234 1.
Page 36: Command 964 - Erase Programming Key
Installation Manual Solution 862 Command 964 - Erase Programming Key This command erases all data from the programming key. Only the Programming Key (CC891) may be used with the control panel. Solution 862 How To Erase The Programming Key 1234 Enter Installer's Programming Mode (i.e.
Page 37: Command 965 - Set Up Domestic Dialling Format
Programming Command 965 - Set Up Domestic Dialling Format Command 965 has been included to allow the set up of the domestic dialling format a one step operation. Refer to page 120 for more information on Domestic Dialling Format. After you enter Installer's Programming Mode, enter command followed by the button.
Page 38: Command 966 - Enable/Disable Automatic Stepping Of Locations
Installation Manual Solution 862 Command 966 - Enable/Disable Automatic Stepping Of Locations This command allows automatic stepping of locations while programming via Installer’s Programming Mode. When enabled via the hand held programmer, the decimal point of the left most display will reflect the mode of operation.
Page 39 Programming Example (Auto Step Disabled) To enter the Primary Telephone Number "02 pause 9672 1055" with auto step disabled (i.e. Decimal point extinguished when using the hand held programmer). Press followed by the button. (This will position you at "LOCATION 000" being the start of the Primary Telephone Number For Receiver 1).
Page 40: Command 999 - Display Panel Type Or Software Version Number
Installation Manual Solution 862 Command 999 - Display Panel Type Or Software Version Number When using this command via the remote codepad, the codepad will display the panel version of the control panel. As there are two different control panel’s using the same PCB, it is difficult to know which control panel the PCB has been set up to be.
Page 41: Disable Factory Default
Installer Code MUST be used for further programming of the control panel. If the Installer Code is not known, the control panel will need to be returned to your EDM Distributor for exchange. A nominal fee applies for this service.
Page 42: Defaulting The Control Panel
Installation Manual Solution 862 Defaulting The Control Panel If the control panel does not have "LOCATION 900" programmed as 15, Solution 862 follow the procedure outlined below to successfully default the control panel back to the factory default settings. How To Default The Control Panel Via Installer Code Enter Installer Programming Mode.
Page 43: Codepad Indicators
Codepad Indicators This section includes the following; • CP5 Eight Zone LED Codepad • CP5 Eight Zone LCD Codepad...
Page 44: Cp5 Eight Zone Led Codepad
Installation Manual Solution 862 CP5 Eight Zone LED Codepad The codepad is the communications interface between you and your alarm system. The codepad allows you to issue commands and offers both visual and audible indications that guide you through the general operation.
Page 45: Stay Indicator
Codepad Indicators STAY Indicator STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY Mode 2. STAY indicator will also flash in unison with the AWAY indicator when Installer’s Programming Mode or Master Code Functions are used. Refer to page 54 for the different methods of arming the system in STAY Mode 1.
Page 46: Audible Indicators
Installation Manual Solution 862 Audible Indicators In general, the audible indications given out by the codepad are as follows: Indicator Definition A Button Has Been Pressed On The Codepad Or End Of Exit Time When Armed In Either STAY Mode 1 Or...
Page 47: Cp5 Eight Zone Lcd Codepad
Codepad Indicators CP5 Eight Zone LCD Codepad The codepad is the communications interface between you and your alarm system. The codepad allows you to issue commands and offers both visual and audible indications that guide you through the general operation. The codepad incorporates numerous indicators.
Page 48: Stay Indicator
Installation Manual Solution 862 STAY Indicator STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY Mode 2. indicator will also flash in unison with the indicator when STAY AWAY Installer’s Programming Mode or Master Code Functions are used.
Page 49: Fault Indicator
Codepad Indicators FAULT Indicator FAULT indicator is used to display that the system has detected a system fault. Refer to Fault Analysis Mode on page 63 for more information on system faults. Every time a new system fault has been detected (e.g.: indicator flashing), the codepad FAULT will begin to beep once every minute.
Page 50: Audible Indicators
Installation Manual Solution 862 Audible Indicators In general, the audible indications given out by the codepad are as follows: Indicator Definition A Button Has Been Pressed On The Codepad Or End Of Exit Time When Armed In Either STAY Mode 1 Or...
Page 51: System Operations
System Operations This section includes the following; • Arming The System In AWAY Mode • Disarming The System From AWAY Mode • Arming The System In STAY Mode 1 • Disarming The System From STAY Mode 1 • Arming The System In STAY Mode 2 •...
Page 52: System Operations
Installation Manual Solution 862 System Operations This section explains the general operations of the system. The operations will explain how to arm and disarm the system in the various modes, how to isolate zones, initiate codepad alarms and determine any fault that may occur.
Page 53: Disarming The System From Away Mode
System Operations Disarming The System From AWAY Mode When you enter the premises after the system has been armed in AWAY Mode, you will need to disarm the system from AWAY Mode to disable detection devices that will activate the sirens, strobe and bell outputs.
Page 54: Arming The System In Stay Mode 1
Installation Manual Solution 862 Arming The System In STAY Mode 1 Arming the system in STAY Mode 1 is only used when the perimeter and unused areas of the premises need to be armed to detect any would be intruder from entering the premises, at the same time allowing you to move freely within an area which has been automatically isolated.
Page 55: Forced Arming
System Operations Method Two How To Arm The System In STAY Mode 1 1. Hold down the button until two beeps are heard. STAY indicator will illuminate and exit time will now commence. Any zones that have been programmed to be automatically isolated in STAY Mode 1 will begin to flash until exit time expires.
Page 56: Disarming The System From Stay Mode 1
Installation Manual Solution 862 Disarming The System From STAY Mode 1 There are two methods for disarming the system from STAY Mode 1. Method one is standard and will always operate. Method two is optional and needs Option 4 to be enabled in "LOCATION 429"...
Page 57: Arming The System In Stay Mode 2
System Operations Arming The System In STAY Mode 2 Arming the system in STAY Mode 2 is only used when the perimeter and unused areas of the premises need to be armed to detect any would be intruder from entering the premises, at the same time allowing you to move freely within an area which has been automatically isolated.
Page 58: Disarming The System From Stay Mode 2
Installation Manual Solution 862 Disarming The System From STAY Mode 2 There are two methods for disarming the system from STAY Mode 2. Method one is standard and will always operate. Method two is optional and needs Option 4 to be enabled in "LOCATION 429"...
Page 59: Codepad Duress Alarm
System Operations Codepad Duress Alarm A codepad duress alarm is used as a silent hold up alarm. This will only occur when the number is added to the end of any valid user code that is being used to disarm the system. However, if a user code has a priority level of arming only, entering their user code followed by 9 will still transmit a duress alarm when the system is armed.
Page 60: Isolating Zones
Installation Manual Solution 862 Isolating Zones Isolating zones allow you to manually disable one or more zones before arming the system in AWAY Mode, STAY Mode 1 or STAY Mode 2. Once a zone has been isolated, access is allowed into that zone during the armed state without activating the sirens or dialler.
Page 61: Standard Isolating
System Operations Standard Isolating Standard isolating allows all operators to be able to isolate zones. Therefore, no code is required to be used when isolating zones. 1. Press the button twice. Three beeps will be heard. 2. * Enter the required to be isolated followed by the button.
Page 62: Code To Isolate
Installation Manual Solution 862 Code To Isolate The method of code to isolate restricts only those user codes that have the priority level Code To Isolate set to be able to isolate zones. Therefore, if any user code has this priority level set, the method of standard isolating will be disabled.
Page 63: Fault Analysis Mode
System Operations Fault Analysis Mode Whenever a system fault occurs, the indicator will flash and the codepad will FAULT MAINS beep once every minute. If the MAINS indicator is flashing, this is because the AC mains supply has been disconnected from the control panel.
Page 64: Fault Descriptions
Installation Manual Solution 862 Fault Descriptions Low Battery A low battery fault will register when the battery supply voltage falls below 10.5 volts or when a dynamic battery test detects a low capacity battery. This fault will clear after a successful dynamic battery test.
Page 65: Fuse Fail
System Operations Fuse Fail This fault will occur when either the 1 Amp – 12 V accessories fuse or the 1 Amp codepad fuse has failed. After 10 seconds has expired since the fuse had failed, the control panel will automatically send a System Trouble code (Contact ID Event Code 300) to the base station receiver.
Page 66: Ac Mains Failure
Installation Manual Solution 862 AC Mains Failure An AC mains supply failure will automatically flash the indicator. If the AC mains MAINS supply has been disconnected continuously for more than two minutes, the remote codepad will beep the codepad buzzer once every minute. If the control panel has been programmed to report an AC mains fail to a base station receiver,”AC Fail"...
Page 67: Remote Radio Transmitter Operations
Remote Radio Transmitter Operations This section includes the following; • Remote Radio Transmitter Operations • Changing Or Deleting Remote Radio User Codes • 2 Channel Radio Remote Hand Held Transmitter Operations • 4 Channel Radio Remote Hand Held Transmitter Operations...
Page 68: Remote Radio Transmitter Operations
Installation Manual Solution 862 Remote Radio Transmitter Operations control panel has the ability to be remotely operated using hand held Solution 862 radio remote transmitters. There is a choice of using either a 2 channel hand held transmitter or a 4 channel hand held transmitter to operate the system.
Page 69: Changing Or Deleting Remote Radio User Codes
Remote Radio Transmitter Operations Changing Or Deleting Remote Radio User Codes Up to eight remote radio hand held transmitters (User Codes 9 – 16) may be used to operate the system. Before the control panel will accept any of the signals from any radio remote hand held transmitter, the control panel must learn the code of the transmitter.
Page 70 Installation Manual Solution 862 How To Delete A Remote Radio User Code 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the (9-16) that you wish to delete followed by the button.
Page 71: Channel Radio Remote Hand Held Transmitter Operations
Remote Radio Transmitter Operations 2 Channel Radio Remote Hand Held Transmitter Operations All operations via the 2 button radio remote hand held transmitter are fixed once the control panel has been taught the hand held transmitters code. Therefore, there is no programming required for each button of the transmitter.
Page 72: Channel Radio Remote Hand Held Transmitter Operations
Installation Manual Solution 862 4 Channel Radio Remote Hand Held Transmitter Operations All operations via the 4 channel radio remote hand held transmitter are fixed once the control panel has been taught the hand held transmitters code. Therefore, there is no programming required for each button of the transmitter.
Page 73: Turning Output 1 On
Remote Radio Transmitter Operations There are two remote outputs than can be operated from the DOOR and AUX buttons on the 4- channel hand held transmitter. These outputs can only be programmed by the installer. The output event types that can be used are listed in the table below. Refer to the section on Programmable Outputs on page 189 for more information.
Page 74 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 75: System Functions
System Functions This section includes the following; • Installer Code Functions • Master Code Functions • Hold Down Functions...
Page 76: System Functions
Installation Manual Solution 862 System Functions This section explains the more advanced features that are required for testing and regular maintenance of the system. Features such as Installer Code Functions, Master Code Functions and Hold Down Functions are covered in this section.
Page 77: Set The Number Of Days Until The First Test Report
System Functions Set The Number Of Days Until The First Test Report If you require the first test to report (Contact ID Event Code 602) the day after you are installing the control panel and you have programmed the repeat interval between each test report for every 7 days, you will need to set when the first test report will occur.
Page 78: Changing Domestic Phone Numbers
Installation Manual Solution 862 Changing Domestic Phone Numbers When the system has been set up for domestic dialling, this function allows the installer to view and program the required telephone numbers that the system will call in the event of an alarm.
Page 79 System Functions Example If you wish to program two separate telephone numbers (9672 1777 and 9672 1233), follow the sequence below and replace the telephone numbers mentioned in the manual with the telephone numbers that you wish to program. 1234 96721777 96721233 How To Disable Domestic Dialling...
Page 80: Change Telco Arm/Disarm Sequence
Installation Manual Solution 862 Change Telco Arm/Disarm Sequence This installer code function allows you to program the call forward sequence to automatically operate when you arm the system in AWAY Mode. This feature is only available if your telecommunication provider has the call forward option available.
Page 81 System Functions How To Program Telco Arming Sequence - Easy Call Forward (No Answer On) 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Press button followed by the button to change the telco arming sequence.
Page 82 Installation Manual Solution 862 How To Program The Telco Disarming Sequence – Easy Call Forward (No Answer Off) 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2.
Page 83 System Functions How To Program Telco Arming Sequence - Easy Call Forward (Immediate On) 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Press button followed by the button to change the telco arming sequence.
Page 84 Installation Manual Solution 862 How To Program The Telco Disarming Sequence – Easy Call Forward (Immediate Off) 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2.
Page 85: Setting Stay Mode 2 Zones
System Functions Setting STAY Mode 2 Zones This function allows the installer to select which zones are to be automatically isolated when the system is armed in STAY Mode 2. Every time the system is armed in STAY Mode 2, the zones selected using this function will be automatically isolated.
Page 86: Satellite Siren Service Mode
Installation Manual Solution 862 How To Disable STAY Mode 2 Zones If at any time you wish to disable all zones selected to be automatically isolated for STAY Mode 2, you may enter your followed by and the button, followed button.
Page 87: Turning Telephone Monitor Mode On/Off
System Functions Turning Telephone Monitor Mode On/Off Telephone monitor mode allows the remote codepad to be used for a visual representation of data transmissions between the control panel and the base station receiver. The dialling sequence is also shown in this mode. The codepad will beep once every two seconds while telephone monitor mode active regardless of whether the system is in Installer's Programming Mode or normal operating mode.
Page 88: Event Memory Recall Mode
Installation Manual Solution 862 Event Memory Recall Mode This function allows you to playback the last forty events that have occurred to the system. The event memory recall mode reports all alarms and arming/disarming of the system in the AWAY Mode, STAY Mode 1 and STAY Mode 2. This function helps with trouble shooting system faults.
Page 89: Master Code Functions
System Functions Master Code Functions Master Code Functions are designed to allow those users that have the appropriate priority level to perform certain functions of a supervisory level. These functions can only be carried out when the system is in the disarmed state. 2580 The default Master Code is and is known as User Code 1.
Page 90: Changing And Deleting User Codes
Installation Manual Solution 862 Changing and Deleting User Codes This function allows a Master Code holder to add/change or delete any of the system user codes. How To Add Or Change A User Code Enter your followed by and the button.
Page 91 System Functions How To Delete A User Code 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Enter the (1-8) that you wish to delete followed by the button.
Page 92: Changing And Deleting Remote Radio User Codes
Installation Manual Solution 862 Changing and Deleting Remote Radio User Codes This function allows a Master Code holder to add/change or delete any of the system user codes. How To Add Or Change A Remote Radio User Code Enter your...
Page 93 System Functions How To Delete A Remote Radio User Code 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Enter the (9-16) that you wish to delete followed by the button.
Page 94: Changing Domestic Phone Numbers
Installation Manual Solution 862 Changing Domestic Phone Numbers When the system has been set up for domestic dialling, this function allows the Master Code holder to view and program the required telephone numbers that the system will call in the event of an alarm.
Page 95 System Functions Example If you wish to program two separate telephone numbers (9672 1777 and 9672 1233), follow the sequence below and replace the telephone numbers mentioned in the manual with the telephone numbers that you wish to program. 2580 96721777 96721233 How To Disable Domestic Dialling...
Page 96: Change Telco Arm/Disarm Sequence
Installation Manual Solution 862 Change Telco Arm/Disarm Sequence This Master Code Function allows you to program the call forward sequence to automatically operate when you arm the system in AWAY Mode. This feature is only available if your telecommunication provider has the call forward option available.
Page 97 System Functions How To Program Telco Arming Sequence - Easy Call Forward (No Answer On) 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Press button followed by the button to change the telco arming sequence.
Page 98 Installation Manual Solution 862 How To Program The Telco Disarming Sequence – Easy Call Forward (No Answer Off) 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2.
Page 99 System Functions How To Program Telco Arming Sequence - Easy Call Forward (Immediate On) 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Press button followed by the button to change the telco arming sequence.
Page 100 Installation Manual Solution 862 How To Program The Telco Disarming Sequence – Easy Call Forward (Immediate Off) 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2.
Page 101: Setting Stay Mode 2 Zones
System Functions Setting STAY Mode 2 Zones This function allows the Master Code Holder to select which zones are to be automatically isolated when the system is armed in STAY Mode 2. Every time the system is armed in STAY Mode 2, the zones selected using this function will be automatically isolated.
Page 102: Turning Outputs On/Off
Installation Manual Solution 862 How To Disable STAY Mode 2 Zones If at any time you wish to disable all zones selected to be automatically isolated for STAY Mode 2, you may enter your followed by and the button, followed by button.
Page 103 System Functions How To Turn An Output Off From The Remote Codepad 1. Enter your followed by and the button. Three beeps will be heard and the STAY AWAY indicators will begin to flash. 2. Enter the required (1–3) followed by the button.
Page 104: Setting The Date And Time
Installation Manual Solution 862 Setting The Date and Time This function only needs to be used when the date and time requires to be changed or the system has been powered down. If the date and time has not been set using this function, the date and time fault will only display when the Auto Arming Time in “LOCATION 414 - 417”...
Page 105: Walk Test Mode
System Functions Walk Test Mode Walk test mode allows you to test detection devices to ensure that they are functioning correctly. Before activating walk test mode, isolate any zones that are not required for testing. Refer to Isolating Zones on page 60 for further information. How To Enter Walk Test Mode 1.
Page 106: Event Memory Recall Mode
Installation Manual Solution 862 Event Memory Recall Mode This function allows you to playback the last forty events that have occurred to the system. The event memory recall mode reports all alarms and arming/disarming of the system in the AWAY Mode, STAY Mode 1 and STAY Mode 2. This function helps with trouble shooting system faults.
Page 107: Hold Down Functions
System Functions Hold Down Functions Hold down functions have been incorporated to allow easy activation of specific operations. When a button is held down for two seconds, two beeps will be heard and a particular function will operate. The hold down functions available are listed below. Arm The System In AWAY Mode Holding the button down until two beeps are heard will arm the system in AWAY Mode.
Page 108: Bell Test
Installation Manual Solution 862 Bell Test Holding the button down until two beeps are heard will sound the internal screamers for a two-second burst. No other sounding device will sound in this mode. If an EDMSAT (SS914) has been connected to the control panel, this function will test both the horn speaker and the strobe connected to the satellite siren for a two second burst.
Page 109: Fault Analysis Mode
System Functions Fault Analysis Mode There are various system faults that can be detected by the control panel. When any of these faults are present, the indicator will begin to flash and the codepad will beep once every FAULT minute. Refer to Fault Descriptions on page 64 for a more detailed description on each fault type.
Page 110: Codepad Buzzer Tone Change
Installation Manual Solution 862 Codepad Buzzer Tone Change Holding the button down continuously will change the tone of the buzzer in the remote codepad. There are fifty different tones to choose from between 1500 Hz - 5000 Hz and they are specific to each codepad.
Page 111: Remote System
Remote System Operations Via Telephone This section includes the following; • Remote Arming Via The Telephone...
Page 112: Remote Arming Via The Telephone
Installation Manual Solution 862 Remote Arming Via The Telephone This feature allows you to arm your system from any remote location via the telephone line. For obvious security reasons, the system cannot be disarmed using this method. To make use of this feature, you will require a touch-tone telephone or the Phone Controller (CC911).
Page 113: Alarm Link Operations
Alarm Link Operations This section includes the following; • Alarm Link Software • Remote Connect • Remote Connect With Customer Control • Remote Connect Without Call Back Verification • Remote Connect With Call Back Verification • Direct Connect • Alarm Link Options...
Page 114: Alarm Link Software
Control Panels Software Version Select Panel Type S406_V10 Solution 862 V1.00 – 1.02 Table 43: Alarm Link Panel Forms After selecting the correct panel type when adding a new customer in the Alarm Link Software, the Subscriber ID Number and the Installer Code must match that of the control panel for synchronisation when making connection to the control panel.
Page 115: Remote Connect Without Call Back Verification
Alarm Link Operations Remote Connect Without Call Back Verification Remote connect without call back verification can be handy where you have a need to perform Upload/Download functions from multiple locations. There are two methods that you may program so that the call back verification is disabled. It should be noted that by using this feature you are reducing the security of the control panel.
Page 116: Direct Connect
Installation Manual Solution 862 Direct Connect The direct connect feature has been incorporated giving the installer a simple method for programming the control panel at the office or on site visits using a portable Solution 862 computer. There is no need for telephone lines or modems that makes programming of the control panel completed easily in minutes.
Page 117: Alarm Link Options
Alarm Link Operations Alarm Link Options LOCATION 180 Option Description Enable Upload/Download Via Alarm Link Enable Alarm Link Call Back Terminate Alarm Link Connection On Alarm Use External Modem Module (CC811) For Alarm Link Operations Table 44: Alarm Link Options Enable Upload/Download Via Alarm Link This option will need to be selected if you require to use the Alarm Link Software (CC816) to remotely program the control panel.
Page 118 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 119: Domestic Dialling
Domestic Dialling This section includes the following; • Domestic Dialling Format • Domestic Dialling Function • Acknowledge Domestic Dialling • Setting Up and Programming Domestic Reporting • Disable Domestic Dialling...
Page 120: Domestic Dialling Format
Installation Manual Solution 862 Domestic Dialling Format The locations of the primary telephone number and secondary telephone number for Receiver 1 or Receiver 2 are only used for base station reporting and pager reporting. When either Receiver 1 or Receiver 2 is set up for domestic reporting, both the primary telephone number and the secondary telephone number will be ignored.
Page 121: Setting Up And Programming Domestic Reporting
Domestic Dialling Setting Up and Programming Domestic Reporting Programming the control panel for domestic reporting has been made extremely simple by the use of the Installer's Programming Command 965. Refer to Command 965 - Set Up Domestic Dialling Format on page 37 for more information. How To Set Up The Control Panel For Domestic Dialling 1234 1.
Page 122: Disable Domestic Dialling
Installation Manual Solution 862 Digit Required Number To Program Digit Required Number To Program Followed By Followed By Four Second Pause Followed By Break Followed By Table 45: Domestic Dialling Digits Example If you wish to program two separate telephone numbers (9672 1777 and 9672 1233), follow the sequence below and replace the telephone numbers mentioned in the manual with the telephone numbers that you wish to program.
Page 123: Dialler Reporting Formats
Dialler Reporting Formats This section includes the following; • Transmission Formats • Contact ID Format • Point ID Codes • 4+2 Reporting Format • Basic Pager Reporting Format • Basic Pager Display Information...
Page 124: Transmission Formats
Installation Manual Solution 862 Transmission Formats When making use of the control panel's dialling and communication features, there are a number of transmission formats available. Refer to "LOCATION 033" on page 133 to set the required transmission format for Receiver 1 and “LOCATION 073” on page 136 to set the required transmission formation for Receiver 2.
Page 125: Point Id Codes
Dialler Reporting Formats Point ID Codes The table below shows the different Point ID Codes and Event Codes that are transmitted to the base station receiver when using Contact ID Reporting Format. All event codes are fixed and will always transmit the same code as there are no programming locations made available to alter these.
Page 126: Reporting Format
Installation Manual Solution 862 4+2 Reporting Format The 4+2 Express Format will report a Subscriber ID Number followed by an expansion code and the reporting channel number is transmitted directly after the expansion code. Subscriber ID Number Expansion Code Channel Number...
Page 127: Basic Pager Reporting Format
Dialler Reporting Formats Basic Pager Reporting Format Basic Pager Format requires some interpretation of the numbers that appear on the display, however, it is possible to differentiate between 1000 different control panels when a number of control panels are reporting to the one pager. How To Setup Receiver 1 For Basic Pager Reporting "LOCATION 000 - 015"...
Page 128: Basic Pager Display Information
Installation Manual Solution 862 Basic Pager Display Information Subscriber ID Number This is the identification number of the control panel and is programmed in “LOCATION 034 – 039” on page 133 for Receiver 1 and “LOCATION 074 – 079” on page 136 for Receiver 2.
Page 129: Dialler Information
Dialler Information This section includes the following; • Dialler Information • Primary Telephone Number For Receiver 1 • Secondary Telephone Number For Receiver 1 • Handshake Tone For Receiver 1 • Transmission Format For Receiver 1 • Subscriber ID Number For Receiver 1 •...
Page 130: Dialler Information
Installation Manual Solution 862 Dialler Information This section outlines the programming information required for the control Solution 862 panel when communicating with base station receivers. Typically these parameters specify the telephone numbers to call, the transmission formats, handshake tones and transmission speeds.
Page 131: Primary Telephone Number For Receiver 1
Dialler Information Primary Telephone Number For Receiver 1 0000000000000000 LOCATION 000 - 015 When the control panel needs to transmit a report, the control panel will dial this number in an attempt to contact the monitoring station or pager etc. If the call is successful, the relevant information will be transmitted and the dialler will return back to the stand-by mode.
Page 132: Handshake Tone For Receiver 1
Installation Manual Solution 862 Handshake Tone For Receiver 1 LOCATION 032 This location sets the type of handshake tone required for receiver 1 before data transmissions to the monitoring station will begin. 1. HI LO Handshake Tone is required when the control panel requires to communicate in Contact ID Format or High Speed DTMF.
Page 133: Transmission Format For Receiver 1
Dialler Information Transmission Format For Receiver 1 LOCATION 033 Enter the desired transmission format here. This location selects the data format that will be transmitted to the base station receiver. This location also allows you to configure the control panel for domestic or basic pager formats. Option Transmission Format Option...
Page 134: Primary Telephone Number For Receiver 2
Installation Manual Solution 862 Primary Telephone Number For Receiver 2 0000000000000000 LOCATION 040 - 055 When the control panel needs to transmit a report, the control panel will dial this number in an attempt to contact the monitoring station or pager etc. If the call is successful, the relevant information will be transmitted and the dialler will return back to the stand-by mode.
Page 135: Handshake Tone For Receiver 2
Dialler Information Handshake Tone For Receiver 2 LOCATION 072 This location sets the type of handshake tone required for Receiver 2 before data transmissions to the monitoring station will begin. HI LO Handshake Tone is required when the control panel requires to communicate in 1.
Page 136: Transmission Format For Receiver 2
Installation Manual Solution 862 Transmission Format For Receiver 2 LOCATION 073 Enter the desired transmission format here. This location selects the data format that will be transmitted to the base station receiver. This location also allows you to configure the control panel for domestic or basic pager formats.
Page 137: Dialling Format
Telecommunications Network. The International DTMF dialling option should only be used in those countries that allow both the caller and the receiver to terminate the phone call. Using the incorrect format will disable EDM's patent Telephone Anti-Jamming feature. Option Dialling Format...
Page 138: Telco Arming Sequence
Installation Manual Solution 862 Telco Arming Sequence LOCATION 113 – 142 000000000000000000000000000000 These locations allow you to automatically activate call diversion on your telephone when you arm the system in AWAY Mode. Upon activating the Telco Arming Sequence when arming the system in AWAY Mode, the control panel will redirect all calls to your mobile phone, pocket pager or answering service.
Page 139: Telco Disarming Sequence
Dialler Information Telco Disarming Sequence 0000000000000000 LOCATION 143 – 158 These locations allow you to automatically deactivate call diversion on your telephone when you disarm the system from AWAY Mode. Digit Required Number To Program Digit Required Number To Program Four Second Pause Break Table 60: Telco Arm/Disarm Dialling Digits...
Page 140: Ring Count
Installation Manual Solution 862 Ring Count LOCATION 175 This location sets the number of rings before the control panel will answer an incoming call. This should be set at an acceptable level bearing in mind that one ring = "Ring, Ring - Ring, Ring"...
Page 141: Telephone Line Fault Options
Dialler Information Telephone Line Fault Options LOCATION 176 When programming this location, you will notice that there are four options per location. If you require options 1, 2, 4 or all of these options, only one number needs to be programmed. This number is calculated by adding the option bit numbers together.
Page 142: Ring Burst Time
Installation Manual Solution 862 Ring Burst Time LOCATION 748 - 749 Location Description Increments Of 5 ms Increments Of 80 ms Table 62: Ring Burst Time Locations (V1.07+) These locations program the ring burst time (Default = 500 ms). If the duration of the telephone ring tone is 1.5 seconds, programming the ring burst time more than the...
Page 143: Dialler Options
Dialler Options This section includes the following; • Dialler Options 1 • Dialler Options 2 • Dialler Options 3 • Alarm Link Options...
Page 144: Programming Option Bits
Installation Manual Solution 862 Programming Option Bits When programming these locations, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed. This number is calculated by adding the option bit numbers together.
Page 145: Dialler Options 1
Dialler Options Dialler Options 1 LOCATION 177 Option Description Dialler Reporting Functions Allowed Remote Arming Via The Telephone Allowed Answering Machine Bypass Only When Armed Use Bell 103 For FSK Format (Disabled = CCITT V21) Table 64: Dialler Options 1 Dialler Reporting Functions Allowed If this option has been selected, the dialler will function for all operations.
Page 146: Dialler Options 2
Installation Manual Solution 862 Dialler Options 2 LOCATION 178 Option Description Open/Close Reports Only If Previous Alarm Open/Close Reports For STAY Mode 1 and STAY Mode 2 Delay Siren Until Transmission Complete Extend Time To Wait For Handshake From 30 To 55 Seconds...
Page 147: Dialler Options 3
Dialler Options Dialler Options 3 LOCATION 179 Option Description Set DTMF Dialling Pulses To 1 Digit/Second Reserved Change Decadic Dialling To 60/40 Reserved Table 66: Dialler Options 3 Set DTMF Dialling Pulses To 1 Digit/Second If this option is not selected, the dialling format – Australian DTMF dials at the rate of 5 digits per second (i.e.
Page 148: Alarm Link Options
Installation Manual Solution 862 Alarm Link Options LOCATION 180 Option Description Upload/Download Allowed Call Back Phone Number Required For Upload/Download Terminate Upload/Download On Alarm External Modem Module (CC811) Required For Upload/.Download Table 67: Alarm Link Options Upload/Download Allowed This option will need to be selected if you require to use the Alarm Link Software (CC816) to remotely program the control panel.
Page 149: User Codes
User Codes This section includes the following; • Installer Code • User Codes • User Code Priority...
Page 150: Access Codes
Installation Manual Solution 862 Access Codes This section describes the access codes that are used to assign privileges and access functions for user code holders of the system. Two types of user codes exist within the system, the Installer Code and User Codes. Each of these codes allow specific access and operation of the varied functions of the control panel.
Page 151: User Codes
User Codes User Codes LOCATION 185 - 264 The purpose of user codes is to arm and disarm the system as well as perform other specific functions as described in Master Code Functions on page 89. User codes (1–8) can be any length between one to four digits long. Each user code may have a different priority level multiple user codes may have the same priority level.
Page 152: User Codes
Installation Manual Solution 862 User Codes The control panel has the ability to have up to eight programmable user codes (User Codes 1 – 8) to operate the system. Refer to System Operations on page 52 for information on the different methods of arming and disarming the system.
Page 153: User Code Priority
User Codes User Code Priority There are ten different priority levels that can be allocated to the user code. Each priority level allows or restricts the functions that different user code holders may perform. Priority Level Description Arm/Disarm Arm Only Arm/Disarm + Open/Close Report Arm Only + Close Report Arm/Disarm + Code To Isolate...
Page 154 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 155: Zone Information
EOL Resistor Value • Connections Of Split EOL Resistors Using N/C Contacts • Connections Of Split EOL Resistors Using N/O Contacts • Zone Programming • Solution 862 Zones Defaults • Zone Types • Zone Pulse Count • Zone Pulse Count Handover •...
Page 156: Day Alarm Zones
Installation Manual Solution 862 Day Alarm Zones LOCATION 265 When programming this location, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed.
Page 157: Day Alarm Operation
Zone Information Day Alarm Operation If a zone has been programmed for day alarm, the zone can be isolated in the normal way so that it does not register as a day alarm zone during the disarmed state. Only zones 1 – 4 can be used as day alarm zones.
Page 158: Eol Resistor Value
Installation Manual Solution 862 EOL Resistor Value LOCATION 266 Option Resistor Value Option Resistor Value No EOL Resistor 6K8 (Blue, Grey, Black, Brown) 1% 1K (Brown, Black, Red) 10K (Brown, Black, Orange) 1K5 (Brown, Green, Red) 12K (Brown, Red, Orange)
Page 159: Connections Of Split Eol Resistors Using N/C Contacts
Zone Information Connections Of Split EOL Resistors Using N/C Contacts Figure 7: Connections Of Split EOL Resistors For 8 Zones Electronics Design and Manufacturing Pty Limited ISSUE130...
Page 160: Connections Of Split Eol Resistors Using N/O Contacts
Installation Manual Solution 862 Connections Of Split EOL Resistors Using N/O Contacts Figure 8: Connections Of Split EOL Resistors Using One N/O Contact Figure 9: Connections Of Split EOL Using Two N/O Contacts ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 161: Zone Programming
Zone Information Zone Programming Each zone contains seven locations that are divided into three groups. The first 3 locations determine how the zone will operate, the next two locations allow various options for each zone and the last two locations contain the dialler reporting information of each zone. Zone Operating Information Zone Type This location programs the "Zone Type"...
Page 162: Solution 862 Zones Defaults
Installation Manual Solution 862 Solution 862 Zones Defaults LOCATION 267 - 322 Zone 1 Zone 2 Location 267 - 273 Location 274 - 280 2 0 0 1 14 1 1 1 0 0 1 14 1 1 Zone 3...
Page 163: Delay-1 Zone
Zone Information Delay-1 Zone A Delay-1 zone (Contact ID Event Code 130) will have a delay time determined by the value in Entry Timer 1 on page 204. After entry time has expired, the system will activate into alarm condition. If a Delay-1 zone has not restored at the time the system is disarmed, a zone restore report will be automatically sent to the receiving party.
Page 164: Keyswitch Zone
Installation Manual Solution 862 Keyswitch Zone A Keyswitch zone is used when you need to connect a keyswitch to operate the system. Refer to Keyswitch Zone Options on page 169 for selecting options such as momentary, toggle etc. User code number 16 will be reported when arming and disarming using this method of operation.
Page 165: Zone Pulse Count
Zone Information Zone Pulse Count Zone pulse count is the number of times a zone must be triggered before the zone registers as an alarm. The number of pulses vary between 0 – 15. The zone pulse count value is relative to the time frame (i.e.
Page 166: Zone Pulse Count Time
Installation Manual Solution 862 Zone Pulse Count Time Zone pulse count time is the time frame or period over which the programmed number of pulses must register before an alarm condition is generated. 20 ms Loop Response Time 150 ms Loop Response Time...
Page 167: Zone Options 1
Restore signals will be transmitted when the system has been disarmed. control panel performs lockout different to most other control panels in Solution 862 that only the first zone to trigger an alarm condition will be locked out. All other zones that are triggered during the same siren run time will reset when the sirens reset.
Page 168: Silent Alarm
Installation Manual Solution 862 Silent Alarm A zone programmed to be silent will not trigger the horn speaker, bell, strobe or EDMSAT outputs. The dialler and all other programmable outputs will function as per their particular programming. Sensor Watch Sensor watch gives the control panel the ability to recognise that detection devices may have stopped working.
Page 169: Keyswitch Zone Options
Zone Information Keyswitch Zone Options When you select a zone to be a keyswitch input, then the following table relates to the options available to that keyswitch zone. These keyswitch zone options replace Zone Options 1 only for the zones that have been programmed to operate as a keyswitch zone. Keyswitch zones will report as user code 16.
Page 170: Momentary Arm And Disarm In Away Mode
Installation Manual Solution 862 Momentary Arm and Disarm In AWAY Mode If this option has been selected, the system will either arm or disarm from AWAY Mode when using the momentary keyswitch input. Momentary Arm In AWAY Mode If this option has been selected, the system will arm in AWAY Mode when using the momentary keyswitch input.
Page 171: Zone Options 2
Zone Information Zone Options 2 When programming this location, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed. This number is calculated by adding the option bit numbers together. Program a seven (7) if you require options 1, 2 and 4 simultaneously (i.e.
Page 172: Zone Reporting Information
Installation Manual Solution 862 Zone Reporting Information Zone Report Code If you wish the control panel to transmit zone alarm reports, this location should be programmed as 1. If you do not wish to transmit zone alarm reports, this location should be programmed as a 0.
Page 173: Swinger Shutdown Count For Siren
Zone Information Swinger Shutdown Count For Siren LOCATION 323 Location Description Swinger Shutdown Count For Siren (0-15) Table 78: Swinger Shutdown Count For Siren Location This location determines the number of times the sirens can be triggered before any lockout options will take effect.
Page 174: Swinger Shutdown Count For Dialler
Installation Manual Solution 862 Swinger Shutdown Count For Dialler LOCATION 324 Location Description Swinger Shutdown Count For Dialler (0-15) Table 79: Swinger Shutdown Count For Dialler Location This location determines the number of times the dialler can be triggered before any lockout options will take effect.
Page 175: System Reporting Information
System Reporting Information This section includes the following; • Zone Status – Bypass Reports • Zone Status – Trouble Reports • Zone Status – Sensor Watch Reports • Zone Status – Alarm Restore Code • Zone Status Reporting Options • Open/Close Reports •...
Page 176: Reporting Information
Installation Manual Solution 862 Reporting Information This section covers features that are involved with the basic house keeping of the system. This includes monitoring of the zones - whether they are isolated from the system or more importantly that they are actually operating, the status of both the AC mains and DC power to the system and codepad generated alarms activated by the user.
Page 177: Zone Status – Trouble Reports
System Reporting Information Zone Status – Trouble Reports LOCATION 327 – 328 Location Description Zone Trouble Report Zone Trouble Restore Report Table 81: Zone Status - Trouble Report Locations A zone is in trouble when it is unsealed at the end of exit time. A "Sensor Trouble" report (Contact ID Event Code 380) will be transmitted to indicate that one or more zones have been automatically isolated by the system.
Page 178: Zone Status – Sensor Watch Reports
Installation Manual Solution 862 Zone Status – Sensor Watch Reports LOCATION 329 - 330 Location Description Sensor Watch Report Sensor Watch Restore Report Table 82: Zone Status – Sensor Watch Report Locations A "Self Test Failure" report (Contact ID Event Code 307) will be transmitted to the base station receiver when a zone has not been triggered during the Sensor Watch Time programmed in "LOCATION 408 - 409"...
Page 179: Open/Close Reports
System Reporting Information Open/Close Reports LOCATION 333 - 334 Location Description Opening Report Closing Report Table 84: Open/Close Reporting Locations An "Opening" report (Contact ID Event Code 401) will be transmitted to the base station receiver when the system has been disarmed from AWAY Mode. A "Closing" report (Contact ID Event Code 401) is transmitted at the end of exit time when the system has been armed in AWAY Mode.
Page 180: Codepad Duress Report
Installation Manual Solution 862 Codepad Duress Report LOCATION 336 Location Description Codepad Duress Report Table 86: Codepad Duress Report Location A "Duress" report (Contact ID Event Code 121) will be transmitted to the base station receiver when the button is added to the end of any valid user code being used to disarm the system.
Page 181: Codepad Fire Report
System Reporting Information Codepad Fire Report LOCATION 339 - 340 Location Description Codepad Fire Reporting Code (Tens Digit) Codepad Fire Reporting Code (Units Digit) Table 88: Codepad Fire Report Locations A "Fire Alarm" report (Contact ID Event Code 110) will be transmitted to the base station receiver when the buttons are pressed simultaneously.
Page 182: Codepad Reporting Options
Installation Manual Solution 862 Codepad Reporting Options LOCATION 343 Option Description No Report Required Receiver 1 Receiver 2 Receiver 1 and Receiver 2 Receiver 2 Only When Receiver 1 Fails Table 90: Codepad Reporting Options Location This location is factory default to report only to receiver 1. You can select whether the codepad reporting options will report on receiver 1, receiver 2, both receiver 1 and receiver 2, receiver 2 only when receiver 1 fails or no reporting at all.
Page 183: System Status – Ac Fail Report
System Reporting Information System Status – AC Fail Report LOCATION 348 - 349 Location Description System Status – AC Fail Reporting Code (Tens Digit) System Status – AC Fail Reporting Code (Units Digit) Table 93: System Status – AC Fail Report Locations An "AC Loss"...
Page 184: System Status - Low Battery Report
Installation Manual Solution 862 System Status - Low Battery Report LOCATION 352 - 353 Location Description System Status – Low Battery Reporting Code (Tens Digit) System Status – Low Battery Reporting Code (Units Digit) Table 95: System Status – Low Battery Report Locations A "Battery Test Failure"...
Page 185: System Status - Access Denied
System Reporting Information System Status - Access Denied LOCATION 356 - 358 Location Description Code Retries (0–15) System Status – Access Denied Reporting Code (Tens Digit) System Status – Access Denied Reporting Code (Units Digit) Table 97: System Status – Access Denied Locations An "Access Denied"...
Page 186: System Status Reporting Options
Installation Manual Solution 862 System Status Reporting Options LOCATION 359 Option Description No Report Required Receiver 1 Receiver 2 Receiver 1 and Receiver 2 Receiver 2 Only When Receiver 1 Fails Table 98: System Status Reporting Options Location This location is factory default to report only to receiver 1. You can select whether the system status reporting options will report on receiver 1, receiver 2, both receiver 1 and receiver 2, receiver 2 only when receiver 1 fails or no reporting at all.
Page 187: Test Reporting Time
System Reporting Information Test Reporting Time 0000 71 0 LOCATION 360 - 366 Location Description Actual Hour Of The Day (Tens Digit) Actual Hour Of The Day (Units Digit) Actual Minute Of The Day (Tens Digit) Actual Minute Of The Day (Units Digit) Test Report Code (Tens Digit) Test Report Code (Units Digit) Repeat Interval In Days...
Page 188 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 189: Programmable Outputs
Programmable Outputs This section includes the following; • Outputs • Output Defaults • Redirecting Outputs To The Codepad Buzzer • Output Event Types • Output Polarity • Timing Of Outputs • Pulsing Polarities • One Shot Polarities...
Page 190: Outputs
Installation Manual Solution 862 Outputs control panel has four fully programmable outputs on the main PCB and Solution 862 one other programmable output that operates the codepad buzzer. These four outputs are factory default to operate as horn speaker, fire alarm verification, strobe and an internal screamer.
Page 191: Redirecting Outputs To The Codepad Buzzer
Programmable Outputs Redirecting Outputs To The Codepad Buzzer Multiple output event types can be directed to the codepad buzzer so that it may be used to indicate any number of events. This is achieved by selecting an output and programming it for the required output event type. When you are satisfied that the output is functioning correctly, change the first digit of the output event type (i.e.
Page 192: Output Event Types
Installation Manual Solution 862 Output Event Types There are approximately seventy five different output event types to choose from. Two numbers designate each output event type. These two numbers need to be programmed into the appropriate locations of the output being used to indicate when the output should operate.
Page 193 Programmable Outputs Exit Warning Finished This output operates when the exit time has expired when the system has been armed in AWAY Mode, STAY Mode 1 or STAY Mode 2. The output will reset when the system has been disarmed. Kiss-Off After Exit Time This output will operate after the first successful transmission to the base station receiver when exit time has expired.
Page 194 Installation Manual Solution 862 Day Alarm Enabled This output will operate as soon as day alarm has been enabled. The output will reset when day alarm has been turned off. Refer to Day Alarm Zones on page 156 for programming zones to operate for day alarm.
Page 195 Programmable Outputs Codepad Fire Alarm This output will operate when a codepad medical alarm has been activated by pressing the buttons on the remote codepad simultaneously. This output will reset once a valid user code has been entered at the remote codepad. Codepad Panic Alarm This output will operate when a codepad panic alarm (audible or silent) has been activated by pressing the...
Page 196 Installation Manual Solution 862 Alarm When In AWAY Mode This output will operate whenever an audible or silent zone alarm has triggered when the system has been armed in AWAY Mode. The output will reset when the system has been disarmed.
Page 197 Programmable Outputs Remote Control 1 Remote Control 2 Remote Control 3 These outputs can be remotely activated (Turned "On" or "Off") via the following methods: Remote Codepad - Refer to the Master Code Functions - Turning Outputs On/Off on page 102 for further information. Remotely Via Alarm Link Software - Refer to your Alarm Link Instruction Manual for further information.
Page 198 Installation Manual Solution 862 Mimic Zone 1 Mimic Zone 5 Mimic Zone 2 Mimic Zone 6 Mimic Zone 3 Mimic Zone 7 Mimic Zone 4 Mimic Zone 8 These output types will mimic the zone inputs. he output will operate when the zone is unsealed and will reset when the zone is sealed.
Page 199: Output Polarity
Programmable Outputs Output Polarity There are fifteen different polarities to choose from. Each polarity is designated by a number. This number needs to be programmed into the appropriate location of the output being used to indicate how the output should operate. Option Polarity Option...
Page 200: Normally Open, One Shot Low With Alarm
Installation Manual Solution 862 Normally Open, One Shot Low With Alarm This one shot polarity is normally open circuit and will switch to zero volts when the event occurs. The output will switch back to open circuit once the one shot time has expired, when the event has returned to normal or when the system has been disarmed.
Page 201: Timing Of Outputs
Programmable Outputs Timing Of Outputs The timing of outputs is calculated by the time base and a multiplier. These two values play different roles depending on the polarity selected. When programming outputs to pulse, both the "On" and "Off" times can be set. One shot polarities can be programmed to operate between 200 ms up to 99 hours in duration.
Page 202: One Shot Polarities
Installation Manual Solution 862 One Shot Polarities The duration or "On" time of an output is determined by the product of the time base and the multiplier. If an output is required to operate for five seconds, program the time settings as follows;...
Page 203: System Event Timers
System Event Timers This section includes the following; • Entry Timer 1 ( • Entry Timer 2 ( • Exit Time ( • Entry Guard Timer For STAY Mode ( • Delay Alarm Reporting Time ( • Sensor Watch Time ( •...
Page 204: System Event Timers
Installation Manual Solution 862 System Event Timers This section covers the features that involve timing. Features such as entry and exit times, sensor watch time, siren run time and system date and time along with a host of other timers are discussed extensively in this section.
Page 205: Exit Time
System Event Timers Exit Time LOCATION 402 – 403 (Defaulted To 60 Seconds) Location Description Increments Of 1 Second (0 - 15 Sec’s) Increments Of 16 Seconds (0 –240 Sec’s) Table 108: Exit Time Locations Exit time can be programmed between 0 and 255 seconds in increments of one second. When arming the system in AWAY Mode, the remote codepad will beep during exit time until the remaining 10 seconds where the codepad will give you one continuous beep to inform you that the end of exit time is approaching.
Page 206: Sensor Watch Time
Installation Manual Solution 862 Sensor Watch Time LOCATION 408 - 409 Location Description Increments Of Days (Tens Digit) Increments Of Days (Units Digit) Table 111: Sensor Watch Time Locations The time set in these two locations determine how many days (0-99) a zone may remain sealed before registering as a fault.
Page 207: Siren Run Time
System Event Timers Siren Run Time LOCATION 411 (Defaulted To 5 Minutes) Location Description Increments Of 1 Minute (0 – 15) Table 113: Siren Run Time Location The siren run time determines how long the horn speaker will activate during an alarm condition.
Page 208: Auto Arming Pre-Alert Timer
Installation Manual Solution 862 Auto Arming Pre-Alert Timer LOCATION 413 Location Description Increments Of 5 Minutes (0 – 75 Minutes) Table 115: Auto Arming Pre-Alert Timer Location This location sets the time period that will warn you before the control panel will automatically arm in AWAY Mode.
Page 209: Auto Disarming Time
System Event Timers Auto Disarming Time 0000 LOCATION 418 - 421 Location Description Actual Hour Of The Day (Tens Digit) Actual Hour Of The Day (Units Digit) Actual Minute Of The Day (Tens Digit) Actual Minute Of The Day (Units Digit) Table 117: Auto Disarming Time Locations These locations are used to program the actual time of the day that the system will automatically disarm itself from AWAY Mode, STAY Mode 1 or STAY Mode 2.
Page 210: System Time
Installation Manual Solution 862 System Time 0000 LOCATION 901 – 904 Location Description Current Hour In 24 Hour Time (Tens Digit) Current Hour In 24 Hour Time (Units Digit) Current Minute (Tens Digit) Current Minute (Units Digit) Table 120: System Time Locations...
Page 211: System Date
Table 121: System Date Locations control panel has a real time 12 month calendar that needs to be set Solution 862 during installation. This time must be set using the format DDMMYY (i.e. If the date that is required to be set is the 1 July 1997, you would then program 010797). Every time the system has been powered down, the system date will need to be reset.
Page 212 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 213: System And Consumer Options
System and Consumer Options This section includes the following; • System Options 1 • System Options 2 • System Options 3 • System Options 4 • Consumer Options 1 • Consumer Options 2 • Consumer Options 3 • Radio Input Options...
Page 214: Programming Option Bits
In this example, the number to be programmed is 7 (i.e. 1 + 2 + 4 = 7). Option Description EDM Smart Lockout Allowed Horn Speaker Monitor Strobe Indication For Radio Arm/Disarm Horn Speaker Beeps For Radio Arm/Disarm...
Page 215: System Options 1
System and Consumer Options System Options 1 LOCATION 424 Option Description EDM Smart Lockout Allowed Horn Speaker Monitor Strobe Indications For Radio Arm/Disarm Horn Speaker Beeps For Radio Arm/Disarm Table 123: System Options 1 EDM Smart Lockout Allowed This feature allows the control panel to remove any zones that are programmed for lockout dialler from the lockout list while the sirens are running.
Page 216: System Options 2
Installation Manual Solution 862 System Options 2 LOCATION 425 Option Description Codepad Panic To Be Silent Codepad Fire To Be Silent Codepad Medical To Be Silent Access Denied (Code Retries) To Be Silent Table 126: System Options 2 Codepad Panic To Be Silent If this option has been selected, a codepad panic alarm or radio remote panic alarm will not operate the horn speaker, the bell or the strobe outputs.
Page 217: System Options 3
System and Consumer Options System Options 3 LOCATION 426 Option Description AC Fail After 1 Hour (Disabled = After 2 Minutes) Ignore AC Mains Fail Indication Pulse Count Handover Handover Delay To Be Sequential Table 127: System Options 3 AC Fail After 1 Hour (Disabled = After 2 Minutes) If this option has been selected, the indicator will begin to flash as soon as the AC MAINS...
Page 218: System Options 4
Installation Manual Solution 862 System Options 4 LOCATION 427 Option Description Panel To Power Up Disarmed (If Power Reset) Arm/Disarm Tracking On Power Up Internal Crystal To Keep Time Keyswitch Interface, Night Arm Station Or RE005 Installed Table 128: System Options 4...
Page 219: Consumer Options 1
System and Consumer Options Consumer Options 1 LOCATION 428 Option Description Test Reports Only When Armed Test Report After Siren Reset Auto Arm In STAY Mode 1 STAY Indicator To Display Day Alarm Status Table 129: Consumer Options 1 Test Reports Only When Armed If this option has been selected, test reports (Contact ID Event Code 602) will only be sent when the system has been armed in AWAY Mode, STAY Mode 1 or STAY Mode 2.
Page 220: Consumer Options 2
Installation Manual Solution 862 Consumer Options 2 LOCATION 429 Option Description Codepad Display Extinguish After 60 Seconds Single Button Arming Allowed (AWAY/STAY Mode 1 & 2) Single Button Disarming Allowed (STAY Mode 1 & 2) Alarm Memory Reset On Disarm...
Page 221: Consumer Options 3
System and Consumer Options Consumer Options 3 LOCATION 430 Option Description Codepad Fault Beeps Allowed Use Digit 3 For Codepad Duress Instead Of Digit 9 Alarms Activate Sirens and Strobe Outputs In STAY Mode 1 & 2 Reserved Table 131: Consumer Options 3 Codepad Fault Alarm Beeps If this option has been enabled, the codepad will flash the indicator and beep once...
Page 222: Radio Input Options
Installation Manual Solution 862 Radio Input Options LOCATION 431 Option Description Radio Receiver (WE800) Latching Keyswitch Input Momentary Keyswitch Input Reserved Table 132: Radio Input Options Radio Receiver (WE800) This option needs to be selected when using the optional 304 Mhz RF Receiver (WE800) for remote operations using radio remote hand held transmitters.
Page 223: Optional Equipment
Optional Equipment This section includes the following; • 2 Channel/4 Channel Hand Held Transmitters 304 Mhz (RE012/RE013) • 304 Mhz RF Receiver (WE800) • 2 Channel Radio Interface (RE005) • EDMSAT - Satellite Siren (SS914) • Programming Key (CC891) • Alarm Link Software (CC816) •...
Page 224: Optional Equipment
Figure 11: Solution Wireless ON/OFF Interface (WE800) 2 Channel Radio Interface (RE005) The EDM 2 channel radio interface has been designed to allow customers to remotely operate Solution control panels and control two on-board relays. The interface may also be used as a stand alone receiver, independent of a Solution control panel and used solely for remote control of external devices connected to the two on-board relays.
Page 225 The hand held programmer is used to program the locations in the control Solution 862 panel. The unit displays the actual location number and the data value currently programmed. It comes complete with a one metre connecting cable and a socket for an external programming key.
Page 226 TF008 Plug Pack (TF008) The TF008 plug packs have been designed to be used with the EDM control panels and the PS100 Power Supply Module. The plug pack includes built in thermal fuses which under overload or fault conditions will blow and eliminate any possible fire threat due to excessive heat build up inside the casing.
Page 227 Optional Equipment 2 Wire Smoke Detector Interface (FA101) The 2 Wire Smoke Detector Interface (FA101) has been designed to allow high quality 2 wire, 24 volt DC smoke detectors to be easily connected to the Solution range of control panels. The interface provides the 24 volts required to power the smoke detector and also provides a relay output that is used to trigger the control panel.
Page 228 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 229: Terminals And Descriptions
Terminals and Descriptions This section includes the following; • Terminal Definitions and Descriptions • Glossary Of Terms • Solution 862 Wiring Diagram • Solution 862 Component Overlay • Telecom Connection Diagrams...
Page 230: Terminal Definitions And Descriptions
PCB for connecting the COM terminal to either GND or 12V. This link should be connected to +12V as shown in "Figure 12: Solution 862 Wiring Diagram" on page 234. The relay is rated at 1 Amp/30 V +12V These terminals are zones three and four.
Page 231: Glossary Of Terms
Terminals and Descriptions Glossary Of Terms Term Description Alarm Condition Is when your alarm system is armed and one of the detection devices are violated. A 24 hour zone (e.g.. Smoke detector) may trigger when your system is armed or disarmed. Answering Machine Answering machine bypass has been incorporated so that it is possible to make a connection with Bypass...
Page 232 Installation Manual Solution 862 Term Description Exit Time or Is the amount of time you have to leave your premises after you have armed your system. Exit Delay External Equipment Is any device connected to your system such as detectors, codepads and sirens.
Page 233 Terminals and Descriptions Term Description STAY Mode 1 Is a condition that automatically isolates certain zones when your system is armed in STAY Mode 1. These zones can only be programmed by your installer. STAY Mode 2 Is a condition that automatically isolates certain zones when your system is armed in STAY Mode 2.
Page 234: Solution 862 Wiring Diagram
Installation Manual Solution 862 Solution 862 Wiring Diagram Figure 12: Solution 862 Wiring Diagram ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 235: Solution 862 Component Overlay
Terminals and Descriptions Solution 862 Component Overlay Figure 14: Solution 862 Component Overlay Electronics Design and Manufacturing Pty Limited ISSUE130...
Page 236: Telecom Connection Diagrams
Installation Manual Solution 862 Telecom Connection Diagrams Figure 15: Telecom Connection Diagrams For Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 237: Appendices
Appendices This section includes the following; • Telephone Anti-Jamming • Test Reports Only When Armed...
Page 238: Appendix A
Installation Manual Solution 862 Appendix A Telephone Anti-Jamming There are many companies today importing American designed products that claim to have Anti-Jamming and believe it or not, they push this feature as if it were a major break through in control panel technology.
Page 239: Appendix B
Test Reports Only When Armed control panel allows for test reports to be transmitted to the base station Solution 862 receiver to verify that the dialler functional. So what you might say, as most alarm diallers allow you to do this.
Page 240 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 241: Specifications
Specifications This section includes the following; • Warranty Statement • Specifications • Software Version Number • Advice To Users • New Zealand Telepermit Notes...
Page 242: Warranty Statement
Installation Manual Solution 862 Warranty Statement Electronics Design and Manufacturing Pty Limited warrants this product to be free from defects in material and workmanship for a period of three years from the date of manufacture as indicated by the date stamp and /or the serial number on the product.
Page 243: Specifications
Advice To Users The Austel permit that has been issued for this product is subject to the following conditions. • Control Panel may only be powered by an EDM TF008 Plug Pack Solution 862 (Approval Number Q92128). Electronics Design and Manufacturing Pty Limited...
Page 244: New Zealand Telepermit Notes
Installation Manual Solution 862 New Zealand Telepermit Notes • The grant of a telepermit for a device in no way indicates Telecom acceptance of responsibility for the correct operation of that device under all operating conditions. • This equipment shall not be used in any manner that could constitute a nuisance to other Telecom customers.
Page 245: Programming Sheets
Programming Sheets...
Page 246 Installation Manual Solution 862 Location 000 – 015 Page 131 Primary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Location 016 – 031 Page 131 Secondary Telephone Number For Receiver 1...
Page 247 Programming Sheets Solution 862 Location 177 Page 145 Dialler Options 1 1 = Dialler Reporting Functions Allowed 2 = Remote Arming Via The Telephone Allowed 4 = Answering Machine Bypass Only When Armed 8 = Use Bell 103 For FSK Format (Disabled – CCITT V21)
Page 248 Installation Manual Solution 862 Location 265 Page 156 Day A larm Zones 1 = Zone 1 4 = Zone 3 2 = Zone 2 8 = Zone 4 Location 266 Page 158 EOL Resistor Value 0 = No End Of Line Resistor...
Page 249 Programming Sheets Solution 862 Zone Pulse Count Settings The pulse count settings for each zone can be programmed between 0 - 15. Zone Pulse Count Time Zone pulse count time is the time frame or period over which the number of pulses must register.
Page 250 Installation Manual Solution 862 Location 323 Page 173 Swinger Shutdown Count For Siren Location 324 Page 174 Swinger Shutdown Count For Dialler Location 325 – 326 Page 176 Zone Status - Bypass Reports Location 325 Zone Bypass Report Location 326 Zone Bypass Restore Report Location 327 –...
Page 251 Programming Sheets Solution 862 Location 344 – 345 Page 182 System Status – Fuse Fail Report 10 3 Location 346 – 347 Page 182 System Status – Fuse Fail Restore Report 10 8 Location 348 – 349 Page 183 System Status AC Fail Report –...
Page 252 Installation Manual Solution 862 Location 398 – 399 Page 204 Entry Timer 1 Location 398 Increments Of 1 Second (0 - 15 S ec’s) Location 399 Increments Of 16 Seconds (0 - 240 Sec’s) Location 400 – 401 Page 204...
Page 253 Programming Sheets Solution 862 Location 424 Page 215 System Options 1 1 = EDM Smart Lockout Allowed 2 = Horn Speaker Monitor 4 = Strobe Indications For Radio Arm/Disarm 8 = Horn Speaker Beeps For Radio Arm/Disarm Location 425 Page 216...
Page 254 Installation Manual Solution 862 ISSUE130 Electronics Design and Manufacturing Pty Limited...
Page 255: Index
Index...
Page 256 Installation Manual Solution 862 Audible Indicators...........46, 50 Auto Arm In STAY Mode 1 ........219 Auto Arming Pre-Alert Timer........208 2 Channel Hand Held Transmitter Operations Auto Arming Time............208 Arming In AWAY Mode.......... 71 Auto Disarming Time ..........209 Arming In STAY Mode 1......... 71 Automatic Stepping Of Locations.........38...
Page 257 Status Indicator ............219 Turning On/Off ............108 E2 Fault ................ 64 Decadic Dialling To 60/40 ..........147 EDM Smart Watch ............. 215 Defaulting The Control Panel .........33, 42 EDMSAT..........86, 192, 225, 231 Delay Alarm Reporting Time........205 Entry Guard Timer For STAY Mode ..... 54, 57, 205 Delay Siren Until Transmission Complete....146...
Page 258 Installation Manual Solution 862 Determine Type ............109 Internal Crystal To Keep Time........218 Exit ................. 109 Introduction..............16 Invalid Code..........185, 206, 216 FAULT Indicator............ 45, 49 Features Isolate In STAY Mode 1 ..........171 Solution 404.............. 17 Isolating Allowed ............171 Fire Alarm ..............59 Isolating Zones ..............60...
Page 259 Index 259 Phone Controller .............225 Sensor Watch Alarm..........194 Programming Key ...........225 Silent Alarm............195 PS100 Power Supply Module .........226 Sirens Running ............195 Radio Key/Keyswitch Interface ......227 Strobe Operating............. 195 Solution Codepad Mimic Board......226 System Armed ............192 TF008 Plug Pack .............226 System Disarmed............
Page 260 Disarming From STAY Mode 2........58 Add or Changing Transmitter Codes ....69, 92 System Options 1 ............215 Arming In AWAY Mode........71, 72 EDM Smart Lockout ..........215 Arming In STAY Mode 1........71, 72 Monitoring Of Horn Speaker ........215 Deleting Transmitter Codes ........70 System Options 2 ............216...
Page 261 Index 261 Telephone Numbers Pulse Count Handover ........165, 217 Changing Domestic Phone Numbers ......78 Pulse Count Time ........... 161, 166 Terminal Definitions and Descriptions .......230 Report Code............161 Test Reports ..............110 Reporting Information ........161, 172 After Siren Reset .............219 Restore Code ............

EDM Solution 862 Installation Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EDM Solution 862

Summary of Contents for EDM Solution 862
