EDM Solution Ultima 844 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Solution Ultima 844/862/880
Installation Manual
ISSUE 1.62

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solution Ultima 844 and is the answer not in the manual?

Questions and answers

Related Manuals for EDM Solution Ultima 844

Summary of Contents for EDM Solution Ultima 844

  • Page 1 Solution Ultima 844/862/880 Installation Manual ISSUE 1.62...
  • Page 3 MA48XI Solution This page has been included for you to cut out and insert into the spine Ultima of the folder 844 /862 /880 Installation Manual ISSUE 1.62 (61-2) 9672 1233...
  • Page 5 Solution Ultima 844/862/880 Installation Manual Copyright  2001 by Electronics Design and Manufacturing Pty Limited, SYDNEY, AUSTRALIA Document Part Number MA48XI DOCUMENT ISSUE 1.62 Printed 29 October 2001 This documentation is provided to suit Solution Ultima 844/862/880 Control Panel (CC484/CC486/CC488) Firmware Revision 1.00 –...

  • Page 7: Table Of Contents

    Table Of Contents Introduction _____________________________________________________________________ 17 Introduction __________________________________________________________________________ 18 Solution Ultima 844 Features ____________________________________________________________ 19 Solution Ultima 862 Features ____________________________________________________________ 20 Solution Ultima 880 Features ____________________________________________________________ 21 Quick Start___________________________________________________________________________ 22 Solution Ultima 844 Zone Defaults________________________________________________________________ 24 Solution Ultima 862 Zone Defaults________________________________________________________________ 24...
  • Page 8 Codepad Duress Alarm_________________________________________________________________________ 47 Codepad Panic Alarm __________________________________________________________________________ 47 Codepad Fire Alarm ___________________________________________________________________________ 47 Codepad Medical Alarm________________________________________________________________________ 47 Isolating Zones ________________________________________________________________________ 48 Standard Isolating ___________________________________________________________________________ 49 Code To Isolate_____________________________________________________________________________ 50 Fault Analysis Mode____________________________________________________________________ 51 Fault Descriptions _____________________________________________________________________ 53 System Fault _________________________________________________________________________________ 53 Low Battery _______________________________________________________________________________ 53 Date and Time______________________________________________________________________________ 53 RF Receiver Fail ____________________________________________________________________________ 53...
  • Page 9 Strobe Test ________________________________________________________________________________ 94 Turning Day Alarm On and Off ________________________________________________________________ 95 Fault Analysis Mode _________________________________________________________________________ 95 Initiate A Modem Call _______________________________________________________________________ 96 Reset Latching Outputs _______________________________________________________________________ 96 Codepad Buzzer Tone Change _________________________________________________________________ 97 Send Test Report ____________________________________________________________________________ 97 Remote System ___________________________________________________________________ 99 Operations Via Telephone__________________________________________________________ 99 Remote Arming Via The Telephone _____________________________________________________ 100 Programming___________________________________________________________________ 101 Programming________________________________________________________________________...
  • Page 10 Basic Pager Display Information ________________________________________________________ 135 Subscriber ID Number ________________________________________________________________________ 135 Zone Status _________________________________________________________________________________ 135 System Status _______________________________________________________________________________ 135 Dialler Information ______________________________________________________________ 137 Dialler Information ___________________________________________________________________ 138 Primary Telephone Number For Receiver 1 ________________________________________________________ 139 Secondary Telephone Number For Receiver 1 ______________________________________________________ 139 Handshake Tone For Receiver 1_________________________________________________________________ 140 Transmission Format For Receiver 1 _____________________________________________________________ 141 Subscriber ID Number For Receiver 1 ____________________________________________________________ 141...
  • Page 11 User Codes _____________________________________________________________________ 157 Access Codes ________________________________________________________________________ 158 Installer Code _______________________________________________________________________________ 158 User Codes _________________________________________________________________________________ 159 Solution Ultima 844/862 User Codes _____________________________________________________________ 160 Solution Ultima 880 User Codes_________________________________________________________________ 160 User Code Priority ___________________________________________________________________________ 161 Arm and Disarm ___________________________________________________________________________ 161 Arm Only ________________________________________________________________________________ 161 Arm and Disarm + Open/Close Reports _________________________________________________________ 161...
  • Page 12 Latching Arm In STAY Mode 1_______________________________________________________________ 177 Latching Disarm From STAY Mode 1 Or STAY Mode 2 ___________________________________________ 177 Momentary Arm and Disarm In AWAY Mode ___________________________________________________ 178 Momentary Arm In AWAY Mode _____________________________________________________________ 178 Momentary Disarm From AWAY Mode, STAY Mode 1 Or STAY Mode 2 ____________________________ 178 Momentary Arm and Disarm In STAY Mode 1 ___________________________________________________ 178 Momentary Arm In STAY Mode 1 ____________________________________________________________ 178 Momentary Disarm From STAY Mode 1 Or STAY Mode 2 _________________________________________ 178...
  • Page 13 System and Consumer Options _____________________________________________________ Programming Option Bits _____________________________________________________________ System Options 1 ____________________________________________________________________________ 227 EDM Smart Lockout Allowed ________________________________________________________________ Horn Speaker Monitor_______________________________________________________________________ 227 Strobe Indications For Radio Arm/Disarm _______________________________________________________ 227 Assign Button 4 On Transmitter To Arm STAY Mode 1 ____________________________________________...
  • Page 14 Consumer Options 2 __________________________________________________________________________ 232 Codepad Display Extinguish After 60 Seconds ___________________________________________________ 232 Single Button Arming Allowed (AWAY Mode, STAY Mode 1 & 2) __________________________________ 232 Single Button Disarming Allowed (STAY Mode 1 & 2) ____________________________________________ 232 Alarm Memory Reset On Disarm ______________________________________________________________ 232 Consumer Options 3 __________________________________________________________________________ 233 Codepad Fault Alarm Beeps Allowed __________________________________________________________ 233 Use Digit 3 For Codepad Duress Instead Of Digit 9 _______________________________________________ 233...
  • Page 15 Terminals and Descriptions _______________________________________________________ 257 Terminal Definitions and Descriptions ___________________________________________________ 258 Glossary Of Terms ___________________________________________________________________ 259 Solution Ultima 844/862/880 Wiring Diagram _____________________________________________ 262 Solution Ultima 844/862/880 Component Overlay __________________________________________ 263 RF3212 Radio Receiver Wiring Diagram _________________________________________________ 264 Telecom Connection Diagrams _________________________________________________________ 265...

  • Page 17: Introduction

    Introduction • Solution Ultima 844 Features • Solution Ultima 862 Features • Solution Ultima 880 Features • Quick Start • Solution Ultima 844 Zones Defaults • Solution Ultima 862 Zone Defaults • Solution Ultima 880 Zone Defaults • Zone Types...

  • Page 18: Introduction

    Installation Manual Solution Ultima 844/862/880 Introduction Congratulations on selecting the control panel for your Solution Ultima 844/862/880 installation. So that you can obtain the most from your unit, we suggest that you take the time to read through this manual and familiarise yourself with the numerous outstanding operating and installation features of this system.

  • Page 19: Solution Ultima 844 Features

    Introduction Solution Ultima 844 Features security system uses the very latest in microprocessor technology to Solution Ultima 844 provide you with more useful features and superior reliability and performance. Following is a list of the main features that the control panel will provide.

  • Page 20: Solution Ultima 862 Features

    Installation Manual Solution Ultima 844/862/880 Solution Ultima 862 Features security system uses the very latest in microprocessor technology to Solution Ultima 862 provide you with more useful features and superior reliability and performance. Following is a list of the main features that the control panel will provide.

  • Page 21: Solution Ultima 880 Features

    Introduction Solution Ultima 880 Features security system uses the very latest in microprocessor technology to Solution Ultima 880 provide you with more useful features and superior reliability and performance. Following is a list of the main features that the control panel will provide. Eight Programmable User Codes (1 –...

  • Page 22: Quick Start

    Installation Manual Solution Ultima 844/862/880 Quick Start The following steps will allow you to use the control panel Solution Ultima 844/862/880 with the factory default values. The default values allow the control panel to communicate in the Contact ID format. If you are not familiar to programming the...
  • Page 23 Introduction How To Set The Date and Time 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the day, month, year, hour and minute using the (DD, MM, YY, HH, MM) format (i.e. DD = Day of the month, MM = Month of the year, YY = Current year, HH = Hour of the day, MM = Minute of the day).

  • Page 24: Solution Ultima 844 Zone Defaults

    24 Hour Fire Instant 24 Hour Tamper Table 1: Zone Defaults For Solution Ultima 844 Solution Ultima 862 Zone Defaults The default zone settings of the control panel are listed in the table below. Zones 1 – 6 may be programmed to any of the available zone types.

  • Page 25: Zone Types

    There are thirteen different zone types to choose from when programming zones. These thirteen different zone types are available for all control panels. Refer Solution Ultima 844/862/880 to Zone Programming on page 169 for more information on programming zones. Zone Type...
  • Page 26 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 27: Codepad Indicators

    Codepad Indicators This section includes the following; • CP5 Eight Zone LED Codepad • CP5 Eight Zone LCD Codepad • CP5 Master Partitioned LED Codepad...

  • Page 28: Cp5 Eight Zone Led Codepad

    Installation Manual Solution Ultima 844/862/880 CP5 Eight Zone LED Codepad The codepad is the communications interface between you and your alarm system. The codepad allows you to issue commands and offers both visual and audible indications that guide you through the general operation.

  • Page 29: Stay Indicator

    Codepad Indicators STAY Indicator STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY Mode 2. STAY indicator will also flash in unison with the AWAY indicator when Installer’s Programming Mode or Master Code Functions are used. For the different methods of arming the system in STAY Mode 1, refer to page 42.

  • Page 30: Audible Indicators

    Installation Manual Solution Ultima 844/862/880 Audible Indicators In general, the audible indications given out by the codepad are as follows: Indicator Definition A Button Has Been Pressed On The Codepad Or End Of Exit Time When Armed In Either STAY Mode 1 Or...

  • Page 31: Cp5 Eight Zone Lcd Codepad

    Codepad Indicators CP5 Eight Zone LCD Codepad The codepad is the communications interface between you and your alarm system. The codepad allows you to issue commands and offers both visual and audible indications that guide you through the general operation. The codepad incorporates numerous indicators.

  • Page 32: Stay Indicator

    Installation Manual Solution Ultima 844/862/880 STAY Indicator STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY Mode 2. indicator will also flash in unison with the indicator when Installer’s Programming STAY AWAY Mode or Master Code Functions are used.

  • Page 33: Fault Indicator

    Codepad Indicators FAULT Indicator FAULT indicator is used to display that the system has detected a fault. Refer to Fault Descriptions on page 53 for more information on system faults. Every time a new system fault has been detected (e.g.: FAULT indicator flashing), the codepad will begin to beep once every minute.

  • Page 34: Audible Indicators

    Installation Manual Solution Ultima 844/862/880 Audible Indicators In general, the audible indications given out by the codepad are as follows: Indicator Definition A Button Has Been Pressed On The Codepad Or End Of Exit Time When Armed In Either STAY Mode 1 Or...

  • Page 35: Cp5 Master Partitioned Led Codepad

    Codepad Indicators CP5 Master Partitioned LED Codepad This codepad is only used on the control panel Solution Ultima 880 when partitioned. The Master Partitioned LED codepad will allow the user to operate both areas individually from the same codepad, without the need to operate individual areas from separate codepads.

  • Page 36: Area Display Indicators

    Installation Manual Solution Ultima 844/862/880 Area Display Indicators A group of four Area Display indicators display which area is currently being displayed (i.e. If number 1 is being displayed, all information provided on the codepad display relates only to Area 1.

  • Page 37: Mains Indicator

    Codepad Indicators MAINS Indicator indicator is used to display that the systems AC mains supply is normal or has failed. MAINS When programming numbers (i.e. Installer’s Programming Mode or Master Code Functions), the indicator will illuminate when you program numbers between 10 and 15. The MAINS MAINS indicator represents digit 10 plus the value of the illuminated zone indicator (e.g.: If you program a...
  • Page 38 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 39: System Operations

    System Operations This section includes the following; • Arming The System In AWAY Mode • Disarming The System From AWAY Mode • Arming The System In STAY Mode 1 • Disarming The System From STAY Mode 1 • Arming The System In STAY Mode 2 •...

  • Page 40: System Operations

    Installation Manual Solution Ultima 844/862/880 System Operations This section explains the general operations of the system. The operations will explain how to arm and disarm the system in the various modes, how to isolate zones, initiate codepad alarms and determine any fault that may occur.

  • Page 41: Disarming The System From Away Mode

    System Operations Disarming The System From AWAY Mode When you enter the premises after the system has been armed in AWAY Mode, you will need to disarm the system from AWAY Mode to disable detection devices that will activate the sirens, strobe and bell outputs.

  • Page 42: Arming The System In Stay Mode 1

    Installation Manual Solution Ultima 844/862/880 Arming The System In STAY Mode 1 Arming the system in STAY Mode 1 is only used when the perimeter and unused areas of the premises need to be armed to detect any would be intruder from entering the premises, at the same time allowing you to move freely within an area which has been automatically isolated.

  • Page 43: Forced Arming

    System Operations Method Two How To Arm The System In STAY Mode 1 1. Hold down the button until two beeps are heard. STAY indicator will illuminate and exit time will now commence. Any zones that have been programmed to be automatically isolated in STAY Mode 1 will begin to flash until exit time expires.

  • Page 44: Disarming The System From Stay Mode 1

    Installation Manual Solution Ultima 844/862/880 Disarming The System From STAY Mode 1 There are two methods for disarming the system from STAY Mode 1. Method one is standard and will always operate. Method two is optional and needs Option 4 to be enabled in "LOCATION 441"...

  • Page 45: Arming The System In Stay Mode 2

    System Operations Arming The System In STAY Mode 2 Arming the system in STAY Mode 2 is only used when the perimeter and unused areas of the premises need to be armed to detect any would be intruder from entering the premises, at the same time allowing you to move freely within an area which has been automatically isolated.

  • Page 46: Disarming The System From Stay Mode 2

    Installation Manual Solution Ultima 844/862/880 Disarming The System From STAY Mode 2 There are two methods for disarming the system from STAY Mode 2. Method one is standard and will always operate. Method two is optional and requires Option 4 to be enabled in "LOCATION 441"...

  • Page 47: Codepad Duress Alarm

    System Operations Codepad Duress Alarm A codepad duress alarm is used as a silent hold up alarm. This will only occur when the number added to the end of any valid user code that is being used to disarm the system. However, if a user code has a priority level of arming only, entering their user code followed by 9 will still send a duress alarm when the system is armed.

  • Page 48: Isolating Zones

    Installation Manual Solution Ultima 844/862/880 Isolating Zones Isolating zones allow you to manually disable one or more zones before arming the system in AWAY Mode, STAY Mode 1 or STAY Mode 2. Once a zone has been isolated, access is allowed into that zone during the armed state without activating the sirens or dialler.

  • Page 49: Standard Isolating

    System Operations Standard Isolating Standard isolating allows all operators to be able to isolate zones. Therefore, no code is required to be used when isolating zones. 1. Press the button twice. Three beeps will be heard and the STAY indicator will begin to flash. 2.

  • Page 50: Code To Isolate

    Installation Manual Solution Ultima 844/862/880 Code To Isolate The method of code to isolate restricts only those user codes that have the priority level Code To Isolate set to be able to isolate zones. Therefore, if any user code has this priority level set, the method of standard isolating will be disabled.

  • Page 51: Fault Analysis Mode

    System Operations Fault Analysis Mode If a fault should occur, the FAULT or MAINS indicator will flash and the codepad will beep once every minute. If the AC mains supply has failed, the MAINS indicator will flash until the AC mains supply has estored.
  • Page 52 Installation Manual Solution Ultima 844/862/880 Zone Fault Hold Down Zone Fault Indicator Description Button Indicator Condition Low Battery System Fault Date & Time RF Receiver Jamming RF Receiver Tamper Switch RF Receiver Comms Failure Horn Speaker Telephone Line Fail E2 Fault...

  • Page 53: Fault Descriptions

    System Operations Fault Descriptions System Fault A system fault will only display when any of the following faults occur. After entering fault analysis mode, holding down button will determine which of the following faults have occurred. Low Battery A low battery fault will register when the system detects a low capacity back-up battery. The system automatically performs a battery test every 4 hours and also every time you arm the system.

  • Page 54: Tamper Fail

    Installation Manual Solution Ultima 844/862/880 Tamper Fail This fault will occur when any zone has become open circuit. By holding down button until two beeps are heard in fault analysis mode will display which zone has reported the tamper fail fault.

  • Page 55: Remote Radio Transmitter Operations

    Remote Radio Transmitter Operations This section includes the following; • Remote Radio Transmitter Operations • Indications Upon Remote Radio Transmitter Operations • Remote Radio User Code Priority Levels • Changing Or Deleting Remote Radio User Codes...

  • Page 56: Remote Radio Transmitter Operations

    Installation Manual Solution Ultima 844/862/880 Remote Radio Transmitter Operations control panel has the ability to be remotely operated using Solution Ultima 844/862/880 hand held radio remote Transmitters. There is a choice of using either a 2-channel hand held Transmitter or a 4-channel hand held Transmitter to operate the system.

  • Page 57: Indications Upon Remote Radio Transmitter Operations

    Remote Radio Transmitter Operations Indications Upon Remote Radio Transmitter Operations When using either the 2-channel or 4-channel hand held transmitters to operate the system, audible and/or visual indications can be provided via the horn speakers or the strobe. This will allow you to operate the system from outside the premises with confidence.

  • Page 58: Changing Or Deleting Remote Radio User Codes

    Installation Manual Solution Ultima 844/862/880 Changing Or Deleting Remote Radio User Codes Up to eight remote radio hand held Transmitters (User Codes 9 – 16) may be used to operate the system. Before the control panel will accept any of the signals from any radio remote hand held Transmitter, the control panel must learn the code of the Transmitter.
  • Page 59 Remote Radio Transmitter Operations How To Delete A Remote Radio User Code 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the (9-16) that you wish to delete followed by the button.
  • Page 60 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 61: System Functions

    System Functions This section includes the following; • Installer Code Functions • Master Code Functions • Hold Down Functions...

  • Page 62: System Functions

    Installation Manual Solution Ultima 844/862/880 System Functions This section explains the more advanced features that are required for testing and regular maintenance of the system. Features such as Installer Code Functions, Master Code Functions and Hold Down Functions are covered in this section.

  • Page 63: Adding Or Deleting Rf Wireless Devices

    System Functions Adding Or Deleting RF Wireless Devices The control panel has the ability to accept a maximum total of 16 wireless devices on any or all of the 8 zones that are used by the system. This means that it is possible to connect wireless PIR's, reed switches and smoke detectors directly to the control panel.
  • Page 64 Installation Manual Solution Ultima 844/862/880 How To Delete A RF Wireless Device 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the (1-16) that you wish to delete followed by the button.

  • Page 65: Set The Number Of Days Until The First Test Report

    System Functions Set The Number Of Days Until The First Test Report If you require the first test to report (Contact ID Event Code 602) the day after you are installing the control panel and you have programmed the repeat interval between each test report for every 7 days, you will need to set when the first test report will occur.

  • Page 66: Changing Domestic Phone Numbers

    Installation Manual Solution Ultima 844/862/880 Changing Domestic Phone Numbers When the system has been set up for domestic dialling, this function allows the installer to view and program the required telephone numbers that the system will call in the event of an alarm. For a more detailed description, refer to Domestic Dialling on page 125 for further information.
  • Page 67 System Functions Example If you wish to program two separate telephone numbers (9672 1777 and 9672 1233), follow the sequence below and replace the telephone numbers mentioned in the manual with the telephone numbers that you wish to program. 1234 96721777 96721233 How To Disable Domestic Dialling...

  • Page 68: Change Telco Arm/Disarm Sequence

    Installation Manual Solution Ultima 844/862/880 Change Telco Arm/Disarm Sequence This feature allows you to program the Telco Arm Sequence (Option 1) and Telco Disarm Sequence (Option 2). This feature is only available if your telecommunication provider has the call forward option available.
  • Page 69 System Functions How To Program Telco Arming Sequence 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Press button followed by the button to change the telco arm sequence. Three beeps will be heard.
  • Page 70 Installation Manual Solution Ultima 844/862/880 How To Program The Telco Disarm Sequence 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Press button followed by the button to change the telco disarm sequence.

  • Page 71: Setting Stay Mode 2 Zones

    System Functions Setting STAY Mode 2 Zones This function allows the installer to select which zones are to be automatically isolated when the system is armed in STAY Mode 2. Every time the system is armed in STAY Mode 2, the zones selected using this function will be automatically isolated.

  • Page 72: Satellite Siren Service Mode

    Installation Manual Solution Ultima 844/862/880 How To Disable STAY Mode 2 Zones If at any time you wish to disable all zones selected to be automatically isolated for STAY Mode 2, you may enter the following sequence. Satellite Siren Service Mode If an EDMSAT is connected to Output 1, this function will allow you to perform service work on the system without triggering the satellite siren.

  • Page 73: Turning Telephone Monitor Mode On/Off

    System Functions Turning Telephone Monitor Mode On/Off Telephone monitor mode allows the remote codepad to be used for a visual representation of data transmissions between the control panel and the base station receiver. The dialling sequence is also shown in this mode. The codepad will beep once every two seconds while telephone monitor mode is active regardless of whether the system is in Installer's Programming Mode or normal operating mode.

  • Page 74: Walk Test Mode

    Installation Manual Solution Ultima 844/862/880 Walk Test Mode Walk test mode allows you to test detection devices to ensure that they are functioning correctly. Before activating walk test mode, isolate any zones that are not required for testing. Refer to Isolating Zones on page 48 for further information.

  • Page 75: Event Memory Recall Mode

    System Functions Event Memory Recall Mode This function allows you to playback the last forty events that have occurred to the system. The event memory recall mode reports all alarms and arming/disarming of the system in the AWAY Mode, STAY Mode 1 and STAY Mode 2. This function helps with trouble shooting system faults. The events are displayed via the codepad indicators.

  • Page 76: Master Code Functions

    Installation Manual Solution Ultima 844/862/880 Master Code Functions Master Code Functions are designed to allow those users that have the appropriate priority level to perform certain functions of a supervisory level. These functions can only be carried out when the system is in the disarmed state.

  • Page 77: Changing And Deleting User Codes

    System Functions Changing and Deleting User Codes This function allows a Master Code holder to add/change or delete any of the system user codes. When using a control panel that has been partitioned, user codes cannot be Solution Ultima 880 added, changed or deleted by the Master Code holder unless they (the user code) have been allocated to an area or the same area as the Master Code.
  • Page 78 Installation Manual Solution Ultima 844/862/880 How To Delete A User Code 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the (1-8) that you wish to delete followed by the button.

  • Page 79: Changing And Deleting Remote Radio User Codes

    System Functions Changing and Deleting Remote Radio User Codes This function allows a Master Code holder to add/change or delete any of the system user codes. How To Add Or Change A Remote Radio User Code 1. Enter your followed by and the button.
  • Page 80 Installation Manual Solution Ultima 844/862/880 How To Delete A Remote Radio User Code 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the (9-16) that you wish to delete followed by the button.

  • Page 81: Changing Domestic Phone Numbers

    System Functions Changing Domestic Phone Numbers When the system has been set up for domestic dialling, this function allows the Master Code holder to view and program the required telephone numbers that the system will call in the event of an alarm. For a more detailed description, refer to Domestic Dialling on page 125 for further information.
  • Page 82 Installation Manual Solution Ultima 844/862/880 Example If you wish to program two separate telephone numbers (9672 1777 and 9672 1233), follow the sequence below and replace the telephone numbers mentioned in the manual with the telephone numbers that you wish to program. Remember to substitute the default Master Code (2580) with the Master Code that has been programmed.

  • Page 83: Change Telco Arm/Disarm Sequence

    System Functions Change Telco Arm/Disarm Sequence This feature allows you to program the Telco Arm Sequence (Option 1) and Telco Disarm Sequence (Option 2). This feature is only available if your telecommunication provider has the call forward option available Option 1 – Telco Arm Sequence This allows you to program the Call Forward –...
  • Page 84 Installation Manual Solution Ultima 844/862/880 How To Program Telco Arming Sequence 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Press button followed by the button to change the telco arm sequence. Three beeps will be heard.
  • Page 85 System Functions How To Program The Telco Disarm Sequence 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Press button followed by the button to change the telco disarm sequence. Three beeps will be heard.

  • Page 86: Setting Stay Mode 2 Zones

    Installation Manual Solution Ultima 844/862/880 Setting STAY Mode 2 Zones This function allows the Master Code Holder to select which zones are to be automatically isolated when the system is armed in STAY Mode 2. Every time the system is armed in STAY Mode 2, the zones selected using this function will be automatically isolated.

  • Page 87: Turning Outputs On/Off

    System Functions How To Disable STAY Mode 2 Zones If at any time you wish to disable all zones selected to be automatically isolated for STAY Mode 2, you may enter the following sequence. Turning Outputs On/Off If an output has been programmed for remote operation, you can turn the remote output on or off using this Master Code function or remotely using the Alarm Link Software.
  • Page 88 Installation Manual Solution Ultima 844/862/880 How To Turn An Output Off From The Remote Codepad 1. Enter your followed by and the button. Three beeps will be heard and the indicators will begin to flash. STAY AWAY 2. Enter the required (1-3) followed by the button.

  • Page 89: Setting The Date And Time

    System Functions Setting The Date and Time This function only needs to be used when the date and time requires to be changed or the system has been powered down. If the date and time has not been set using this function, the date and time fault will only display when the Auto Arming Time in “LOCATION 426 - 429”...

  • Page 90: Walk Test Mode

    Installation Manual Solution Ultima 844/862/880 Walk Test Mode Walk test mode allows you to test detection devices to ensure that they are functioning correctly. Before activating walk test mode, isolate any zones that are not required for testing. Refer to Isolating Zones on page 48 for further information.

  • Page 91: Event Memory Recall Mode

    System Functions Event Memory Recall Mode This function allows you to playback the last forty events that have occurred to the system. The event memory recall mode reports all alarms and arming/disarming of the system in the AWAY Mode, STAY Mode 1 and STAY Mode 2. This function helps with trouble shooting system faults. The events are displayed via the codepad indicators.

  • Page 92: User Code Functions

    Installation Manual Solution Ultima 844/862/880 User Code Functions Function Description Arm Or Disarm Both Areas At The Same Time (CC488) Table 44: User Code Functions Arm or Disarm Both Areas At The Same Time This user code function only operates on systems that have been partitioned.

  • Page 93: Hold Down Functions

    System Functions Hold Down Functions Hold down functions have been incorporated to allow easy activation of specific operations. When a button is held down for two seconds, two beeps will be heard and a particular function will operate. The hold down functions available are listed below. Arm The System In AWAY Mode Holding the button down until two beeps are heard will arm the system in AWAY Mode.

  • Page 94: Arm The System In Stay Mode 2

    Installation Manual Solution Ultima 844/862/880 Arm The System In STAY Mode 2 Holding the button down until two beeps are heard will arm the system in STAY Mode 2. Option 2 in "LOCATION 441" on page 232 will need to be enabled for this function to operate.

  • Page 95: Turning Day Alarm On And Off

    System Functions Turning Day Alarm On and Off Holding the button down will turn day alarm on or off. If the indicator is required to STAY indicate the status of day alarm operation (enabled/disabled), refer to Option 8 in "LOCATION 440" on page 231 for further information.

  • Page 96: Initiate A Modem Call

    Installation Manual Solution Ultima 844/862/880 Zone Fault Hold Down Zone Fault Indicator Description Button Indicator Condition Low Battery System Fault Date & Time RF Receiver Jamming RF Receiver Tamper Switch RF Receiver Comms Failure Horn Speaker Telephone Line Fail E2 Fault...

  • Page 97: Codepad Buzzer Tone Change

    System Functions Codepad Buzzer Tone Change Holding the button down continuously will change the tone of the buzzer in the remote codepad. There are fifty different tones to choose from between 1500 Hz - 5000 Hz and they are specific to each codepad.
  • Page 98 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 99: Remote System

    Remote System Operations Via Telephone This section includes the following; • Remote Arming Via The Telephone...

  • Page 100: Remote Arming Via The Telephone

    Installation Manual Solution Ultima 844/862/880 Remote Arming Via The Telephone This feature allows you to arm your system from any remote location via the telephone line. For obvious security reasons, the system cannot be disarmed using this method. To make use of this feature, you will require a touch tone telephone or the Phone Controller (CC911).

  • Page 101: Programming

    Programming This section includes the following; • Programming • Programming With The Remote Codepad • Programming With The Hand Held Programmer • Programming With The Programming Key • Programming Option Bits • Installer’s Programming Commands • Disable Factory Default • Defaulting The Control Panel...

  • Page 102: Programming

    Installation Manual Solution Ultima 844/862/880 Programming The programming options of the control panel are stored in a non-volatile EPROM. This memory will hold all the relevant configuration and user specific data even during a total power loss. The data retention time is as long as ten years without power; therefore, no reprogramming will be required after powering the control panel down.

  • Page 103: Programming With The Remote Codepad

    Programming Programming With The Remote Codepad When programming the control panel via the remote codepad, the system must be in the disarmed state with no alarm memory present. To access the Installer’s Programming Mode, enter the four digit followed by the 1234 button.
  • Page 104 Installation Manual Solution Ultima 844/862/880 To change data in the current location, enter the new value (0 – 15) followed by the button. This will store the new data into the location and still leave you positioned at the same location. You will notice that the new information programmed will be displayed on the codepad indicators (e.g..

  • Page 105: Programming With The Hand Held Programmer

    Programming Programming With The Hand Held Programmer The Hand Held Programmer (CC814) has five, seven segment displays. The three seven segment displays on the left display the current location number and the two seven segment displays on the right display the data for the location currently being displayed. To connect the hand held programmer, locate the socket marked PROGRAMMING KEY found at the top of the PCB (printed circuit board) next to the Auxiliary Module socket.

  • Page 106: Programming With The Programming Key

    Installation Manual Solution Ultima 844/862/880 To exit the Installer's Programming Mode, enter command followed by the button. Two beeps will be heard and the system will return to the disarmed state. Refer to Installer’s Programming Commands on page 107 for further information on commands that can be performed during access of the Installer's Programming Mode.

  • Page 107: Programming Option Bits

    Programming Programming Option Bits When programming these locations, you will notice that there are four alternatives per location. You may select one, two, three or all of these alternatives for each location, however, only one number is required to be programmed. This number is calculated by adding the option bit numbers together. Example If at "LOCATION 177"...

  • Page 108: Command 958 - Enable/Disable Zone Status Mode

    Installation Manual Solution Ultima 844/862/880 Command 958 - Enable/Disable Zone Status Mode This function enables and disables the zone status display mode when using the hand held programmer. The hand held programmer will display the zones on the seven-segment display from left to right.

  • Page 109: Command 959 - Test Programming Key

    (CC891) may be used with the control panel. Solution Ultima 844/862/880 The programming key test is non-destructive and any data in the programming key will remain intact after the test has been completed. One long beep indicates that the programming key test has failed and two beeps indicates a successful test.

  • Page 110: Command 960 - Exit Installer's Programming Mode

    Installation Manual Solution Ultima 844/862/880 How To Test The Programming Key Using The Hand Held Programmer 1. Before connecting the hand held programmer onto the pins marked PROGRAMMING KEY, make sure that the switch on the hand held programmer is in the EXT position and that no external key has been plugged onto the hand held programmer.

  • Page 111: Command 962 - Copy Control Panel Memory To Programming Key

    Programming Command 962 - Copy Control Panel Memory To Programming Key This command is used to copy the control panel memory to the programming key. Only the Programming Key (CC891) may be used with the control Solution Ultima 844/862/880 panel. How To Copy The Control Panel Memory To The Programming Key 1234 1.

  • Page 112: Command 963 - Copy From Programming Key To Control Panel

    Installation Manual Solution Ultima 844/862/880 Command 963 - Copy From Programming Key To Control Panel This command is used to copy data from the programming key to the control panel. Only the Programming Key (CC891) may be used with the...

  • Page 113: Command 964 - Erase Programming Key

    Command 964 - Erase Programming Key This command erases all data from the programming key. Only the Programming Key (CC891) may be used with the control panel. Solution Ultima 844/862/880 How To Erase The Programming Key 1234 1. Enter Installer's Programming Mode (i.e..

  • Page 114: Command 965 - Set Up Domestic Dialling Format

    Installation Manual Solution Ultima 844/862/880 Command 965 - Set Up Domestic Dialling Format Command 965 has been included to allow the set up of the domestic dialling format a one step operation. Refer to page 126 for more information on Domestic Dialling Format.

  • Page 115: Command 966 - Enable/Disable Automatic Stepping Of Locations

    Programming Command 966 - Enable/Disable Automatic Stepping Of Locations This command allows automatic stepping of locations while programming via Installer’s Programming Mode. When enabled via the hand held programmer, the decimal point of the left most display will reflect the mode of operation. If the decimal point is illuminated on the hand held programmer, automatic stepping of locations is active.
  • Page 116 Installation Manual Solution Ultima 844/862/880 Example (Auto Step Disabled) To enter the Primary Telephone Number "02 pause 9672 1055" with auto step disabled (i.e.. Decimal point extinguished when using the hand held programmer). Press followed by the button. (This will position you at "LOCATION 000" being the start of the Primary Telephone Number For Receiver 1).

  • Page 117: Command 999 - Display Panel Type Or Software Version Number

    The codepad will display a 4, 6 or 8 depending on the software of the control panel. Refer to the “Table 50: Control Panel Type” below for more information. Indicator Control Panel Type Solution Ultima 844 Solution Ultima 862 Solution Ultima 880 Table 50: Control Panel Type When using this command via the hand held programmer, the hand held programmer will display the software version number of the control panel.

  • Page 118: Disable Factory Default

    Installation Manual Solution Ultima 844/862/880 Disable Factory Default LOCATION 900 This feature prevents the control panel from being manually defaulted via the default button or to prevent using a programming key to perform an automatic download to the control panel when the system is disarmed.

  • Page 119: Defaulting The Control Panel

    Programming Defaulting The Control Panel If the control panel does not have "LOCATION 900" Solution Ultima 844/862/880 programmed as 15, follow the procedure outlined below to successfully default the control panel back to the factory default settings. How To Default The Control Panel Via Installer Code Enter Installer Programming Mode.
  • Page 120 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 121: Alarm Link Operations

    Alarm Link Operations This section includes the following; • Alarm Link Software • Remote Connect • Remote Connect With Customer Control • Remote Connect Without Call Back Verification • Remote Connect With Call Back Verification • Direct Connect • Alarm Link Options...

  • Page 122: Alarm Link Software

    Software, refer to the table below to select the software version number that corresponds to the control panel type required. Control Panels Software Version Select Panel Type Solution Ultima 844 - 1.00 S844_V10 Solution Ultima 862 - 1.00 S862_V10 S880_V10 Solution Ultima 880 - 1.00...

  • Page 123: Remote Connect Without Call Back Verification

    The direct connect feature has been incorporated giving the installer a simple method for programming the control panel at the office or on site visits Solution Ultima 844/862/880 using a portable computer. There is no need for telephone lines or modems, which makes programming of the control panel completed easily in minutes.

  • Page 124: Alarm Link Options

    Installation Manual Solution Ultima 844/862/880 Alarm Link Options LOCATION 180 Option Description Enable Upload/Download Via Alarm Link Enable Alarm Link Call Back Terminate Alarm Link Connection On Alarm Use External Modem Module (CC811) For Alarm Link Operations Table 52: Alarm Link Options...

  • Page 125: Domestic Dialling

    Domestic Dialling This section includes the following; • Domestic Dialling Format • Domestic Dialling Function • Acknowledge Domestic Dialling • Setting Up and Programming Domestic Reporting • Disable Domestic Dialling...

  • Page 126: Domestic Dialling Format

    Installation Manual Solution Ultima 844/862/880 Domestic Dialling Format The locations of the primary telephone number and secondary telephone number for Receiver 1 or Receiver 2 are only used for base station reporting and pager reporting. When either Receiver 1 or Receiver 2 is set up for domestic reporting, both the primary telephone number and the secondary telephone number will be ignored.

  • Page 127: Setting Up And Programming Domestic Reporting

    Domestic Dialling Setting Up and Programming Domestic Reporting Programming the control panel for domestic reporting has been made extremely simple by the use of the Installer's Programming Command 965. Refer to Command 965 - Set Up Domestic Dialling Format on page 114 for more information. However, if you wish to set up Receiver 2 for Domestic Dialling, you will need to manually program the reporting functions.

  • Page 128: Disable Domestic Dialling

    Installation Manual Solution Ultima 844/862/880 Digit Required Number To Program Digit Required Number To Program Followed By Followed By Four Second Pause Followed By Break Followed By Followed By Table 53: Domestic Dialling Digits Example If you wish to program two separate telephone numbers (9672 1777 and 9672 1233), follow the sequence below and replace the telephone numbers mentioned in the manual with the telephone numbers that you wish to program.

  • Page 129: Dialler Reporting Formats

    Dialler Reporting Formats This section includes the following; • Transmission Formats • Contact ID Format • Point ID Codes • 4+2 Reporting Format • Basic Pager Reporting Format • Basic Pager Display Information...

  • Page 130: Transmission Formats

    Installation Manual Solution Ultima 844/862/880 Transmission Formats When making use of the control panel's dialling and communication features, there are a number of transmission formats available. Refer to "LOCATION 033" on page 141 to set the required transmission format for Receiver 1 and “LOCATION 073” on page 144 to set the required transmission formation for Receiver 2.

  • Page 131: Point Id Codes

    Dialler Reporting Formats Point ID Codes The table below shows the different Point ID Codes and Event Codes that are sent to the base station receiver when using Contact ID Reporting Format. All event codes are fixed and will always send the same code as there are no programming locations made available to alter these.
  • Page 132 Installation Manual Solution Ultima 844/862/880 Event Event Point ID Code Description Number Explanation Page Walk Test User Specific Walk Test Mode Page 184 Zone Specific Tamper Zone Tamper Page 184 1 - 8 Zone Specific RF Low Battery RF Low Battery...

  • Page 133: 4+2 Reporting Format

    Dialler Reporting Formats 4+2 Reporting Format The 4+2 Express Format will report a Subscriber ID Number followed by an expansion code and the reporting channel number is sent directly after the expansion code. Subscriber ID Number Expansion Code Channel Number SSSS Table 56: Example Reporting In 4+2 Format New Event...

  • Page 134: Basic Pager Reporting Format

    Installation Manual Solution Ultima 844/862/880 Basic Pager Reporting Format Basic Pager Format requires some interpretation of the numbers that appear on the display; however, it is possible to differentiate between 1000 different control panels when a number of control panels are reporting to the one pager.

  • Page 135: Basic Pager Display Information

    Dialler Reporting Formats Basic Pager Display Information Subscriber ID Number This is the identification number of the control panel and is programmed in “LOCATION 034 – 039” on page 141 for Receiver 1 and “LOCATION 074 – 079” on page 144 for Receiver 2. The pocket pager will only display the last three digits of the Subscriber ID Number.
  • Page 136 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 137: Dialler Information

    Dialler Information This section includes the following; • Dialler Information • Primary Telephone Number For Receiver 1 • Secondary Telephone Number For Receiver 1 • Handshake Tone For Receiver 1 • Transmission Format For Receiver 1 • Subscriber ID Number For Receiver 1 •...

  • Page 138: Dialler Information

    Installation Manual Solution Ultima 844/862/880 Dialler Information This section outlines the programming information required for the Solution Ultima control panel when communicating with base station receivers. Typically these 844/862/880 parameters specify the telephone numbers to call, the transmission formats, handshake tones and transmission speeds.

  • Page 139: Primary Telephone Number For Receiver 1

    Dialler Information Primary Telephone Number For Receiver 1 0000000000000000 LOCATION 000 - 015 When the control panel requires to send a report, the control panel will dial this number in an attempt to contact the monitoring station or pager etc. If the call is successful, the relevant information will be sent and the dialler will return back to the stand-by mode.

  • Page 140: Handshake Tone For Receiver 1

    Installation Manual Solution Ultima 844/862/880 Handshake Tone For Receiver 1 LOCATION 032 This location sets the type of handshake tone required for Receiver 1 before data transmissions to the monitoring station will begin. 1. HI LO Handshake Tone is required when the control panel requires to communicate in Contact ID Format or High Speed DTMF.

  • Page 141: Transmission Format For Receiver 1

    Dialler Information Transmission Format For Receiver 1 LOCATION 033 Enter the desired transmission format here. This location selects the data format that will be sent to the base station receiver. This location also allows you to configure the control panel for domestic or basic pager formats.

  • Page 142: Primary Telephone Number For Receiver 2

    Installation Manual Solution Ultima 844/862/880 Primary Telephone Number For Receiver 2 0000000000000000 LOCATION 040 - 055 When the control panel requires to send a report, the control panel will dial this number in an attempt to contact the monitoring station or pager etc. If the call is successful, the relevant information will be sent and the dialler will return back to the stand-by mode.

  • Page 143: Handshake Tone For Receiver 2

    Dialler Information Handshake Tone For Receiver 2 LOCATION 072 This location programs the type of handshake tone required for Receiver 2 before data transmissions to the monitoring station will begin. 1. HI LO Handshake Tone is required when the control panel requires to communicate in Contact ID Format or High Speed DTMF.

  • Page 144: Transmission Format For Receiver 2

    Installation Manual Solution Ultima 844/862/880 Transmission Format For Receiver 2 LOCATION 073 Enter the desired transmission format here. This location selects the data format that will be sent to the base station receiver. This location also allows you to configure the control panel for domestic or basic pager formats.

  • Page 145: Dialling Format

    Telecommunications Network. The International DTMF dialling option should only be used in those countries that allow both the caller and the receiver to terminate the phone call. Using the incorrect format will disable EDM's patent Telephone Anti-Jamming feature. Option Dialling Format...

  • Page 146: Telco Arming Sequence

    Installation Manual Solution Ultima 844/862/880 Telco Arming Sequence LOCATION 113 – 142 000000000000000000000000000000 These locations allow you to automatically activate call diversion on your telephone when you arm the system in AWAY Mode. Upon activating the Telco Arming Sequence when arming the system in AWAY Mode, the control panel will redirect all calls to your mobile phone, pocket pager or answering service.

  • Page 147: Telco Disarming Sequence

    Dialler Information Telco Disarming Sequence 0000000000000000 LOCATION 143 – 158 These locations allow you to automatically deactivate call diversion on your telephone when you disarm the system from AWAY Mode. Digit Required Number To Program Digit Required Number To Program Terminator Four Second Pause Break...

  • Page 148: Ring Count

    Installation Manual Solution Ultima 844/862/880 Ring Count LOCATION 175 This location sets the number of rings before the control panel will answer an incoming call. This should be set at an acceptable level bearing in mind that one ring = "Ring, Ring - Ring, Ring" and that a ring count of 10 represents approximately 60 seconds.

  • Page 149: Telephone Line Fault Options

    Dialler Information Telephone Line Fault Options LOCATION 176 When programming this location, you will notice that there are four options per location. If you require options 1, 2, 4 or all of these options, only one number needs to be programmed. This number is calculated by adding the option bit numbers together.

  • Page 150: Ring Burst Time

    Installation Manual Solution Ultima 844/862/880 Ring Burst Time LOCATION 748 - 749 Location Description Increments Of 5 ms Increments Of 80 ms Table 69: Ring Burst Time Locations (V1.07+) These locations program the ring burst time (Default = 500 ms). If the duration of the telephone ring tone is 1.5 seconds, programming the ring burst time more than the...

  • Page 151: Dialler Options

    Dialler Options This section includes the following; • Dialler Options 1 • Dialler Options 2 • Dialler Options 3 • Alarm Link Options...

  • Page 152: Programming Option Bits

    Installation Manual Solution Ultima 844/862/880 Programming Option Bits When programming these locations, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed.

  • Page 153: Dialler Options 1

    Dialler Options Dialler Options 1 LOCATION 177 Option Description Dialler Reporting Functions Allowed Remote Arming Via The Telephone Allowed Answering Machine Bypass Only When Armed Use Bell 103 For FSK Format (Disabled = CCITT V21) Table 71: Dialler Options 1 Dialler Reporting Functions Allowed If this option has been selected, the dialler will function for all operations.

  • Page 154: Dialler Options 2

    Installation Manual Solution Ultima 844/862/880 Dialler Options 2 LOCATION 178 Option Description Open/Close Reports Only If Previous Alarm Open/Close Reports For STAY Mode 1 and STAY Mode 2 Delay Siren Until Transmission Complete Extend Time To Wait For Handshake From 30 To 55 Seconds...

  • Page 155: Dialler Options 3

    Dialler Options Dialler Options 3 LOCATION 179 (Default For Software Version 1.00 - 1.03 = 0) Option Description Set DTMF Dialling Pulses To 1 Digit/Second Lockout Telephone Line Fail Alarm (New - Software Version 1.03) Change Decadic Dialling To 60/40 Reserved Table 73: Dialler Options 3 Set DTMF Dialling Pulses To 1 Digit/Second...

  • Page 156: Alarm Link Options

    Installation Manual Solution Ultima 844/862/880 Alarm Link Options LOCATION 180 Option Description Upload/Download Allowed Call Back Phone Number Required For Upload/Download Exit Upload/Download Connection On Alarm External Modem Module (CC811) Required For Upload/Download Table 74: Alarm Link Options Upload/Download Allowed This option will need to be selected if you require to use the Alarm Link Software (CC816) to remotely program the control panel.

  • Page 157: User Codes

    User Codes This section includes the following; • Installer Code • User Codes • User Code Priority...

  • Page 158: Access Codes

    Installation Manual Solution Ultima 844/862/880 Access Codes This section describes the access codes that are used to assign privileges and access functions for user code holders of the system. Two types of user codes exist within the system, the Installer Code and User Codes.

  • Page 159: User Codes

    User Codes User Codes LOCATION 185 - 264 The purpose of user codes is to arm and disarm the system as well as perform other specific functions as described in Master Code Functions on page 76. User codes (1–8) can be any length between one to four digits long. Each user code may have a different priority level or multiple user codes may have the same priority level.

  • Page 160: Solution Ultima 844/862 User Codes

    Installation Manual Solution Ultima 844/862/880 Solution Ultima 844/862 User Codes has the ability to have up to eight programmable user codes Solution Ultima 844/862 (User Codes 1 – 8) to operate the system. Refer to System Operations on page 40 for information on the different methods of arming and disarming the system.

  • Page 161: User Code Priority

    User Codes User Code Priority There are ten different priority levels that can be allocated to the user code. Each priority level allows or restricts the functions that different user code holders may perform and can only be changed by the installer.

  • Page 162: Arm And Disarm + Code To Isolate

    Installation Manual Solution Ultima 844/862/880 Arm and Disarm + Code To Isolate This priority level allows the user code holder to arm and disarm the system. No opening or closing reports will be sent when this user code has been used to arm or disarm the system. However, a user code with this priority level will only send a closing report after a previous code that has the ability to send an opening report has disarmed the system.

  • Page 163: Zone Information

    Connections Of Split EOL Resistors Using N/C Contacts • Connections Of Split EOL Resistors Using N/O Contacts • Zone Programming • Solution Ultima 844 Zones Defaults • Solution Ultima 862 Zones Defaults • Solution Ultima 880 Zones Defaults • Zone Types •...

  • Page 164: Day Alarm Zones

    Installation Manual Solution Ultima 844/862/880 Day Alarm Zones LOCATION 265 When programming this location, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed.

  • Page 165: Day Alarm Operation

    Zone Information Day Alarm Operation If a zone has been programmed for day alarm, the zone can be isolated in the normal way so that it does not register as a day alarm zone during the disarmed state. Only zones 1 – 4 can be used as day alarm zones.

  • Page 166: Eol Resistor Value

    Installation Manual Solution Ultima 844/862/880 EOL Resistor Value LOCATION 266 Option Resistor Value Option Resistor Value No EOL Resistor 6K8 (Blue, Grey, Black, Brown) 1% 1K (Brown, Black, Red) 10K (Brown, Black, Orange) 1K5 (Brown, Green, Red) 12K (Brown, Red, Orange)

  • Page 167: Connections Of Split Eol Resistors Using N/C Contacts

    Zone Information Connections Of Split EOL Resistors Using N/C Contacts Figure 6: Connections Of Split EOL Resistors For 8 Zones Connections Of Split EOL Resistors With Tamper Circuit Figure 7: Connections Of Split EOL With Tamper Circuit Electronics Design and Manufacturing Pty Limited ISSUE162.DOC...

  • Page 168: Connections Of Split Eol Resistors Using N/O Contacts

    Installation Manual Solution Ultima 844/862/880 Connections Of Split EOL Resistors Using N/O Contacts Figure 8: Connections Of Split EOL Resistors Using One N/O Contact Figure 9: Connections Of Split EOL Using Two N/O Contacts ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 169: Zone Programming

    Zone Information Zone Programming Each zone contains seven locations that are divided into three groups. The first 3 locations determine how the zone will operate, the next two locations allow various options for each zone and the last two locations contain the dialler reporting information of each zone. Zone Operating Information Zone Type This location programs the "Zone Type"...

  • Page 170: Solution Ultima 844 Zones Defaults

    Installation Manual Solution Ultima 844/862/880 Solution Ultima 844 Zones Defaults LOCATION 267 - 322 Zone 1 Zone 2 Location 267 - 273 Location 274 - 280 2 0 0 1 14 1 1 1 0 0 1 14 1 1...

  • Page 171: Zone Types

    Zone Information Zone Types There are thirteen different zone types to choose from. Refer to the table below for the different zone types available. Zone Type Description Zone Type Description Instant 24 Hour Hold-Up Handover 24 Hour Tamper Delay-1 Reserved Delay-2 Keyswitch Reserved...

  • Page 172: Reserved

    Installation Manual Solution Ultima 844/862/880 Reserved 24 Hour Medical A 24-Hour Medical zone (Contact ID Event Code 100) is always ready to trigger the dialler, horn speaker, bell and strobe regardless of whether the system is in the armed or disarmed state. A medical report will be sent to the base station receiver.

  • Page 173: Chime Zone

    Zone Information Chime Zone 14 A Chime zone is not a burglary zone. It can never sound the sirens or trigger the dialler. Its purpose is to map it to a programmable output for an indication of sealed or unsealed state. Refer to Output Event Type - Global Chime on page 208.

  • Page 174: Zone Pulse Count Time

    Installation Manual Solution Ultima 844/862/880 Zone Pulse Count Time Zone pulse count time is the time frame or period over which the programmed number of pulses must register before an alarm condition is generated. 20 ms Loop Response Time 150 ms Loop Response Time...

  • Page 175: Zone Options 1

    Restore signals will be sent when the system has been disarmed. control panel performs lockout different to most other Solution Ultima 844/862/880 control panels in that only the first zone to trigger an alarm condition will be locked out. All other zones that are triggered during the same siren run time will reset when the sirens reset.

  • Page 176: Silent Alarm

    Installation Manual Solution Ultima 844/862/880 Silent Alarm A zone programmed to be silent will not activate the horn speaker, bell strobe or EDMSAT outputs. The dialler and all other programmable outputs will function as per their particular programming. Sensor Watch Sensor watch gives the control panel the ability to recognise that detection devices may have stopped working.

  • Page 177: Keyswitch Zone Options

    Zone Information Keyswitch Zone Options When you select a zone to be a keyswitch input, then the following table relates to the options available to that keyswitch zone. These keyswitch zone options replace Zone Options 1 only for the zones that have been programmed to operate as a keyswitch zone. Keyswitch zones will report as user code 16.

  • Page 178: Momentary Arm And Disarm In Away Mode

    Installation Manual Solution Ultima 844/862/880 Momentary Arm and Disarm In AWAY Mode If this option has been selected, the system will either arm or disarm from AWAY Mode when using the momentary keyswitch input. Momentary Arm In AWAY Mode If this option has been selected, the system will arm in AWAY Mode when using the momentary keyswitch input.

  • Page 179: Zone Options 2

    Zone Information Zone Options 2 When programming this location, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed. This number is calculated by adding the option bit numbers together. Program a seven (7) if you require options 1, 2 and 4 simultaneously (i.e..

  • Page 180: Zone Reporting Information

    Installation Manual Solution Ultima 844/862/880 Zone Reporting Information Zone Report Code If you wish the control panel to send zone alarm reports, this location should be programmed as 1. If you do not wish to send zone alarm reports, this location should be programmed as a 0.

  • Page 181: Swinger Shutdown Count For Siren

    Zone Information Swinger Shutdown Count For Siren LOCATION 323 Location Description Swinger Shutdown Count For Siren (0 - 15) Table 86: Swinger Shutdown Count For Siren Location This location determines the number of times the sirens can be triggered before any lockout options will take effect.

  • Page 182: Swinger Shutdown Count For Dialler

    Installation Manual Solution Ultima 844/862/880 Swinger Shutdown Count For Dialler LOCATION 324 Location Description Swinger Shutdown Count For Dialler (0-15) Table 87: Swinger Shutdown Count For Dialler Location This location determines the number of times the dialler can be triggered before any lockout options will take effect.

  • Page 183: System Reporting Information

    System Reporting Information...

  • Page 184: Reporting Information

    Installation Manual Solution Ultima 844/862/880 Reporting Information This section covers features that are involved with the basic house keeping of the system. This includes monitoring of the zones - whether they are isolated from the system or more importantly that they are actually operating, the status of both the AC mains and DC power to the system and codepad generated alarms activated by the user.

  • Page 185: Zone Status - Bypass Reports

    System Reporting Information Zone Status – Bypass Reports LOCATION 329 - 330 Location Description Zone Bypass Report Zone Bypass Restore Report Table 90: Zone Status - Bypass Report Locations A zone is bypassed when it is manually isolated. Refer to Isolating Zones on page 48 for information on isolating zones.

  • Page 186: Zone Status - Sensor Watch Reports

    Installation Manual Solution Ultima 844/862/880 Zone Status – Sensor Watch Reports LOCATION 333 - 334 Location Description Sensor Watch Report Sensor Watch Restore Report Table 92: Zone Status – Sensor Watch Report Locations A "Self Test Failure" report (Contact ID Event Code 307) will be sent to the base station receiver when a zone has not been triggered during the Sensor Watch Time programmed in "LOCATION 420...

  • Page 187: Rf Supervision Time

    System Reporting Information RF Supervision Time LOCATION 337 Location Description Increments Of 6 Hours (0 – 90 Hours) Table 94: Zone Status – RF Supervision Time Location A "RF Supervision Failure" report (Contact ID Event Code 307) will be sent to the base station receiver when the wireless receiver has not received a signal from any RF wireless zone during the RF Supervision Time.

  • Page 188: Rf Receiver Trouble Report

    Installation Manual Solution Ultima 844/862/880 RF Receiver Trouble Report LOCATION 340 - 341 Location Description RF Receiver Trouble Report (Tens Digit) RF Receiver Trouble Report (Units Digit) Table 96: RF Receiver Trouble Report Locations A “RF Receiver Trouble” report (Contact ID Event Code 355) will be sent to the base station receiver...

  • Page 189: Open/Close Reports

    System Reporting Information Open/Close Reports LOCATION 345 - 346 Location Description Opening Report Closing Report Table 99: Open/Close Reporting Locations An "Opening" report (Contact ID Event Code 401) will be sent to the base station receiver when the system has been disarmed from AWAY Mode. A "Closing" report (Contact ID Event Code 401) is sent at the end of exit time when the system has been armed in AWAY Mode.

  • Page 190: Codepad Duress Report

    Installation Manual Solution Ultima 844/862/880 Codepad Duress Report LOCATION 348 Location Description Codepad Duress Report Table 101: Codepad Duress Report Location A "Duress" report (Contact ID Event Code 121) will be sent to the base station receiver when the button is added to the end of any valid user code being used to disarm the system. This alarm will always be silent.

  • Page 191: Codepad Fire Report

    System Reporting Information Codepad Fire Report LOCATION 351 - 352 Location Description Codepad Fire Reporting Code (Tens Digit) Codepad Fire Reporting Code (Units Digit) Table 103: Codepad Fire Report Locations A "Fire Alarm" report (Contact ID Event Code 110) will be sent to the base station receiver when the buttons are pressed simultaneously.

  • Page 192: Codepad Reporting Options

    Installation Manual Solution Ultima 844/862/880 Codepad Reporting Options LOCATION 355 Option Description No Report Required Receiver 1 Receiver 2 Receiver 1 and Receiver 2 Receiver 2 Only When Receiver 1 Fails Table 105: Codepad Reporting Options Location This location is factory default to report only to Receiver 1. You can select whether the codepad reporting options will report on Receiver 1, Receiver 2, both Receiver 1 and Receiver 2, Receiver 2 only when Receiver 1 fails or no reporting at all.

  • Page 193: System Status - Ac Fail Report

    System Reporting Information System Status – AC Fail Report LOCATION 360 - 361 Location Description System Status – AC Fail Reporting Code (Tens Digit) System Status – AC Fail Reporting Code (Units Digit) Table 108: System Status – AC Fail Report Locations An "AC Loss"...

  • Page 194: System Status - Low Battery Report

    Installation Manual Solution Ultima 844/862/880 System Status - Low Battery Report LOCATION 364 - 365 Location Description System Status – Low Battery Reporting Code (Tens Digit) System Status – Low Battery Reporting Code (Units Digit) Table 110: System Status – Low Battery Report Locations A "Battery Test Failure"...

  • Page 195: System Status - Access Denied

    System Reporting Information System Status - Access Denied LOCATION 368 - 370 Location Description Code Retries (0 – 15) System Status – Access Denied Reporting Code (Tens Digit) System Status – Access Denied Reporting Code (Units Digit) Table 112: System Status – Access Denied Locations An "Access Denied"...

  • Page 196: System Status Reporting Options

    Installation Manual Solution Ultima 844/862/880 System Status Reporting Options LOCATION 371 Option Description No Report Required Receiver 1 Receiver 2 Receiver 1 and Receiver 2 Receiver 2 Only When Receiver 1 Fails Table 113: System Status Reporting Options Location This location is factory default to report only to Receiver 1. You can select whether the system status reporting options will report on Receiver 1, Receiver 2, both Receiver 1 and Receiver 2, Receiver 2 only when Receiver 1 fails or no reporting at all.

  • Page 197: Test Reporting Time

    System Reporting Information Test Reporting Time 0000 71 0 LOCATION 372 - 378 Location Description Actual Hour Of The Day (Tens Digit) Actual Hour Of The Day (Units Digit) Actual Minute Of The Day (Tens Digit) Actual Minute Of The Day (Units Digit) Test Report Code (Tens Digit) Test Report Code (Units Digit) Repeat Interval In Days...
  • Page 198 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 199: Programmable Outputs

    Programmable Outputs This section includes the following; • Outputs • Output Defaults • Redirecting Outputs To The Codepad Buzzer • Output Event Types • Output Polarity • Timing Of Outputs • Pulsing Polarities • One Shot Polarities...

  • Page 200: Outputs

    Installation Manual Solution Ultima 844/862/880 Outputs control panel has four fully programmable outputs on the Solution Ultima 844/862/880 main PCB and one other programmable output that operates the codepad buzzer. These four outputs are factory default to operate a horn speaker, fire alarm verification, strobe and an internal screamer.

  • Page 201: Redirecting Outputs To The Codepad Buzzer

    Programmable Outputs Redirecting Outputs To The Codepad Buzzer Multiple output event types can be directed to the codepad buzzer so that it may be used to indicate any number of events. This is achieved by selecting an output and programming it for the required output event type. When you are satisfied that the output is functioning correctly, change the first digit of the output event type (i.e..

  • Page 202: Output Event Types

    Installation Manual Solution Ultima 844/862/880 Output Event Types There are approximately seventy-five different output event types to choose from. Two numbers designate each output event type. These two numbers need to be programmed into the appropriate locations of the output being used to indicate when the output should operate.
  • Page 203 Programmable Outputs Exit Warning This output operates during exit time when the system has been armed in AWAY Mode, STAY Mode 1 or STAY Mode 2. The output will reset once exit time has expired. Exit Warning Finished This output operates when the exit time has expired when the system has been armed in AWAY Mode, STAY Mode 1 or STAY Mode 2.
  • Page 204 Installation Manual Solution Ultima 844/862/880 Day Alarm Latching This output will operate when a zone programmed for day alarm has been triggered. The output will reset when the button has been pressed. Day alarm may be turned on and off by holding down the button.
  • Page 205 Programmable Outputs Sensor Watch Alarm This output will operate when the sensor watch count has been reached. Refer to Zone Options 1 on page 175 for more information on programming zones for sensor watch. Refer to "LOCATION 420 - 421" on page 218 for setting how many days before a zone can register as a faulty sensor watch zone.
  • Page 206 Installation Manual Solution Ultima 844/862/880 Sirens Running This output will operate for the duration of the siren run time programmed in "LOCATION 423" on page 219. When the sirens have been activated, this output will reset once the siren run time has expired. The relay output (Output 4) is factory default for this operation.
  • Page 207 Programmable Outputs Fire Alarm Verification This feature is used on some commercial fire control panels to reduce false alarms on smoke detectors. It is conceptually very similar to zone pulse count as used in some motion detectors. Basically, a fire zone is allotted a pulse count of 3 pulses over a period of 3 minutes.
  • Page 208 Installation Manual Solution Ultima 844/862/880 Radio Control Output 2 – Not In AWAY Mode This output will operate when you hold down button 4 on the 4-channel hand held Transmitter only when the system is disarmed or armed in STAY Mode 1 or STAY Mode 2.
  • Page 209 Programmable Outputs Zone Not Sealed After Exit Time This output will operate at the end of exit time if a burglary zone is unsealed. The output will reset when all zones are sealed or the system has been disarmed. Chime zones will not operate this output event type.
  • Page 210 Installation Manual Solution Ultima 844/862/880 Area 1 Codepad Data Terminal This output type is used to connect the data terminal of the Area 1 codepad when you are using the Master Partitioned codepad as the main codepad. Set DIP switch 1 in the ON position for the Area 1 codepad to operate correctly.

  • Page 211: Output Polarity

    Programmable Outputs Output Polarity There are fifteen different polarities to choose from. Each polarity is designated by a number. This number needs to be programmed into the appropriate location of the output being used to indicate how the output should operate. Option Polarity Option...

  • Page 212: Normally Open, One Shot Low With Alarm

    Installation Manual Solution Ultima 844/862/880 Normally Open, One Shot Low With Alarm This one shot polarity is normally open circuit and will switch to zero volts when the event occurs. The output will switch back to open circuit once the one shot time has expired, when the event has returned to normal or when the system has been disarmed.

  • Page 213: Timing Of Outputs

    Programmable Outputs Timing Of Outputs The timing of outputs is calculated by the time base and a multiplier. These two values play different roles depending on the polarity selected. When programming outputs to pulse, both the "On" and "Off" times can be set. One shot polarities can be programmed to operate between 200 ms up to 99 hours in duration.

  • Page 214: One Shot Polarities

    Installation Manual Solution Ultima 844/862/880 One Shot Polarities The duration or "On" time of an output is determined by the product of the time base and the multiplier. If an output is required to operate for five seconds, program the time settings as follows;...

  • Page 215: System Event Timers

    System Event Timers This section includes the following; • Entry Timer 1 • Entry Timer 2 • Exit Time • Entry Guard Timer For STAY Mode • Delay Alarm Reporting Time • Sensor Watch Time • Codepad Lockout Time • Siren Run Time •...

  • Page 216: System Event Timers

    Installation Manual Solution Ultima 844/862/880 System Event Timers This section covers the features that involve timing. Features such as entry and exit times, sensor watch time, siren run time and system date and time along with a host of other timers are discussed extensively in this section.

  • Page 217: Exit Time

    System Event Timers Exit Time LOCATION 414 – 415 (Defaulted To 60 Seconds) Location Description Increments Of 1 Second (0 - 15 Sec’s) Increments Of 16 Seconds (0 –240 Sec’s) Table 123: Exit Time Locations Exit time can be programmed between 0 and 255 seconds in increments of one second. When arming the system in AWAY Mode, the remote codepad will beep during exit time until the remaining 10 seconds where the codepad will give you one continuous beep to inform you that the end of exit time is approaching.

  • Page 218: Sensor Watch Time

    Installation Manual Solution Ultima 844/862/880 Sensor Watch Time LOCATION 420 - 421 Location Description Increments Of Days (Tens Digit) Increments Of Days (Units Digit) Table 126: Sensor Watch Time Locations The time set in these two locations determine how many days (0-99) a zone may remain sealed before registering as a fault.

  • Page 219: Siren Run Time

    System Event Timers Siren Run Time LOCATION 423 (Defaulted To 5 Minutes) Location Description Increments Of 1 Minute (0 – 15) Table 128: Siren Run Time Location The siren run time determines how long the horn speaker will activate during an alarm condition. The siren run time can be programmed between 0 - 15 minutes (+/- 1 minute).

  • Page 220: Auto Arming Pre-Alert Timer

    Installation Manual Solution Ultima 844/862/880 Auto Arming Pre-Alert Timer LOCATION 425 Location Description Increments Of 5 Minutes (0 – 75 Minutes) Table 130: Auto Arming Pre-Alert Timer Location This location sets the time period that will warn you before the control panel will automatically arm in AWAY Mode.

  • Page 221: Auto Disarming Time

    System Event Timers Auto Disarming Time 0000 LOCATION 430 - 433 Location Description Actual Hour Of The Day (Tens Digit) Actual Hour Of The Day (Units Digit) Actual Minute Of The Day (Tens Digit) Actual Minute Of The Day (Units Digit) Table 132: Auto Disarming Time Locations These locations are used to program the actual time of the day that the system will automatically disarm itself from AWAY Mode, STAY Mode 1 or STAY Mode 2.

  • Page 222: System Time

    Installation Manual Solution Ultima 844/862/880 System Time 0000 LOCATION 901 – 904 Location Description Current Hour In 24 Hour Time (Tens Digit) Current Hour In 24 Hour Time (Units Digit) Current Minute (Tens Digit) Current Minute (Units Digit) Table 135: System Time Locations...

  • Page 223: System Date

    Table 136: System Date Locations control panel has a real time 12 month calendar that needs Solution Ultima 844/862/880 to be set during installation. This time must be set using the format DDMMYY (i.e.. If the date that is required to be set is the 1 July 1997, you would then program 010797). Every time the system has been powered down, the system date will need to be reset.
  • Page 224 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 225: System And Consumer Options

    System and Consumer Options This section includes the following; • System Options 1 • System Options 2 • System Options 3 • System Options 4 • Consumer Options 1 • Consumer Options 2 • Consumer Options 3 • Radio Input Options...

  • Page 226: Programming Option Bits

    Installation Manual Solution Ultima 844/862/880 Programming Option Bits When programming these locations, you will notice that there are four options per location. You may select one, two, three or all four of these options, however, only one number needs to be programmed.

  • Page 227: System Options 1

    System and Consumer Options System Options 1 LOCATION 436 Option Description EDM Smart Lockout Allowed Horn Speaker Monitor Strobe Indications For Radio Arm/Disarm Assign Button 4 On Transmitter To Operate STAY Mode 1 Table 138: System Options 1 EDM Smart Lockout Allowed This feature allows the control panel to remove any zones that are programmed for lockout dialler from the lockout list while the sirens are running.

  • Page 228: System Options 2

    Installation Manual Solution Ultima 844/862/880 System Options 2 LOCATION 437 Option Description Codepad Panic To Be Silent Codepad Fire To Be Silent Codepad Medical To Be Silent Access Denied To Be Silent Table 140: System Options 2 Codepad Panic To Be Silent If this option has been selected, a codepad panic alarm or radio remote panic alarm will not operate the horn speaker, the bell or the strobe outputs.

  • Page 229: System Options 3

    System and Consumer Options System Options 3 LOCATION 438 Option Description AC Fail In 1 Hour (Disabled = After 2 Minutes) Ignore AC Fail Pulse Count Handover Allowed Handover Delay To Be Sequential Table 141: System Options 3 AC Fail In 1 Hour (Disabled = After 2 Minutes) If this option has been selected, the indicator will begin to flash as soon as the AC mains MAINS...

  • Page 230: System Options 4

    Installation Manual Solution Ultima 844/862/880 System Options 4 LOCATION 439 Option Description Panel To Power Up Disarmed (If Power Reset) Arm/Disarm Tracking On Power Up Internal Crystal To Keep Time Keyswitch Interface, Night Arm Station Or RE005 Installed Table 142: System Options 4...

  • Page 231: Consumer Options 1

    System and Consumer Options Consumer Options 1 LOCATION 440 Option Description Test Reports Only When Armed Test Report After Siren Reset Auto Arm In STAY Mode 1 STAY Indicator To Display Day Alarm Status Table 143: Consumer Options 1 Test Reports Only When Armed If this option has been selected, test reports (Contact ID Event Code 602) will only be sent when the system has been armed in AWAY Mode, STAY Mode 1 or STAY Mode 2.

  • Page 232: Consumer Options 2

    Installation Manual Solution Ultima 844/862/880 Consumer Options 2 LOCATION 441 Option Description Codepad Display Extinguish After 60 Seconds Single Button Arming Allowed (AWAY Mode, STAY Mode 1 & 2) Single Button Disarming Allowed (STAY Mode 1 & 2) Alarm Memory Reset On Disarm...

  • Page 233: Consumer Options 3

    System and Consumer Options Consumer Options 3 LOCATION 442 Option Description Codepad Fault Alarm Beeps Allowed Use Digit 3 For Codepad Duress Instead Of Digit 9 Alarms Activate Siren and Strobe Outputs In STAY Mode 1 & 2) Zone Tamper Alarms To Be Silent Table 145: Consumer Options 3 Codepad Fault Alarm Beeps Allowed If this option has been enabled, the codepad will flash the...

  • Page 234: Radio Input Options

    Installation Manual Solution Ultima 844/862/880 Radio Input Options LOCATION 443 Option Description DS304 MHz Receiver (RF3212) Latching Keyswitch Input Momentary Keyswitch Input Reserved Table 146: Radio Input Options DS304 MHz Receiver (RF3212) This option needs to be selected when using the optional 304 MHz RF Receiver (RF3212) for remote operations using radio remote hand held Transmitters.

  • Page 235: Partitioning

    Partitioning This section includes the following; • CP5 Master Partitioned LED Codepad • Operating Codepads In Partitioning • Programming • Partitioning Options 1 • Partitioning Options 2 • Zone Allocations • User Code Allocations • Setting Up and Programming Codepads For Partitioning •...

  • Page 236: Cp5 Master Partitioned Led Codepad

    Installation Manual Solution Ultima 844/862/880 control panel includes a feature called partitioning which can Solution Ultima effectively transform your single control panel and split the system into two separate areas. Normally arming and disarming the system would turn the entire system on or off. However, when the...

  • Page 237: Area On/Off Indicators

    Partitioning Area On/Off Indicators The group of four Area On/Off indicators (1 – 4) show the status of each area (i.e.. If an indicator is illuminated, that area is armed and if the indicator is not illuminated, that area is disarmed). If an area is armed in STAY Mode 1, the corresponding Area On/Off indicator will be illuminated in conjunction with the indicator.

  • Page 238: Aux Indicator

    Installation Manual Solution Ultima 844/862/880 AUX Indicator If Option 8 in “LOCATION 444” on page 241 has been enabled, the indicator will be used to display when the control panel is using the telephone line. The indicator will also flash in unison...

  • Page 239: Audible Indicators

    Partitioning Audible Indicators In general, the audible indications given out by the codepad are as follows: Indicator Definition A Button Has Been Pressed On The Codepad Or End Of Exit Time When Armed In Either STAY Mode 1 Or One Short Beep STAY Mode 2 Two Short Beeps The System Has Accepted Your Code...

  • Page 240: Operating Codepads In Partitioning

    Installation Manual Solution Ultima 844/862/880 Operating Codepads In Partitioning Operating From A CP5 Area Addressable LED Codepad When operating a CP5 Area Addressable (CP500A) codepad in a system that has been partitioned, the display and operations are exactly the same as the CP5 Eight Zone LED codepad except that the commands issued from the codepad only effects the area that the codepad is allocated to.

  • Page 241: Programming

    Partitioning Programming The following locations area only applicable when partitioning the control Solution Ultima 880 panel. Remember that when programming option bit locations, you may add the options together (e.g.: If you require both options 2 and 4, you would add the two options together and program a 6). Partitioning Options 1 LOCATION 444 Option...

  • Page 242: Reset Sirens From Any Area Allowed

    Installation Manual Solution Ultima 844/862/880 Reset Sirens From Any Area Allowed This option is only applicable when the control panel has been partitioned. If this option has been enabled, any valid user code from either Area 1 or Area 2 will be able to reset the horn speaker, strobe, bell or EDMSAT outputs from operating.

  • Page 243: Zone Allocations

    Partitioning Zone Allocations Each area can have up to eight zones allocated to it. The eight locations for each area represents indicators one to eight on the remote area addressable codepad. Any of the zone inputs 1 – 8 ZONE can be mapped to any area to appear as any zone on the remote area addressable codepad (i.e..
  • Page 244 Installation Manual Solution Ultima 844/862/880 Example In this example, zones 1, 2, 3 and 4 have been allocated to Area 1 to appear as zones 1, 2, 3 and 4. Zones 1, 5, 6, 7 & 8 have been allocated to Area 2 to appear as zones 1, 5, 6, 7 and 8. Programming the same zone into more than one area indicates that the zone will operate as a common zone.

  • Page 245: User Code Allocations

    Partitioning User Code Allocations “LOCATION 462 – 477” is used to assign each user code to an area or multiple areas when the control panel has been partitioned. A number 0 – 3 is required to be entered Solution Ultima 880 into each of these locations to assign each user code holder to the areas they are required to operate.

  • Page 246: Setting Up And Programming Codepads For Partitioning

    Installation Manual Solution Ultima 844/862/880 Setting Up and Programming Codepads For Partitioning Only the CP5 Area Addressable (CP500A) and CP5 Master Partitioned (CP500P) codepads can be used when partitioning a control panel. Solution Ultima 880 Setting Up The Master Partitioned Codepad As The Main Codepad.

  • Page 247: Codepad Connections For Partitioning - Examples

    Partitioning Codepad Connections For Partitioning - Examples If the CP-5 Area Addressable (CP500A) codepad is assigned to Area 1, DIP Switch 1 on the back of the remote codepad will need to be in the ON position. The following locations for Output 1 will need to be programmed.
  • Page 248 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 249: Rf Information

    RF Information This section includes the following; • RF Option Bit • RF Device Mapping (Devices 1 – 8) • RF Device Mapping (Devices 9 – 16) • RF Device Signal Strength (Devices 1 – 8 Read Only) • RF Device Signal Strength (Devices 9 – 16 Read Only)

  • Page 250: Rf Option Bit

    Installation Manual Solution Ultima 844/862/880 RF Option Bit LOCATION 527 Option Description Sound Siren On RF Receiver Fail Sound Siren On RF Receiver Tamper / Jamming Unseal Zone That Fails Supervision (If Supervision Enabled) Enable RF Jamming Monitoring Table 160: RF Option Bit...

  • Page 251: Rf Device Signal Strength (Devices 1 - 8 Read Only)

    RF Information RF Device Signal Strength (Devices 1 – 8 Read Only) 00000000 LOCATION 801 - 808 These locations allow you to view the signal strength received for each of the RF wireless devices 1 – 8 (e.g.: LOCATION 801 will display the signal strength of Device 1, LOCATION 802 will display the signal strength of Device 2 etc).
  • Page 252 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 253: Optional Equipment

    Optional Equipment This section includes the following; • 2 Channel/4 Channel Hand Held Transmitters 304 MHz (RE012/RE013) • 2 Channel Radio Interface (RE005) • EDMSAT - Satellite Siren (SS914) • Programming Key (CC891) • Alarm Link Software (CC816) • CP5 Eight Zone LED Codepad (CP508) •...

  • Page 254: Optional Equipment

    2 Channel Radio Interface (RE005) The EDM 2 channel radio interface has been designed to allow customers to remotely operate Solution control panels and control two on-board relays. The interface may also be used as a stand alone receiver, independent of a Solution control panel and used solely for remote control of external devices connected to the two on-board relays.
  • Page 255 Optional Equipment CP5 Eight Zone LED Codepad (CP508) This codepad is designed to operate with the range of control panels. This codepad Solution provides indications for up to 8 zones. This codepad cannot be used with the Solution Ultima control panel when partitioned. CP5 Eight Zone LCD Codepad (CP508L) This codepad is designed to operate with the range of control panels with a fixed icon...
  • Page 256 Solution Ultima 844/862/880 TF008 Plug Pack (TF008) The TF008 plug packs have been designed to be used with the EDM control panels and the PS100 Power Supply Module. The plug pack includes built in thermal fuses that under overload or fault conditions will blow and eliminate any possible fire threat due to excessive heat build up inside the casing.

  • Page 257: Terminals And Descriptions

    Terminals and Descriptions This section includes the following; • Terminal Definitions and Descriptions • Glossary Of Terms • Solution Ultima 844/862/880 Wiring Diagram • Solution Ultima 844/862/880 Component Overlay • Telecom Connection Diagrams...

  • Page 258: Terminal Definitions And Descriptions

    PCB for connecting the COM terminal to either GND or 12V. This link should be connected to +12V as shown in "Figure 19: Solution Ultima 844/862/880 Wiring Diagram" on page 262. The relay is rated at 1 Amp/30 VDC.

  • Page 259: Glossary Of Terms

    Terminals and Descriptions Glossary Of Terms Term Description Alarm Condition Is when your alarm system is armed and one of the detection devices are violated. A 24 hour zone (e.g.. Smoke detector) may trigger when your system is armed or disarmed. Answering Machine Answering machine bypass has been incorporated so that it is possible to make a connection with Bypass...
  • Page 260 Installation Manual Solution Ultima 844/862/880 Term Description Exit Time or Is the amount of time you have to leave your premises after you have armed your system. Exit Delay External Equipment Is any device connected to your system such as detectors, codepads and sirens.
  • Page 261 Terminals and Descriptions Term Description STAY Mode 1 Is a condition that automatically isolates certain zones when your system is armed in STAY Mode 1. These zones can only be programmed by your installer. STAY Mode 2 Is a condition that automatically isolates certain zones when your system is armed in STAY Mode 2.

  • Page 262: Solution Ultima 844/862/880 Wiring Diagram

    Installation Manual Solution Ultima 844/862/880 Solution Ultima 844/862/880 Wiring Diagram Figure 19: Solution Ultima 844/862/880 Wiring Diagram ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 263: Solution Ultima 844/862/880 Component Overlay

    Terminals and Descriptions Solution Ultima 844/862/880 Component Overlay Figure 20: Solution Ultima 844/862/880 Component Overlay Electronics Design and Manufacturing Pty Limited ISSUE162.DOC...

  • Page 264: Rf3212 Radio Receiver Wiring Diagram

    Installation Manual Solution Ultima 844/862/880 RF3212 Radio Receiver Wiring Diagram Figure 21: RF Receiver (RF3212) Wiring Diagram Wiring and Power Up Operation - Remove power from the control panel. The following describes the status of the module based on the LED condition.

  • Page 265: Telecom Connection Diagrams

    Terminals and Descriptions Telecom Connection Diagrams Figure 22: Telecom Connection Diagrams For Solution Ultima 844/862/880 Electronics Design and Manufacturing Pty Limited ISSUE162.DOC...
  • Page 266 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 267: Appendices

    Appendices This section includes the following; • Telephone Anti-Jamming • Test Reports Only When Armed...

  • Page 268: Telephone Anti-Jamming

    Installation Manual Solution Ultima 844/862/880 Appendix A Telephone Anti-Jamming There are many companies today importing American designed products that claim to have Anti-Jamming and believe it or not, they push this feature as if it were a major break through in control panel technology.

  • Page 269: Test Reports Only When Armed

    Test Reports Only When Armed control panel allows for test reports to be sent to Solution Ultima 844/862/880 the base station receiver to verify that the dialler functional. So what you might say, as most alarm diallers allow you to do this.
  • Page 270 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 271: Specifications

    Specifications This section includes the following; • Warranty Statement • Specifications • Software Version Number • Advice To Users • New Zealand Telepermit Notes...

  • Page 272: Warranty Statement

    Installation Manual Solution Ultima 844/862/880 Warranty Statement Electronics Design and Manufacturing Pty Limited warrants this product to be free from defects in material and workmanship for a period of three years from the date of manufacture as indicated by the date stamp and /or the serial number on the product.

  • Page 273: Specifications

    N771 New Zealand Telepermit: PTC 211/98/083 – Solution Ultima 880 PTC 211/98/084 – Solution Ultima 862 PTC 211/98/085 – Solution Ultima 844 Software Version Number 1.00 LOCATION 999 When using the Hand Held Programmer (CC814), you have the ability to display the software version number of the control panel.

  • Page 274: New Zealand Telepermit Notes

    Installation Manual Solution Ultima 844/862/880 New Zealand Telepermit Notes • The grant of a telepermit for a device in no way indicates Telecom acceptance of responsibility for the correct operation of that device under all operating conditions. • This equipment shall not be used in any manner that could constitute a nuisance to other Telecom customers.

  • Page 275: Solution Ultima 844 Programming Sheets

    Solution Ultima 844 Programming Sheets...
  • Page 276 Installation Manual Solution Ultima 844/862/880 Location 000 – 015 Page 139 Primary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0 Location 016 – 031 Page 139 Secondary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0...
  • Page 277 Programming Sheets Solution Ultima 844 Location 177 Page 153 Dialler Options 1 1 = Dialler Reporting Functions Allowed 2 = Remote Arming Via The Telephone Allowed 4 = Answering Machine Bypass Only When Armed 8 = Use Bell 103 For FSK Format (Disabled – CCITT V21)
  • Page 278 Installation Manual Solution Ultima 844/862/880 Location 265 Page 164 Day Alarm Zones 1 = Zone 1 4 = Zone 3 2 = Zone 2 8 = Zone 4 Location 266 Page 166 EOL Resistor Value 0 = No End Of Line Resistor...
  • Page 279 Programming Sheets Solution Ultima 844 Zone Pulse Count Settings The pulse count settings for each zone can be programmed between 0 - 15. Zone Pulse Count Time Zone pulse count time is the time frame or period over which the number of pulses must register.
  • Page 280 Installation Manual Solution Ultima 844/862/880 Location 323 Page 181 Swinger Shutdown Count For Siren Location 324 Page 182 Swinger Shutdown Count For Dialler Location 325 – 326 Page 184 Zone Status - Zone Tamper Report Location 325 Zone Tamper Report...
  • Page 281 Programming Sheets Solution Ultima 844 Location 353 – 354 Page 191 Codepad Medical Report 7 13 Location 355 Page 192 Codepad Reporting Options 0 = No Report Required 1 = Receiver 1 2 = Receiver 2 4 = Receiver 1 + 2 8 = Receiver 2 Only When Receiver 1 Fails Location 356 –...
  • Page 282 0 = No Beeps / 15 = Loudest Beeps Location 436 Page 227 System Options 1 1 = EDM Smart Lockout Allowed 2 = Horn Speaker Monitor 4 = Strobe Indications For Radio Arm/Disarm 8 = Assign Button 4 On Transmitter To Operate STAY Mode 1...
  • Page 283 Programming Sheets Solution Ultima 844 Location 440 Page 231 Consumer Options 1 1 = Test Reports Only When Armed 2 = Test Report After Siren Reset 4 = Auto Arm In STAY Mode 1 8 = STAY Indicator To Display Day Alarm Status...
  • Page 284 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 285: Solution Ultima 862 Programming Sheets

    Solution Ultima 862 Programming Sheets...
  • Page 286 Installation Manual Solution Ultima 844/862/880 Location 000 – 015 Page 139 Primary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0 Location 016 – 031 Page 139 Secondary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0...
  • Page 287 Programming Sheets Solution Ultima 862 Location 177 Page 153 Dialler Options 1 1 = Dialler Reporting Functions Allowed 2 = Remote Arming Via The Telephone Allowed 4 = Answering Machine Bypass Only When Armed 8 = Use Bell 103 For FSK Format (Disabled – CCITT V21) Location 178 Page 154 Dialler Options 2...
  • Page 288 Installation Manual Solution Ultima 844/862/880 Location 265 Page 164 Day Alarm Zones 1 = Zone 1 4 = Zone 3 2 = Zone 2 8 = Zone 4 Location 266 Page 166 EOL Resistor Value 0 = No End Of Line Resistor...
  • Page 289 Programming Sheets Solution Ultima 862 Zone Pulse Count Settings The pulse count settings for each zone can be programmed between 0 - 15. Zone Pulse Count Time Zone pulse count time is the time frame or period over which the number of pulses must register. 20 ms Loop Response Time 150 ms Loop Response Time Zone Pulse Count Time...
  • Page 290 Installation Manual Solution Ultima 844/862/880 Location 323 Page 181 Swinger Shutdown Count For Siren Location 324 Page 182 Swinger Shutdown Count For Dialler Location 325 – 326 Page 184 Zone Status - Zone Tamper Report Location 325 Zone Tamper Report...
  • Page 291 Programming Sheets Solution Ultima 862 Location 353 – 354 Page 191 Codepad Medical Report 7 13 Location 355 Page 192 Codepad Reporting Options 0 = No Report Required 1 = Receiver 1 2 = Receiver 2 4 = Receiver 1 + 2 8 = Receiver 2 Only When Receiver 1 Fails Location 356 –...
  • Page 292 0 = No Beeps / 15 = Loudest Beeps Location 436 Page 227 System Options 1 1 = EDM Smart Lockout Allowed 2 = Horn Speaker Monitor 4 = Strobe Indications For Radio Arm/Disarm 8 = Assign Button 4 On Transmitter To Operate STAY Mode 1...
  • Page 293 Programming Sheets Solution Ultima 862 Location 440 Page 231 Consumer Options 1 1 = Test Reports Only When Armed 2 = Test Report After Siren Reset 4 = Auto Arm In STAY Mode 1 8 = STAY Indicator To Display Day Alarm Status Location 441 Page 232 Consumer Options 2...
  • Page 294 Installation Manual Solution Ultima 844/862/880 ISSUE162.DOC Electronics Design and Manufacturing Pty Limited...

  • Page 295: Solution Ultima 880 Programming Sheets

    Solution Ultima 880 Programming Sheets...
  • Page 296 Installation Manual Solution Ultima 844/862/880 Location 000 – 015 Page 139 Primary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0 Location 016 – 031 Page 139 Secondary Telephone Number For Receiver 1 0 0 0 0 0 0 0 0 0...
  • Page 297 Programming Sheets Solution Ultima 880 Location 177 Page 153 Dialler Options 1 1 = Dialler Reporting Functions Allowed 2 = Remote Arming Via The Telephone Allowed 4 = Answering Machine Bypass Only When Armed 8 = Use Bell 103 For FSK Format (Disabled – CCITT V21) Location 178 Page 154 Dialler Options 2...
  • Page 298 Installation Manual Solution Ultima 844/862/880 Location 265 Page 164 Day Alarm Zones 1 = Zone 1 4 = Zone 3 2 = Zone 2 8 = Zone 4 Location 266 Page 166 EOL Resistor Value 0 = No End Of Line Resistor...
  • Page 299 Programming Sheets Solution Ultima 880 Zone Pulse Count Settings The pulse count settings for each zone can be programmed between 0 - 15. Zone Pulse Count Time Zone pulse count time is the time frame or period over which the number of pulses must register. 20 ms Loop Response Time 150 ms Loop Response Time Zone Pulse Count Time...
  • Page 300 Installation Manual Solution Ultima 844/862/880 Location 323 Page 181 Swinger Shutdown Count For Siren Location 324 Page 182 Swinger Shutdown Count For Dialler Location 325 – 326 Page 184 Zone Status - Zone Tamper Report Location 325 Zone Tamper Report...
  • Page 301 Programming Sheets Solution Ultima 880 Location 353 – 354 Page 191 Codepad Medical Report 7 13 Location 355 Page 192 Codepad Reporting Options 0 = No Report Required 1 = Receiver 1 2 = Receiver 2 4 = Receiver 1 + 2 8 = Receiver 2 Only When Receiver 1 Fails Location 356 –...
  • Page 302 0 = No Beeps / 15 = Loudest Beeps Location 436 Page 227 System Options 1 1 = EDM Smart Lockout Allowed 2 = Horn Speaker Monitor 4 = Strobe Indications For Radio Arm/Disarm 8 = Assign Button 4 On Transmitter To Operate STAY Mode 1...
  • Page 303 Programming Sheets Solution Ultima 880 Location 440 Page 231 Consumer Options 1 1 = Test Reports Only When Armed 2 = Test Report After Siren Reset 4 = Auto Arm In STAY Mode 1 8 = STAY Indicator To Display Day Alarm Status Location 441 Page 232 Consumer Options 2...
  • Page 304 Installation Manual Solution Ultima 844/862/880 Location 528 – 535 Page 250 RF Device Mapping (Devices 1 – 8) 6 7 8 Location 536 – 543 Page 250 RF Device Mapping (Devices 9 – 16) 0 0 0 Location 801 – 808 Page 251 RF Device Signal Strength (Devices 1 –...

  • Page 305: Index

    Index...
  • Page 306 Installation Manual Solution Ultima 844/862/880 2 Wire Smoke Detector Interface ....... 256 Basic Pager..............134 24 Hour Zone.............. 261 Basic Pager Reporting..........134 Battery Testing ............259 Bell Test ................94 Bypass Reports............185 4 + 2 Reporting Format ..........133 Call Back Telephone Number ........147 AC Mains Cellular Diallers ............255...
  • Page 307 Defaulting The Control Panel ......110, 119 Delay Alarm Reporting Time........217 Delay Siren Until Transmission Complete....154 E2 Fault ................ 53 Delete EDM Smart Watch ............. 227 RF Zones ..............64 EDMSAT..........72, 202, 254, 259 Detectors ..............259 Entry Guard Timer For STAY Mode ..... 42, 45, 217 Dialler .................259...
  • Page 308 Installation Manual Solution Ultima 844/862/880 Date and Time ............53 Setting STAY Mode 2 Zones ......71, 86 E2 Fault ..............53 Telephone Monitor Mode..........73 Walk Test Mode............74 Fuse Fail ..............53 Horn Speaker ............53 Installer's Programming Commands Low Battery .............. 53 958 - Enable/Disable Zone Status ......108...
  • Page 309 Index Day Alarm Enabled ..........204 Day Alarm Latching ..........204 New Zealand Telepermit Notes........274 Day Alarm Resetting ..........203 Night Arm Station ..........230, 255 Dialler Active ............208 Dialler Disabled............208 EDMSAT - Satellite Siren ........202 OFF Indicator/Zone Sealed ...........33 Entry Warning ............
  • Page 310 Installation Manual Solution Ultima 844/862/880 Normally Open, Pulsing Low ......... 211 Output Not Used ............. 211 Quick Start ..............22 Outputs ............... 200 One Shot Polarities ..........214 Polarity ..............211 Radio Input Options ............234 Pulsing Polarities ............ 213 Latching Keyswitch Input ........234 Redirecting Output To Codepad Buzzer....
  • Page 311 Assign Button 4 On Transmitter To Arm STAY Mode Adding Or Changing .......... 77, 79 1 ................227 Allocations When Partitioning ....... 245 EDM Smart Lockout ..........227 Deleting .............. 78, 80 Monitoring Of Horn Speaker ........227 Priority Level............161 Strobe Indications For Radio Arm/Disarm .....227 System Options 2 ............228...
  • Page 312 Installation Manual Solution Ultima 844/862/880 Isolating - Code To Isolate........50 Zone Restore Report ..........179 Isolating - Standard........... 49 Zone Reporting Information Isolating Allowed............ 179 Dialler Options ............180 Operating Information ..........169 Zone Report Code ...........180 Options 1............169, 175 Zone Restore Code..........186...
  • Page 313 Index Electronics Design and Manufacturing Pty Limited ISSUE162.DOC...

This manual is also suitable for:

Solution ultima 880Solution ultima 862

Table of Contents
