Meta System T.30-Def-Com 30 Installation Manual page 6

When installation is complete and the wiring connector is connected to the alarm control unit, do the following:
1. Restore the motorcycle's battery connection.
2. Turn the motorcycle key to ON and then OFF again.
3. After 50 sec. from this last step, the burglar alarm engine block is automatically triggered: the arrows will fl ash once
briefl y, the siren will sound 1 BEEP and the LED will start fl ashing very slowly.
4. Switch the burglar alarm off from the radio control: the arrows will fl ash once, the siren will BEEP 1 time and the LED
will switch off .
5. Within 50 sec. start the motorcycle to make sure that the connections are working properly.
6. After turning off the engine and turning the motorcycle key to OFF, within 50 sec. turn on the burglar alarm from
the radio control: the arrows will fl ash 2 times, the siren will BEEP 2 times and the LED will fl ash with brief off times.
7. During the initial 26 sec. immunity, perform the following test which need to produce a BEEP if the result is positive:
• Turn the motorcycle key to ON.
• Enable any protection buttons (seat compartment opening, bulkhead removal,...).
• Move the motorcycle, enabling movement protection. With every BEEP the initial immunity time starts over from
zero again.
8. When the initial immunity is over, the LED fl ashes at an inverted phase (long off times) and one of the protection
contacts is enabled, turning the motorcycle key to ON or moving it will generate a 26 sec. alarm cycle: the siren
makes its characteristic modulated sound, the turn signals fl ash and the horn, if connected, sounds intermittently.
Check the correct operation of the engine block protections during the alarm cycle.
9. When the burglar alarm is switched off the LED will stay on and the siren will make 1 BOOP to signal the alarm me-
mories: refer to the user manual to decode the signal and for all the other product characteristics/programming.
Hereby, Meta System S.p.A. with address in Via Galimberti 5, 42124 Reggio Emilia – Italy – declares that Telematic Tra-
cking device Moto Alarm T.30 and Def-Com 30 models are in compliance with Radio Equipment Directive 2014/53/
EU.
Frequency Bands and Power Supply in which the radio equipments
operates:
T.30
880-960 MHz: 1710-1880 MHz ..........................GSM: class 4 (2W); DCS: Class 1 (1W)
1575,42 – 1602 MHz (Rx only)
863,1-864,6 MHz .....................................................< 10 mW
DefCom30
863,1-864,6 MHz .....................................................< 10 mW
The full text of the EU Declaration of Conformity is available at the following internet address:
http://docs.metasystem.it
Certifi cate Holder's Address:
Meta System S.p.A.
Via Galimberti 5
42124 Reggio Emilia
Italy
ALARM CONTROL UNIT: FINAL TEST
PROCEDURE FOR THE CORRECT DISMANTLING
OF THE TELEMATIC CONTROL UNIT
SIMPLIFIED DECLARATION OF CONFORMITY
6
