Meta System T.30-Def-Com 30 Installation Manual page 5

CONTROL-OPERATED HORN
POSITIVE - LOCKED
IGNITION
ORIGINAL
KEY BLOCK
COMMAND
HORN
ALARM CONTROL UNIT: ELECTRICAL CONNECTIONS (connection to the battery)
ATTENTION: First connect the fork contact
with RED SHEATH to the POSITIVE POLE
of the battery and, subsequently, the fork
contact with BLACK SHEATH to the NEGATIVE
POLE.
RED
The telematic control unit is equipped with a LED to provide diagnostic information and it is installed on top of the de-
vice. Based on the indications in the table below it is possible to verify the connectivity relative to the GSM to the GSM
& GPRS.
STATUS OF THE CONTROL UNIT DURING
REGISTRATION ON THE NETWORK
Registration in progress
Registration completed
Registration completed
Registration denied
Registration denied
ADDITIONAL
RELAY
BROWN
TELEMATIC CONTROL UNIT: DIAGNOSTICS
STATUS OF THE CONTROL
UNIT AFTER ACTIVATION
Awake
Awake
Sleep Mode
Awake
Sleep Mode
CONTROL-OPERATED HORN
NEGATIVE - LOCKED
P600 DIODES
IGNITION
TO BE INSTALLED
KEY BLOCK
HORN
ADDITIONAL
ORIGINAL
COMMAND
Verify that the led on the device fl ashes; if
not, check the connections and/or contact the
after-sales service
BLACK
LED - RED
Alternate fast RED and GREEN fl ash
Alternate slow RED and GREEN fl ash
5
TURN
SIGNALS
RELAY
BROWN
LED - GREEN
1 fast fl ash
Always ON
1 slow fl ash
TO
ROOT
COMMANDS
