TELEMATIC CONTROL UNIT: WARNINGS ON DEVICE POSITIONING
If horizontal installation is not possible, pro-
ceed with vertical installation.
Do not secure the telematic control unit
with the cables set up upwards!!
ATTENTION: make sure that the telematic control unit is
at least 50 cm from the ECU (engine control unit).
IN HORIZONTAL POSITION
Below is some information on positioning and mounting the telematic control unit:
• Identify a fl at area for mounting.
• Clean the area with the supplied detergent wipe and remove the adhesive fi lm from the telematic control unit.
• Position and mount the telematic control unit by pressing for at least 10 seconds.
ATTENTION
TELEMATIC CONTROL UNIT: INSTALLATION
WIRING - METAL PANELS
3
GPS
DIRECTIONAL
ANTENNA
