Printronix SL5000r MP2 Specifications page 5

Label Perforation
Centered in Gap
(see Para 3.4)
Leading Edge of Label
Inlay Outline
Label
Rafsec Short Dipole
Antenna outline
Chip facing down,
Minimum
center slot back
Pitch 2.0"
Liner
Corner radius:
0.125" typ.
Printronix RFID Label Requirements for
PRINTRONIX
All Dimensions in Inches
(+/- 0.1250")
Liner edge to
center of chip
4.0" minimum
Variable see para
3.7.2 and 3.7.3
Rafsec Short Dipole Inlay
Viewed from Facestock Side
Figure 1. Label Layout
182316-000 Rev C
1.00" (+/-0.125")
Trailing edge of timing
mark to leading edge
of antenna
2.0625"
1.0" min x 0.125"
timing mark on
back side of liner
RFID Label Guide Specification
Gen 2, Rafsec Short Dipole Antenna
Direction of label
travel out of
printer
Page 5 of 5
