3.3.2. Adhesive interface to liner shall be uniform and exhibit the same release
characteristics along the full length of the label.
3.4. Perforations Between Labels
3.4.1. For SL4M and SL5000 models – per user requirements except no perforations for
Peel Mode.
3.4.2. For SLPA8000 and SLPA7000 models – no perforation between labels.
3.5. Roll Configurations
3.5.1. SL4M and SL5000 models
3.5.1.1. Inside core diameter: 3 inches (76.2 mm).
3.5.1.2. Outside roll diameter: 8" (203.2 mm) maximum.
3.5.1.3. Label wind direction – label side out with orientation per Figure 1.
3.5.2. SLPA8000 and SLPA7000 models
3.5.2.1. Inside core diameter: 3.000" (+0.032", -0.0") (76.190 mm (+0.813, -
0.0)) core acceptable for label lengths less than 5" (127.0 mm) with
inlay lengths less than 2" (50.8 mm). For label lengths greater than 5"
(127.0 mm) core diameter shall be 6.0" (+0.032", -0.0") (152.4 mm
(+0.813, -0.0).
3.5.2.2. Outside roll diameter: up to 12" (304.8 mm) maximum.
3.5.2.3. Label wind direction – label side out with orientation per Figure 1.
3.5.3. General
3.5.3.1. Roll to be wound with sufficient tension to prevent telescoping during
transit and handling.
3.5.3.2. Splices to use clear tape, should be angled and placed under the labels
and not between.
3.6. Inlay
3.6.1. Inlay: Rafsec Gen 2 Short Dipole inlay (similar to Rafsec sales code 3000704).
3.6.2. Base antenna material: Etched aluminum.
3.6.3. Nominal operating frequency: 915 (+/-15) MHz.
3.6.4. EPC Protocol: UHF Class 1, Gen 2.
3.6.5. Memory: 96 Bit Read/Write.
3.7. Label Construction
3.7.1. Inlay location with respect to label facestock outlined in Figure 1.
3.7.2. 4" Printer Models
3.7.2.1. Nominal label facestock width with inlay is 4.0" (101.6 mm).
Maximum width of label construction supported by printer is 4.5"
(114.3 mm) edge to edge (4.1" (104.1 mm) is printable).
3.7.3. 6" Printer Models
