WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any oth-
er appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference
Installation/Operator's Manual
www.acucraft.com
This is a vented decorative gas appliance: not a source of heat; not for use with solid fuel.
Cette unité est appareil à gas décoratif à évacuation: n'est pas une source de chaleur; ne
convient pas auz combustibles solides.
888-317-6499
ADVERTISSEMENT:
RISQUE D'INDENDIE OU D'EXPLOSION
Le non-respect des avertissements de sécurité
pourrait d'entraîner des blessures graves, la mort
ou des dommages matériels.
- Ne pas entreposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage de
cet appareil ou de tout autre appareil.
- QUE FAIR SI VOUE SENTEZ UNE ORDEUR DE
GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones se trouvant dans le bâtiment
où vous vous trouvez.
• Sortez immédiatement votre fourmisseur de gas
depus un voisin. Suivez les instructions du fornis-
seur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incendies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifée; ou par le
fourmisseur de gaz.
INSTALLATEUR: Laissez cette notice ave l'appareil.
CONSOMMATEUR: Conservez cette notice pour
consultation ultérieure.
Rev.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E6IO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blaze E6IO

  • Page 1 www.acucraft.com 888-317-6499 This is a vented decorative gas appliance: not a source of heat; not for use with solid fuel. Cette unité est appareil à gas décoratif à évacuation: n’est pas une source de chaleur; ne convient pas auz combustibles solides. ADVERTISSEMENT: RISQUE D’INDENDIE OU D’EXPLOSION Le non-respect des avertissements de sécurité...
  • Page 2 Connecting the Gas Valve & Ignition System ......pg 17 Installing the Media ............... pg 18 Installing the Glass Panel ............pg 19 Blaze 6 Components pg 20 Component Quick Reference Guide & Replacement Parts... Draft Controller ..............pg 21-22 Gas Valve & Ignition Module ..........
  • Page 3: Introduction

    INTRODUCTION Dedication to innovation, honesty, excellence, and hard work ensure that we can provide solutions to each and every one of our customers. Our team stays up-to-date on all the latest trends and technologies to ensure we can provide customers with the perfect solution for their project. Our passion for excellence paves the way for our world-class products, systems &...
  • Page 4 SAFETY INSTALLATION GUIDELINES: INSTALLATION SAFETY CODES: SAFETY STATEMENTS: - Acucraft does not install fireplace systems. Safety is very important and is referenced throughout These instructions should be used as a guideline only, and - Contact a licensed installer for proper installation. do not supersede local codes in any way.
  • Page 5 SAFETY WARNING FIRE & EXPLOSION HAZARD Gasoline or flammable vapors can ignite or explode. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Follow lighting instructions provided on the label of the fireplace and in this manual. If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 6 SAFETY DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. DANGER If you smell gas: •...
  • Page 7 SAFETY MONOXYDE DE CARBONE DANGER Cette appareil peut produire du monoxyde de carbon, un gas indore. L’utilisation de cet appareil dans des espaces clos peut entraîner la mort. Ne jamais utiliser cet appareil dans un espace clos comme un véhicule de camping, une tente, une automobile ou une maison.
  • Page 8 SAFETY...
  • Page 9 SAFETY...
  • Page 10 SAFETY Due to high temperatures, the appliance should be located out of traffic and away from furni- ture and draperies. Clothing or other flammable material should not be placed on or near the appliance. Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns or clothing ignition.
  • Page 11 INSTALLATION GUIDE This is a vented decorative gas appliance: not a source of heat; not for use with solid fuel. Cette unité est appareil à gas décoratif à évacuation: n’est pas une source de chaleur; ne convient pas auz combustibles solides. IMPORTANT NOTE TO INSTALLER: 1.
  • Page 12 INSTALLATION GUIDE...
  • Page 13: Positioning The Fireplace

    INSTALLATION GUIDE Positioning the Fireplace Clearance to combustibles: Top of appliance = 4” Using a hand truck or other appropriate equipment, Sides of appliance = 2” that is rated to handle the weight of the fireplace Back of appliance = 2” Bottom of appliance = 0”...
  • Page 14 INSTALLATION GUIDE Vent terminal locations to intersecting walls, overhangs or eaves, window openings, air intakes, above-ground grade or deck shall maintain the clearances specified as shown below. Vent terminals shall not be recessed into a wall or siding. Installing the Ventilation CAUTION: Extreme temperatures if damper is not used! The entire ventilation system, including Class A Combustion air supply: It is always recommended...
  • Page 15 INSTALLATION GUIDE Canadian installations US installations Clearance above grade, ve- 12 in (30 cm) 12in (30 cm) randa, porch, desk or balcony Clearance to window or door 6 in (15 cm) for appliances ≤ 10,000 6 in (15 cm) for appliances ≤ 10,000 that may be opened Btuh (3 kW), 12 in (30 cm) for appli- Btuh (3 kW), 9 in (23 cm) for applianc-...
  • Page 16: Vent Requirements

    SUPPLEMENTAL MATERIAL VENT REQUIREMENTS Vent Requirements Vent Installation • Slide the vent sections together, use screws pro- • The gas appliance and vent system must be vided with flue (3 screws at each joint). vented directly to the outside of the building, and never be attached to a chimney serving a •...
  • Page 17: Connecting The Gas Valve & Ignition System

    INSTALLATION GUIDE Connecting the Gas Valve & Ignition System IMPORTANT: The location of the stubbed gas line port and electrical pass through port for running the ignition cable are All connections and components should be made determined during design. The location may either be and installed by qualified persons only and checked directly with the fireplace, or these components may and tested for leaks prior to wiring of valve module.
  • Page 18: Installing The Media

    INSTALLATION GUIDE Installing the Media WARNING Next, carefully place media over top of round burner located inside of square burner tray, allowing media to fill void alongside tube and to cover over top of tube with ¼” of media, as shown below: Always wear protective equipment when dealing with open flames.
  • Page 19 INSTALLATION GUIDE Installing the Dual Pane Glass Step 2: Install the inner frame with the countersunk screws WARNING provided Always wear protective equipment when dealing with hot surfaces. Failure to follow this warning may result in serious injury. Step 1: Install inner pane of glass in the channel Step 3: Install the outer glass in the channel Step 4: Install the outer removable frame with the countersunk screws provided...
  • Page 20: Draft Controller

    REPLACEMENT COMPONENTS INFORMATION IMPORTANT: This fireplace system consists of several components that are designed specifically for this appliance. No parts on this appliance may be substituted or replaced with anything other than original components. Replacement parts as listed below can be obtained by contacting Acucraft Customer Service by phone or email. Acucraft Customer Service Contact Information: •...
  • Page 21: Draft Controller

    SUPPLEMENTAL MATERIAL Draft Controller Product Information USE: CONSTRUCTION: The Control Board is a fan speed and appliance con- The housing is NEMA 1 rated ABS plastic. trol used to control draft for a gas appliance such as a fireplace, stove or furnace. It may be interlocked with CODE COMPLIANCE: the appliance and is for use in systems where modu- System installation must conform to the requirements...
  • Page 22: Specifications

    SUPPLEMENTAL MATERIAL Draft Controller Specifications Mechanical Installation Dimensions & Capacities: LOCATION: Power Supply = V 1x120 VAC The Control Board must be installed indoors. Amperage = A As shown in the diagram below, the control will be Operating Temp = ºF/ºC -4 to 122 / -20 to 50 wired directly to a 120/1/60 VAC power supply.
  • Page 23 SUPPLEMENTAL MATERIAL Draft Controller CONNECTION OF THE DRAFT SWITCH AND INSTALLATION OF THE CHIMNEY PROBE: STACK PROBE: The probe must be installed between the appliance The Draft Switch must be installed indoors, in the ver- and the exhaust fan. If a damper is used in the tical position (pre-drilled knockouts face down).
  • Page 24: Gas Valve & Ignition Module

    SUPPLEMENTAL MATERIAL Gas Valve & Ignition Module...
  • Page 25: Gas Valve & Ignition Module

    SUPPLEMENTAL MATERIAL Gas Valve & Ignition Module...
  • Page 26 SUPPLEMENTAL MATERIAL Gas Valve & Ignition Module...
  • Page 27 SUPPLEMENTAL MATERIAL Gas Valve & Ignition Module...
  • Page 28 SUPPLEMENTAL MATERIAL Gas Valve & Ignition Module...
  • Page 29: Draft Switch

    SUPPLEMENTAL MATERIAL Draft Switch Mechanical Installation INSTALLATION OF DRAFT SWITCH INSTALLATION OF STACK PROBE FOR PDS 1: The Draft Switch is for indoor installation only. The A stack probe is used with Draft Switch. The Draft Switch monitors the pressure inside the stack and sig- Draft Switch must be installed in a vertical position nals the control to shut down the appliance if insuff- with the pressure connection pointing down.
  • Page 30: Draft Switch

    SUPPLEMENTAL MATERIAL Draft Switch For all installations, the stack probe must be placed so the flow through the stack is perpendicular to the tip of the probe. Locate the probe at least the distance “A” away from any elbows or tees in the stack. The distance “A”...
  • Page 31: Inline Fan

    SUPPLEMENTAL MATERIAL Inline Fan Installation and Maintenance INSTALLATION (cont.): WIRING: CAUTION All installation should be wired according to the following diagrams. Failure to comply will cause the motor to “hum” or not work. Instruction for all model FG fans...
  • Page 32: Chimney Fan

    SUPPLEMENTAL MATERIAL Chimney Fan Dimensions & Capacities Model Chimney Fan Discharge Horizontal Fan Type Axial Vane Motor Type Totally enclosed, vari- able speed, Class H Voltage (VAC) 1 x 120 1600 CFM (0.0Ps) Amperage (Amps) Motor Output (HP) 1/30 Motor Output (kW) 0.025 Weight (lbs) Weight (kg)
  • Page 33: Chimney Fan

    SUPPLEMENTAL MATERIAL Chimney Fan Planning Ahead Support system for the chimney fan: Prior to WARNING installation of the chimney fan, it must be assured the chimney can safely carry the weight of the chimney fan. 1. Observe proper combustion air requirements. A steel chimney should be well supported at the roof 2.
  • Page 34: Notes

    SUPPLEMENTAL MATERIAL Chimney Fan CAUTION Single Fan on Steel Chimney Step 1: Prepare fan location The steel chimney adapter (SCA) slides right into the Under conditions with extremely strong winds chimney, where the long collar engagement ensures surrounding the top of the chimney, the chimney fan safe anchoring.
  • Page 35: Electrical Installation

    SUPPLEMENTAL MATERIAL Chimney Fan CAUTION The combustion air inlet and flue gas outlet of a direct vent appliance or the flue gas outlet of an appliance other than a direct vent appliance shall terminate at least 1 ft (0.3 m) from the soffit of the roof of the A safety device that prevents the heating appliance structure and at least 3 ft (0.9 m) from an inside operation, in case of a power failure or inadequate...
  • Page 36 SUPPLEMENTAL MATERIAL Chimney Fan Start-Up and Configuration SYSTEM TESTING CARE AND CLEANING Before any adjustments are made to the system, The Chimney Fan System is designed for prolonged follow these procedures: use. The fan should be inspected at least once a year when the chimney is inspected.
  • Page 37 SUPPLEMENTAL MATERIAL Chimney Fan Maintenance (cont.) CHIMNEY CLEANING INTERVALS It is extremely important to keep the chimney flue clean from products of combustion and deposits. Unburned oil residues can cause a chimney fires. Cleaning intervals depend on the use of the appliance. The more the appliance is used, the more often the chimney flue needs cleaning.
  • Page 38 NOTES...
  • Page 39: Specifications

    REPRODUCTION IN PART OR AS A Big Lake, MN 55309 WHOLE WITHOUT THE WRITTEN SPECIFIED ALL PERMISSION OF ACUCRAFT IS DIMENSIONS PROHIBITED. ARE IN INCHES 75" TITLE: BLAZE 6 INDOOR/OUTDOOR DRAWN BY: DATE: (GARCO CONST. 0817) A.REDBERG 7/17/17 MATERIAL: SIZE DWG. NO. SHEET 1...
  • Page 40: Specifications

    PRODUCT SPECIFICATIONS INDOOR/OUTDOOR VENTED GAS FIREPLACE MANUFACTURER: Serial #/En Série: Acucraft Fireplaces MODEL/ MODELE: BLAZE6io Gas Fireplace 19672 172nd St Big Lake, MN 55309 (763) 263-3156 LPG Type Natural Gas / Type de Gaz: (Gaz naturel) (Propane) INPUT RATING (ENTRÈE NOTE) (Btu/hr) 0-610m: 100,000 80,000 ORIFICE SIZE (DIMENSIONS DE L’ORIFICE) (DMS) 0-610m:...
  • Page 41: Product Specifications

    PRODUCT SPECIFICATIONS FOR YOUR SAFETY, READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. This appliance has a pilot. It is equipped with an ignition If you cannot reach your gas supplier, call the fire device which automatically lights the burner.
  • Page 42 OPERATION GUIDE Basic Sequence of Operation Lighting the Ignition System (cont.) Listed below is a sequence of operation when the For complete lighting instructions refer to “Lighting fireplace is functioning properly. If you are experienc- Instructions” on page 39 ing problems with the fireplace not operating normally, see the Troubleshooting section.
  • Page 43 DRAFT CONTROL OPERATION Sequence of Operation The sequence of operation flow chart is shown in the figure below. Maintain Flashing State Idle State De- Energize for 30 seconds All for Retry Aux In Enabled Taking longer than One Flash Open Damper 90 seconds Alarm Damper Open Proof...
  • Page 44 TROUBLESHOOTING PROBLEM SOLUTION Appliance does not light within If the appliance does not light within 20 seconds, the gas valve will lock 20 seconds. out automatically. Turn off switch, wait 10 seconds, and try turning it on again. If there is still no ignition, turn off switch and visually inspect wiring harness for loose connections and check to be sure the gas supply is connected and all valves are open.
  • Page 45: Maintenance & Care

    MAINTENANCE & CARE Always use proper precautions and turn off fireplace before performing any maintenance. Do not clean appliance when hot. Clean the tempered glass with a basic household glass cleaner every 3 months to 1 year (depending on frequency of use). Never use abrasive cleaners or glass cleaner that contains ammonia, as it may etch the tempered glass.
  • Page 46: Notes

    NOTES...
  • Page 47: Warranty

    WARRANTY *ALL WARRANTIES EFFECTIVE DATE OF SHIPMENTS* The Warranty Acucraft warrants the gas appliance to be free from defects in materials and workmanship at the time of manufacture. On all gas appliances, there is a lifetime warranty on the firebox. There is a five-year warranty on the main burner. A one-year warranty is given to the pilot burner, gas control valve, glass media and logs, and other gas components.
  • Page 48 FIRE IS OUR PASSION www.acucraft.com 888-317-6499 Acucraft Fireplaces 19672 172nd Street Big Lake, MN 55309...
