X1R Smart
INSTALLATION GUIDE
WARNINGS
When you switch on X1R Smart for the first time, the lock automatically updates, if necessary, connected devices: external and
internal control modules and the Bluetooth radio module. This operation can take up to 50 seconds and it is indicated by the orange
led on the external module continuously flashing.
or disconnect any cable, in order to avoid device malfunctions.
Read this manual prior to use the device in order to ensure a safe and proper use.
Preserve this manual as future reference.
The installation of the device requires the intervention of qualified staff, adequately trained by ISEO.
The instructions should be carefully followed during installation. These instructions and any maintenance instructions should be
passed on by the installer to the user.
The product can be destined only for the use for which it was expressly made and, therefore, as an armored door lock for civil and industrial
locations. Any other use is to be considered improper and dangerous.
Do not work on the door with the lock installed in order to prevent wood or metal residue getting into the lock.
Distance between striking plate and latch tip, completely in (from both motor or key), must be between 2 and 3mm.
Handle must not have any friction during the return phase.
Connecting rods must have a play of at least 1 millimeters so that the deadbolt does not remain subjected to traction in the rest
position. This would compromise infact the latch to be correctly relased when recalled by key.
Connect the "remote opening command" input to 8÷30Vdc/ac power supply source (opto-insulated input).
To use the "door status" internal relay (30Vdc/Vac - 1A MAX), an external power supply source is mandatory. Fit therefore a cable gland to
allow the cable to pass through the hinge side of the door
Electrical connections must be done according to the manufacturer's istructions and in compliance with the current regulations.
When using a feeder as a direct power supply source (8÷30Vdc/ 30W MAX), fit a cable gland to allow the cable to pass through the hinge
side of the door.
Single Action
version allow to withdraws bolts and latch by handle at the same time.
handle.
®
