Pro-Nets Technology Corporation WR750RL User Manual

802.11n wireless broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Draft 802.11n
Wireless Broadband Router
User's Manual
November 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WR750RL and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Nets Technology Corporation WR750RL

  • Page 1 Draft 802.11n Wireless Broadband Router User’s Manual November 2009...

  • Page 2: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication.

  • Page 3: Revision History

    Copyright 2009 All Rights Reserved. No part of this document can be copied or reproduced in any form without written consent from the company. Trademarks: All trade names and trademarks are the properties of their respective companies. Revision History Revision History Release...
  • Page 4 Table of Contents 1. Introduction ................5 1.1 Features ................ 5 1.2 Package Contents ............6 1.3 System Requirements............. 6 1.4 LEDs Indication & Connectors of Wireless Router .... 6 1.5 Installation Instruction ........... 7 2. PC Configuration..............8 2.1 TCP/IP Networking Setup ..........8 3.
  • Page 5 3.7.1 DDNS Setting............42 3.7.2 NTP Setting ............43 3.7.3 Administration ........... 43 3.7.4 Upgrade Firmware ..........44 3.7.5 Setting Management .......... 44 3.7.6 Status..............45 3.7.7 Statistics............. 45 3.7.8 System Log............46 3.7.9 Logout..............47...

  • Page 6: Introduction

    1. Introduction This Wireless Broadband Router is a draft 802.11n compliant device that provide faster and farther range than 802.11g while backward compatible with 802.11g and 802.11b devices. This Router uses advanced broadband router chipset and wireless LAN chipset solution let you enjoy high-speed Wired and Wireless connection.

  • Page 7: Package Contents

    1.2 Package Contents One Wireless AP Router with 1 antennas One External Power Adapter One CD-ROM (user’s manual) One RJ-45 Ethernet Cable 1.3 System Requirements Computers with an installed Ethernet adapter. Valid Internet Access account and Ethernet based DSL or Cable modem. 10/100Base-T Ethernet cable with RJ-45 connector.

  • Page 8: Installation Instruction

    Back Panel Connectors Button/Port Description Reset Reset configurations to default. You would use the reset button only when a program error has caused your 11n AP router to hang. Press the button and hold for 10 seconds. Click WPS button about 2-3 seconds while you are connecting a PC of wireless adapter with WPS function (you must enable WPS’...

  • Page 9: Pc Configuration

    2. PC Configuration To communicate and configure 802.11n AP router, the PC on your LAN must install TCP/IP protocol. Make sure the TCP/IP protocol of the PC is configured for Obtain IP address from DHCP and is connected to LAN (Ethernet) port of the AP router. In doing so, the PC obtains an IP address of 192.168.1.1 from 802.11n AP router.
  • Page 10 Click “Properties”, the window below will appear and then click “IP Address” tab, If you decide to use DHCP, select “Obtain an IP address automatically”, then click “OK” to confirm your settings. Once you restart your system, Wireless Router will obtain an IP address for this system. If you decide to use fixed IP address for your system, select “Specify an IP address”, and make sure that IP Address and Subnet Mask are correct.
  • Page 11 Select “DNS Configuration” tab and make sure select “Enable DNS”, enter the DNS address provides from your ISP in the “DNS Server Search Order” field, then click “Add”, Checking TCI/IP Setting for Windows NT4.0 Select “Control Panel Network”, window below will appear, click “Protocols” tab then select “TCP/IP protocol”,...
  • Page 12 Click “Properties”, window below will appear. Select the network card on your system from “Adapter” field. If you decide to use IP address from Wireless Router, select “Obtain an IP address from a DHCP server”. If you decide to use the IP address you are desired, select “Specify an IP address”.
  • Page 13 Checking TCP/IP Settings for Windows 2000 Select “Start Control Panel Network and Dial-up Connection” and right click “Local Area Connection” then click “Properties”,...
  • Page 14 Select the “Internet Protocol (TCP/IP)” for the network card on your system, then click “Properties”, window below will appear. If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”. If you decide to use the IP address you are desired, select “Use the following IP address”.
  • Page 15 Select “Internet Protocol (TCP/IP)” then click “Properties”, window below will appear.
  • Page 16 If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”. If you decide to use the IP address you are desired, select “Use the following IP address”. Make sure enter correct addresses in “IP Address” and “Subnet Mask”...
  • Page 17 If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”. If you decide to use the IP address you are desired, select “Use the following IP address”. Make sure enter correct addresses in “IP Address” and “Subnet Mask”...
  • Page 18 Configure IP address Automatically: Select “Obtain an IP address automatically” and “Obtain DNS server address automatically” Click “OK” to finish the configuration.
  • Page 19 Configure IP Address Manually: Select “Use the following IP address” and “Use the following DNS server addresses”. IP address: Fill in IP address 192.168.1.x (x is a number between 2 to 254). Subnet mask: Default value is 255.255.255.0. Default gateway: Default value is 192.168.1.1. Preferred DNS server: Fill in preferred DNS server IP address.

  • Page 20: Configure Wireless Router Via Web Based Utility

    If the communication link between your computer and router is not setup correctly, after you type ping 192.168.1.1 under DOS prompt following messages will appear: Pinging 192.168.1.1 with 32 bytes of data: Request timed out. Request timed out. Request timed out. This failure might be caused by cable issue or something wrong in configuration procedure.
  • Page 21 Step2: Login dialog box will appear, enter admin as Administrator Name and 1234 as default Administrator Password, and then click “OK” to access Configuration Utility. Step3: After log in, you can see the Main menu as below.

  • Page 22: Operation Mode

    3.2 Operation Mode In this option, you can configure the operation mode which suitable for your environment. The default setting is Gateway. There have three modes is provided: -- Gateway: The first Ethernet port is treated as WAN port. The other Ethernet ports and the wireless interface are bridge together and are treated as LAN ports.

  • Page 23: Internet Settings

    3.4 Internet Settings The Internet Settings contains the following sections: DHCP Clients VPN Passthrough Advanced Routing 3.4.1 WAN The WAN port is the connection of the 802.11n AP Router module to existing broadband device such as Cable modem or ADSL CPE. Click WAN on Internet Setting, below screen will prompt for WAN setting.
  • Page 24 IP Address: The router IP address to LAN. The factory default setting is 192.168.1.1. You can change it according to your requirements. Subnet Mask: The LAN net-mask. Default: 255.255.255.0 DHCP Type: Select Disable to disable this Router to distribute IP address. Select Server to enable this Router to distribute IP addresses (DHCP server).

  • Page 25: Dhcp Clients

    LLTD: Default: Disable. IGMP Proxy (Internet Group Management Protocol): IGMP proxy can be used to implement multicast routing. It works by IGMP frame forwarding from ISP to gateway client. Default: Disable. UPnP (Universal Plug and Play): UPuP is architecture for pervasive peer-to-peer network connectivity of PCs and intelligent devices or appliances, particularly within the home.

  • Page 26: Vpn Passthrough

    3.4.4 VPN Passthrough VPN passthrough configurations including: L2TP, IPSec, and PPTP passthrough. L2TP Passthrough: L2TP is an extension to the Point-to-Point Protocol, which is an important component for VPNs. VPNs allow users and telecommuters to connect to their corporate intranets or extranets. IPSec Passthrough: IPSec is a framework for a set of protocols for security at the network or packet processing layer of network verification.

  • Page 27: Advanced Routing

    3.4.5 DNS Domain Name Servers are used to map an IP address to search domain name, your ISP may provide the IP address for one or more domain name servers. DNS Proxy: Enable/Disable this Wireless Router DNS. Use Static DNS: Specify the DNS server.

  • Page 28: Wireless Settings

    <Add a routing rule> Destination: Defines the base IP address (Network Number) that will be compared with the destination IP address (after an AND with NetMask) to see if this is the target route. Range: select the range from drop down list Gateway: Enter IP address of the next hop router that will be used to route traffic for this route.
  • Page 29 Setting on Wireless Settings, below screen will prompt for Basic Setting. [Wireless Network] Radio On/Off: Enable/Disable the Wireless radio feature. Default setting is Radio OFF. Network Mode: Choose a mode from the pull-down menu. Make sure that you have the equipment you need.

  • Page 30: Advanced

    [HT Physical Mode] Operation Mode: Mixed mode operation – In this mode, both the MIMO-OFDM system and the legacy systems shall co-exist. The MIMO system should have the capability to generate legacy packets for the legacy system and high throughout packets for MIMO-OFDM systems. So, the burst structure should be decodable to legacy systems and should provide better performance to MIMO-systems.
  • Page 31 [Advanced Wireless] Beacon Interval: Beacon Interval is the amount of time between beacon transmissions. Before a station enters power save mode, the station needs the beacon interval to know when to wake up to receive the beacon. Range 20-999, default is 100. Data Beacon Rate (DTIM): The DTIM period indicates how many beacon frames can transmit before another DTIM is transmitted.

  • Page 32: Security

    Short Slot: When short slot is Enable, the wireless device uses the short slot time only when all clients associated to the 802.11g, 2.4-GHz radio supports short slot time. Short slot time is an 802.11g-only feature and does not apply to 802.11a radios. Tx Burst: Enable the transmitted time slot can increase transmission throughput.
  • Page 33 are None and WEP. For WPA, WPA2, WPA-PSK, and WPA2-PSK authentication mode, the encryption type supports both TKIP and AES. WPA Pre-shared Key: This is the shared secret between AP and STA, For WPA-PSK and WPA2-PSK authentication mode, this field must be filled with character longer than 8 and less then 64 lengths.
  • Page 34 There are 3 modes of WDS: (1) Lazy – Automatic detection of WDS peers: when a LAN user searches for a network, AP router will attempt to connect to WDS devices in its vicinity. (2) Bridge – AP router will function as a wireless bridge, merely forwarding traffic between access points, and will not respond to wireless requests.
  • Page 35 The access point in repeater mode connects to clients as an access point and connects to the upstream restricted access point as a client itself. Using an access point in Repeater mode is not suggested unless absolutely necessary because cells around each access point in the scenario must overlap by minimum of 50%.This configuration drastically reduces the range at which clients can connect to the repeater access point.
  • Page 36 configure a network and enable security, like pushing a button (PBC method) or entering a PIN code (PIN method). The new system, which will be incorporated in Windows Vista, will work with computers, gateways peripherals, and consumer electronics. You would initiate a WPS mode on gateway and then enter a simple sequence of digits (like a PIN code) or press a button, use a similarly easy method to start a secure key exchange to retrieve the WPA/WPA2 key.

  • Page 37: Station List

    In PBC Method (PBC-Push Button Communication), while the AP router acts as Registrar or Enrollee, and click “Start WPS Config” button, the WPS (Wi-Fi Protected Setup) will establish the connection automatically. PIN: Enter the PIN code from the registrar or enrollee. WPS Status: Here shows the current status of the WPS function.

  • Page 38: Firewall

    3.6 Firewall The Firewall contains the following sections: MAC/IP/Port Filtering Port Forwarding System Security Setting Content Filtering Port Trigger 3.6.1 MAC/IP/Port Filtering Settings You can setup firewall rules to protect your network from virus, worm and malicious activity on the internet. Filters are used to deny or allow LAN computers from access the Internet. Within the local area network, the unit can be setup to deny Internet access to computers using the assigned IP or MAC addresses.

  • Page 39: Port Forwarding

    3.6.2 Port Forwarding You may setup virtual servers to provide service on internet. Virtual Server Setting: Enable/Disable the port forward. Address: This is the port number on the WAN side that will be used to access the application. You may define a single port or a range of ports. You can use a comma to add multiple ports or port ranges.

  • Page 40: System Security Settings

    3.6.3 DMZ You may setup a De-Militarized Zone (DMZ) to separate internet network and internet. DMZ Setting: If the DMZ Host Function is enabled, it means that you set up DMZ host at a particular computer to be exposed to the Internet so that some applications/software, especially Internet/Online game can have two-way connections.

  • Page 41: Content Filtering

    Remote management: Let User could management router's web from WAN specify TCP port. Ping form WAN Filter: Let Router WAN IP address could reply PING package. Stateful Inspection: Tracks the transaction to ensure that inbound packets were requested by the user. 3.6.5 Content Filtering You can setup content filter to restrict the improper content access.

  • Page 42: Port Trigger

    matter the URL string is found full or partial matched with a keyword. -- Filter URL: Blocks HTTP requests containing specify URL string. Example: cgi-bin -- Filter HOST: Blocks HTTP requests containing specify HOST string. Example: www.xxx.com Web Host Filter Settings: Web Host Filter is a web solution that blocks web-sites access according the Web Host name or partial matched with a keyword.

  • Page 43: Administration

    application. You may define a single port or a range of ports. You can use a comma to add multiple ports or port ranges. Trig open protocol: This is the protocol used for the special application. 3.7 Administration The Administration contains the following sections: DDNS NTP Setting Administration...

  • Page 44: Ntp Setting

    3.7.2 NTP Setting User could change Network Time Protocol (NTP) for time synchronization needs. Current Time: Show router's current time. Time Zone: Time zone is a region of the earth that has uniform standard time, usually referred to as the local time. By convention, time zones compute their local time as an offset from UTC (see also Greenwich Mean Time).

  • Page 45: Upgrade Firmware

    3.7.4 Upgrade Firmware Firmware is the main software image, which the AP Router needs to perform all tasks in real time. Firmware upgrades are required for adding new features or to resolves bugs. It takes about 1 minute to upload/upgrade flash and be patient please. Caution: A corrupted image will hang up the system.

  • Page 46: Status

    3.7.6 Status In this section, you can look at the status of this wireless 11n Router, such as System Info, Internet Configurations, and Local Network…etc. 3.7.7 Statistics In this section, you can look at the statistics of this wireless 11n Router, such as Memory statistics, WAN/LAN’s Rx &...

  • Page 47: System Log

    3.7.8 System Log This 802.11n Router supports sending system log (sending UDP packets and keeping log messages in Log Server. Click Refresh on Administration, below screen will prompt for System Log information...

  • Page 48: Logout

    3.7.9 Logout Click “Logout” to exit Wireless 11n router configuration page.
