INSTRUCTION MANUAL
SENSIT
Gas Detection Instrument
For use with combustible gases and optionally available
oxygen and toxic gases.
Read and understand
instructions before use.
7WA6
Approved UL913, For Class 1,
Division I, Groups C & D
hazardous locations when used
with alkaline batteries.
Warning: To prevent ignition of flammable
or combustible atmospheres, disconnect
power before servicing.
GOLD 100
®
851 Transport Drive • Valparaiso, IN 46383 (USA)
Phone: 219.465.2700 • www.gasleaksensors.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOLD 100 and is the answer not in the manual?

Questions and answers

James R Blevins
June 6, 2025

INSTRUMENT SHOWS SERVICE REQUIRED COM FAILURE

0

Subscribe to Our Youtube Channel

Related Manuals for Sensit GOLD 100

Summary of Contents for Sensit GOLD 100

  • Page 1 INSTRUCTION MANUAL SENSIT GOLD 100 ® Gas Detection Instrument For use with combustible gases and optionally available oxygen and toxic gases. Read and understand instructions before use. 7WA6 Approved UL913, For Class 1, Division I, Groups C & D hazardous locations when used with alkaline batteries.
  • Page 2 1000ppm) or exhaust gases. Continuously low calibration check results or fluctuation of zero readings may indicate sensor end of life or failure. Consult Sensit Technologies with any questions. For best accuracy always zero in clean air environments similar in temperature and relative humidity to the environment where the instrument will be used.
  • Page 3 CONTENTS Preparation For Your Safety .............. ii Contents ..............3-4 Parts and Accessories ...........5 General Description ............6 Sensor Specifications ............7 Product Specifications ...........7 Product Features ............. 8-10 Sensor Types and Pumps ...........11 Basic Operation Battery Installation/Replacement .........12 Operation and Use ..........13-17 Calibration Check ............18 User Menu and Detailed Operation User Menu / Function Descriptions .......
  • Page 4 CONTENTS Tests and Calibration Bump Test ..............28 O2 Test ................29 Smart-Cal ..............30 Autolog ................31 CO Test and How to Conduct a CO Test .....32 Show and Print CO Test ..........33 CF Test and How to Conduct a CF Test ....34-35 Show a CF Test ............36 Print a CF Test .............37 Calibration Notes ............38...

  • Page 5: Parts And Accessories

    PARTS AND ACCESSORIES Standard Accessories (Included) 872-00001 Hard Carrying Case 360-00040 Wrist Strap 870-00018 Extra Sensor Cap with O-Rings 750-00038 Instruction Manual 310-00004 3”C” Alkaline Batteries Accessories and Replacement Parts 870-00018 Sensor Cap with O-Rings 870-00012 Extension Adapter 873-00016 Hydrocarbon Filter (1) 883-00023 Hot Air Probe Assembly 883-00021...

  • Page 6: General Description

    GOLD 100 can be re-configured or upgraded by the manufacturer for an additional charge should your sensing requirements change. Consult Sensit Technologies for a listing of new sensors available for use with the SENSIT® GOLD 100. All SENSIT® GOLD 100 instruments incorporate an advanced low power semiconductor sensor to measure combustible gases in LEL (Lower Explosive Limit) range.

  • Page 7: Sensor Specifications

    SPECIFICATIONS SENSOR SPECIFICATIONS TYPE RESOLUTION RANGE ACCURACY 0.1%** up to 2% 0-100% LEL ±10% %GAS .01% . 2.5-100% GAS ±5% 1ppm or 10ppm 0-2,000ppm ±10% Increments 0.1% . 0-25% ±0.2% or 10%** 1ppm 0-2000ppm ±5ppm or 5%** 1ppm 0-100ppm ±2ppm or 5%** ** Whichever is greater PRODUCT SPECIFICATIONS Size:...

  • Page 8: Product Features

    PRODUCT FEATURES LUER PROBE CONNECTOR WATER / DIRT FILTER LEL / PPM SENSOR INFRARED COMMUNICATIONS BACKLIT LCD DISPLAY ALARM LEDs OPERATION BUTTONS TICK ADJUST FLEXIBLE GOOSENECK BATTERY COMPARTMENT...
  • Page 9 PRODUCT FEATURES SENSIT® GOLD 100 instruments are constructed of durable ABS plastic to withstand the rigors of field use. Incorporated in the hand grip area is the battery compartment. All SENSIT® GOLD 100 instruments require 3 “C” type alkaline batteries.

  • Page 10: Product Features

    Below the display is a series of LEDs that are preset to indicate combustible gas concentrations. The red LED on the right side will flash during any alarm condition. There are 3 operational button pads on the front of all Sensit®Gold instruments. BUTTON (A) POWER/MUTE Operates POWER and MUTE features and exit menu items.

  • Page 11: Sensor Types And Pumps

    PPM (if so equipped), LEL and percent volume. The Pump The SENSIT® GOLD 100 instruments are equipped with a powerful and efficient diaphragm pump. A water/dirt filter at the end of the gooseneck protects the pump from foreign material. An additional internal filter also helps to protect the pump from damaging debris.

  • Page 12: Battery Installation/Replacement

    BATTERY INSTALLATION/REPLACEMENT Battery replacement is necessary when the display reads BAT LOW, an audible alarm sounds and the green ready LED flashes. When the instrument remains in BAT LOW, a count down will appear starting at 300 seconds (5 minutes) which is the maximum time remaining before shut down.

  • Page 13: Operation And Use

    OPERATION AND USE ⚠ CAUTION: Always start any SENSIT® GOLD 100 in a gas free environment to insure a proper zero. 1. Push the POWER/MUTE BUTTON (A). The following start-up sequence will be displayed. a. Product name and model version number b.
  • Page 14 OPERATION AND USE An alternative option is to request a PPM display. Resolution for this option is 1ppm or every 10ppm. An X on the display indicates that the instrument is not outfitted with that sensor. 6. Prior to use, test the integrity of the sensor cap and tubing. Use your finger to block the inlet of the sensor cap for 4-5 seconds.
  • Page 15 OPERATION AND USE 10. When sampling areas the appropriate sensors will cause the display to update when a gas is encountered. Additionally, if a combustible gas is encountered a series of LEDs on the front of the instrument will illuminate when the preset concentrations are reached.
  • Page 16 OPERATION AND USE 11. To disable the alarm, quickly press the POWER/MUTE BUTTON (A). To enable the alarm press the same button again. During an alarm the gas that has exceeded the preset alarm point will flash on the display and the HAZARD 3 LED will flash indicating a potentially unsafe condition.

  • Page 17: Operation And Use

    OPERATION AND USE 13. At any time the operator may save the readings on the display by pressing the ZERO/SAVE (C) button. This will save all readings for download at a later time. The memory is factory set to store 6 events. This can be adjusted from 1-15 at the factory.

  • Page 18: Calibration Check

    CALIBRATION CHECK To verify the accuracy of any SENSIT® Gold 100, it must be exposed to a known concentration of test gas that will test any sensor combination included in your particular model. Any sensor that does not meet the specifications listed in this manual may require calibration or repair.
  • Page 19 USER MENU The SENSIT® Gold 100 has several categories within the User Menu. The first nine fields are standard with all instruments. The last three are only available in certain instrument models when ordered with the Extended Memory option. PRINT MENU:...
  • Page 20 MENU The SENSIT® Gold 100 has several categories within the User Menu. The first nine fields are standard with all instruments. The last three are only available in certain instrument models when ordered with the Extended Memory option. BUMP TEST: Perform automatic test for sensors response to calibration gas within 60 seconds or less.
  • Page 21 USER MENU OPERATION PRINT MENU From the working display access the menu by pressing & holding the BH TEST/MENU BUTTON (B) until the top line of the display reads USER MENU. The bottom line will read PRINT MENU. Press & release the MENU BUTTON (B) once to enter the menu.

  • Page 22: Gas Type

    USER MENU OPERATION GAS TYPE From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Press & release the SAVE/ZERO BUTTON (C) until the bottom line reads GAS TYPE. Press & release the MENU BUTTON (B) once and the current primary gas type will appear.
  • Page 23 USER MENU OPERATION POWER OFF From the working display access the menu by pressing & holding the BH TEST/MENU BUTTON (B) until the top line reads USER MENU and the bottom line will read PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) until the bottom line displays POWER OFF.

  • Page 24: Set Clock

    USER MENU OPERATION SET CLOCK From the working display access the menu by pressing and holding the MENU BUTTON (B) until the top line reads USER MENU and the bottom reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) until the bottom line displays SET CLOCK.
  • Page 25 USER MENU OPERATION SHOW A CALIBRATION LOG From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU, the bottom line reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads SHOW CAL LOG.
  • Page 26 USER MENU OPERATION SHOW A SESSION LOG From the working display, press & hold the MENU BUTTON (B) until the top line reads USER MENU and the bottom line reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads SHOW SES LOG.
  • Page 27 USER MENU OPERATION PRINT A SESSION LOG From the working display, press & hold the MENU BUTTON (B) until the top line reads USER MENU and the bottom line reads PRINT MENU. Press & release the MENU BUTTON (B) once to enter this menu, SESSION LOG will be displayed.

  • Page 28: Bump Test

    TESTS AND CALIBRATION BUMP TEST From the working display, press & hold the MENU BUTTON (B) until the top line reads USER MENU and bottom line reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads BUMP TEST.
  • Page 29 TESTS AND CALIBRATION O2 TEST From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU and the bottom line reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads O2 TEST.

  • Page 30: Smart-Cal

    TESTS AND CALIBRATION SMART-CAL From the working display, press & hold the MENU BUTTON (B) until the top line reads USER MENU and the bottom line reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads SMART CAL.

  • Page 31: Autolog

    TESTS AND CALIBRATION AUTOLOG (Automatically included with every unit that has the optional CF Test feature) With this feature the instrument will automatically save the peak readings of all sensors while the unit is operating in the working display. These peak readings are stored in Events with a maximum capacity of 1,600 events.
  • Page 32 TESTS AND CALIBRATION CO TEST Only available as an option for instruments with CO and the extended memory feature. TO CONDUCT A CO TEST: From the working display, press & release MENU BUTTON (B) once, SELECT TEST will appear on the top line of the display. Press & release the MENU BUTTON (B) againto enter the CO test menu.
  • Page 33 TESTS AND CALIBRATION TO SHOW A CO TEST: From the working display, press & hold the MENU BUTTON (B) until the top line reads USER MENU, the bottom line reads PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads SHOW CO TEST.
  • Page 34 TESTS AND CALIBRATION CF TEST Only available as an option for instruments with CO and O2 and the extended memory feature. TO CONDUCT A CF TEST IMPORTANT: Air free CO levels or CF readings are calculated by the instrument based on CO and O2 levels detected during flue gas sampling of gas fired appliances.
  • Page 35 TESTS AND CALIBRATION TO CONDUCT A CF TEST ( CONTINUED ) If this segment continues to flash during the test period, conditions for a proper test were not possible. In this case any test results are invalid. The display and printout will show N/A for the peak CF reading. The test should be repeated.
  • Page 36 TESTS AND CALIBRATION TO SHOW A CF TEST From the working display, press & hold MENU BUTTON (B) until the top line reads USER MENU, the bottom line will read PRINT MENU. Press & release the SAVE/ZERO BUTTON (C) to scroll until the bottom line reads SHOW CF TEST.
  • Page 37 TESTS AND CALIBRATION TO PRINT A CF TEST From the working display, press & hold the BH TEST/MENU BUTTON (B) until the top line reads USER MENU, the bottom line will read PRINT MENU. Press & release the BH TEST/MENU BUTTON (B) once to enter this menu.
  • Page 38 The following instructions pertain to manual calibration of the SENSIT GOLD 100. If you are using the automatic Smart-Cal Calibration System, the procedure is different. See the Smart-Cal sections of this manual or consult the Smart-Cal instruction manual for details.

  • Page 39: Carbon Monoxide (Co) Calibration

    MANUAL CALIBRATION CARBON MONOXIDE (CO) CALIBRATION (100PPM CO/AIR) From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Press & release the SAVE/ZERO BUTTON (C) once. The bottom line will read CALIBRATION. Press &...

  • Page 40: Hydrogen Sulfide (H2S) Calibration

    MANUAL CALIBRATION HYDROGEN SULFIDE (H2S) CALIBRATION (H2S 25 PPM) From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Press & release the SAVE/ZERO BUTTON (C) once. The bottom line will read CALIBRATION. Press &...

  • Page 41: Combustible Gas Calibration (50% Lel Methane)

    MANUAL CALIBRATION COMBUSTIBLE GAS CALIBRATION (50% LEL METHANE) From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Press & release the SAVE/ZERO BUTTON (C) once. The bottom line will read CALIBRATION. Press &...

  • Page 42: Combustible Gas Calibration (100% Methane)

    MANUAL CALIBRATION COMBUSTIBLE GAS CALIBRATION (100% METHANE) From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Press & release the SAVE/ZERO BUTTON (C) once. The bottom line will read CALIBRATION. Press & release the MENU BUTTON (B) once, the bottom line will read CO 100ppm.
  • Page 43 MANUAL CALIBRATION COMBUSTIBLE GAS CALIBRATION (1.1% PROPANE or 50% LEL PROPANE) From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Press & release the SAVE/ZERO BUTTON (C) once. The bottom line will read CALIBRATION. Press & release the MENU BUTTON (B) once.
  • Page 44 POWER/MUTE BUTTON (A) to return to the working display. NOTE: A calibration failure is indicated on the display by BAD CAL. Recalibration should be attempted. Any instrument that does not accept calibration should be taken out of service. Please contact SENSIT TECHNOLOGIES for any needed repairs.

  • Page 45: Using The Smart-Cal Calibration Station

    SMART - CAL CALIBRATION USING THE SMART-CAL CALIBRATION STATION From the working display press & hold the MENU BUTTON (B) until the top line reads USER MENU. Scroll with SAVE/ZERO BUTTON (C) until the bottom line reads SMART CAL. Place the instrument into the cradle on the left side of the Smart-Cal Calibration Station.
  • Page 46 FACTORY ADJUSTABLE FEATURES USING THE SMART-CAL CALIBRATION STATION FEATURE RANGE DEFAULT Session Saves /BH Saves 1-15 Extended Memory Uo to 1600 Purge Time 0-30 Seconds 0 Seconds 0-100% by .1% up to 2% increments %LEL (by 0.1%) 0-2000ppm by 1ppm or 10ppm %GAS 0 - 100% Alarm - LEL...
  • Page 47 NOTES ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________...
  • Page 48 WARRANTY Your SENSIT® GOLD 100 is warranted to be free from defects in materials and workmanship for a period of two years after purchase (excluding calibration and batteries). The % gas sensor (TC) is warranted for 5 years. If within the warranty period, your instrument should become inoperative from such defects, the unit will be repaired or replaced at our option.
