Page 1: User Guide
Line Selector USER GUIDE For Technical Assistance call the Manufacturers direct ph 0800 530 8645 8AM - 5PM West Coast Pacific Time NATCOMM USA LLC Responsible Supplier Code : NC... - Page 2 Page 2 Natcomm...
-
Page 3: Packing List
You SHOULD ALWAYS connect your MAIN TELEPHONE LINE (POTS, PSTN or your battery backed Fiber IP) to the LINE 1 port of LINE SELECTOR, so that you can make emergency and other calls in the event that power is lost. Natcomm Page 3... - Page 4 You can 'toggle' between Lines by pressing *. Note: With Model LS1, the other is always 'busied' when one line is in use. This prevents the other line making a call or receiving a call.
- Page 5 Connect the Attached Device to Line 2 so that it can make an Outgoing Call. If Both LINE 1 and LINE 2 are IN USE or NOT CONNECTED, Model LS1 will not be able to connect the Attached Device to Either Line to make an Outgoing Call. The Device will have to re-try at a later time.
- Page 6 ‘On Hold’ and return to the original call by again pressing *. This procedure can be repeated as many times as necessary. Note - The * command for this function is fixed and cannot be changed. Both calls will be terminated whenever you hang up your telephone. Page 6 Natcomm...
-
Page 7: Installation Procedure
12VDC or 12VAC Power Adaptor, which provides a minimum of 300mA. Polarity is not important. Model LS2 Options only 5. Change the Dip Switch Settings (if required) See pages 8-10 for details. 6. Change the Special Programming Options (if required) See pages 8-10 for details. Natcomm Page 7... - Page 8 Machine or Modem, it is recommended that you set Dip Switches 1 & 2 to the ON position. This setting will cause the other line to always be "busy" whenever the DEVICE is in operation (as per Model LS1). The dip switch settings for this application are ;...
-
Page 9: Dip Switch Settings
Switch 1 = ON Switch 2 = ON Switch 3 = ON Switch 4 = ON Note - Dip Switch 1 and Dip Switch 2 must be set to OFF when the Call Advice Facility is enabled (SW4 = ON). Natcomm Page 9... - Page 10 Where x = the required Line Change Delay Time (0-9 seconds). You will hear 1 short beep to confirm this entry. If you hear 2 beeps, you have made an incorrect entry and must re-enter #1. 4. Hang Up. Page 10 Natcomm...
- Page 11 Consult the dealer or an experienced technician for help. Call NATCOMM ph 0800 530 8645 The Power adaptor supplied with the Door Station Controller that powers this product complies with UL (USA) and cUL (Canada) specifications. Natcomm...
-
Page 12: Specifications
Damage caused to this device or attached equipment by lightning strikes or over voltage surge is not covered under this warranty. THE CASE IS SEALED AT THE FACTORY. OPENING THE CASE WILL VOID THE WARRANTY. Page 12 Natcomm...
