The compressor unit has factory installed service valves on the earth loop vapor and liquid stubouts
outside the compressor cabinet.
For the installation of system components requiring refrigeration connections, refer to Figure 6 for line
set sizes and the appropriate installation manual(s) following Figure 6.
LINE SET ADAPTERS REQUIRED FOR THE AIR HANDLER OR CASED COIL ARE FIELD
SUPPLIED. CHECK ALL APPROPRIATE COMPRESSOR UNIT STUB-OUT TUBING SIZES FOR
REQUIRED FIELD SUPPLIED ADAPTERS!
Series AVS and AVV Air Handler
Series CCS Cased Coil
Series HCM Hybrid Cooling Module
Earth Loop Specification and Installation Manual
After installing and nitrogen brazing the HVAC system components, turn the Service Valves to Full
Open and pressurize the refrigeration system to 150 psig with dry nitrogen and a trace of refrigerant.
Valve off the nitrogen Tank from the HVAC system components and check joints with a sensitive
Electronic Leak Detector and bubble solution to ensure they are sealed. Repair any leaks and re-test
as appropriate.
PSC-QS (10/16)
EARTHLOOP, AIR HANDLER, CASED COIL LINE SETS
COMPRESSOR UNIT
SIZE
2.0 Tons (-025)
2.5 Tons (-030)
3.0 Tons (-036)
3.3 Tons (-040)
4.2 Tons (-050)
5.0 Tons (-060)
*Liquid and Vapor lines must BOTH be insulated with Armaflex®
or equivalent with at least 1/2" wall thickness for the full length of
the line set.
Figure 6. Line Set Sizes
LINE SET O.D., INCHES
LIQUID
VAPOR
3/8
5/8
3/8
3/4
1/2
3/4
1/2
3/4
1/2
7/8
1/2
7/8
Page 12
