Installation

Important: This camera should be placed where the WiFi signal is
strong for optimal performance.
①
②
③

Specifications

Image sensor 1/4" CMOS sensor
Min. illumination 0.02Lux @(F2.0,AGG ON),
0 Lux with lR
Shutter time 1/50s to 1/100,000s
Lens 2.4mm F2.0
Angle of view 95°
Video compression H.264
Bit rate Self-adaption
Max. image resolution 1280 x 720
Frame rate 30fps (1280 × 720)
Storage Built-in microSD card slot, up to 32GB
Wireless standards IEEE802.11b/g/n
Frequency range 2.4 GHz ~ 2.4835 GHz
Channel bandwidth 20/40MHz Support
Operating conditions Temperature: -5 °C - 60 °C
(23 °F - 140 °F)
Humidity: < 95% (non-condensing)
Power supply DC 5V 1A
Power consumption 5W MAX
Dimensions (L x W x H) 91 x 78 x 115 mm
