Network Type; Additional Information - Altronix NetWay1DWP Installation Manual

2. Network Setup page will be displayed. You may now configure your NetWay1DWPM/H for network connection.
Fig. 5 -
NETWORK SETTING MENU.
This menu is for configuring the
NetWay1DWPM/H units for a
network connection.
Static IP User can set a fixed IP for network connection.
DHCP DHCP server in LAN will automatically an assign IP configuration for the network connection.
This field shows the NetWay1DWPM/H current IP Address. A static IP address must be set manually.
IP
If DHCP this value will be assigned automatically.
This field shows the subnet mask for your network so the NetWay1DWPM/H will be recognized within
Subnet Mask
the network. If DHCP is selected, this value will be assigned automatically.
Inbound Port Port number for HTTP/WEB communication.
Host Name Name of the NetWay1DWPM/H device on the LAN
1. If using DHCP, all settings will be detected automatically.
While DHCP is a useful tool for determining the network settings, if you set up your NetWay1DWPM/H in this
manner, its IP address may change at different times for different reasons, particularly after a power failure.
If the IP address of the NetWay1DWPM/H changes, you may have difficulties accessing your NetWay1DWPM/H
locally and/or remotely.
It is strongly recommended that you connect via host name when units configured as DHCP.
Please do not set the DHCP address issued to the NetWay1DWPM/H by the router as its static IP address unless you
take specific steps that program your router to prevent such address conflicts.
2. If using a Static IP (recommended), you will need to input the information manually. In order for DDNS to work,
you must enter valid data compatible with your network for all of the network setting fields: IP address,
Subnet Mask, Gateway and Inbound Port.
3. If you are connecting through a router, make sure that you have 'opened up' all the required network ports in the port
forwarding section of your router's setup options. That is, you have directed the router to send any incoming traffic
using those IP ports to the LAN IP address of the NetWay1DWPM/H. Useful information about router port
forwarding can be found at www.portforward.com. Different routers may use different terms for port forwarding
function. For instance, D-Link calls it virtual server, Netopia calls it pinholes.
The default port for NetWay1DWPM/H is: 80
Note: Port 80 is the default port used for web browsing. Because of this, in order to prevent the average user from
hosting a web server, most ISPs BLOCK traffic using port 80 from reaching the average site. If you only plan to
- 4 -
NetWay Network Settings x
192.168.168.168/networksetup.htm
Status Setup Network Settings
NetWay1DWPM
Site ID: Altronix Site ID
Network Settings:
Static
IP Address Method:
192.168.168.168
IP Address:
255.255.255.0
Subnet Mask:
192.168.168.100
Gateway:
80
Inbound Port:
Submit Network Settings
Reboot Server

Network Type:

Additional Information:

Management Interface
®
Trap Receiver Settings:
Trap Receiver Address 1:
Trap Receiver Address 2:
Trap Receiver Address 3:
Trap Receiver Address 4:
Trap Receiver Address 5:
Syslog Settings:
NetWay1DWP/NetWay1DWPH/NetWay1DWPM/NetWay1DWPMH
Version 0.88
Network Settings
Friday, May 16 2014 [11:11 am]
10.10.10.53
10.10.10.76
10.10.10.12
10.10.10.13
10.10.10.14
Submit Trap Receiver IP Settings
Syslog Server IP: 10.10.10.15
100
Syslog Server Port:
Submit Syslog Settings
