1. Document History

Revision Issue Date Reason
2.1.0.0 07-20-2016

2. Overview of the Credential Cam Pro Plus

2.1.

About the Camera

The Credential Cam Pro Plus is a UVC compliant, high-resolution (up to 5MP) USB camera with
autofocus, ideally suited for photo ID badging applications. It provides a quick and easy means of
displaying and capturing high quality video and images on any desktop or laptop computer equipped with
USB 2.0 and running a supported Microsoft, Linux, or Mac OS.
The Credential Cam Pro Plus supports both raw and compressed video output, and is capable of
supporting a single image "snapshot" mode (no frame grabber required) with optional JPEG compression.
Both photo ID camera and accompanying LED flash unit are powered directly by USB port. No external
power supply is needed.
2.2.

Contents

The Credential Cam Pro Plus camera with built-in flash comes with a 10-foot USB mini cable, ¼-20 tripod
mount (attached to camera base), and Demonstration Viewer Installation CD containing USB Viewer
software, TWAIN driver, USB drivers and user manual.

3. Specifications

Image Sensor Size
Video Output
Compression
Data Format
Resolution / Frame rate
Image Control Functions
Exposure
Focus
White Balance
Brightness
Doc # INS-16001
Revision: 2.1.0.0
Initial release
1/4"
USB 2.0
MJPEG / JPEG
YUV 422
Resolution
2592x1944
2048x1536
1920x1080
1600x1200
1280x720
1024x768
800 x 600
640x 480
352x288
320x240
Auto/ Manual
Auto (push to focus)/ Manual
Auto/ Manual
via UVC Interface
Frame Rate
2.5
2.5
5
5
7.5
10
15
30
30
30
CN#16-0072
Issue Date: 07/20/2016
Page 3 of 27
