5.4.

Video Capture Pin

5.4.1. Stream Format

On clicking the Video Capture Pin sub menu from the Options drop-down, a dialog box will open
allowing you to configure the output size and compression features of stream format. The preview
running in the main application will be stopped until the Video Capture Pin dialog box is active. Once
the dialog box is closed preview will start automatically. The available output size and color spaces will
be listed in the combo box. After selecting the required output size and color space, press "Apply" to
configure the changes. Pressing "OK" will start previewing the video stream with newly configured
output size and compression values. At any point in time, you can click "Cancel" to exit the dialog and
start the preview.
The window will be resized to the same size as that of the video stream output format.
The video window height and width reduced/enlarged according to selected output size of video stream
as shown in the figure below.
