SAB SabVision 2300 Quick Start Manual

Network turret camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Network Turret Camera
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SabVision 2300 and is the answer not in the manual?

Questions and answers

Related Manuals for SAB SabVision 2300

Summary of Contents for SAB SabVision 2300

  • Page 1 Network Turret Camera Quick Start Guide...
  • Page 2 Network Turret Camera·Quick Start Guide About this Manual This Manual is applicable to SABVISION 2300 Network Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network Turret Camera·Quick Start Guide Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Network Turret Camera·Quick Start Guide EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
  • Page 5 Network Turret Camera·Quick Start Guide These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 6 Network Turret Camera·Quick Start Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed.
  • Page 7 Network Turret Camera·Quick Start Guide camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation. ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use. ●...

  • Page 8: Table Of Contents

    Network Turret Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 1.1 Type I ................9 1.2 Type II ................10 1.3 Type III ................11 1.4 Type IV ................12 2 Installation ..................14 2.1 Ceiling Mounting ............14 2.1.1 Type I ..............
  • Page 9 Network Turret Camera·Quick Start Guide Guarding Vision Setup ........... 50 Adding Camera to Guarding Vision ........ 50 Initializing the Memory Card ......... 52 0504051070109...

  • Page 10: Appearance Description

    Network Turret Camera·Quick Start Guide 1 Appearance Description This camera series of turret camera has four appearance types. Type I Figure 1-1 Overview of Type I Turret Camera Table 1-1 Description Description Description Trim Ring Camera Enclosure Power Cord 10M/100M self-adaptive Mounting Base Ethernet interface...
  • Page 11 Network Turret Camera·Quick Start Guide Type II Figure 1-2 Overview of Type II Turret Camera Table 1-2 Description Description Description Trim Ring Camera Enclosure Power Cord 10M/100M self-adaptive Mounting Base Ethernet interface...

  • Page 12: Type Iii

    Network Turret Camera·Quick Start Guide Type III Overview of Type III Turret Camera Table 1-3 Description Description Description Audio Output Trim Ring 1-ch Alarm Input and Enclosure 1-ch Alarm Output RST (Reset) Button Mounting Base...

  • Page 13: Type Iv

    Network Turret Camera·Quick Start Guide Description Description Memory Card Slot Camera Power Cord 10M/100M self-adaptive Ethernet interface Note: Press Reset button about 10s when the camera is power on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
  • Page 14 Network Turret Camera·Quick Start Guide Table 1-4 Description Description Description Trim Ring Power Cord 10M/100M self-adaptive Enclosure Ethernet interface (PoE) RST (Reset) Button Mounting Base Memory Card Slot Camera Notes: ● For this type IV camera, the layout of memory card slot and reset button may be different from model to model.

  • Page 15: Installation

    Network Turret Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC, please make sure your power supply matches with your camera.
  • Page 16 Network Turret Camera·Quick Start Guide Rotate the trim ring anticlockwise to take it off from the camera. Separate the camera and the enclosure. ③ Trim Ring ② Camera Lock Screw ① Mounting Base Figure 2-1 Disassemble the Camera Drill the screw holes and the cable hole on the ceiling according to the drill template.
  • Page 17 Network Turret Camera·Quick Start Guide There are two cable outlet methods. One is to route the cables through the cable hole, and the other is to route the cables through the side outlet shown below. Figure 2-3 Side Outlet Three side outlets on the enclosure are selectable, which makes routing the cables easier instead of drilling a cable hole on the ceiling.
  • Page 18 Network Turret Camera·Quick Start Guide Ceiling Figure 2-4 Secure the Mounting to the Ceiling Connect the corresponding power/network cable and then install the camera to the mounting base with the supplied screws. Rotate the camera to secure it. Figure 2-5 Secure the Camera to the Mounting Base Adjust the Lens.
  • Page 19 Network Turret Camera·Quick Start Guide Lock Screw Figure 2-6 Loosen Lock Screw 2). Rotate the enclosure to adjust the pan angle; rotate the camera to adjust the tilt angle. P Direction T Direction R Direction ~ 75 Figure 2-7 Adjust the Lens 3).

  • Page 20: Type Ii

    Network Turret Camera·Quick Start Guide Trim Ring Figure 2-8 Install the Trim Ring 2.1.2 Type II Steps: Disassemble the camera. Rotate the enclosure anticlockwise to take it off from the camera. Separate the camera, the mounting base, and the trim ring.
  • Page 21 Network Turret Camera·Quick Start Guide ② Trim Ring ① Camera Mounting Base Figure 2-9 Disassemble the Camera Drill the screw holes and the cable hole on the ceiling according to the drill template. Figure 2-10 The Drill Template There are two cable outlet methods. One is to route the cables through the cable hole, and the other is to route the cables through the side outlet shown below.
  • Page 22 Network Turret Camera·Quick Start Guide Figure 2-11 Side Outlet Three side outlets on the enclosure are selectable, which makes routing the cables easier instead of drilling a cable hole on the ceiling. Use a plier to remove the plastic and route the cables through the hole.
  • Page 23 Network Turret Camera·Quick Start Guide Connect the corresponding power/network cable. Install the camera along with the enclosure to the mounting base by anticlockwise rotating the camera. Rotate the enclosure to adjust the pan angle; rotate the camera to adjust the tilt angle. P Direction T Direction R Direction...

  • Page 24: Type Iii

    Network Turret Camera·Quick Start Guide 2.1.3 Type III Steps: Disassemble the camera. Rotate the trim ring anticlockwise to take it off from the camera. Rotate the mounting base anticlockwise to take it off from the camera. Separate the camera and the enclosure. Trim Ring ①...
  • Page 25 Network Turret Camera·Quick Start Guide Take off the cover and insert the microSD card into the card slot. microSD Card Figure 2-17 Memory Card Slot Place the cover back. Stick the drill template on the installation place and drill the screw holes and the cable hole on the ceiling according to the drill template.
  • Page 26 Network Turret Camera·Quick Start Guide Figure 2-19 Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. Install the camera along with the enclosure to the mounting base by anticlockwise rotating the camera.

  • Page 27: Type Iv

    Network Turret Camera·Quick Start Guide 360° P Direction 0° to 75° 360° T Direction R Direction Figure 2-21 Adjust the Lens Attach the trim ring to the camera and rotate the trim ring clockwise to get it secured. Trim Ring Install the Trim Ring Figure 2-22 2.1.4 Type IV...
  • Page 28 Network Turret Camera·Quick Start Guide Loosen the fixing screw. Take the mounting base off from the camera and the enclosure. Separate the camera and the enclosure. ① ③ Fixing Screw ② Figure 2-23 Disassemble the Camera Install memory card. Unscrew the memory card slot cover. Insert the memory card.
  • Page 29 Network Turret Camera·Quick Start Guide (Optional) to unmount the memory card, push to get it ejected. Screw the memory card slot cover back. Paste the drill template to desired mounting place. Drill the screw holes (for expansion screws) and the cable hole on the ceiling according to the drill template.
  • Page 30 Network Turret Camera·Quick Start Guide Drill Template Mounting Base Figure 2-26 Fix Mounting Base Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. Install the camera along with the enclosure to the mounting base.

  • Page 31: Mounting With Brackets

    Network Turret Camera·Quick Start Guide Pan: 0° to 360° Rotate: Tilt: 0° to 360° 0° to 75° Figure 2-28 Adjust Surveillance Angle Attach the trim ring to the camera and rotate the trim ring clockwise to get it secured. Install Trim Ring Figure 2-29 Mounting with Brackets This camera series supports mounting with wall mounting bracket...

  • Page 32: Wall Mounting

    Network Turret Camera·Quick Start Guide 2.2.1 Wall Mounting The wall mount is not included in the package. You need to prepare one, if you adopt this mounting type. Steps: Mark the screw holes on desired mounting place. Dimension of Demonstrated Wall Mounting Bracket Figure 2-30 Drill four screw holes with a Φ10 mm drill.
  • Page 33 Network Turret Camera·Quick Start Guide Mounting Base Fix Mounting Base Figure 2-31 Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor. Install the camera and the enclosure to the mounting base, adjust the surveillance angle, and fix the trim ring.

  • Page 34: Pendant Mounting

    Network Turret Camera·Quick Start Guide 2.2.2 Pendant Mounting The pendant mounting bracket is not included in the package. You need to prepare one in advance, if you adopt this mounting type. Steps: Mark the screw holes on desired mounting place. Drill three screw holes for expansion bolts.
  • Page 35 Network Turret Camera·Quick Start Guide Mounting Base Fix Mounting Base Figure 2-34 Screw the cap to the pendant mount. Pendant Mount Install the Cap Figure 2-35 Connect the corresponding power/network cable. Refer to the section 2.3 for the water-proof accessory installation if the camera is installed in the outdoor.

  • Page 36: Network Cable Water-Proof Accessory Installation

    Network Turret Camera·Quick Start Guide Install the camera and the enclosure to the mounting base, adjust the surveillance angle, and fix the trim ring. Refer to corresponding steps in ceiling mounting of each camera type. Pendant Mounting Figure 2-36 Network Cable Water-proof Accessory Installation Purpose: If the camera is installed outdoor, you can adapt the water-proof...
  • Page 37 Network Turret Camera·Quick Start Guide ① ② ③ ④ ⑤ ⑥ ⑦ Figure 2-37 Water-proof Accessory Components Components Table 2-1 Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Steps: Feed the plugless network cable ⑦...
  • Page 38 Network Turret Camera·Quick Start Guide Place the O-type gasket ② onto the end of the camera’s network interface socket ①. Insert the network plug ③ into the camera’s network interface socket①. Insert the water-proof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥...

  • Page 39: Setting The Network Camera Over The Lan

    Network Turret Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 40: Activating The Camera

    Network Turret Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 41: Activation Via Sadp Software

    Network Turret Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 42 Network Turret Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods.

  • Page 43: Modifying The Ip Address

    Network Turret Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 44 Network Turret Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an activate device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
  • Page 45 Network Turret Camera·Quick Start Guide Note: You can enable the Guarding Vision service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Please refer to the User Manual of SADP for details.

  • Page 46: Accessing Via Web Browser

    Network Turret Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 47 Network Turret Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 48: Operating Via Guarding Vision App

    Network Turret Camera·Quick Start Guide 5 Operating via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain camera models. Enable Guarding Vision Service on Camera Purpose: Guarding Vision service should be enabled on your camera before...

  • Page 49: Enable Guarding Vision Service Via Web Browser

    Network Turret Camera·Quick Start Guide “Privacy Policy” Service” Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Guarding Vision Service via Web Browser Before you start:...
  • Page 50 Network Turret Camera·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Guarding Vision dev.guardingvision.com Figure 5-2 Platform Access Configuration (Web) 3.

  • Page 51: Guarding Vision Setup

    Network Turret Camera·Quick Start Guide Guarding Vision Setup Steps: 1. Download and install the Guarding Vision app by searching “Guarding Vision” in App Store or Google Play 2. Launch the app and register for a Guarding Vision user account. 3. Log in Guarding Vision app after registration. Adding Camera to Guarding Vision Before you start: You need to enable the Guarding Vision service on camera before...
  • Page 52 Network Turret Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 53: Initializing The Memory Card

    Network Turret Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
