Summary of Contents for Helmholz REX 100 3G
- Page 1 Quick Start Guide REX 100 3G | LTE Version as of FW 1.5.0 www.helmholz.com...
-
Page 2: Table Of Contents
7. Description of LEDs and buttons 7.1 LED description 7.2 Button description 8. Restoring the REX 100 router to its default settings 9. Load configuration/firmware update from USB stick 10. Technical data 10.1 UL Quick Start Guide REX 100 3G | LTE... -
Page 3: Introduction
IN2: When the alarm management in the device has been activated and configured, e-mails, for example, can be sent through an externally installed button or relay contact. Quick Start Guide REX 100 3G | LTE... -
Page 4: Antenna Connections
For the same reason, the second antenna should be mounted cross-polarized (with reference to the main antenna, 90° to one another). Quick Start Guide REX 100 3G | LTE... -
Page 5: Creating A Rex 100 Configuration In The Myrex24 Portal
Note: Your login name is composed of a user name preceding the @ character and the name of your company. Example: admin@helmholz Other users can be created and administered after you log onto the myREX24 portal. Quick Start Guide REX 100 3G | LTE... -
Page 6: Creating A Router Configuration
REX 100 router's serial number. The purpose of the additional description fi eld is to make it possible to distinguish between several remote servicing units internally. Open the “Network” tab without clicking "Save". Quick Start Guide REX 100 3G | LTE... - Page 7 In the event that the dialog for "Submit to Device" appears automatically, you can cancel this dialog and call it up later when needed. Note: The myREX24 portal’s online help provides information on the function of the advanced settings. Quick Start Guide REX 100 3G | LTE...
-
Page 8: Router Configuration Transfer Options
The configuration is transferred via a local LAN connection of the computer on which shDIALUP is running (see chapter 4.3, page 14). You can use this option if the REX 100 router can be reached directly through the local network (LAN). Quick Start Guide REX 100 3G | LTE... -
Page 9: Transferring The Configuration Using A Usb Flash Drive
"Download to PC" option. Once the file has been stored on the local computer, carry out the steps as described in chapter 9 "Load configuration/firmware update from USB stick" on page 18. Quick Start Guide REX 100 3G | LTE... -
Page 10: Configuration Transfer Manager (Ctm)
In order to be able to reach the REX 100 router, the PC network adapter must also be set to the IP address space and subnet of the router. The device with serial number must be created in the myREX24 portal for successful commissioning. Quick Start Guide REX 100 3G | LTE... - Page 11 Password: router router. To change them, go to the configuration menu on the myREX24 portal. The Internet connection path of the REX 100 is now defined uniquely at the "First Start" website. Quick Start Guide REX 100 3G | LTE...
- Page 12 "CON" LED on the router will start flashing (see LED description, chapter 7, page 18). If a configuration file is available on the portal server, it will be automatically loaded onto the device and enabled. Quick Start Guide REX 100 3G | LTE...
- Page 13 CTM, the icon will be shown in “Device Administration”. Note: In order to establish a VPN connection with the REX 100, please read Chapter 5, page 15. Quick Start Guide REX 100 3G | LTE...
-
Page 14: Transferring The Configuration Using A Local Lan Connection
The transfer will start if a device with the right serial number is found. Once the transfer is complete, the REX 100 router will start using the new confi guration after being restarted. Quick Start Guide REX 100 3G | LTE... -
Page 15: Establishing A Vpn Connection To Your Rex 100
TCP ports (80, 1194, or 443) required for the VPN tunnel must more credit for prepaid SIM cards. be open. - The required outbound TPC address is 5.39.123.5 Quick Start Guide REX 100 3G | LTE... -
Page 16: Remotely Servicing An Ethernet Plc
The SNAT function should be enabled under "General Firewall Settings" so that you will be able to reach devices in which a gateway IP has not been entered. This function is always enabled in myREX24 configurations. Quick Start Guide REX 100 3G | LTE... - Page 17 As soon as a VPN connection to the REX 100 unit has been established (see chapter 5, page 15), you can start working with the PLC from the project (e.g., transferring a hardware project, monitoring variables, etc.). Quick Start Guide REX 100 3G | LTE...
-
Page 18: Description Of Leds And Buttons
Reset button for restarting the router Note: Once the configuration file has been successfully transferred, the file will auto- matically be renamed “Xmyrex24.mbn", making it impossible to accidentally reuse it a second time. Quick Start Guide REX 100 3G | LTE... -
Page 19: Technical Data
-40 °C … +85 °C Humidity 0 to 95 %, non-condensing 0 to 95 %, non-condensing Location of use Dry location Dry location Protection rating IP20 IP20 Certifications CE, UL CE, UL Quick Start Guide REX 100 3G | LTE... - Page 20 1) Windows is a registered trademark of the Microsoft Corporation. 2) SIMATIC and STEP 7 are registered trademarks of Siemens AG. Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany | Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.com...
