(F2): GLITCH capture.

Glitch

RESET
F1
查询"381285"供应商
The Glitch key sets the meter to trigger a measurement on any single event which
causes an overrange indication or is greater than one vertical division or is greater
than 10% of one horizontal division.
The F1 RESET key will trigger a new measurement. "SEARCHING" will appear on
the display until a pulse arrives that triggers the event.
The F2 and F3 arrow keys adjust the time per division and trigger a new
measurement.
The F4 EXIT key returns the screen to the "More" menu.
Pulse must exceed 10% of one time division

Position

(F3): POSITION
RESET
F1
The POSITION key adjusts the vertical position of the waveform.
The F1 RESET key sets the vertical position cursor to the default 0 position.
The F2 and F3 arrow keys adjust the vertical position of the waveform.
The F4 EXIT key returns the screen to the "More" menu.
▲ ▼ EXIT
F2 F3 F4
Trigger Point
▲ ▼ EXIT
F2 F3 F4
