TOURBEAM MC60WB
BEDIENUNGSANLEITUNG
FÜR LED21400
TOURBEAM MC60WB
USER MANUAL
FOR LED21400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOURBEAM MC60WB and is the answer not in the manual?

Questions and answers

Summary of Contents for Expolite TOURBEAM MC60WB

  • Page 1 TOURBEAM MC60WB BEDIENUNGSANLEITUNG FÜR LED21400 TOURBEAM MC60WB USER MANUAL FOR LED21400...
  • Page 2: Technische Daten

    PRODUKTEIGENSCHAFTEN TECHNISCHE DATEN Spannung 100-240V AC @ 50/60Hz Leistungsaufnahme 110 Watt Betriebstemperatur 0 bis 40° Schutzklasse IP 20 Breite 250 mm Tiefe 210 mm Höhe 340 mm Gewicht 6,50 kg FEATURES MENÜ UP/HOCHBLÄTTERN KOPF ENTER DOWN/RUNTERBLÄTTERN SPANNUNGSVERSORGUNG DMX 5-PIN EINGANG DMX 3-PIN EINGANG SICHERUNGSHALTER DMX 3-PIN AUSGANG...
  • Page 3 SICHERHEITSHINWEISE LESEN SIE VOR DER INBETRIEBNAHME IMMER DIE BEDIENUNGS- ANLEITUNG. STELLEN SIE SICHER, DASS DER AM GERÄT ANGEGE- BENE WERT FÜR DIE NETZSPANNUNG DEM DER VERSORGUNGS- SPANNUNG VOR ORT ENTSPRICHT. Dieses Produkt darf nur von qualifiziertem Fachpersonal installiert werden. Arbeiten am Gerät dürfen nur von qualifizierten Servicekräften vorgenommen werden.
  • Page 4 SCHUTZ GEGEN FREMDKÖRPER UND WASSER Für Geräte mit Schutz gegen Fremdkörper und Wasser nach IP-Code Die Schutzart eines Gerätes wird anhand genormter Prüfverfahren festgestellt. Zur Einordnung der Schutzart wird der IP-Code be- nutzt. Dieser setzt sich aus den Buchstaben IP und zwei Kennzif- fern zusammen.
  • Page 5 TEMPORÄRER BETRIEB Grundsätzlich ist Veranstaltungsequipment immer für den vorübergehenden Einsatz konzipiert, der einer repräsentativen Anwendung für Eventbeleuchtung entspricht. Hierzu zählen Kon- zerte, Festivals, Einsätze in Spielstätten wie Theatern, Clubs und Diskotheken oder vergleichbare Venues. Ein Dauerbetrieb, besonders unter Außenbedingungen oder eine dauerhafte bauliche Anbringung im Außenbereich kann zu Einschränkungen in der Funktion sowie vorzeitiger Ermüdung der Dichtungen, Kabel und Oberflächenbeschichtung führen.
  • Page 6: Installation

    INSTALLATION BEFESTIGUNG SICHERUNGSSEIL SCHELLE HÄNGEND: Das Gerät kann an dem Haltebügel hängend QUICKLOCK montiert werden. Hierzu muss BRACKET eine geeignete Befestigung wie eine Traversenschelle benutzt werden. Bitte achten Sie auf geltende Vorschriften zur Sicherung wie das Anschlagen eines Sicherungsseiles. STEHEND: Das Gerät kann direkt auf dem Basement stehend betrieben werden.
  • Page 7: Sicherung Wechseln

    SICHERUNG WECHSELN ACHTUNG! NUR SICHERUNGEN MIT DEN AUF DEM GERÄT ANGEGEBENEN WERTEN BENUTZEN! DIE SICHERUNG NIEMALS DURCH HÖHERE WERTE ERSETZEN ODER ÜBERBRÜCKEN! LEBENSGEFAHR! 1. Den Sicherungshalter mit einem Schraubendreher öffnen. 2. Die alte Sicherung aus der Kappe entfernen. 3. Die neue Sicherung in die Kappe einsetzen. 4.
  • Page 8: Bedienung

    DISPLAYMENÜ BEDIENUNG Menu: Weiter zum nächsten Menü. Enter: Auswahl des aktuellen Punktes. MENU Scrollen durch das Menü oder DOWN ENTER erhöhen von Werten. Down: Scrollen durch das Menü oder senken von Werten MENÜSTRUKTUR ADRESS 001-512 MENÜ PERSON HSIC PERSON 1 PERSON 2 PERFORM FANS...
  • Page 9 STAND ALONE DM 512 AUTO 1 AUTO 2 CUSTOM TEST SLAVE EDIT STEP (01-50) 00 - 255 TILT 00 - 255 00 - 255 GREEN 00 - 255 BLUE 00 - 255 WHITE 00 - 255 DIMMER 00 - 255 STROBE 00 - 25 ZOOM...
  • Page 10 PERFORMANCE EINSTELLUNGEN MENÜ PERFORM FANS SLOW NORMAL FAST AUTO PAN/TILT PAN INVERT NORMAL INVERT TILT INVERT NORMAL INVERT PT SPEED FAST SLOW BLACKOUT DIMMER DIM 4 DIM 3 DIM 2 DIM 1 COLOUR RGB TO W DMX ERROR SAVE BLACK DMX RESET DISPLAY DISPLAY ON...
  • Page 11 DMXERROR: SAVE/BLACK legt das Verhalten bei Verlust des DMX- Signals fest. DMXRESET: DMX/DISPLAY legt fest ob der Reset-Befehl über DMX akzeptiert wird. DISPLAY ON: LONG/SHORT/DISPLAY LOCK legt fest ob und nach welcher Zeit das Gerätedisplay abgeschaltet wird. UPLOAD: LOAD PARA/LOAD EDIT lädt die Geräteeinstellungen oder die benutzerdefinierten Programme über XRL-Kabel angeschlossene Geräte.
  • Page 12: Service-Menü

    Hinweis: Für weniger als 50 Schritte muss die Time des letzten Schrittes auf 0 gesetzt werden. Beispiel für Time-Settings eines Stand-Alone Programmes mit 3 Schritten Step 1 Time = 4 Use = Yes Step 2 Time = 5 Use = Yes Step 3 Time = 0 Use = Yes INFO-MENÜ...
  • Page 13 STEUERUNG MIT DMX512 KONTROLLERN KANALBELEGUNG HSIC DMX-KANAL WERT FUNKTION 0ó255 PAN FiNE 0ó255 0ó255 TILT TILT FINE 0ó255 PT SPEED 0ó255 CONTINIOUS PAN STOP 1ó127 CLOCKWISE ROTATION SLOW TO FAST 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 INTENSITY 0ó255 0ó255 HUE FINE 0ó255...
  • Page 14 DMX-KANAL WERT FUNKTION AUTO 1 70ó79 80ó89 AUTO 2 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET 120ó129 NO FUNCTION DIM 0 130ó139 140ó149 DIM 1 DIM 2 150ó159 DIM 3 160ó169 DIM 4 170ó179 180ó255 NO FUNCTION...
  • Page 15 PERSON 1 DMX-KANAL WERT FUNKTION 0ó255 0ó255 PAN FiNE TILT 0ó255 TILT FINE 0ó255 0ó255 PT SPEED CONTINIOUS PAN STOP 1ó127 CLOCKWISE ROTATION SLOW TO FAST 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 0ó255 GREEN 0ó255 BLUE WHITE 0ó255 0ó255 DIMMER MARCOS...
  • Page 16 DMX-KANAL WERT FUNKTION CONTROL 0ó9 NO FUNCTION 10ó19 PAN/TILT BLACK ACTIVATED 20ó29 PAN/TILT BLACK DEACTIVATED 30ó39 FAN AUTO 40ó49 FAN SLOW 50ó59 FAN NORMAL 60ó69 FAN FAST AUTO1 70ó79 80ó89 AUTO2 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET NO FUNCTION 120ó129 130ó139 DIM0 140ó149...
  • Page 17 PERSON 2 DMX-KANAL WERT FUNKTION 0ó255 0ó255 PAN FiNE TILT 0ó255 TILT FINE 0ó255 0ó255 PT SPEED CONTINIOUS PAN STOP 1ó127 CLOCKWISE ROTATION SLOW TO FAST 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 0ó255 RED FINE 0ó255 GREEN GREEN FINE 0ó255 0ó255 BLUE...
  • Page 18 DMX DMX-KANAL WERT FUNKTION ZOOM 0ó255 CONTROL NO FUNCTION 0ó9 10ó19 PAN/TILT BLACK ACTIVATED 20ó29 PAN/TILT BLACK DEACTIVATED 30ó39 FAN AUTO 40ó49 FAN SLOW FAN NORMAL 50ó59 60ó69 FAN FAST 70ó79 AUTO1 80ó89 AUTO2 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET NO FUNCTION 120ó129 130ó139...
  • Page 19 DMX-KANAL WERT FUNKTION 0ó255 PAN FiNE 0ó255 0ó255 TILT TILT FINE 0ó255 PT SPEED 0ó255 CONTINIOUS PAN STOP CLOCKWISE ROTATION SLOW TO FAST 1ó127 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 CYAN MAGENTA 0ó255 0ó255 YELLOW 0ó255 DIMMER MACROS 0ó9 NO FUNKTION 10ó29...
  • Page 20 DMX-KANAL WERT FUNKTION CONTROL 0ó9 NO FUNCTION 10ó19 PAN/TILT BLACK ACTIVATED 20ó29 PAN/TILT BLACK DEACTIVATED FAN AUTO 30ó39 40ó49 FAN SLOW 50ó59 FAN NORMAL 60ó69 FAN FAST 70ó79 AUTO1 AUTO2 80ó89 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET 120ó129 NO FUNCTION 130ó139 DIM0 140ó149...
  • Page 21: Product Specifications

    PRODUCT SPECIFICATIONS TECHNICAL SPECIFICATION voltage 100-240V AC @ 50/60Hz power consumption 110 Watt operation temperature 0 bis 40° protection class IP 20 width 250 mm depth 210 mm height 340 mm weight 6,50 kg FEATURES MENÜ HEAD ENTER DOWN SIDE ARM POWER INPUT DMX 5-PIN SIGNAL INPUT DMX 3-PIN SIGNAL INPUT...
  • Page 22: Safety Warnings

    SAFETY WARNINGS This product must be installed by a qualified professional. All maintenance must be carried out by a qualified electrician. A minimum distance of 0.5 m must be maintained between the equipment and a combustible surface. The product must always be operated in a well ventilated area. DO NOT stare directly into the LED light source.
  • Page 23: Protection Against Solids And Water

    PROTECTION AGAINST SOLIDS AND WATER Only for IP-rated fixtures The protection level of a housing is set by apllied standards. For classification there is used the IP-Code. It contains the declaration „IP“ and two following numbers. The first number charaterises the protection against harmful effects of solids, the second is rating the waterprotection.
  • Page 24 TEMPORARY USE Eventequipment is designed for temporary use. This are typical purpose as concerts, festivals, theatre, clubs and disco use and referable venues. Longterm use, specially under outdoorconditions and fixed out- door installation can bring damage in aging materials and affect the coated surface.
  • Page 25 INSTALLATION MOUNTING SAFETY CABLE CLAMP HANGING: The fixture can be mounted in a hanging position using the supporting bracket. BRACKET The bracket should be secured to the mounting truss or struc- ture using a standard mount- ing clamp. Please note that when hanging the unit a safety cable should also be used.
  • Page 26: Fuse Replacement

    FUSE REPLACEMENT 1. Remove the safety cap by a screwdriver. 2. Fetch the old fuse from safety cap. 3. Install a new fuse. 4. Install the safety cap. FUSE SAFTY CAP POWER CONNECTIONS 220~240V: 13 units may be connected in series 110~120V: 7 units may be connected in series NOTE! If the signal cable is over 60 m between the DMX512 controller...
  • Page 27: Display Panel Operation

    DISPLAY PANEL OPERATION DISPLAY OPERATION Menu: back Enter: enter MENU DOWN ENTER Down: down MENU MAP ADRESS 001-512 MENU PERSON HSIC PERSON 1 PERSON 2 PERFORM FANS SLOW NORMAL FAST AUTO PAN/TILT PAN INVERT NORMAL INVERT TILT INVERT NORMAL INVERT PT SPEED FAST SLOW...
  • Page 28: Dmx 512 - Settings

    STAND ALONE DM 512 AUTO 1 AUTO 2 CUSTOM TEST SLAVE EDIT STEP (01-50) 00 - 255 TILT 00 - 255 00 - 255 GREEN 00 - 255 BLUE 00 - 255 WHITE 00 - 255 DIMMER 00 - 255 STROBE 00 - 25 ZOOM...
  • Page 29 PERFORM SETTINGS MENU PERFORM FANS SLOW NORMAL FAST AUTO PAN/TILT PAN INVERT NORMAL INVERT TILT INVERT NORMAL INVERT PT SPEED FAST SLOW BLACKOUT DIMMER DIM 4 DIM 3 DIM 2 DIM 1 COLOUR RGB TO W DMX ERROR SAVE BLACK DMX RESET DISPLAY DISPLAY ON...
  • Page 30 adjusted and the output is most powerful. When UC is selected, the RGB output are adjusted to a standard preset universal color which balances fixtures from different generations. DMXERROR menu, select SAVE to maintain last command in case of DMX error or BLACK for blackout.
  • Page 31 Note: if user want to circulate the created steps, please set the last steps Time as 0. For example, there are 3 steps, the setting should be like belowed: Step 1 Time = 4 Use = Yes Step 2 Time = 5 Use = Yes Step 3 Time = 0 Use = Yes...
  • Page 32: Using A Dmx512 Controller

    USING A DMX512 CONTROLLER CHANNEL ASSIGNMENT HSIC DMX-CHANNEL VALUE FUNCTION 0ó255 PAN FiNE 0ó255 0ó255 TILT TILT FINE 0ó255 PT SPEED 0ó255 CONTINIOUS PAN STOP 1ó127 CLOCKWISE ROTATION SLOW TO FAST 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 INTENSITY 0ó255 0ó255 HUE FINE...
  • Page 33 DMX-CHANNEL VALUE FUNCTION AUTO 1 70ó79 80ó89 AUTO 2 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET 120ó129 NO FUNCTION DIM 0 130ó139 140ó149 DIM 1 DIM 2 150ó159 DIM 3 160ó169 DIM 4 170ó179 180ó255 NO FUNCTION...
  • Page 34 PERSON 1 DMX-CHANNEL VALUE FUNCTION 0ó255 0ó255 PAN FiNE TILT 0ó255 TILT FINE 0ó255 0ó255 PT SPEED CONTINIOUS PAN STOP 1ó127 CLOCKWISE ROTATION SLOW TO FAST 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 0ó255 GREEN 0ó255 BLUE WHITE 0ó255 0ó255 DIMMER MARCOS...
  • Page 35 DMX-CHANNEL VALUE FUNCTION CONTROL 0ó9 NO FUNCTION 10ó19 PAN/TILT BLACK ACTIVATED 20ó29 PAN/TILT BLACK DEACTIVATED 30ó39 FAN AUTO 40ó49 FAN SLOW 50ó59 FAN NORMAL 60ó69 FAN FAST AUTO1 70ó79 80ó89 AUTO2 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET NO FUNCTION 120ó129 130ó139 DIM0 140ó149...
  • Page 36 PERSON 2 DMX-CHANNEL VALUE FUNCTION 0ó255 0ó255 PAN FiNE TILT 0ó255 TILT FINE 0ó255 0ó255 PT SPEED CONTINIOUS PAN STOP 1ó127 CLOCKWISE ROTATION SLOW TO FAST 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 0ó255 RED FINE 0ó255 GREEN GREEN FINE 0ó255 0ó255 BLUE...
  • Page 37 DMX-CHANNEL VALUE FUNCTION ZOOM 0ó255 CONTROL NO FUNCTION 0ó9 10ó19 PAN/TILT BLACK ACTIVATED 20ó29 PAN/TILT BLACK DEACTIVATED 30ó39 FAN AUTO 40ó49 FAN SLOW FAN NORMAL 50ó59 60ó69 FAN FAST 70ó79 AUTO1 80ó89 AUTO2 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET NO FUNCTION 120ó129 130ó139 DIM0...
  • Page 38 DMX-CHANNEL VALUE FUNKTION 0ó255 PAN FiNE 0ó255 0ó255 TILT TILT FINE 0ó255 PT SPEED 0ó255 CONTINIOUS PAN STOP CLOCKWISE ROTATION SLOW TO FAST 1ó127 128ó254 COUNTERCLOCKWISE ROTATION FAST TO SLOW STOP 0ó255 CYAN MAGENTA 0ó255 0ó255 YELLOW 0ó255 DIMMER MACROS 0ó9 NO FUNKTION 10ó29...
  • Page 39 DMX-CHANNEL VALUE FUNCTION CONTROL 0ó9 NO FUNCTION 10ó19 PAN/TILT BLACK ACTIVATED 20ó29 PAN/TILT BLACK DEACTIVATED FAN AUTO 30ó39 40ó49 FAN SLOW 50ó59 FAN NORMAL 60ó69 FAN FAST 70ó79 AUTO1 AUTO2 80ó89 90ó99 CUSTOM 100ó109 TEST 110ó119 RESET 120ó129 NO FUNCTION 130ó139 DIM0 140ó149...
  • Page 40 WWW.EXPOLITE-LED.DE...
