CONPROSYS
M2M Gateway for PLC
Multi-Function 3G OPC UA
CPS-MG341G-ADSC1-930
Hardware Manual
CONTEC CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPS-MG341G-ADSC1-930 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Contec CPS-MG341G-ADSC1-930

Summary of Contents for Contec CPS-MG341G-ADSC1-930

  • Page 1 CONPROSYS M2M Gateway for PLC Multi-Function 3G OPC UA CPS-MG341G-ADSC1-930 Hardware Manual CONTEC CO., LTD.
  • Page 2 To the customer Before using the product, visit our website to check the firmware version and be certain to use the latest one.

  • Page 3: Check Your Package

    Check Your Package Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List - Product [CPS-MG341G-ADSC1-930]…1...
  • Page 4 No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 5: Table Of Contents

    Cable Connection ..........................21 Power............................21 LAN (LAN A, LAN B) ......................21 RS-422A/485(COM A) ......................22 RS-232C (COM B)........................25 Analog Input (AI) ........................26 Digital/Counter Input (DI/CNT) ....................27 Digital Output (DO) ........................30 Software Setup ..........................31 CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 6 Counter function ......................... 42 Digital Filter ..........................43 System Reference Specifications ............................ 45 Power Requirements........................48 Physical Dimensions ........................49 Physical Dimensions (Antenna) ....................49 Antenna Steerable Range ......................50 Standard SIM size ........................50 List of Optional Products CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 7: Before Using The Product

    RS232C, LAN interface, Ethernet Hub and 3G network communication module. CPS-MG341G-ADSC1-930 contains OPC UA server function within. This product can communicate directly with HMI and SCADA software that support OPC UA clients from various makers. The product is the data collector M2M Gateway for PLC that supports respective PLCs as well as various Modbus devices.

  • Page 8: Software Features

    - Web Task Script By combining icons such as arithmetic operations, conditional branching, data outputting, you can set up the executions or its processes like drawing them in the flowchart. All operations can be completed on the Web browser. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 9: How To Use

    10 links and transmit or receive messages. Message communication can be accomplished from Web task script. How to use Visit our website for the CPS-MG341 system setup guide. (http://www.contec.com) Model details CPS - MG 3 4 1 G - ADSC1 - 9 3 0...

  • Page 10: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note: For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited Two-Year Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 11: Safety Precautions

    When using the product at high altitudes, refer to the relational expression below to find an appropriate ambient temperature. The heat dissipation decreases due to air pressure drop and could lead to damages or a shorter product life. -Ambient temperature = 60[°C] - 0.005 x altitude [m] CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 12 - Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (Including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein.
  • Page 13 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 14 These ingredients may cause hazardous conditions for human and the environment. the chapter 5 Please refer to for the specification as well as how to remove and dispose the batteries. Display of power (Input Rating Label) DC power supply Functional earth terminal Functional earth terminal CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 15: Setup

    Reconfirm that you have correctly followed steps 1 to 5. Then, turn on the power. If you find some errors or abnormalities after turning on the power, turn it off immediately and check whether the set-up has been properly performed. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 16: Switch Setup

    [A or D] Terminator Terminator (1 bit) (1 bit) Use the terminator Set the terminator outside inside [B or C] When not using the terminator neither inside nor outside Figure 2.1. Half duplex connection (Party line connection) CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 17: Rs-422A/485 Full Duplex Setup

    See the examples of terminator installation below for full duplex setting. - Full-duplex Terminator (1 bit) Terminator (2 bit) Use the terminator Set the terminator inside outside Terminator (2 bit) Terminator (1 bit) Figure 2.2. Full-duplex connection CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 18: Antenna Setup

    Set the supplied antenna to the antenna connector of the product. Turn the antenna in the direction of the arrow shown to fasten. Figure 2.3. Antenna setup CAUTION Double-check whether the antenna has firmly fastened and securely connected. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 19: How To Place And Remove The Sd Cover

    Figure 2.4. Placing the SD Cove Figure 2.5. After placing the SD Cover How to remove Reverse the placing procedure. (1) Unfasten the screw. (2) Slide the SD cover in the opposite direction of the arrow 2 to remove it. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 20: Inset Sim Card

    Upon inserting the card, make certain that the terminal side is facing up. Please use a Standard SIM card with this product. Do not use a Micro or Nano size SIM card with an adapter to make it as a Standard SIM card. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 21: Installation

    (2) Hook the product on the upper part of the DIN rail, and press it to the lower side of the DIN rail. Figure2.7. Mounting on a DIN Rail < 2 / 3 > (3) Push the fixing hooks up with a slotted screwdriver to lock. Figure2.7. Mounting on a DIN Rail < 3 / 3 > CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 22 Figure 2.8. Removing the product from the DIN Rail < 2 / 3 > (3) By lifting the product, you can easily remove it from the DIN rail. Figure 2.8. Removing the product from the DIN Rail < 3 / 3 > CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 23: Installation Onto The Wall

    Appropriate screws (fit into φ3.5 hole) are required to install the product on the wall. The commercial screws can be purchased individually. Figure 2.9. Installation onto the wall CAUTION Tightening torque should be carefully controlled according to the wall on which you are installing CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 24: Installation Conditions

    Mount the product in the orientations shown below. Other orientations could cause problems in use such as malfunctions due to inadequate heat dissipation. DIN rail fixation Vertical installation (0°) Figure 2.10. DIN rail fixation Screws fixation Vertical installation (0°) Figure 2.11. Screws fixation CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 25 Long-term usage might increase the temperature and lead to malfunctions or other troubles. When using the product in a high temperature environment, its life time will be shorten. Perform the forced air cooling to counteract. CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 26 - Do not leave any metal pieces around the antenna. - Do not install the product outside of the communication area of the carrier. When communication failures or quality deterioration occurs, use the antenna listed in the optional product in chapter 5. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 27: Cable Connection

    This product is designed to operate at least with 15watt power supply. In addition, the power supply must fulfill the following requirements. Rising time for up to 12 voltage: 2 milliseconds up till 30 milliseconds Recommended power supply is CPS-PWD-15AW12-01(by CONTEC). CAUTION Tightening torque of the attached connector is 0.25N·m.

  • Page 28: Rs-422A/485(Com A)

    See the table below for the baud rate that you can set with this product. Table 2.4. Baud Rate List Baud Rate(bps) Error (%) 0.00 0.00 0.00 1,200 0.00 2,400 0.00 4,800 0.00 9,600 0.16 14,400 0.16 19,200 0.16 28,800 0.16 38,400 0.16 57,600 0.16 115,200 0.16 CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 29 If you find the problems, remove the grounding of the shield. About a caution mark on the product: Please use copper wires that tolerate the temperature of 75 degrees Celsius and higher. CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 30 Communication with the external Communication with the external device of Half Duplex. device of Full Duplex. TX+ TX- RX+ RX - TX+ TX- RX+ RX- RX+ RX- TX+ TX- － External Device External Device Figure 2.16. Wiring Specifications CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 31: Rs-232C (Com B)

    (Clear to Send) (Data Terminal Ready) (Data Set Ready) (Signal Ground) External device Figure 2.17. Example Connection to a Mode External device Figure 2.18. Example Connection to a PC External device Figure 2.19. Example Connection to a Device CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 32: Analog Input (Ai)

    Both the [+] input and [-] input terminals not connected Signal source, please be connected to the analog ground. About a caution mark on the product: Please use copper wires that tolerate the temperature of 75 degrees Celsius and higher. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 33: Digital/Counter Input (Di/Cnt)

    Figure 2.21. Digital/Counter Input Circuit (Corresponded to current sink output). Examples of connecting the product to an external device This Product A_COM Input pin External Souce type output Power Supply B_COM Figure 2.22. Connecting the Input to the sink type output CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 34 Figure 2.23. Digital/Counter Input Circuit (Corresponded to current source output). Examples of connecting the product to an external device This Product A_COM Input pin External Souce type output Power Supply B_COM Figure 2.24. Connecting the Input to the sink type output CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 35 Figure 2.25 Digital/Counter Input Circuit (Corresponded to current sink output) Examples of connecting the product to an external device This Product +12V Input pin Sink type output B_COM Figure 2.26 Connecting the Input to the sink type output CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 36: Digital Output (Do)

    The corresponding LED will be lit up when you output “1” into the appropriate bit. The corresponding LED will be turned off when you output “0” into the appropriate bit. Figure 2.28. Example of connection to the LED CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 37: Software Setup

    For wiring, strip off approximately 7mm (plus or minus 0.5mm) of the covered part of a wire rod to use. About a caution mark on the product: Please use copper wires that tolerate the temperature of 75 degrees Celsius and higher. Software Setup Visit our website for the CPS-MC341system setup guide (http://www.contec.com). CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 38 2 Setup CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 39: Unit Nomenclature And Function

    ⑭ ⑮ ⑯ Figure 3.1. CPS-MG341G-ADSC1-930 1. Power Connector: Use the 3-pin connector, included in this package. 2. Antenna Connector: Use the supplied connector or optional one listed in the chapter 5. 3. SIM Slot: It is a slot for inserting SIM card.

  • Page 40: Component Function

    Figure 3.2. Antenna Connector CAUTION To follow the regulation by the Radio Act, use only the supplied antenna or optional one listed in the chapter 5 SIM Slot It is a slot for inserting SIM card of the standard size. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 41: 3G Led

    The product has 1 port of USB interface of TYPE-A. Table 3.3. USB Connector Signal Name Pin No. USB_VCC DATA- DATA+ USB_GND CAUTION If you use the USB device with bus power, the ambient temperature should be 55 °C or less. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 42: Rs-232C Interface (Com B)

    Signal Pin No. Meaning Direction name Carrier detection Input Received data Input Transmitted data Output Data terminal ready Output Signal ground ----- Data set ready Input Request to send Output Clear to send Input Ring Indicate Input CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 43: Led Indicator

    DO0-DO1 (Yellow) It indicates there is no outputting. It will light up upon measuring. AI0-AI1(Yellow) It indicates there is no measuring. Reset Switch This resets the product. Shut Down Switch This shuts down OS of the product. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 44: Dip Switch (Sw1, Sw2)

    Turn off SW No.2 and 3, and go to “Reboot/Shutdown” in Status menu. Choose “Reboot”, then click the “start” button. *2: This initializes all other settings. Check whether PWR and ST1’s LED are both flashing upon booting. Turn off SW No.2 and 3, then, press the “RESET” button on the left side of the product. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 45: Lan Port (Lan A, Lan B)

    Indicates that LAN port is not connected. CAUTION HUB mode of this product might be slower than other standard switching HUB products. If a large amount of data and/or high-speed response is requested, an external switching HUB will be required. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 46: Isolated Digital Input/Counter Input/Digital Output Connector (Di0, Di1/Di2, Di3 (Cnt0, Cnt1) /Do0, Do1)

    (-) from the other devices This indicates the output signals (+). It connects the input DO1+ signals (+) from the other devices This indicates the output signals (-). It connects the input DO1- signals (-) from the other devices CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 47: Inter-Channel Isolated Analog Input Connecter (Ai0, Ai1)

    Use the connector, included in the package. Attached Connector type: DEGSON 15EDGK-3.5-05P-14-1000AH (or equivalent) Table 3.12. RS-422A/485 Connector Pin No. Signal Name Meaning Transmission data (+) Transmission data ( Reception data (+) Reception data ( Signal ground CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 48: Other Function

    Compare the count value of a corresponding channel with the compare register value. If these two values match, it is possible either to cause an interrupt. This register can be set to any value from 0h to FFFFFFh. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 49: Digital Filter

    1µsec 10 (0Ah) 128µsec 17 (11h) 16.384msec 4 (04h) 2µsec 11 (0Bh) 256µsec 18 (12h) 32.768msec 5 (05h) 4µsec 12 (0Ch) 512µsec 19 (13h) 65.536msec 6 (06h) 8µsec 13 (0Dh) 1.024msec 20 (14h) 131.072msec *1: Default setting CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 50 To pass input signal without gail, the pulse width should be twice larger than setting filter time. A digital filter doesn't work effectively if the filter time is set (setting data: 1-10) shorter than the opto- coupler response time. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 51: System Reference

    Baud Rate 300 - 115.2kbps Isolation Non-isolated Data length 5, 6, 7, 8 bits 1, 1.5, 2 stop bits RS-232C Parity check Even, Odd, Non-parity The number of channels Connector 9-pin D-SUB Connector (Male) Transmission (Yellow), Reception (Yellow) CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 52 The sampling interval differs by the software programmed by the user. Analog Input Data buffer None Resolution 12bit Non-Linearity error *5 ±10LSB Isolation Bus isolation/500VDC, Inter Channel Isolation/200V Connector 2-piece 3.5mm pitch 3pin Terminal (AI+, AI-, SG) Applicable wire AWG28 – 16 AI0 - AI1(Yellow) CPS-MG341G-ADSC1-930 Hardware Manual...
  • Page 53 Table 4.2 Wireless Specification Item CPS-MG341G-ADSC1-930 Support SIM MVNO SIM SIM slot Standard SIM Communication method 3G (UMTS) Wireless frequency Band1(2100MHz), Band2(1900MHz), Band5(850MHz), Band6(800MHz), (domestic support exclusively) Band8(900MHz), Band19(800MHz) Upload Maximum 384kBit/s Communication speed Download Maximum 384kBit/s CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 54: Power Requirements

    When you restart the power, give the product for at least one second (or more) of the power OFF time. When you use with the CPS-PWD-15AW12-01 (by CONTEC), instantaneous voltage drop allowed time will be 20 millisecond or less. CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 55: Physical Dimensions

    12-24V DC Half F ull Half F ull Isolated R S -422A/485 LAN A LAN B DI/CNT COM A （154） 4-3.5 [mm] Figure 4.1. Physical dimensions (CPS-MG341G-ADSC1-930) Physical Dimensions (Antenna) 9.5±0.3 1/4-36UNS-2B 10±0.3 Figure4.2. Antenna physical dimensions CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 56: Antenna Steerable Range

    4 System Reference Antenna Steerable Range 180° 360° Rotation Figure4.3. Antenna steerable range Standard SIM size 15mm Figure4.4. Standard SIM size CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 57: List Of Optional Products

    15[w] (Input: 100-240VDC, Output: 12VDC 1.3A) SD Card - SD-2GB-B : SD card 2GB 3G Antenna - CPS-ANT-R3-01: Antenna (Cable length: 3 meters) *Information regarding the optional products, see the Contec website. (http://www.contec.com) CPS-MG341G-ADSC1-930 Hardware Manual...

  • Page 58: Revision History

    3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [04212017] [04212017] Management No. NA05608 Parts No.
