Reference Manual
(Hardware)
M2M Gateway for PLC Multi-Function 3G OPC UA
CPS-MG341G-ADSC1-930
CONTENTS
Introduction .................................................................. 5
Safety Precautions .................................................... 14
Product Nomenclature and Function ............... 23
Setup ............................................................................. 40
Installation ................................................................... 49
Appendix ...................................................................... 75
Optional Products .................................................... 87
Customer Support and Inquiry ............................ 89
Index .............................................................................. 91

Advertisement

Table of Contents
loading

Related Manuals for Contec CONPROSYS CPS-MG341G-ADSC1-930

Summary of Contents for Contec CONPROSYS CPS-MG341G-ADSC1-930

  • Page 1 Reference Manual (Hardware) M2M Gateway for PLC Multi-Function 3G OPC UA CPS-MG341G-ADSC1-930 CONTENTS Introduction ..............5 Safety Precautions ............ 14 Product Nomenclature and Function ....23 Setup ................40 Installation ..............49 Appendix ..............75 Optional Products ............ 87 Customer Support and Inquiry ......89 Index ................

  • Page 2: Table Of Contents

    Table of Contents Introduction ............... 5 1. Related Manuals ..............................6 2. Check the Firmware Version ..........................7 3. About the Product ..............................8 4. Interface Within ............................... 9 5. Features ................................... 10 1. Hardware features ............................10 2. Software Features ............................11 6.
  • Page 3 Table of Contents 1. Set Data Transfer Mode ............................ 41 1. RS-422A/485 ..............................41 2. Set Antenna ................................44 3. Insert SD Card ............................... 45 4. Inset SIM Card............................... 47 Installation ................ 49 1. Install the Product ............................... 50 1. Installation Conditions ..........................50 2.
  • Page 4 Table of Contents Index .................. 91 — 4 —...

  • Page 5: Introduction

    Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. — 5 —...

  • Page 6: Related Manuals

    (Printed matter) package. and describes the precautions. Setup Manual Download from Read this when setting up the This describes the required items for the Contec product. setup and configuration procedure. website (PDF) Reference Manual Download from Read this when operating the...

  • Page 7: Check The Firmware Version

    Before start using the product, visit our website to check the firmware version and update to the latest one if necessary. Updating firmware to the latest version will resolve troubles and stabilize the operation. https://www.contec.com/download/ Download Refer to the "Reference Manual (Software)" for the details of the firmware updating.

  • Page 8: About The Product

    — — Introduction CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. About the Product This product is a M2M controller with isolated RS-422A/485, isolated digital input/output, isolated input counter, inter-channel isolated analog input, RS-232C, LAN interface, and 3G network communication module. It is equipped with the ARM®Cortex®-A8 processor (600MHz) and the 512MB DDR3-SDRAM system memory.

  • Page 9: Interface Within

    — — Introduction CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 4. Interface Within This product is a M2M controller with the following interfaces. SD Card Analog Output Analog Input Digital Input Digital Output Slot ［Current］ ［Current］ 3GSIM Analog Output Analog Input Counter RS-422A/485 RS-232C (Standard SIM) ［Voltage］...

  • Page 10: Features

    — — Introduction CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 5. Features 1. Hardware features  The product contains I/O interface such as digital I/O, analog input, counter, and serial communication. RS-232C: 1-channel, RS-422A/485: 1-channel, Opto-coupler isolation input (compatible with current sink output): 4-channel, Semiconductor relay output: 2-channel, Bus isolation analog input (current input): 2-channel.

  • Page 11: Software Features

    The product has LED for an operation check, which helps you visually confirm the communication status of each interface.  No electrolytic capacitor No electrolytic capacitor is used. The Contec is creating the product with a longer life. 2. Software Features ...
  • Page 12 — — Introduction CPS-MG341G-ADSC1-930 Reference Manual (Hardware)  Measurement and Upload CPS-MG341G-ADSC1-930 uploads measured data of a sensor and also collected data from PLC to the Cloud server.  Web Monitoring The product contains a web server function. Even with the PC located remotely, I/O information can be monitored and updated through a Web browser On the monitoring screen, the standard GUI parts (graphic, slider, button, etc.) can be freely arranged.

  • Page 13: Product Configuration List

    Conformity…1 *This product is verified in conformity with our recommended power supply. In case you use other power supplies, thus, it may not be able to fulfil certification requirements. Please see the Contec website regarding power supply recommendation (https://www.contec.com/). *The type of connectors in the package differs depending on the period of manufacturing.

  • Page 14: Safety Precautions

    Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. — 14 —...

  • Page 15: Safety Information

    — — Safety Precautions CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 16: Handling Precautions

    — — Safety Precautions CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 2. Handling Precautions DANGER Do not use the product in locations exposed to a flammable or corrosive gas. It may cause  explosion, fire, electrical shock, or malfunction. Do not allow the device to come into contact with foreign substances (metal particles, ...
  • Page 17 When removing connectors or cables, always unplug the power cables and confirm the LEDs  are turned off. Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting  from modifying the product. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ...
  • Page 18 Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever  (Including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein.
  • Page 19 Lors du dépôt de connecteurs ou de câbles, toujours débrancher les câbles d’alimentation de  l’unité centrale et confirmer la mise hors tension des DEL. Ne pas modifier le produit. CONTEC ne pourra être tenue responsable de tout problème, etc.,  issu de la modification du produit.
  • Page 20 Lors d’un fonctionnement du produit sans interruption, s’assurer de lire le manuel du site Web CONTEC et d’assimiler le contenu. Lorsque le produit est utilisé à un endroit influencé par une surintensité ou une surtension ...

  • Page 21: Fcc Part15 Subpart B Class A

    — — Safety Precautions CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. FCC PART15 Subpart B Class A NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 22: Battery Handling And The Storage In Eu Signatory

    — — Safety Precautions CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. Battery handling and the storage in EU signatory This symbol mark is for EU countries only. This symbol mark is according to the directive 2006/66/EC Article 20 Information for end-users and Annex II.

  • Page 23: Product Nomenclature And Function

    Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. — 23 —...

  • Page 24: Nomenclature Of Product Components

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. Nomenclature of Product Components Component names of the product are shown in the figure below. RS - 232 C C OM B 12-24VDC Iso late d R S - 42 2A /48 5 LAN A LAN B DI/CNT...
  • Page 25 — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Name Function RS-422A/485 Connector This is a connector for RS-422A/485 communication. (Use the 5-pin connector included in the package) — 25 —...

  • Page 26: Description Of Product Components

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 2. Description of Product Components Components such as connectors, switches are described. 1. Power Connector Use the 3-pin connector, included in the package, to connect to external power. Connector type: DEGSON 15EDGK-3.5-03P-14-1000AH (or equivalent) *The type of connectors in the package differs depending on the period of manufacturing.

  • Page 27: Sim Card Slot

    15 - 21 10 - 14 Flashing 0 - 9 Disconnected 5. Debug Connector Do not use this. 6. SD Card Slot Insert the SD card to store such as data. *Use the Contec SD card "SD-4GB-A (4GB)". — 27 —...

  • Page 28: Usb Port

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 7. USB Port The product has 1 port of USB interface of TYPE-A. Pin Assignment Pin No. Signal Name USB_VCC DATA- DATA+ USB_GND CAUTION If you use the USB device with bus power, the ambient temperature should be 55 °C or lower. ATTENTION Si vous utilisez le dispositif USB avec alimentation par bus, la température ambiante devrait être de 55 °C ou moins.

  • Page 29: Rs-232C Serial Port

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 8. RS-232C Serial Port This product has 1port of RS-232C compliant serial interface. The baud rate is 115,200bp (Max) 9-pin D-SUB (Male) No.4-40UNC inch nut Pin Assignment Pin No. Signal Name Direction Description Input...

  • Page 30: Led Indicator

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 9. LED Indicator Status of the product is indicated by ON/OFF and flashing of LED. The meaning of each LED is described below. Color and Description Color Display Description Green ON Power has been supplied.

  • Page 31: Dip Switch

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 12. DIP switch SW1, SW2 DIP switch for system setup and RS-422A/485 setup of COM A. The factory default of all switches are set to “OFF”. R S-232 C C O M B 2 3 4 1 2 3 4 5 6 DIP Switch...

  • Page 32: Lan Port

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 13. LAN Port This product has 2 ports of Ethernet LAN Port. The LAN ports are independent, which makes it possible to split the network segment. Network type: 100BASE-TX/10BASE-T Transmission speed: 100M/10Mbps Maximum network path length: 100m/segment Speed Link /Act...
  • Page 33 — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) CAUTION If a large amount of data or high-speed response is requested, an external switching HUB will be required. ATTENTION En présence d’un volume élevé de données ou lorsqu’une réponse haute vitesse s’avère nécessaire, il faudra un concentrateur de commutation externe.

  • Page 34: Digital Input / Counter Input / Digital Output Connecter

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 14. Digital Input / Counter Input / Digital Output Connecter This product has 4 channels of digital Input and 2 channels of digital output. You can switch DI2 and DI3 to counter input and operate them. Use the 10-pin connector included in the package.

  • Page 35: Analog Input Connecter

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 15. Analog Input Connecter This product has 2 channels of analog input that supports isolated inter-channel. Use the 3-pin connector, included in the package, to connect to external power. Connector type: DEGSON 15EDGK-3.5-03P-14-1000AH (or equivalent) *The type of connectors in the package differs depending on the period of manufacturing.

  • Page 36: Rs-422A/485 Connector

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 16. RS-422A/485 Connector This product has 1 port of RS-422A/485 communication. Use the 5-pin connector, included in the package, to connect to external power. Connector type: DEGSON 15EDGK-3.5-05P-14-1000AH (or equivalent) *The type of connectors in the package differs depending on the period of manufacturing.

  • Page 37: Other Functions

    — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. Other Functions 1. Counter function When a pulse is input, the product performs incremental counting at the falling edges of input pulse. Input pulse Internal data Count value  Compare Register Compare the count value of a corresponding channel with the compare register value.
  • Page 38 — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) The signal level remains the same over the digital filter setting time, the digital filter recognizes that signals as normal and changes the filter output signal level. Digital Filter Setting Time Set the digital filter time to 0 - 20 (14h).
  • Page 39 — — Product Nomenclature and Function CPS-MG341G-ADSC1-930 Reference Manual (Hardware) CAUTION The digital filter applies to all input channels; it cannot apply to only specific input pins.  To pass input signal without fail, the pulse width should be twice or larger than setting filter ...

  • Page 40: Setup

    Setup This section describes how to set switches and an antenna that are necessary to operate the product. — 40 —...

  • Page 41: Set Data Transfer Mode

    — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. Set Data Transfer Mode With the DIP switch (SW1, SW2), data transfer mode can be changed (half-duplex or full-duplex). Set the data transfer mode in accordance with a device which you are connecting to. 1.
  • Page 42 — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) DIP Switch Bit No. ON/OFF Description Enable the TX Terminator Disable the TX Terminator Enable the RX Terminator Disable the RX Terminator Internal connection state of TX+ and RX+: Short (Half Duplex) Internal connection state of TX+ and RX+: Open (Full Duplex) Internal connection state of TX- and RX-: Short (Half Duplex) Internal connection state of TX- and RX-: Open (Full Duplex) RTS Communication Mode: Half Duplex...
  • Page 43 — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Terminator(Bit 1) Terminator(Bit 2) This Product External Device Terminator(Bit 2) Terminator(Bit 1) Use the terminator inside Set the terminator outside 2 3 4 1 2 3 4 5 6 2 3 4 1 2 3 4 5 6 DIP Switch Bit No.

  • Page 44: Set Antenna

    — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 2. Set Antenna Set the supplied antenna to the antenna connector. Turn the antenna in the direction of the arrow shown to fasten. CAUTION Double-check whether the antenna has been securely fastened and connected. —...

  • Page 45: Insert Sd Card

    — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. Insert SD Card Unfasten the screw of the cover. (Card cover is attached to the product upon shipping). Slide the card cover to remove it. With the chipped edge of the SD card is in the position shown below, insert the card all the way into the slot.
  • Page 46 — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Fasten with a screw. *Reverse the procedure described in the "Insert SD card "to remove the card. — 46 —...

  • Page 47: Inset Sim Card

    Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 4. Inset SIM Card SIM card is required individually. Visit the Contec website to find the compatible card with the product. https://www.contec.com/ Website Unfasten the screw of the cover. (Card cover is attached to the product upon shipping).
  • Page 48 — — Setup CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Insert the catch of the card cover into the opening shown in the figure below. Catch Fasten with a screw. *Reverse the procedure described in the "Insert SIM card "to remove the card. —...

  • Page 49: Installation

    Installation This section describes how to mount the product on a DIN rail or on the wall, and to connect to an external device with a cable. — 49 —...

  • Page 50: Install The Product

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. Install the Product 1. Installation Conditions  Installation Orientation Install the product in the orientations shown below (0 °C). Other orientations may cause problems such as malfunctions due to inadequate heat dissipation. DIN rail Mounting Wall Mounting Operating ambient temperature should be between -20 °C and +55 °C when the product is installed...
  • Page 51 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware)  Ambient Temperature The ambient temperature is decided from the multiple measurement points which are a 50mm- distance from the product. During the operation, adjust the air current to make certain that the temperatures measured in the points stay within the specified temperature.
  • Page 52 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) ATTENTION Remarquez que même si la température ambiante se situe dans la plage de température  spécifiée, une défaillance opérationnelle peut survenir si un autre appareil à proximité émet beaucoup de chaleur. Le rayonnement influence la hausse de température du produit. N’installez pas le produit dans un espace entièrement scellé...

  • Page 53: Mounting On/Removing From A Din Rail

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 2. Mounting on/Removing from a DIN Rail  How to Mount Pull down the hooks to unlock. If the hooks are stuck, use a slotted screwdriver to unlock. Fixed hooks (1). Hang the product on the upper part of the DIN rail. (2).
  • Page 54 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware)  How to Remove Pull down the hooks to unlock. If the hooks are stuck, use a slotted screwdriver to unlock. Fixed hooks (1). With the hooks unlocked, pull the lower part of the product toward you. (2).

  • Page 55: Mounting On The Wall

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. Mounting on the Wall Appropriate screws (fit into φ3.5 hole) are required to install the product on the wall. The commercial screws can be purchased individually. Get the screws fit into φ3.5 hole and set the product.

  • Page 56: Connecting To An External Device

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 2. Connecting to an External Device Use the supplied connector plug to connect the product to an external device. The following example describes how to make the connecting cable with a 3-pin connector. Connection Cable The supplied connector...
  • Page 57 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) ATTENTION Ne tirez pas sur le câble de la fiche du connecteur pour retirer la fiche, vous risquez de briser  le fil. Saisissez toujours le connecteur pour le retirer. Le couple de serrage pour le connecteur fourni est indiqué ci-dessous. ...

  • Page 58: Cable Connection

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. Cable Connection 1. Power  Power Cable Use the power cable described below. Cable Twisted pair cable (when using a single wire, twist V+ wire and V- wire) Cable AWG24 - 16 (0.2mm - 1.25mm Diameter Cable Length Within 3 meters...

  • Page 59: Lan

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) If the maximum output current of the external power supply is smaller than the maximum  consumption current of the product, the abnormal operations might occur due to the inrush current at the start-up time or the load fluctuation. The aging external power supply could cause a start-up failure About a caution mark on the product: Please use copper wires that tolerate the...

  • Page 60: Rs-422A/485

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. RS-422A/485  RS-422A/485 Cable Use the RS-422A/485 cable described below. Cable Twisted pair cable with the shield Cable AWG28 - 16 (0.08mm - 1.25mm Diameter Cable Length Affected by the communication speed (baud rate) between the product and the external device.
  • Page 61 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware)  Baud Rate See the table below for the baud rate that can be set with the product. Error rate differs depending on the set baud rate. Baud Rate (bps) Error (%) 0.00 0.00 0.00 1,200...
  • Page 62 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Connecting to an external device Connect the product in accordance with the specification of the external device. RS-422A/485 5-pin connector TX+ TX－ RX+ RX－ SG External device －  Full Duplex Full duplex needs three or more sets of twisted-pair. Two sets are for a signal line, other free line(s) is (are) for the signal ground (SG).
  • Page 63 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Connecting to an external device Connect the product in accordance with the specification of the external device. RS-422A/485 5pin-connector TX+ TX－ RX+ RX－ SG External device RX+ RX－ TX+ TX－  Notes on the Shield Connection Ground the shield to the frame ground (FG) of the external device.
  • Page 64 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) ATTENTION Ne tirez pas sur le câble de la fiche du connecteur pour retirer la fiche, vous risquez de briser  le fil. Saisissez toujours le connecteur pour le retirer. Le couple de serrage pour le connecteur fourni est indiqué ci-dessous. ...

  • Page 65: Rs-232C

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 4. RS-232C  RS-232C Cable When using an RS-232C interface, different cables are required depending on the type of device to which you are connecting (computer or modem, etc.). Check the requirements of the external device and select either a straight-through or crossed (null modem) cable as appropriate.
  • Page 66 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Example Connection to a Device External device  Baud Rate See the table below for the baud rate that can be set with the product. Error rate differs depending on the set baud rate. Baud Rate (bps) Error (%) 0.00...

  • Page 67: Analog Input

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 5. Analog Input  Analog Input Cable Use the Analog Input cable described below Cable Use copper wires that tolerate the temperature of 75 °C and higher. Cable Diameter AWG28 - 16 Cable Length Within 20 meters.
  • Page 68 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Connect both the [+] input and the [-] input terminals that are not connected to signal source  to the analog ground. About a caution mark on the product : Please use copper wires that tolerate the ...

  • Page 69: Digital Input/Counter Input

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 6. Digital Input/Counter Input  Digital Input/Counter Input Cable Use the Digital Input/Counter Input cable described below. Cable Use copper wires that tolerate the temperature of 75 °C and higher. Cable Diameter AWG28 - 16 Cable Length The length differs depending on the actual use environment.
  • Page 70 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Connecting the Input to the sink type output (Connecting to an external device) This Product A_COM Input pin External Power Supply Sink type output B_COM Corresponded to current source output Connecting Switch External device This Product Minus A_COM...
  • Page 71 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Input equivalent circuit (When the product using the built-in power supply) Corresponded to current sink output Connecting Switch External device This Product +12V Input Switch Opto-coupler Input Switch Opto-coupler B_COM Connecting the Input to the sink type output (Connecting the product to an external device) This Product +12V Input pin...

  • Page 72: Digital Output

    — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 7. Digital Output  Digital Output Cable Use the Digital Output cable described below Cable Use copper wires that tolerate the temperature of 75 °C and higher. Cable Diameter AWG28 - 16 Cable Length The length differs depending on the actual use environment.
  • Page 73 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Example of connecting to the LED The corresponding LED lights up when you output "1" into the appropriate bit. The corresponding LED turns off when you output "0" into the appropriate bit. Output pin (+) External power 5.1kΩ...
  • Page 74 — — Installation CPS-MG341G-ADSC1-930 Reference Manual (Hardware) ATTENTION Ne tirez pas sur le câble de la fiche du connecteur pour retirer la fiche, vous risquez de briser  le fil. Saisissez toujours le connecteur pour le retirer. Le couple de serrage pour le connecteur fourni est indiqué ci-dessous. ...

  • Page 75: Appendix

    Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. — 75 —...

  • Page 76: Specifications

    — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. Specifications 1. Specifications Function Specifications Item Description ARM Cortex-A8 600MHz Memory On Board 512MB DDR3 SDRAM On-Board 64MB NOR Flash for OS Transmission standard 10BASE-T/100BASE-TX The number of channels 2 *1 Connector RJ-45 Connector Speed (Yellow), Link/Act (Green) RS-422A/485...
  • Page 77 — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Item Description Connector 9-pin D-SUB connector (Male) Transmission (Yellow), Reception (Yellow) Digital input Input type Opto-coupler Isolation Input (Compatible with current sink Counter input output and current source output) (negative logic) *2 Isolation/Resistance Bus Isolation /500VDC, Inter Channel Isolation /1000V External circuit power 12 - 24 VDC (±10%)
  • Page 78 — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Item Description Maximum input rating 30mA Input impedance 250Ω The number of channels Current Input 2ch Channel switching rate 3msec/ch (Max.) *5 Conversion rate The sampling interval differs by the software programmed by the user. Data buffer None Resolution...
  • Page 79 — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) *8 Commercial screws are required (fit into φ3.5 hole). Wireless Specification Item Description Support SIM MVNO SIM SIM slot Standard SIM Communication method 3G (UMTS) Wireless frequency Band1 (2100MHz), Band2 (1900MHz), Band5 (850MHz), Band6 (800MHz), Band8 (900MHz), Band19 (800MHz) Maximum Output Power 23 dBm...

  • Page 80: Power Requirements

    Quand vous remettez le courant, laissez le produit hors tension pendant au moins une  seconde (ou plus) du délai hors tension. Lorsque vous utilisez le produit avec CPS-PWD-15AW12-01 (de CONTEC), le délai permis de  chute instantanée de tension sera de 20 millisecondes ou moins.

  • Page 81: Physical Dimensions

    — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 2. Physical Dimensions 1. Product RS-232C COM B 3G ANT 3G LED 12-24VDC Half F ull Half F ull Isolated R S-422A/485 LAN A LAN B DI/CNT DO0 DO1 COM A (154) 4-φ3.5 [mm] 2.

  • Page 82: Standard Sim Size

    — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 4. Standard SIM size 15mm — 82 —...

  • Page 83: The Details Of Model Name

    — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 3. The Details of Model Name Details of the model name are described below. CPS - MG 3 4 1 G - ADSC 1 - 9 3 0 CONPROSYS Series Item Description Model Gateway Integrated Type Model ARM Cortex A8 Memory...

  • Page 84: Connector Check

    — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 4. Connector Check The maker of connectors in the package or embedded in the product differs depending on the period of manufacturing. The maker and types of the connectors can be checked by the color. Maker, Type CAUTION See the table below for maker, type, and tightening torque value of the connectors to check and...
  • Page 85 — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Vérification du connecteur Selon la période de fabrication, le fabricant des connecteurs de l’emballage ou intégré au produit varie. Il est possible de confirmer le fabricant et les types de connecteur par la couleur. le nom du fabricant et le type ATTENTION Consultez le tableau ci-dessous pour connaître le fabricant, le type de connecteur et le couple de...

  • Page 86: Battery Disposal

    — — Appendix CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 5. Battery Disposal 1. Battery Specification The battery details are as follows: Item Description Type Lithium primary battery Model BR2330A/HD Maker Panasonic Nominal Voltage Nominal Volume 255mAh 2. How to remove the battery When disposing of the product, follow the instruction below and remove the battery.

  • Page 87: Optional Products

    Optional Products This section lists optional items that can be used along with the product. — 87 —...

  • Page 88: Optional Products

    (Input: 100-240VDC, Output: 12VDC 1.3A) SD Card SD-4GB-A SD card (4GB) Magnet CPS-MAG01-4 Magnet (Four Piece Set) 3G Antenna CPS-ANT-R3-01 Antenna (Cable length: 3 meters) Visit the Contec website for the latest optional products. https://www.contec.com/ Website — 88 —...

  • Page 89: Customer Support And Inquiry

    Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. — 89 —...

  • Page 90: Services

    — — Customer Support and Inquiry CPS-MG341G-ADSC1-930 Reference Manual (Hardware) 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services.
  • Page 91 Index — 91 —...
  • Page 92 — — Index CPS-MG341G-ADSC1-930 Reference Manual (Hardware) Revision History MONTH YEAR Summary of Changes July 2017 The First Edition April 2018 Changed the layout of the manual. September 2018 Additional information was listed due to some parts change. — 92 —...
  • Page 93 CONTEC CO., LTD. 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CPS-MG341G-ADSC1-930 Reference Manual (Hardware) NA05608 (LYUY185) 08302019_rev5 [07072017]...
