Filters must have a weigh 7 - 11 g, with those weighing 10 - 11 g performing the best.
Outside this range, the filter will decrease gimbal performance. DJI MFT 15mm f/1.7 ASPH
supports filters have a size of 46mm. The Balancing Ring must be installed on the camera
lens when a filter is not used.
Attach the Zenmuse X5
Ensure to power off the aircraft.
1. Rotate the Gimbal Lock to the unlocked position.
2. Align the key on the damping plate with the slot on the gimbal's pan motor.
3. While aligning the white lines on the Gimbal Connector and Gimbal Lock, insert the Gimbal Connector.
4. Rotate the Gimbal Lock to the locked position.
1
Be careful not to damage the Gimbal Connector and its metal contacts when attaching or storing
the Zenmuse X5.
INSPIRE 1 PRO User Manual
2
3
©
2016 DJI. All Rights Reserved.
4
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inspire 1 Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji Inspire 1 Pro

Summary of Contents for dji Inspire 1 Pro

  • Page 1 Filters must have a weigh 7 - 11 g, with those weighing 10 - 11 g performing the best. Outside this range, the filter will decrease gimbal performance. DJI MFT 15mm f/1.7 ASPH supports filters have a size of 46mm. The Balancing Ring must be installed on the camera lens when a filter is not used.
  • Page 2 INSPIRE 1 PRO User Manual Attaching 1345T Quick-Release Propellers Following the steps below to attach the 1345T Quick-Release propellers. 1. Pair the propellers and motors with arrows of the same color (red or white). Propeller Lock Rotate the propeller lock until...

  • Page 3: Aircraft Diagram

    INSPIRE 1 PRO User Manual Aircraft Diagram Propeller (P20) Motor Front LED (P14) Landing gear Gimbal and Camera (P37) Intelligent Flight Battery (P20) [10] [11] Aircraft Micro-USB Port Rear LED (P14) Camera Micro-USB Port [10 ] [11 ] Camera Micro-SD Card Slot (P38)
  • Page 4 Circular LED around the RTH button displays RTH status. [16] [17] [18] [19] [10] Camera Settings Dial Turn the dial to adjust camera settings. Only functions when the remote controller is connected to a mobile device running the DJI GO app. [15] [10] [11]...
  • Page 5 Aircraft This chapter describes the features of the Flight Controller, Vision Positioning System and the Intelligent Flight Battery. © 2016 DJI. All Rights Reserved.

  • Page 6: Flight Controller

    Use the Flight Controller mode switch to change the flight mode of the aircraft, refer to the “Flight Mode Switch” on P29 for more information. Flight Status Indicator The Inspire 1 Pro comes with the Front LED, Rear LED and Aircraft Status Indicator. The positions of these LEDs are shown in the figure below: Aircraft Status Indicator...

  • Page 7: Aircraft Status Indicator Description

    Using the RTH button on the remote controller (refer to “RTH button” on P30 for more information) or the RTH button in the DJI GO app when GPS is available to enables smart RTH. The aircraft return to the latest recorded Home Point, you may control the aircraft's orientation to avoid collision during the Smart RTH.
  • Page 8 Low Battery RTH The low battery level failsafe is triggered when the DJI Intelligent Flight Battery is depleted to a point that may affect the safe return of the aircraft. Users are advised to return home or land the aircraft immediately when these warnings are shown.
  • Page 9 (65 feet) radius of the Home Point. Aircraft cannot avoid obstruction during the Failsafe RTH, therefore it is important to set an reasonable Failsafe altitude before each flight. Launch the DJI GO app and enter “Camera” view and select “MODE” to set the Failsafe altitude.

  • Page 10: Vision Positioning System

    DJI Vision Positioning is a positioning system that uses ultrasonic and image data to help the aircraft identify its current position. With the help of Vision Positioning, your Inspire 1 Pro can hover in place more precisely and fly indoors or in other environments where there is no GPS signal available. The main components of DJI Vision Positioning are located on the bottom of your Inspire 1 Pro, including [1]two sonar sensors and[2]one monocular camera.
