Page 1 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference Cisco IOS XR Software Release 3.7.1 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883...
Page 2 OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY. The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
Page 3: Obtaining Documentation And Submitting A Service Request
Obtaining Documentation and Submitting a Service Request For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at: http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html...
Page 4 Preface Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-iv OL-17228-01...
Page 5 Bidirectional Forwarding Detection Commands on Cisco IOS XR Software This module describes the commands used to configure and monitor Bidirectional Forwarding Detection (BFD). Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-1 OL-17228-01...
Page 6 Command History. Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 7 RP/0/RP0/CPU0:router(config)# router static RP/0/RP0/CPU0:router(config-static)# address-family ipv4 unicast 2.2.2.0/24 3.3.3.3 bfd fast-detection Related Commands Command Description bfd fast-detect Enables BFD for communication failure detection. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-3 OL-17228-01...
Page 8 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 9 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 10 RP/0/RP0/CPU0:router(config-bgp-nbr)# remote-as 2 RP/0/RP0/CPU0:router(config-bgp-nbr)# bfd fast-detect Related Commands Command Description bfd minimum-interval Sets the BFD interval. bfd multiplier Sets the BFD multiplier. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-6 OL-17228-01...
Page 11 Router configuration Interface configuration Area configuration Router PIM interface configuration mode Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-7 OL-17228-01...
Page 12 RP/0/RP0/CPU0:router(config-bgp)# bfd minimum-interval 275 Related Commands Command Description bfd fast-detect Enables BFD for communication failure detection. bfd multiplier Sets the BFD multiplier. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-8 OL-17228-01...
Page 13 Command History. Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 14 RP/0/RP0/CPU0:router(config-bgp)# bfd multiplier 2 Related Commands Command Description bfd fast-detect Enables BFD for communication failure detection. bfd minimum-interval Sets the BFD interval. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-10 OL-17228-01...
Page 15 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 16 Command Description bfd fast-detect Enables BFD for communication failure detection. bfd minimum-interval Sets the BFD interval. bfd multiplier Sets the BFD multiplier. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-12 OL-17228-01...
Page 17 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 18 Enables and disables IPv4 uRPF checking on an IPv4 interface. source reachable-via ipv6 verify unicast Enables and disables loose IPv6 uRPF checking on an IPv6 interface. source reachable-via show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-14 OL-17228-01...
Page 19 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 20 Enables and disables IPv4 uRPF checking on an IPv4 interface. source reachable-via ipv6 verify unicast Enables and disables loose IPv6 uRPF checking on an IPv6 interface. source reachable-via show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-16 OL-17228-01...
Page 21 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 22 IPV4 Sessions Up: 0, Down: 1, Standby: 0, Total: 1 Related Commands Command Description bfd fast-detect Enables BFD for communication failure detection. bfd minimum-interval Sets the BFD interval. bfd multiplier Sets the BFD multiplier. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-18 OL-17228-01...
Page 23 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 24 Command Description bfd fast-detect Enables BFD for communication failure detection. bfd minimum-interval Sets the BFD interval. bfd multiplier Sets the BFD multiplier. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-20 OL-17228-01...
Page 25 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 26 Command Description bfd fast-detect Enables BFD for communication failure detection. bfd minimum-interval Sets the BFD interval. bfd multiplier Sets the BFD multiplier. show bfd Displays BFD information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-22 OL-17228-01...
Page 27 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 28 Dest Addr Local det time(int*mult) State Echo Async -------------------- --------------- ---------------- ---------------- --------- PO0/1/0/0 10.0.0.2 300ms(100ms*3) 6s(2s*3) IPv6: ----- Interface Dest Addr Local det time(int*mult) State Echo Async Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-24 OL-17228-01...
Page 29 Discriminator received from the corresponding remote system. This field • reflects back the received value of My discr, or is zero if that value is unknown. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-25 OL-17228-01...
Page 30 Desired interval—Desired interval provided by the client, in milliseconds. • Multiplier—Multiplier value provided by the client. • Related Commands Command Description bfd fast-detect Enables BFD for communication failure detection. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-26 OL-17228-01...
Page 31 Bidirectional Forwarding Detection Commands on Cisco IOS XR Software show bfd session Command Description bfd minimum-interval Sets the BFD interval. bfd multiplier Sets the BFD multiplier. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-27 OL-17228-01...
Page 32 Bidirectional Forwarding Detection Commands on Cisco IOS XR Software show bfd session Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-28 OL-17228-01...
Page 33 Diagnostics Commands on Cisco IOS XR Software This module describes the commands used to manage diagnostics on a router running Cisco IOS XR software. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-29 OL-17228-01...
Page 34 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 35 Displays the current bootup level configured for the specified location. bootup level show diagnostic Displays test information including test ID, test attributes, and supported content coverage test levels for each test and for all components. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-31 OL-17228-01...
Page 36 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 37 Please wait for UUT image downloading ... diagnostic load in progress. Related Commands Command Description diagnostic unload Unloads a diagnostic test. show platform Displays information and status of each node in the system. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-33 OL-17228-01...
Page 38: Diagnostic Monitor
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 39 Related Commands Command Description show diagnostic Displays test information including test ID, test attributes, and supported content coverage test levels for each test and for all components. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-35 OL-17228-01...
Page 40 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 41 Displays test information including test ID, test attributes, and supported content coverage test levels for each test and for all components. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-37 OL-17228-01...
Page 42 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 43 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 44 Related Commands Command Description show diagnostic Displays test information including test ID, test attributes, and supported content coverage test levels for each test and for all components. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-40 OL-17228-01...
Page 45 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 46 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 47: Diagnostic Schedule
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 48 RP/0/RP0/CPU0:router# admin RP/0/RP0/CPU0:router(admin)# configure RP/0/RP0/CPU0:router(admin-config)# diagnostic schedule location 0/0/CPU0 test all daily 12:30 Related Commands Command Description show diagnostic Displays the diagnostic schedule for a specified location. schedule Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-44 OL-17228-01...
Page 49: Diagnostic Start
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 50 Diagnostics Commands on Cisco IOS XR Software diagnostic start Related Commands Command Description diagnostic stop Stops a diagnostic test. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-46 OL-17228-01...
Page 51 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 52 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 53 If a ping does not receive a response before the configured timeout expires, the ping statistics reflect it as a discrepancy between the “Sent:” and “Rec'd:” packet count, and the test is considered failed. Because of this, Cisco recommends that you do not set the timeout to 0.
Page 54: Table Of Contents
The following example shows a ping to a control Ethernet node that has a problem or does not exist: RP/0/RP0/CPU0:router# admin RP/0/RP0/CPU0:router(admin)# ping control-eth location 0/1/CPU0 count 3 Src node: 0/RP0/CPU0 Dest node: 0/1/CPU0 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-50 OL-17228-01...
Page 55: Local Node
Destination node has MAC addr 5246.4800.0011 Running CE node ping. Please wait... Src: 529:, Dest: 17, Sent: 3, Rec'd: 0, Mismatched: 0 Requested ping failed for node: 17 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-51 OL-17228-01...
Page 56 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 57 DIAGNOSTICS RESULTS: ENTRY 1: 0 TIMESTAMP: 00/00/0000 00:00:00 VERSION: v0.0 PARAM1: 0 PARAM2: n/a TESTNUM: 0 RESULT: 0 (PASS) ERRCODE: 0 ENTRY 2: 0 TIMESTAMP: 00/00/0000 00:00:00 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-53 OL-17228-01...
Page 58 VID: CLEI: CNUIAWWAAA Node State : OK SPA 0/0/4 : 4-port OC48/STM16 POS/RPR Shared Port Adapter MAIN: board type 0470 68-2227-01 rev C0 dev N/A S/N JAE1211BBEC Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-54 OL-17228-01...
Page 59 • • Cisco PCA hardware and revision number. revision for the specified node. for the specified node. CLEI CLEI for the specified node. for the specified node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-55 OL-17228-01...
Page 60 Field Descriptions (continued) Field Description Board State Current software on the board (in this case, Cisco IOS XR software) and whether or not the board is running. Information about the following PLD components on the current module: Processor •...
Page 61 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 62 RP/0/RP0/CPU0:router(admin)# show diagnostic bootup level location 0/1/cpu0 Current bootup diagnostic level for LC 0/1/CPU0: minimal Related Commands Command Description diagnostic bootup Specifies the diagnostic bootup level. level Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-58 OL-17228-01...
Page 63 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 64: Fabric
Specifies the test failure threshold. diagnostic schedule Schedules a diagnostic test. diagnostic start Runs specified diagnostic tests for the number of iterations set by the diagnostic ondemand iterations command. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-60 OL-17228-01...
Page 65 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 66 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 67: Error Code
Loads a diagnostic test. diagnostic schedule Schedules a diagnostic test. diagnostic start Runs specified diagnostic tests for the number of iterations set by the diagnostic ondemand iterations command. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-63 OL-17228-01...
Page 68 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 69: Table 6 Describes The Significant Fields Shown In The Display
Time at which the diagnostics are scheduled to run. Test ID(s) to be executed Tests to be run at scheduled time. Related Commands Command Description diagnostic schedule Schedules a diagnostic test. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-65 OL-17228-01...
Page 70 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 71 ------------------------------------ ------------------------------- ------ FC/S 0/SM3/SP ------------------------------------ ------------------------------- ------ FP40 0/5/SP ------------------------------------ ------------------------------- ------ FP40 0/0/SP ------------------------------------ ------------------------------- ------ FP40 0/1/SP ------------------------------------ ------------------------------- ------ FP40 0/6/SP ==================================== =============================== ====== Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-67 OL-17228-01...
Page 72 Defaults No default behavior or values Command Modes EXEC Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-68 OL-17228-01...
Page 73 SPA cfg admin up: YES Subslot 0/0/5 brief info: ----------------------- SPA inserted: NO Subslot 0/1/0 brief info: ----------------------- SPA inserted: YES SPA type: 8xGE SPA SPA operational state: READY Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-69 OL-17228-01...
Page 74 SPA operational state: READY SPA cfg admin up: YES Subslot 0/6/3 brief info: ----------------------- SPA inserted: YES SPA type: 8xGE SPA SPA operational state: READY SPA cfg admin up: YES Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-70 OL-17228-01...
Page 75 SPA 0/1/0 device c2w 0/0 info: C2W driver (0x501969f4), name AUX C2W (busywait), state 4 SPA 0/1/1 device c2w 0/0 info: C2W driver (0x501960f4), name AUX C2W (busywait), state 4 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-71 OL-17228-01...
Page 76: Show Controllers
SPA 0/6/5 device c2w 0/0 info: C2W driver (0x50195068), name AUX C2W (busywait), state 4 Related Commands Command Description show controllers Displays the controller type and other information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-72 OL-17228-01...
Page 77 Ethernet Interface Commands on Cisco IOS XR Software This module describes the Cisco IOS XR commands used to configure the Ethernet interfaces. This module does not include the commands for Management Ethernet interfaces. To configure a Note Management Ethernet interface for routing or modify the configuration of a Management Ethernet...
Page 78 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 79 The following example shows how to delay the processing of hardware link up and down notifications: RP/0/RP0/CPU0:router(config-if)# carrier-delay up 100 down 100 Related Commands Command Description dampening Limits propagation of transient or frequently changing interface states on Interface Manager (IM) clients. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-75 OL-17228-01...
Page 80 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 81 Ethernet Interface Commands on Cisco IOS XR Software clear mac-accounting (Ethernet) Related Commands Command Description mac-accounting Configures MAC accounting on an interface. show mac-accounting Displays MAC accounting statistics for an interface. (Ethernet) Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-77 OL-17228-01...
Page 82 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 83 RP/0/RP0/CPU0:router(config)# interface TenGigE 0/3/0/0 RP/0/RP0/CPU0:router(config-if)# flow-control ingress Related Commands Command Description show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-79 OL-17228-01...
Page 84 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 85 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 86 Ethernet Interface Commands on Cisco IOS XR Software loopback (Ethernet) Examples In the following example, all packets are looped back to the TenGigE controller: RP/0/RP0/CPU0:router(config)# interface TenGigE 0/3/0/0 RP/0/RP0/CPU0:router(config-if)# loopback internal Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-82 OL-17228-01...
Page 87 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 88 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 89: Negotiation Auto
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 90 To use this command, you must be in a user group associated with a task group that includes the proper task IDs. An interface that is connected to a Cisco Catalyst 6000 Series switch can experience packet loss problems that can be resolved by changing the packet interval of traffic from standard (as defined by the IEEE 802.ae specification) to nonstandard using the packet-gap non-standard command.
Page 91 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 92 RateLimCntl Port0: 0x00000001 SysIntMask: 0x000000f0 SysIntCause: 0x00000000 GOPIntMask0: 0x801ffffe GOPIntCause0: 0x40000000 GOPIntMask1: 0x00000000 GOPIntCause1: 0x00000000 GOPIntMask2: 0xffdfb800 GOPIntCause2: 0x00000000 GOPIntMask3: 0x00000000 GOPIntCause3: 0x00000000 CalendarParam: 0x00040004 SPI4SrcDPDeskew: 0x000f2710 SrcClndrCmd: 0x00100404 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-88 OL-17228-01...
Page 93 Number of oversized frames received on this interface. jabber Number of jabber packets received (packet length is greater than the MRU, and there is an invalid CRC, and no Rx Error event). Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-89 OL-17228-01...
Page 94 Global register that controls device reset state. GlobalCfg Global register that controls enable, clock modes, and Rx Interface behavior. PortTest Port diagnostics register. PL4IOGlblStat Register used during SPI4.2 initialization. DeviceTest Diagnostic loopback register. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-90 OL-17228-01...
Page 95 Register used to program the CALENDAR slots in the calendar report generated by the device. SnkCalSeqPrgm Register used to program the CALENDAR slots in the calendar report generated by the device. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-91 OL-17228-01...
Page 96: Packet Size
Xenpak Tx LS Alarm Current Alarm Status: Rx Xenpak Fault: Xenpak PCS Rx Local Fault Xenpak PMA PMD Rx Local Fault No Tx Xenpak Faults Lasi Faults: Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-92 OL-17228-01...
Page 97 PHY XS Loopback Capable DTE XGXS (BCM8011): Previous Alarm Status: XGXS Lanes All Synchronized XGXS Lane Status Valid Current Alarm Status: XGXS Lanes All Synchronized XGXS Lane Status Valid Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-93 OL-17228-01...
Page 98 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 99 MAC address entry, such as non-IP traffic from an unknown MAC source address. Related Commands Command Description clear mac-accounting (Ethernet) Clears MAC accounting statistics. mac-accounting Generates MAC accounting statistics. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-95 OL-17228-01...
Page 100 Ethernet Interface Commands on Cisco IOS XR Software show mac-accounting (Ethernet) Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-96 OL-17228-01...
Page 101 Global Interface Commands on Cisco IOS XR Software This module describes the global interface commands that apply to all interface types. This command set lets you configure, monitor, and troubleshoot the interfaces. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-97 OL-17228-01...
Page 102 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 103 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 104 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 105 RP/0/RP0/CPU0:router(config)# interface POS 0/4/0/0 RP/0/RP0/CPU0:router(config-if))# dampening Related Commands Command Description show im dampening Displays the state of all interfaces (or caps nodes) on which dampening has been configured. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-101 OL-17228-01...
Page 106 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 107 Related Commands Command Description clear interface Clears interface statistics or packet counters. show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-103 OL-17228-01...
Page 108 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 109 HDLC 4474 2488320 Mg0/RP0/CPU0/0 ARPA 1514 100000 Related Commands Command Description show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-105 OL-17228-01...
Page 110 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 111 Limits propagation of transient or frequently changing interface states on IM clients. show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-107 OL-17228-01...
Page 112: Show Interfaces
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 113: Time-Out(S)
In the following sample output, instance 1 is specified on a Packet-over-SONET/SDH (POS) card: RP/0/RP0/CPU0:router# show interfaces POS 0/1/0/1 POS0/1/0/1 is administratively down, line protocol is administratively down Hardware is Packet over SONET Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-109 OL-17228-01...
Page 114 Internet Address Layer 3 (IP) address for the interface. Note Use the ipv4 address command to configure the Internet address for the interface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-110 OL-17228-01...
Page 115 ARP. ARP timeout ARP timeout in hours:mins:secs. This value is configurable using the arp timeout command. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-111 OL-17228-01...
Page 116 This is a subset of the total input packet count. Received multicast packets Total number of Layer 2 multicast packets received on the interface. This is a subset of the total input packet count. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-112 OL-17228-01...
Page 117 Number of times that a packet was not output from the output hold queue because of a shortage of MEMD shared memory. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-113 OL-17228-01...
Page 118 Number of times the carrier detect (CD) signal of a serial interface has changed state. Related Commands Command Description show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-114 OL-17228-01...
Page 119 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 120 Command Description show interfaces Displays statistics for all interfaces configured on the router or for a specific node. show ip interface Displays IPv4 interface status and configuration. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-116 OL-17228-01...
Page 121 Internal Ethernet Control Network Commands on Cisco IOS XR Software This module describes the commands used to administer and configure internal control network commands on Cisco IOS XR software. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-117 OL-17228-01...
Page 122 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 123 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 124: Table 13
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 125 Displays detailed information about the backplane interfaces ethernet detail in a particular location. show controllers backplane Displays information about backplane interfaces that are in ethernet multicast groups multicast groups in a particular location. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-121 OL-17228-01...
Page 126: Fabric
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 127 Packets for ethernet server 81989 For Diag application 24598 QAD echo req 24598 QAD echo reply Test application 1 Test application 2 Test application 1 Test client out-of-band Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-123 OL-17228-01...
Page 128 Displays detailed information about the backplane interfaces detail in a particular location. show controllers backplane ethernet Displays information about backplane interfaces that are in multicast groups multicast groups in a particular location. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-124 OL-17228-01...
Page 129: Fabric
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 130 Number of packets and bytes discarded. Received broadcast packets and multicast Total number of broadcast and multicast packets that are packets received by the interface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-126 OL-17228-01...
Page 131 Displays information about client applications in a particular ethernet clients location. show controllers backplane Displays information about backplane interfaces that are in ethernet multicast groups multicast groups in a particular location. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-127 OL-17228-01...
Page 132: Fabric
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 133 Displays information about client applications in a particular clients location. show controllers backplane ethernet Displays detailed information about the backplane interfaces detail in a particular location. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-129 OL-17228-01...
Page 134: Fabric
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 135 FORWARDING or DISABLED. Connected to Node that owns the specified port. Related Commands Command Description show controllers switch Displays statistics on all ports on the switch controllers. statistics Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-131 OL-17228-01...
Page 136: Fabric
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 137 Number of packets received on the switch port. Rx Errors Number of receive errors. Related Commands Command Description show controllers switch ports Displays status on a switch port. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-133 OL-17228-01...
Page 138 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 139 Table 20 show spantree Field Descriptions Field Description Revision Revision of the current MST configuration. Instances configured MST instance. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-135 OL-17228-01...
Page 140 Internal Ethernet Control Network Commands on Cisco IOS XR Software show spantree Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-136 OL-17228-01...
Page 141 Link Bundling Commands on Cisco IOS XR Software This module contains commands for configuring and monitoring Link Bundling on Cisco IOS XR software. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-137 OL-17228-01...
Page 142 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 143 Displays statistics for all interfaces configured on the router or for a specific node. show lacp bundle Displays detailed information about LACP ports and their peers. show lacp port Displays detailed information about LACP ports. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-139 OL-17228-01...
Page 144 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 145 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 146 Sets the minimum amount of bandwidth required before a user can bring up minimum-active links a specific bundle. show bundle Displays information about a specific Ethernet bundle. Bundle-Ether show bundle Displays information about a specific POS bundle. Bundle-POS Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-142 OL-17228-01...
Page 147 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 148 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 149 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 150 Displays detailed information about LACP ports and their peers. show lacp port Displays detailed information about LACP ports. show lacp system-id Displays the local system ID used by LACP. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-146 OL-17228-01...
Page 151: Clear Lacp Counters
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 152 Examples The following example shows how to clear LACP counters: RP/0/RP0/CPU0:router# clear lacp counters Related Commands Command Description show lacp counters Displays LACP statistics. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-148 OL-17228-01...
Page 153 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 154 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 155 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 156 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 157 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 158 Port bandwidth, in kilobits per second. MAC address MAC address associated with the specified port. Related Commands Command Description bundle id Adds a port to an aggregated interface (or bundle). Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-154 OL-17228-01...
Page 159 Displays detailed information about LACP ports and their peers. show interfaces Displays statistics for all interfaces configured on the router or on a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-155 OL-17228-01...
Page 160 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 161 Displays detailed information about LACP ports and their peers. show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-157 OL-17228-01...
Page 162 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 163 Adds a port to an aggregated interface (or bundle). show bundle Displays information for a specific Ethernet bundle. Bundle-Ether show bundle Displays information for a specific POS bundle. Bundle-POS Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-159 OL-17228-01...
Page 164 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 165 Related Commands Command Description clear lacp counters Clears LACP counters for all members of all bundles, all members of a specific bundle, or for a specific port. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-161 OL-17228-01...
Page 166 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 167 System-ID System identifier. The System ID is an LACP property of the system which is transmitted within each LACP packet together with the details of the link. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-163 OL-17228-01...
Page 168 Adds a port to an aggregated interface (or bundle). show bundle Displays information about a specific Ethernet bundle. Bundle-Ether show bundle Displays information about a specific POS bundle. Bundle-POS Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-164 OL-17228-01...
Page 169 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 170 Displays information about a specific POS bundle. Bundle-POS show lacp bundle Displays detailed information about LACP ports and their peers. show lacp port Displays detailed information about LACP ports Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-166 OL-17228-01...
Page 171 Management Ethernet Interface Commands on Cisco IOS XR Software This module describes the Cisco IOS XR commands used to configure the Management Ethernet interfaces. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-167 OL-17228-01...
Page 172 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 173 MgmtEth Enters interface configuration mode for the Management Ethernet interface. show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-169 OL-17228-01...
Page 174 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 175 Displays statistics for all interfaces configured on the router or for a specific node. speed (Management Configures the speed for a Management Ethernet interface. Ethernet) Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-171 OL-17228-01...
Page 176 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 177 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 178 MgmtEth Enters interface configuration mode for the Management Ethernet interface. show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-174 OL-17228-01...
Page 179 NetFlow Commands on Cisco IOS XR Software This module describes the NetFlow commands on Cisco IOS XR software. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-175 OL-17228-01...
Page 180 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 181 NetFlow Commands on Cisco IOS XR Software cache entries Command Description show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-177 OL-17228-01...
Page 182 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 183 NetFlow Commands on Cisco IOS XR Software cache permanent Command Description show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-179 OL-17228-01...
Page 184 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 185 Creates and configures a flow monitor map and enters flow monitor map configuration submode. show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-181 OL-17228-01...
Page 186 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 187 Description flow exporter-map Configures a flow exporter map. show flow exporter Displays flow exporter data. show flow Displays flow exporter map information for a specific node. exporter-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-183 OL-17228-01...
Page 188 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 189 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 190 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 191 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 192 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 193 Creates and configures a flow monitor map and enters flow monitor map configuration submode. show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-189 OL-17228-01...
Page 194 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 195 Related Commands Command Description flow monitor-map Creates and configures a flow monitor map, and enters flow monitor map configuration submode. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-191 OL-17228-01...
Page 196 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 197 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 198 NetFlow Commands on Cisco IOS XR Software flow monitor-map Command Description show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-194 OL-17228-01...
Page 199 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 200 Configures a flow monitor map and associates an exporter map with a monitor map. show flow exporter Displays flow exporter data. show flow Displays flow exporter map information for a specific node installed in the exporter-map router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-196 OL-17228-01...
Page 201 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 202 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 203 Configures the flow record map name for MPLS. record ipv6 Configures the flow record map name for IPv6. show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-199 OL-17228-01...
Page 204 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 205 NetFlow Commands on Cisco IOS XR Software record ipv6 Command Description show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-201 OL-17228-01...
Page 206 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 207 Configures the flow record map name for IPv4. show flow monitor Displays flow monitor cache information. show flow Displays flow monitor map information. monitor-map Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-203 OL-17228-01...
Page 208 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 209 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 210 Related Commands Command Description clear flow exporter Clears flow exporter statistics or restarts the flow exporter statistics collector. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-206 OL-17228-01...
Page 211 Command Description flow exporter-map Configures a flow exporter map. show flow Displays flow monitor map information for a specific node that is installed exporter-map in the router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-207 OL-17228-01...
Page 212 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 213 Clears flow exporter statistics or restarts the flow exporter statistics collector. flow exporter-map Configures a flow exporter map. show flow exporter Displays flow exporter data. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-209 OL-17228-01...
Page 214 If you specified the show flow monitor monitor-name cache match command to match on ACL and one or more fields: monitor-name Flow monitor map whose details you want to display. cache Displays details about the flow monitor cache. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-210 OL-17228-01...
Page 215 Note Enter the tos keyword followed by the ? command to see a complete list of possible match criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-211 OL-17228-01...
Page 216 • Enter the destination-port-overloaded keyword followed by Note the ? command to see a complete list of possible match criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-212 OL-17228-01...
Page 217 Note Enter the source-as keyword followed by the ? command to see a complete list of possible match criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-213 OL-17228-01...
Page 218 • Enter the first keyword followed by the ? command to see a Note complete list of possible match criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-214 OL-17228-01...
Page 219 Specifies miscellaneous fields for which to compare and match the specified criteria. Enter the forwarding-status keyword or the direction keyword to specify the field whose criteria you want to compare. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-215 OL-17228-01...
Page 220 Specifies sorting criteria for one of the following IPv6 fields: • destination-address source-address • protocol • • Enter the ipv6 keyword followed by the ? command to see Note a complete list of possible sorting criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-216 OL-17228-01...
Page 221 • bottom—Displays bottom cache entries. • Enter the tos keyword followed by the ? command to see a Note complete list of possible sorting criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-217 OL-17228-01...
Page 222 • prefix Displays MPLS information for the destination address. The following sorting options are listed: top—Displays top cache entries. • bottom—Displays bottom cache entries. • Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-218 OL-17228-01...
Page 223 • • bottom—Displays bottom cache entries. Enter the destination-as keyword followed by the ? Note command to see a complete list of possible sorting criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-219 OL-17228-01...
Page 224 • • bottom—Displays bottom cache entries. Note Enter the bytes keyword followed by the ? command to see a complete list of possible match criteria. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-220 OL-17228-01...
Page 225 To see a list of fields that can be included, enter the include Note keyword, followed by the ? command. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-221 OL-17228-01...
Page 226 Includes or excludes IPV4 type of service information in the command output. Includes or excludes IPV6 traffic class information in the command output. protocol Includes or excludes IPV4 or IPV6 protocol information in the command output. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-222 OL-17228-01...
Page 227 Note complete list of fields you can include or exclude. source-as Includes or excludes information about the BGP source address autonomous system number in the command output. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-223 OL-17228-01...
Page 228 Includes or excludes information about the direction of the flow in the command output. Includes or excludes top cache entries in the command output. Replace records with the number of records you want to display. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-224 OL-17228-01...
Page 229 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 230 IPV4Prot IPV4TOS InputInterface OutputInterface L4TCPFlags ForwardStatus ForwardReason FirstSwitched LastSwitched ByteCount PacketCount Dir Sampler ID 17.17.17.2 18.18.18.2 normal PO0/0/0/8 PO0/0/0/12 00:02:43:800 00 00:02:49:980 37200 In 0 18.18.18.2 17.17.17.2 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-226 OL-17228-01...
Page 231 Counter wrap aged • Total • Periodic export Counter wrap • TCP FIN flag • Matching entries Status of various matching criteria for traffic in the flows. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-227 OL-17228-01...
Page 232 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 233 Clears the flow monitor data. flow monitor-map Configures a flow monitor map. flow Specifies a flow monitor map and a sampler map for IPv4, IPv6, or MPLS packets. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-229 OL-17228-01...
Page 234 Configures the flow record map name for IPv4. record ipv6 Configures the flow record map name for IPv6. record mpls Configures the flow record map name for MPLS. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-230 OL-17228-01...
Page 235 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 236 Worker waiting Number of times that the producer needed to use the server. This field is strictly informational and does not indicate any Note error. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-232 OL-17228-01...
Page 237 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 238 Related Commands Command Description sampler-map Configures the sampler map. flow Specifies a flow monitor map and a sampler map for IPv4, IPv6, or MPLS packets. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-234 OL-17228-01...
Page 239 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 240 Configures a flow monitor map and associates an exporter map with a monitor map. show flow exporter Displays flow exporter data. show flow Displays flow exporter map information for a specific node installed in the exporter-map router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-236 OL-17228-01...
Page 241 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 242 Configures a flow monitor map and associates an exporter map with a monitor map. show flow exporter Displays flow exporter data. show flow Displays flow exporter map information for a specific node installed in the exporter-map router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-238 OL-17228-01...
Page 243 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 244 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 245 Command Description show flow exporter Displays flow exporter data. show flow Displays flow exporter map information for a specific node installed in the exporter-map router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-241 OL-17228-01...
Page 246 NetFlow Commands on Cisco IOS XR Software version v9 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-242 OL-17228-01...
Page 247 Null Interface Commands on Cisco IOS XR Software This module describes the Cisco IOS XR commands used to configure null interfaces. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-243 OL-17228-01...
Page 248: Interface Null
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 249 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 250 Total number of packets dropped by the interface. Related Commands Command Description show interfaces Displays statistics for all interfaces configured on the router or for a specific node. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-246 OL-17228-01...
Page 251 (Optional) Saves the configuration to bootflash: file system. file-name compactflash: (Optional) Saves the configuration to compactflash: file system. destination file-name compactflasha: (Optional) Saves the configuration to compactflasha: file system. destination file-name Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-247 OL-17228-01...
Page 252 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 253 0 drops for unrecognized upper-level protocol Received 0 broadcast packets, 0 multicast packets 0 packets output, 0 bytes, 0 total output drops Output 0 broadcast packets, 0 multicast packets Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-249 OL-17228-01...
Page 254 Null Interface Commands on Cisco IOS XR Software show interfaces null0 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-250 OL-17228-01...
Page 255 Packet-over-SONET/SDH Interface Commands on Cisco IOS XR Software This module describes the Cisco IOS XR commands used to configure, monitor, and troubleshoot Packet-over-SONET/SDH (POS). POS provides a method for efficiently carrying data packets in SONET or Synchronous Digital Hierarchy (SDH) frames. High-bandwidth capacity and efficient link utilization are characteristics that make POS largely preferred for building the core of data networks.
Page 256 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 257 Packet-over-SONET/SDH Interface Commands on Cisco IOS XR Software crc (POS) Related Commands Command Description transmit-delay Specifies a number of flag sequences to be inserted between the packets. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-253 OL-17228-01...
Page 258 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 259: Interface Pos
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 260 The keepalive value configured on each router (local and partner) sets the rate at which the Cisco IOS XR software sends packets. It also sets the rate at which the local end expects to receive incoming packets.
Page 261 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 262 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 263: Show Interfaces Pos
Bandwidth of the interface, in kbps. Related Commands Command Description show controllers pos Displays information on the Packet-over-SONET/SDH (POS) controllers. show controllers sonet Displays information about the operational status of SONET layers. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-259 OL-17228-01...
Page 264: Syntax Description
Command History Releases Modifications Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 265 IP Version 6 Control Protocol (IPv6CP) to negotiate IPv6 properties • Multiprotocol Label Switching Control Protocol (MPLSCP) to negotiate MPLS properties • Open System Interconnection Control Protocol (OSICP) to negotiate OSI properties • Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-261 OL-17228-01...
Page 266: Command History Release Release
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 267: Ppp Authentication
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 268 MS-CHAP is the Microsoft version of CHAP. Like the standard version of CHAP, MS-CHAP is used for PPP authentication. In this case, authentication occurs between a personal computer using Microsoft Windows NT or Microsoft Windows 95 and a Cisco router or access server acting as a network access server.
Page 269: Task Id Task Id
This does not affect local authentication of the peer. This command is useful for routers that do not support this command (such as routers running older Cisco IOS XR software images). The CHAP secret password is used by the routers in response to challenges from an unknown peer.
Page 270 Displays the contents of the currently running configuration file or the configuration for a specific interface, or map class information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-266 OL-17228-01...
Page 271 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 272 Enables remote PAP support for an interface, and includes the password sent-username and password commands in the PAP authentication request packet to the peer. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-268 OL-17228-01...
Page 273 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 274 Enables remote PAP support for an interface and includes the password sent-username and password commands in the PAP authentication request packet to the peer. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-270 OL-17228-01...
Page 275 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 276 Configures the maximum number of CONFNAKs to permit before terminating a negotiation. ppp max-terminate Configures the maximum number of terminate requests to send without reply before closing down the LCP or NCP. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-272 OL-17228-01...
Page 277 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 278 Specifies the maximum number of configure requests to attempt (without response) before stopping the requests. ppp max-terminate Configures the maximum number of terminate requests to send without reply before closing down the LCP or NCP. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-274 OL-17228-01...
Page 279 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 280 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 281 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 282 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 283 Enables remote PAP support for an interface, and includes the password sent-username and password commands in the PAP authentication request packet to the peer. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-279 OL-17228-01...
Page 284 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 285 Sets PPP authentication timeout parameters. authentication show running-config Displays the contents of the currently running configuration file or the configuration for a specific interface, or map class information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-281 OL-17228-01...
Page 286 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 287 PPP. ppp authentication Enables CHAP, MS-CHAP, or PAP, and specifies the order in which CHAP, MS-CHAP, and PAP authentication is selected on the interface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-283 OL-17228-01...
Page 288 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 289: Configured On The Router
Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 290 POS0/2/4/3 is down, line protocol is down LCP: Starting Keepalives enabled (10 sec) Local MRU: 4470 bytes Peer MRU: 4470 bytes IPCP: Starting Local IPv4 address: 10.12.32.2 Peer IPv4 address: 10.12.32.1 OSICP: Open Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-286 OL-17228-01...
Page 291 Authentication Type of user authentication configured on the local equipment and on the peer equipment. Possible PPP authentication protocols are Challenge Handshake Authentication Protocol (CHAP), MS-CHAP, and Password Authentication Protocol (PAP). Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-287 OL-17228-01...
Page 292 ACKsent—IPCP has received a request and has replied to it. ACKrcvd—IPCP has received a reply to a request it sent. • Open—IPCP is functioning properly. • Local IPv4 IPv4 address for the local interface. address Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-288 OL-17228-01...
Page 293 Specifies an IPv6 family address. keepalive Controls how often LCP EchoRequest packets are sent after LCP has been negotiated. Adjusts the maximum transmission unit (MTU) value for packets on the interface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-289 OL-17228-01...
Page 294 PPP Commands on Cisco IOS XR Software show ppp interfaces Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-290 OL-17228-01...
Page 295 SONET Controller Commands on Cisco IOS XR Software This module describes the Cisco IOS XR software commands used to configure SONET operation on a router port using Layer 1 SONET transport technology. The configuration of the SONET controller includes SONET Automatic Protection Switch (APS), which is a feature offering recovery from fiber (external) or equipment (interface and internal) failures at the SONET line layer.
Page 296 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 297 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 298 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 299 Changes the time between hello packets and the time before the protect interface process declares a working interface router to be down. unidirectional Configures a protect interface for unidirectional mode. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-295 OL-17228-01...
Page 300 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 301 Assigns a port and interface that is physically located in a remote router as a SONET automatic protection switching (APS) channel (working or protect). show aps Displays the operational status for all configured SONET automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-297 OL-17228-01...
Page 302 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 303 Assigns a port and interface that is physically located in a remote router as a SONET automatic protection switching (APS) channel (working or protect). show aps Displays the operational status for all configured SONET automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-299 OL-17228-01...
Page 304 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 305 Assigns local SONET physical ports as SONET automatic protection switching (APS) channels in the current APS group. show aps Displays the operational status for all configured SONET automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-301 OL-17228-01...
Page 306 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 307 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 308 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 309 SONET Controller Commands on Cisco IOS XR Software controller (SONET) Related Commands Command Description show controllers sonet Displays information about the operational status of SONET layers. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-305 OL-17228-01...
Page 310 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 311 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 312 (SONET) Initiates the SONET overhead bytes in the frame header to conform to a specific standards requirement or to ensure interoperability with equipment from another vendor. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-308 OL-17228-01...
Page 313 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 314 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 315 (SONET) Initiates the SONET overhead bytes in the frame header to conform to a specific standards requirement or to ensure interoperability with equipment from another vendor. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-311 OL-17228-01...
Page 316 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 317 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 318 The following example shows how to set the SS bits value of the H1 byte in the SONET line overhead to 2 for SDH: RP/0/RP0/CPU0:router(config)# controller sonet 0/1/0/1 RP/0/RP0/CPU0:router(config-sonet)# overhead sls0 2 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-314 OL-17228-01...
Page 319 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 320 The following example shows how to set the STS SPE C2 byte in the SONET path frame header: RP/0/RP0/CPU0:router(config)# controller sonet 0/2/0/2 RP/0/RP0/CPU0:router(config-sonet)# path RP/0/RP0/CPU0:router(config-sonet-path)# overhead c2 0x13 Related Commands Command Description scrambling disable Disables payload scrambling on a SONET path. (SONET path) Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-316 OL-17228-01...
Page 321 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 322 Sets the bit error rate (BER) threshold values of the specified alarms for a path) SONET path. uneq-shut (SONET Enables automatic insertion of P-UNEQ code (0x00) in the sent SONET path) path overhead C2 byte. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-318 OL-17228-01...
Page 323 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 324 The following example shows how to enable the reporting of line AIS alarms on the path controller: RP/0/RP0/CPU0:router(config)# controller sonet 0/1/0/1 RP/0/RP0/CPU0:router(config-sonet)# report lais Related Commands Command Description show controllers sonet Displays information about the operational status of SONET layers. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-320 OL-17228-01...
Page 325 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 326 The following example shows how to enable the reporting path of the PAIS alarms: RP/0/RP0/CPU0:router(config)# controller sonet 0/2/0/2 RP/0/RP0/CPU0:router(config-sonet)# path RP/0/RP0/CPU0:router(config-sonet-path)# report pais Related Commands Command Description show controllers sonet Displays information about the operational status of SONET layers. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-322 OL-17228-01...
Page 327 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 328 RP/0/RP0/CPU0:router(config)# aps group 1 RP/0/RP0/CPU0:router(config-aps)# revert 5 Related Commands Command Description show aps Displays the operational status for all configured SONET automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-324 OL-17228-01...
Page 329 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 330 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 331 Displays the status of the automatic protection switching (APS) working-to-protect (WP) distributed communication subsystem. show aps group Displays information about the automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-327 OL-17228-01...
Page 332 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 333 PGP segments are represented as “===” if operational or “==” if broken. Related Commands Command Description show aps Displays the operational status for all configured SONET automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-329 OL-17228-01...
Page 334 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 335 Displays the operational status for all configured SONET automatic protection switching (APS) groups. show aps agents Displays the status of the automatic protection switching (APS) working-to-protect (WP) distributed communication subsystem. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-331 OL-17228-01...
Page 336: Show Controllers Pos
Command History Releases Modifications Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 337 FCS Errors: Min-len errors: 0 Runts: Max-len errors: 0 FIFO Overflows: 0 FIFO Underruns: 0 Giants: Drops: Sky4402 asic #2 registers: 0x000 general_cntrl 0x00 0x002 sys_intf_cntrl_1 0x06 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-333 OL-17228-01...
Page 338 0x181 rsp_cntrl_2 0x02 0x184 rtop_f1_ovrhd 0x00 0x185 rtop_k1_ovrhd 0x00 0x186 rtop_k2_ovrhd 0x00 0x187 rtop_s1_ovrhd 0x00 0x188 rtop_e1_ovrhd 0x00 0x189 rtop_e2_ovrhd 0x00 0x18a rtop_deb_s1_ovrhd 0x00 0x18c rtop_b1_mismatch_cnt_u 0x00 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-334 OL-17228-01...
Page 339 Address in hex of the error detail 2 flag. rx offset Address in hex of the receive offset. Channel Modes Location in hex of the channel mode flag. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-335 OL-17228-01...
Page 340 CPU. FIFO underruns reports the number of times that the transmitter has been running faster than the router can handle. 1. application-specific integrated circuit 2. frame check sequence Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-336 OL-17228-01...
Page 341 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 342 Master DCC Interface Cfg 2 0000 reg[1004] APS Cfg and Status 0000 reg[1005] APS FIFO Cfg and Status 0x0f reg[1006] APS Intr Status 1 0000 reg[1007] APS Intr Status 2 0000 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-338 OL-17228-01...
Page 343 SONET section. Path alarm indication signal is sent by the LTE to alert the • downstream PTE that it has detected a defect on its incoming line signal. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-339 OL-17228-01...
Page 344 PATH TRACE BUFFER SONET path trace buffer is used to communicate information regarding the remote hostname, interface name/number, and IP address. This use of the J1 (path trace) byte is proprietary to Cisco. Remote hostname Name of the remote host.
Page 345 Whether the interface and its associated layers are in the admin-up state. if_state Whether the interface and its associated layers are in the up or down state. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-341 OL-17228-01...
Page 346 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 347 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 348 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 349 6 seconds: RP/0/RP0/CPU0:router(config)# aps group 3 RP/0/RP0/CPU0:router(config-aps)# timers 2 6 Related Commands Command Description show aps group Displays information about the automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-345 OL-17228-01...
Page 350 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 351 (SONET) Permits selected SONET alarms to be logged to the console for a SONET controller. show controllers Displays information about the operational status of SONET layers. sonet Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-347 OL-17228-01...
Page 352 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 353 Displays information about the operational status of SONET layers. sonet report (SONET) Permits selected SONET alarms to be logged to the console for a SONET controller. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-349 OL-17228-01...
Page 354 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 355 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 356 SONET Controller Commands on Cisco IOS XR Software unidirectional Related Commands Command Description show aps Displays the operational status for all configured SONET automatic protection switching (APS) groups. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-352 OL-17228-01...
Page 357 802.1Q VLAN Subinterface Commands on Cisco IOS XR Software This module contains commands for configuring and monitoring 802.1Q VLAN commands on Cisco IOS XR software. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-353 OL-17228-01...
Page 358 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 359 802.1Q VLAN Subinterface Commands on Cisco IOS XR Software dot1q native vlan Related Commands Command Description dot1q vlan Assigns a VLAN ID to a subinterface, or changes the VLAN ID assigned to a subinterface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-355 OL-17228-01...
Page 360 VLAN tag. Use the dot1q tunneling ethertype 0x9100 command if the peer switching devices are using an Ethertype field value of 0x9100. All Cisco switching devices use the default Ethertype field value of 0x8100.
Page 361 0x9100 Related Commands Command Description dot1q vlan Assigns a VLAN ID to a subinterface, or modifies the VLAN ID that is currently assigned to a subinterface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-357 OL-17228-01...
Page 362 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 363 Displays statistics for all interfaces configured on the router or for a specific node, show vlan interface Displays summarized information for the VLAN subinterfaces configured on your router. show vlan tags Displays VLAN tagging allocation information. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-359 OL-17228-01...
Page 364 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 365 Defines the native VLAN ID associated with a VLAN trunk. dot1q vlan Assigns a VLAN ID to a subinterface, or changes the VLAN ID assigned to a subinterface. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-361 OL-17228-01...
Page 366 Command History Release Modification Release 3.7.1 This command was introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 367 Description show interfaces Displays statistics for all interfaces configured on the router or for a specific node. show vlan trunks Displays summary information about VLAN trunk interfaces. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-363 OL-17228-01...
Page 368 Release Modification Release 3.7.1 This command was first introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 369 Displays summary information about each of the VLAN interfaces and subinterfaces. show vlan trunks Displays information about the VLAN trunks currently configured on your router. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-365 OL-17228-01...
Page 370 Release Modification Release 3.7.1 This command was first introduced on the Cisco ASR 14000 Series Router. Usage Guidelines To use this command, you must be in a user group associated with a task group that includes the proper task IDs.
Page 371 • 2Q—One or more double 802.1Q tag ACs are configured. • Qany—One or more double 802.1Q tag ACs are configured • that have a wildcard “any” innertag. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-367 OL-17228-01...
Page 372 802.1Q tag is displayed only if that number is greater than 0. Related Commands Command Description interface (VLAN) Displays summary information about each of the VLAN interfaces and subinterfaces. Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-368 OL-17228-01...
Page 373 HR-145 diagnostic monitor command HR-34 diagnostic monitor interval command HR-36 diagnostic monitor syslog command HR-38 diagnostic monitor threshold command HR-39 cache entries command HR-176 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-369 OL-17228-01...
Page 374 HR-86 interface GigabitEthernet command HR-80 path (SONET) command HR-317 interface MgmtEth command HR-170 ping (administration EXEC) command HR-49 interface null 0 command HR-244 pos command HR-257 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-370 OL-17228-01...
Page 375 HR-362 show bundle Bundle-POS command HR-156 show vlan tags command HR-364 show controller backplane ethernet brief show vlan trunks command HR-366 command HR-120 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-371 OL-17228-01...
Page 376 (SONET path) command HR-348 timers (APS) command HR-344 transmit-delay (POS) command HR-260 transport udp command HR-239 uneq-shut (SONET path) command HR-350 unidirectional command HR-351 version v9 command HR-240 Cisco ASR 14000 Series Router Interface and Hardware Component Command Reference HR-372 OL-17228-01...

Cisco ASR 14000 Series Command Reference Manual

Failed.

Error Code/Total Run Count

Show Interfaces Pos

Quick Links

Chapters

Summary of Contents for Cisco ASR 14000 Series

Page 3: Obtaining Documentation And Submitting A Service Request

Page 38: Diagnostic Monitor

Page 47: Diagnostic Schedule

Page 49: Diagnostic Start

Page 54: Table Of Contents

Page 55: Local Node

Page 64: Fabric

Page 67: Error Code

Page 69: Table 6 Describes The Significant Fields Shown In The Display

Page 76: Show Controllers

Page 89: Negotiation Auto

Page 96: Packet Size

Page 112: Show Interfaces

Page 113: Time-Out(S)

Page 124: Table 13

Page 126: Fabric

Page 129: Fabric

Page 132: Fabric

Page 134: Fabric

Page 136: Fabric

Page 151: Clear Lacp Counters

Page 248: Interface Null

Page 259: Interface Pos

Page 263: Show Interfaces Pos

Page 264: Syntax Description

Page 266: Command History Release Release

Page 267: Ppp Authentication

Page 269: Task Id Task Id

Page 289: Configured On The Router

Page 336: Show Controllers Pos

Cisco ASR 14000 Series Command Reference Manual

Failed.

Error Code/Total Run Count

Show Interfaces Pos

Quick Links

Chapters

Related Manuals for Cisco ASR 14000 Series

Summary of Contents for Cisco ASR 14000 Series

Table of Contents
