OPERATIONS / MAINTENANCE MANUAL
400MHz Fiber Optic Fed & RF Fed
800MHz Fiber Optic Fed & RF Fed
The information set forth in this document and all rights in and to
inventions disclosed herein, and patents that might be granted
thereon disclosing, employing or covering the materials, methods,
techniques or apparatus described herein are the exclusive
property of Andrew Corporation.
This document is an operation and maintenance manual. No
disclosure or reproduction of the information or drawings shall be
made of any other purpose without the prior written consent of
Andrew Corporation. Use of the information contained herein to
fabricate or assemble any item in whole or in part is expressly
prohibited.
DWG NO:
Error! Not a valid link.
For
Bi-Directional Amplifier
AE04A-D1248-001
AE04A-D1246-001
Bi-Directional Amplifier
AE04A-D1437-001
AE04A-D1436-001
MANUAL NO. AE04B-A1669
REVISION A
Wireless Innovations Group
2601 Telecom Parkway
Richardson, Texas 75082
400/800 MHz Fiber Optic & RF Fed Bi-Directional
Amplifier Operations / Maintenance Manual
Rev:
Date:06/16/2004
Error!
Not a
valid
link.
1 of 63
Page:

Advertisement

Table of Contents
loading

Related Manuals for Andrew AE04A-D1246-001

Summary of Contents for Andrew AE04A-D1246-001

  • Page 1 Andrew Corporation. Use of the information contained herein to fabricate or assemble any item in whole or in part is expressly prohibited.

  • Page 2: Table Of Contents

    Table of Contents INTRODUCTION ............................. 5 Scope..................................5 Purpose..................................5 ..........................6 LOSSARY OF ERMS SAFETY CONSIDERATIONS ..................... 7 Electric Shock Hazard ..........................7 Hot Surface Hazard ...........................7 Optical Laser Hazard ..........................7 Emergency Contact Numbers ........................7 EQUIPMENT OVERVIEW / DESCRIPTION ................8 SPECIFICATION .......................... 8 Parts Lists ..............................9 3.1.1 400 MHz Bi-Directional Amplifier ....................9 3.1.2 800 MHz Bi-Directional Amplifier ....................9...
  • Page 3 5.5.3 Photograph............................39 Fiber Optic Transceiver Module (AE04A-D1100-009).................39 5.6.1 Description ............................39 5.6.2 Specification..........................40 5.6.3 Photographs ..........................41 5.6.4 Schematics.............................42 +48V Power Supply Module (AE04A-D0803-002) ................51 5.7.1 Description ............................52 5.7.2 Specification..........................52 5.7.3 Photographs ..........................53 5.7.4 Schematics.............................54 Alarm Module (AE04A-D0805-007): Optional..................55 5.8.1 Description ............................55 5.8.2 Photographs ..........................55 5.8.3...
  • Page 4 AMENDMENT RECORD SHEET Date Reason Page Incorpor Nō. Amended ated By 6/16/04 Issue J. Hsu/ E. Yearby 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 4 of 63...

  • Page 5: Introduction

    INTRODUCTION Scope This handbook is for use solely with the equipment identified by the Andrew Part Numbers shown on the front cover. It is not to be used with any other equipment unless specifically authorized by Andrew Corporation. Purpose The purpose of this handbook is to provide the operator/maintainer with sufficient information to operate, maintain and repair the equipment while in the filed.

  • Page 6: Glossary Of Terms

    GLOSSARY OF TERMS Automatic Level Control Alternating Current Bi-Directional Amplifier Carrier-to-Noise Ratio Direct Current Decibel Decibel Below Carrier Decibel referenced to 1 mW Electrostatic Discharge Electromagnetic Interference FC/APC Fiber Connector /Angle Polish Connector Ground High Power Amplifier Hertz Kilohertz Kilometer Light Emitting Diode Low Power Amplifier Megahertz...

  • Page 7: Safety Considerations

    1.1 Electric Shock Hazard To avoid electric shock, switch the BDA “OFF” prior to performing any repairs. All repairs beyond modular replacement must be performed by Andrew Trained Technicians. 1.2 Hot Surface Hazard RF power into the BDA will be limited by the use of high power attenuators. These attenuators will be located at the transmitter source.

  • Page 8: Equipment Overview / Description

    EQUIPMENT OVERVIEW / DESCRIPTION MBTA System Wide Radio Tunnel Antenna Distribution System provides extended radio coverage within MBTA rail transit tunnels. The new tunnel antenna system is a two-way communication system consisting of 400 MHz base transceiver stations, 800 MHz base transceiver stations, antennas, radiating cable, fiber optic cable and BDAs.

  • Page 9: Parts Lists

    3.1 Parts Lists 3.1.1 400 MHz Bi-Directional Amplifier Andrew Description Qty. Section Part Number AE04A-D1264-001 400 MHz EO Cell Amplifier Module AE04A-D1442-001 480 MHz High Isolation Duplexer AE04A-D1443-001 480 MHz Low Isolation Duplexer AE04A-D1100-009 Fiber Optic Transceiver Module AE04A-D0803-002 +48V Power Supply Module...

  • Page 10: 400 Mhz Bi-Directional Amplifier Uplink Specification

    AC Power 120 VAC Single Phase Notes: 1.Via Front Panel RS232 Connector. 2. Two-Tone Intermodulation: Measured two-output carriers at +20.0 dBm/C (+19.0 dBm/C for RF Fed BDA) at 483.1625 MHz and 483.2375 MHz with a BDA gain setting of 48 dB. 3.2.2 400 MHz Bi-Directional Amplifier Uplink Specification PARAMETER UPLINK SPECIFICATION...

  • Page 11: 800 Mhz Bi-Directional Amplifier Uplink Specification

    Composite Input Power -18 dBm max. Impedance 50 Ohms VSWR OIP3 +44 dBm Noise Power max. @ 48dB Gain -64 dBm/Hz (-110 dBm/Hz; RF Fed BDA) AC Power 120 VAC Single Phase Notes: 1.Via Front Panel RS232 Connector. 2. Two-Tone Intermodulation: Measured two-output carriers at +23.5 dBm/C (+16.8 dBm/C for RF Fed BDA) in the 866 –...

  • Page 12: Environmental Specifications

    3.4 Environmental Specifications PARAMETERS SPECIFICATION Operating Temperature -20°C to +60°C Operating Relative Humidity 5% to 95% (Non-Condensing) Dry Storage Temperature -25°C to +60°C ESD & EMI IEC 65 (Secretariat) 129 Draft Pub. 801-2 Shock, Vibration and Moisture Resistance MIL-STD810(E) Notes: 1.

  • Page 13: 800 Mhz Fiber Optic Fed Bi-Directional Amplifier

    4.2 800 MHz Fiber Optic Fed Bi-Directional Amplifier 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 13 of 63 Error! Not a valid link. Page: Error! Not a...

  • Page 14: Modules

    MODULES 5.1 400 MHz EO Cell Amplifier Module (AE04A-D1264-001) 5.1.1 Description This 2Watt, 483 - 487 MHz, class A Power Amplifier Module provides a nominal 52 dB of gain. It has 30 dB of gain adjustment range, which can be varied electronically thru the front panel RS232 connector.

  • Page 15: Specification

    5.1.2 Specification PARAMETER SPECIFICATION Operating Frequency Range 483.1625 – 486.2375 MHz Gain Typical 51.5 dB Output Gain Adjustment 30 dB ≥ +33.5 dBm Composite Output Power Impedance 50 Ohms VSWR ≥ + 47.5 dBm OIP3 Noise Power max. @ 51.5 dB Gain -111.5 dBm/Hz DC Power + 48 VDC...
  • Page 16 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 16 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 17 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 17 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 18 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 18 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 19 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 19 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 20 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 20 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 21 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 21 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 22 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 22 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 23 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 23 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 24 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 24 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 25 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 25 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 26: 480 Mhz High Isolation Duplexer (Ae04A-D1442-001)

    5.2 480 MHz High Isolation Duplexer (AE04A-D1442-001) 5.2.1 Description The 480 MHz, high isolation duplexer provides the high bandpass selectivity and isolation for the Uplink and the Downlink frequency. The duplexer is based on a 5-cavity cross-coupled bandpass filter design and is aligned carefully during production to optimise the insertion loss, selectivity, and VSWR The duplexer is a fully passive device and should have an extremely long trouble- free working life and requires no maintenance.

  • Page 27: Photograph

    Operating Temperature -20°C to +60°C 5.2.3 Photograph 5.3 480 MHz Low Isolation Duplexer (AE04A-D1443-001) 5.3.1 Description 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 27 of 63...

  • Page 28: Specification

    The 480 MHz, low isolation duplexer provides the band selectivity and isolation for the Uplink and the Downlink frequency. The duplexer is based on 4 ceramic coaxial resonators design and is aligned carefully during production to optimize the insertion loss, isolation, and VSWR The duplexer is a fully passive device and should have an extremely long trouble- free working life and requires no maintenance.

  • Page 29: Specification

    This 2Watt, 821-869 MHz, class A Power Amplifier Module provides a nominally 51 dB of gain. It has 30 dB of gain adjustment range, which can be varied electronically thru the front panel RS232 connector. Additionally, the module has an internal Automatic Level Control (ALC) circuit, which can be set to limit the maximum power level produced by the BDA.

  • Page 30: Photographs

    845 MHz and 845.6 MHz with 51 dB gain setting. 5.4.3 Photographs 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 30 of 63 Error! Not a valid link.
  • Page 31 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 31 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 32: Schematics

    5.4.4 Schematics INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 32 of 63 Error! Not a valid link. Page: Error! Not a valid...
  • Page 33 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 33 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 34 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 34 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 35 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 35 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 36 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 36 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 37 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 37 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 38: 800 Mhz High Isolation Duplexer (Ae04A-D1438-001)

    5.5 800 MHz High Isolation Duplexer (AE04A-D1438-001) 5.5.1 Description The 800 MHz, high isolation duplexer provides the high bandpass selectivity and isolation for the Uplink and the Downlink frequency. The duplexer is based on a 5-cavity cross-coupled bandpass filter design and is aligned carefully during production to optimize the insertion loss, selectivity, and VSWR The duplexer is a fully passive device and should have an extremely long trouble- free working life and requires no maintenance.

  • Page 39: Photograph

    5.5.3 Photograph 5.6 Fiber Optic Transceiver Module (AE04A-D1100-009) 5.6.1 Description The Fiber Optic Transceiver Module converts the Downlink and Uplink electrical (RF) signals into optical signals prior to routing the signals between remote BDAs and the base transceiver station. The fiber optic transceiver is capable of providing up to 18 dB of RF gain.

  • Page 40: Specification

    The fiber optic transceiver module has an on board RISC processor that provides optional alarming/status monitoring and communications capability. The fiber transceiver is also equipped with high reliable parts to provide a long trouble-free operating life. Should the module be suspect of failure, the entire module should be replaced.

  • Page 41: Photographs

    5.6.3 Photographs 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 41 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 42: Schematics

    5.6.4 Schematics INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 42 of 63 Error! Not a valid link. Page: Error! Not a valid...
  • Page 43 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 43 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 44 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 44 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 45 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 45 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 46 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 46 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 47 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 47 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 48 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 48 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 49 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 49 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 50 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 50 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 51: Power Supply Module (Ae04A-D0803-002)

    INTENTIONALLY LEFT BLANK 5.7 +48V Power Supply Module (AE04A-D0803-002) 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 51 of 63 Error! Not a valid link. Page: Error! Not a...

  • Page 52: Description

    5.7.1 Description The AC to DC Power Supply Module provides + 48VDC from the main AC source to the BDA Chassis. The power supply module contains an AC front-end FARM (Filter/Autoranging Rectifier Module) followed by a DC-DC Converter Module. The AC to DC power supply module is capable of interfacing directly with various sources of AC power.

  • Page 53: Photographs

    5.7.3 Photographs 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 53 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 54: Schematics

    5.7.4 Schematics INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 54 of 63 Error! Not a valid link. Page: Error! Not a valid...

  • Page 55: Alarm Module (Ae04A-D0805-007): Optional

    5.8 Alarm Module (AE04A-D0805-007): Optional 5.8.1 Description The optional Alarm Module serves as a communication processor to provide a single point of monitoring interface for all the modules within the Fiber Optical Fed BDA. The summary alarm/monitoring status of each module can then be provided over Alarm Module’s RS-232 interface or sent thru the Fiber Optic Transceiver Module to a remote control location.
  • Page 56 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 56 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 57: Schematics

    5.8.3 Schematics 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 57 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 58 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 58 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 59 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 59 of 63 Error! Not a valid link. Page: Error! Not a valid link.
  • Page 60 INTENTIONALLY LEFT BLANK 400/800 MHz Fiber Optic & RF Fed Bi-Directional Wireless Innovations Group Amplifier Operations / Maintenance Manual 2601 Telecom Parkway Richardson, Texas 75082 DWG NO: Rev: Date:06/16/2004 60 of 63 Error! Not a valid link. Page: Error! Not a valid link.

  • Page 61: Installation

    INTENTIONALLY LEFT BLANK INSTALLATION 6.1 BDA Installation & Gain Setup INSTALLATION 1 Install the BDA in a standard 19” rack. The BDA should be placed in a location where the interconnect cables (i.e. fiber, RF and serial cable) can be easily installed and not susceptible to damage.
  • Page 62 2 Plug the BDA into a 120 VAC single phase three wire grounded receptacle (5-15R). 3 Connect the RF antenna cable to the antenna port (Type-N Female) on the rear panel of the BDA. If a RF fed BDA was installed, connect the base station RF cable to the base station port (Type-N Female) on the rear panel of the BDA.
  • Page 63 The RF fed BDA gain setting is performed at the factory and no field adjustments are required. With a 48 dB factory gain setting, the maximum input signal level is –18 dBm. This input level will ensure that FCC power limit (+30 dBm) is not exceeded. UPLINK GAIN SETUP The fiber fed BDA provides 18 dB of gain for 9 dB of optical loss.

  • Page 64: Bda Maintenance / Troubleshooting & Module Care

    The RF fed BDA uplink gain setting was performed at the factory and no field adjustments are required. For a 48 dB gain setting, the maximum input signal level is – 14 dBm with ALC active and – 43 dBm without ALC active. Note, the ALC is activated at the factory and when the input level exceeds –...

  • Page 65: Module Care

    The minimum tools and test equipment listed below are needed to successfully service the BDA: Spectrum Analyzer: 100kHz to 2GHz Signal Generator: 30MHz to 2GHz Attenuator: 20dB, 10W, DC-2GHz, (N male – N female) Optical Meter: Universal Volt-Watts Test cable x 2: N male –...

  • Page 66: Alarm Module Removal (Optional Equipment)

    Any active module not installed in a BDA must be kept in an anti-static bag or container. Any module sent back to Andrew Corporation for investigation/repair must be shipped in a anti-static container. Please contact Andrew Corporation quality department before returning a module.
  • Page 67 When tightening RF Type-N connectors located on the rear of the BDA, use a dedicated N- Type torque wrench. If Type-N connectors are over-tightened, irreparable damage will occur. Do not use adjustable pliers to loosen or tighten connectors. When connecting or disconnecting the fiber optic cable connectors located on the front panel of the fiber optic transceiver module, exercise caution not to touch the optical connector center pin.

This manual is also suitable for:

Ae04a-d1248-001Ae04a-d1437-001Ae04a-d1436-001
