First Alert F250 Manual

Model: F250
2.4GHz PIR MOTION
ACTIVATED LIGHTING
CAMERA SYSTEM
HALOGEN MOTION DETECTED SECURITY
LIGHTING WITH WIRELESS SECURITY
CAMERA
FEATURES:
• Turns on light when motion is
detected
• Automatically turns lighting off.
• Photocell keeps the lighting off
during daylight hours.
• Wireless security camera to monitor
day or night.
Floodlight
2.4G Antenna
Channel Selection Switch
Wiring Box
Passive Infrared Motion Sensor (PIR)
Adjusting Knob (Time, Lux)
PIR (Passive Infrared) Lens
Adjusting Screw
Camera
INTRODUCTION
Your First Alert 2.4GHz
LIGHTING CAMERA SYSTEM is a unique surveillance
system for your home or business. The system includes
a PIR LIGHTING CAMERA and a Wireless Receiver.
Using the Wireless Receiver as a bridge to connect to
your TV, you will see and hear real-time video images at
all times. At night, the built-in passive infrared (PIR)
motion sensor turns on the floodlight when it detects
motion in its coverage area so the camera images can
be seen on the TV for improved night time vision.
During the day, the built-in photocell sensor saves
electricity by deactivating the floodlight.
time adjustment switch lets you select how long the
floodlight will stay on after activation.
4-channel wireless system avoids interference. Two
operation options let you choose: Automatic Operation
or Manual Override.
Note: Read this entire manual before
you start to install the system.
SAFETY PRECAUTIONS
Do not install the PIR LIGHTING CAMERA when it
is raining.
Be sure to switch off the power at the power source
before installing.
Make sure that the power wiring comes from a
circuit with an external 16A miniature circuit breaker
for the short circuit protection or a suitable fuse.
Do not remove the adjusting screw. Tighten the
connection of the floodlight head assembly and
motion sensor to the base to avoid any rotation.
The unit is wall and ceiling mountable. (FIGURE 1)
FIGURE 1
MOTION ACTIVATED
A 4-position
Adjustable
