2.1 General

2.2 Hardware Installation

2.3 Connection and Startup

TAC AB, 16 May 2003
The TAC Xenta 511 is a device that is used as a web-based presentation
system for L W
ON ORKS
operator can easily view and control the devices in the L
work via the Internet or a local intranet.
The TAC Xenta 511 can also (at the same time) act as a L
adapter between TAC Vista® and a L
The TAC Xenta 511 is cabinet-mounted on a TS 35 mm norm rail
EN 50022.
90 (3.5)
2 3 4 5 6 7 8
12 13 14 15 16 17 18
10.1 70 (2.8)
(0.4)
TAC Xenta 511 dimensions, mm (in.)
Keep the unit dry and clean it externally using a dry cloth.
Sections 2.3.1 through 2.3.4 are mandatory for establishing web brows-
er contact with the TAC Xenta 511.
® networks. Using a standard web browser, the
W
ON ORKS
10
20
75 (3.1)
2 TAC Xenta 511
W net-
ON ORKS
T ®
ON ALK
network.
0-004-7870-0 (EN), 9 (32)
