TAC Xenta 511 and 911 Handbook
2.5 System Program Update
16 (32), 0-004-7870-0 (EN)
• sysinfo: General system information. (This will be needed if
consulting the TAC Solution Team.)
System error log
• err: Error log with the 10 most recent errors.
• err select: Filtering and error log search.
• err file: Error log listing an extended period.
Diagnostics
• ps: Process profile displaying processes currently running.
The TAC Xenta 511 system program can be updated via the IP network
if you run an installation program on the PC (see figure below). The in-
stallation program is distributed by TAC.
LAN
10 Mbps patch
UTP or STP cable
Connecting the TAC Xenta 511 to a Local Area Network
1 Connect the TAC Xenta 511 to a LAN according to the figure.
2 Connect the PC to the same network and start the installation pro-
gram TAC Xenta511_nnnn.exe. (Obtained via TARAI or on a
TAC Vista IV CD.)
Type root, password, the 511 IP address and follow the instructions on
the screen.
MMC
A RS232 B 10Base-T
TAC AB, 16 May 2003
2 TAC Xenta 511
