TAC Xenta 511 and 911 Handbook
2.3.3 Assigning an IP Address to the Xenta 511
TAC AB, 16 May 2003
3 Start a terminal emulator such as the Windows Hyperterminal.
TAC Xenta Programming Serial Kit, part no. 0-073-0920
Connecting a Hyperterminal to TAC Xenta 511
username:root
password:root
dsh/>setip
DHCP enable
(yes/no) no
.
.
dsh/>restart
Assigning the IP address using the Hyperterminal
1 Enter user name and password.
2 Type setip (see "Setting List for Configuration" on previous page)
and then answer the DHCP enable question:
- no if you are using a fixed IP address. Continue with step 3a).
- yes if you are using dynamic IP addressing. Continue with step
3b).
3 a) Enter the IP items from the Setting List:
• IP address
• Subnet mask
3 b) Enter the remaining items from the Setting List:
• Default Gateway
• DNS
• Web site name
• Domain name
• Host name
9600 bps
8 data bits
no parity
1 stop bit
no flow control
A RS232 B
0-004-7870-0 (EN), 11 (32)
2 TAC Xenta 511
10Base-T
