Charging A Hot Or Cold Battery Pack; Operation - sunjoe iONAIR Operator's Manual

NOTE: If the top light remains green while the bottom light
alternately flashes red and green, this indicates a temperature
abnormality (i.e. that the battery pack is either too hot or too
cold). If there is only a red blinking light, this indicates that
something is wrong with the battery. Contact Snow Joe
Sun Joe customer service center at 1-866-SNOW-JOE
®
(1-866-766-9563) for assistance.
Green
Flashing red/green
Temperature abnormal
5. A fully discharged pack with an internal temperature
in the normal range will fully charge in 2.5 to 3 hours
(between 32ºF/0ºC and 113ºF/45ºC). Heavily cycled
battery packs may take longer to charge completely.
6. If the charging light indicator alternately blinks red and
green or the light indicator does not come on at all, check
that the battery pack is fully seated into the bay. Remove
the pack and reinsert. If the problem persists, contact the
Snow Joe + Sun Joe customer service center at
® ®
1-866-SNOWJOE (1-866-766-9563) for assistance.
7. When charging is complete, remove the battery from the
charger by pulling the push lock button and sliding the
battery backward to unlock it from the charger (Fig. 6).
Fig. 6
Push lock button
8. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.

Charging a Hot or Cold Battery Pack

A red and green flashing indicator light on the charger
indicates that the battery pack temperature is outside the
charging range. Once the pack is within the acceptable
+
®
range, normal charging will take place and the red light will
be continuous. Hot or cold battery packs may take longer to
charge.
Flashing red only
Something is wrong

Operation

Building Tank Pressure
IMPORTANT! If the safety valve does not work properly,
over-pressurization may occur and cause an air tank rupture
or explosion. Contact the Snow Joe
service center at 1-866-SNOWJOE (1-866-766-9563) if the
safety valve doesn't work well.
9
Lithium-Ion Charging Status
Battery Pack Red Charger
Temperature Indicator Light
Too hot Flashing
Normal range Continuous
Too cold Flashing
1. Locate the air compressor on flat level surface to ensure
proper pump lubrication and to prevent the damage to
the unit. Keep at least 12 inches of space around the unit
to allow air circulation.
2. Pull out the safety valve to check if it works properly
(Fig. 7).
Fig. 7
3. Make sure the On/Off switch is in O (Off) position. Insert
the battery (Fig. 8).
Charging
Status
Not charging
Normal charging
Not charging
Safety valve
+ Sun Joe customer
® ®
