Using The Air Compressor - sunjoe iONAIR Operator's Manual

Accessory
Teflon tape
Metal connection
Rubber connection
Inflatable needle
Air blow gun
Auto tire chuck
2. The accessories can be connected with the unit as
indicated below (Fig. 12).
Fig. 12
Auto tire chuck
Air hose Air blow gun
3. To connect the auto tire chuck or air blow gun to the air
hose, simply pull back the coupler on the air hose, and
insert the selected accessory. Release the coupler to lock
the accessory (Fig. 13).
Usage
Use to wrap every screw-
on thread to ensure a
proper seal
Connected with the
air blow gun. Used for
cleaning dust.
Connected with the air
blow gun. Used for cleaning
dust on delicate surfaces.
Rubber will prevent the
delicate surfaces from being
scratched.
Connected with the air
blow gun. Used for Inflation
for ball products. e.g.
basketball, football, etc.
Connected to the air hose
and controls the air flow.
Connected to the air hose
and used for inflation of
vehicle tires, such as car,
motorcycle, ATV.
Metal connector
Rubber
connector
Inflation needle
11
Fig. 13
Coupler
4. To connect the inflation needle/metal connection/rubber
connection to the air blow gun, simply screw them on
clockwise. Use the wrench provided for a secure and tight
connection (Fig. 14).
Fig. 14
Screw
5. The air compressor is ready to use.

Using the Air Compressor

1. Turn the pressure regulator knob to adjust the output air
pressure to match the working pressure you need. You
can check the output pressure on the output pressure
gauge (Fig. 15).
Fig. 15
Output air
pressure gauge
Regulator
knob
NOTE: When adjusting the output pressure, turn the
knob clockwise to pass the desired setting, and then turn
counterclockwise to reach the desired pressure. DO NOT
exceed safety working pressure of the product that is
being inflated.
NOTE: The output air pressure cannot be set higher than
the tank pressure.
2. If the air blow gun is attached, press down on the air blow
gun switch to release the air (Fig. 16).
