Know Your Cordless Air Compressor
Read the owner's manual and safety instructions carefully before operating cordless air compressor. Compare the illustration
below to the cordless air compressor in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
1
9
8
7
5
FRONT
18
20
19
21
22
1. Handle
2. Battery compartment
3. Safety valve
4. Air tank
5. Supporting leg
6. Tank air pressure gauge

Technical Data

Battery Voltage*
Battery Capacity
Charging Time
Battery Run Time (Max.)
Working Pressure
Air Flow
*Initial no-load voltage, when fully charged, peaks at 40 volts; nominal voltage under typical load is 36 volts.
2
3
6
4
23
24
25
7. Regulator knob
8. Output air pressure gauge
9. Air outlet
10. On/Off switch
11. Air tank drain valve
12. Push lock button
40 V D.C.
4.0 Ah
2.5 – 3 hours (for full charge)
65 min
85 – 115 PSI (6 – 8 Bar)
0.7 SCFM at 90 PSI
6
10
11
BACK
13. Battery indicator
14. Push button for battery indicator
15. EcoSharp
lithium-ion battery (iBAT40)
®
16. EcoSharp
battery charger (iCHRG40)
®
17. Wrench
18. Air hose
19. Thread tape
20. Tapered inflation needle
21. Rubber blow gun nozzle
22. Pin inflation needle
23. Tire gauge
24. Blow gun switch
25. Blow gun
Load Current (Max.)
Air Tank Volume
Hose Length
Weight (air compressor only)
Weight (air compressor with battery)
15 14 13
12
16
17
5.5 A
1.6 Gal (6.1 L)
25 ft (7.6 m)
16.9 lbs (7.7 kg)
19.6 lbs (8.9 kg)
