- Page 1 Universal 8-Bay Charger for AA/AAA/C/D/9 NiMH & NiCd Rechargeable Batteries Owner's Manual...
- Page 3 Thank you for purchasing the Watson Universal 8-Bay Charger. Be sure to read this manual and note the precautions before using this product. >...
- Page 4 THE WATSON 8-BAY BATTERY CHARGER FEATURES: LED indicators that show the charging status of the batteries. Automatic charge current selection automatically selects the best charging current for each battery size. Reverse polarity protection protects your batteries and charger against incorrectly installed batteries.
- Page 5 An intelligent microprocessor that detects when batteries are fully charged. Delta voltage protection that recognizes the battery type and monitors voltage. Overheating protection that prevents your batteries from attaining dangerously high charging temperatures. Short-circuiting protection protects the charger and batteries from short circuits. Independent safety timer control for the 9 V battery terminals to ensure safe and effective...
-
Page 6: Charging Operation
You can fully charge up to eight AA or AAA, four C or D, or two 9 V batteries. Multiple-battery design accommodates NiMH and NiCd batteries. This is an economical power solution for users of portable devices with removable batteries. The universal 100-240 V AC and 12-16 V DC inputs are ideal for traveling and charging anywhere. - Page 7 The LED charging indicators turn red per channel when the batteries are charging and green when the batteries are fully charged. Note: The LEDs flash red if you insert a disposable battery such as an alkaline. If you see the LEDs flashing red, remove the battery.
-
Page 8: Charging Times
CHARGING TIMES*: (approximate hrs.) Upper Bay Lower Bay Battery Type (mAh) 1 or 2 3 or 4 2 or 4 6 or 8 AAA (850) AA (2500) C (2500) D (5000) 9 V Terminals 9V (180) *Actual charging times may vary depending on the cell's discharge level, capacity, and condition. - Page 9 AC / DC Adapter Port Upper Bay Lower Bay Channel LED AAA/AA 9 V LED Charging Terminals Charging Charging Indicators Contacts Indicators AC Adapter DC Adapter Overview | 8...
-
Page 10: Specifications
SPECIFICATIONS: Input: 100-240 V AC, 50/60 Hz 12-16 V DC Max. Output: 1-4 AA/C/D: 1.5 V/1.0 A 2-8 AAA: 3.0V/0.4A 2-8 AA: 3.0 V/0.6 A 1-2 9 V: 10.5 V/30 mA Dimensions 9.5 ¬ 5 ¬ 2.5 in. (W ¬ H ¬ D): (24.1 ¬... -
Page 11: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS Be sure to observe the following important precautions whenever using the charger and adapter. • Never try to open the case of the charger or attempt your own repairs. High-voltage internal components present the risk of electric shock when exposed. - Page 12 BATTERY HANDLING PRECAUTIONS Incorrect handling or misuse of batteries can cause them to leak or burst and damage your charger. Be sure to note the following important precautions to avoid problems with batteries. • Use only NiMH or NiCd dry cell batteries with the charger.
- Page 13 • Do not operate the charger in an environment with temperatures higher than 104¾F (40¾C) due to the risk of electrolyte leakage, overheating, and battery damage. • It is normal for batteries to become warm as they charge or discharge. •...
- Page 15 ONE-YEAR LIMITED WARRANTY This Watson product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty...
