- Page 1 CS-380-HP 380W 8-Port GaN Quick Charger Thank you for choosing Watson Pro Please read and follow these instructions, and keep this manual in a safe place.
-
Page 2: Compatible Products
THANK YOU FOR CHOOSING WATSON PRO. The Watson Pro 380-watt charger is an ideal accessory for conference rooms, podcast studios, and DAWs where charged devices are always needed. It has a maximum output capacity of 380 watts via eight USB ports, so you can simultaneously charge multiple power-hungry laptops and V-mount batteries. - Page 3 OVERVIEW USB-C1 & USB-C2 USB-C5 & USB-C6 AC power input Power indicator USB-C3 & USB-C4 Heat vent and internal fan USB-A1 & USB-A2...
- Page 4 • Do not attempt to disassemble or repair the charger—doing so will void the warranty, and Watson will not be responsible for any damage. • Make sure that this product is intact and that there are no missing parts.
-
Page 5: Specifications
SPECIFICATIONS Output Ports USB Type-C ( 6) USB Standard-A ( 2) Power Input AC 100-240V 50/60Hz 5A Max Total Power 380 W Max Output Power USB-C1/C2: 3.3-21V 5A, 5V 3A, 9V 3A, Outputs 12V 3A, 15V 3A, 20V 5A, 28V 5A (140W max) USB-C3/C4/C5/C6: 5V 3A, 9V 3A, 12V 3A, 15V 3A, 20V 5A (100W max) USB-A1/A2: 4.5V 5A, 5V 4.5A, 9V 3A,... - Page 6 One-Year Limited Warranty This Watson product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
