Owner's Manual
for
6V BMW Ride On
This manual contains important safety, assembly, operation and
maintenance information.
Please read and fully understand this manual
before operation.
Save this manual for future reference.
See back page for Customer Service Information
Consulte el reverso para Servicio de Información al Cliente
Voir pages verso pour des renseignements le service à la Clientèle

Advertisement

Table of Contents
loading

Related Manuals for Huffy 6V BMW

Summary of Contents for Huffy 6V BMW

  • Page 1 HBMW Rideon EN 040616 © Copyright Huffy Corporation 2017 Date Code Label Here Owner’s Manual 6V BMW Ride On This manual contains important safety, assembly, operation and maintenance information. Please read and fully understand this manual before operation. Save this manual for future reference.

  • Page 2: Table Of Contents

    • Battery Re-charge Interval and Time ............ 22 • Battery Storage ..................23 • Battery replacement and disposal ............23 • Troubleshooting Guide ...............24-25 Huffy Warranty • Huffy Corporation Limited Warranty ............. 26 Tools Needed for Assembly: Small Phillips Screwdriver Spanner Socket (supplied)

  • Page 3: Warnings

    WARNING The user must follow all safety rules and guidelines below or serious injury or death may occur to the user. • Always use common sense and safe practices when using the vehicle. This ve- hicle is unsuitable for children under 3 years. The user must be 3 to 5 years, and weigh no more than 65 lbs (30kgs).

  • Page 4: Warnings

    WARNING - Charging the Drive Motor Battery The following safety hazards may result in serious injury or death to the user of the vehicle: • Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire or explosion. Only use the supplied rechargeable battery (or suitable replacement) and char- ger with the vehicle.

  • Page 5: User Requirements

    Radio Frequency Information Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for the Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 6: Parts Assembly View

    Parts View REAR AXLE STACK-UP LEFT RIGHT...

  • Page 7: Parts Assembly List

    Parts List Description Body Door, Left Door, Right Steering Wheel Assembly Windshield Mirror, Left Mirror, Right Mirror Screws (x2) Seat Drive Motor Drive Wheel Wheel (x3) Axle Motor Cover Motor Cover Screws (x4) Wheel Cover (x4) Wheel Cover Screws (x3 per wheel) Axle Washers (x8) Locknut (x4) Hubcaps (x4)

  • Page 8: Drive Battery First Charge

    Drive Battery First Charge Charger Red battery CAUTION: Do not operate vehicle Connector Connector without FUSE COVER in place! NOTE: Before first use, charge battery 15 to 18 hours. NOTE: It is easier to charge the Drive Battery before beginning assembly: 1.

  • Page 9: Drive Motor And Rear Wheel Installation

    Installing the Drive Motor and Right Rear Wheel Rear axle Spanner NOTE: Begin by turning the vehicle upside down and removing nuts and washers from axle. 1. Slide the Motor (9) onto the rear axle (right side). 2. Feed the Plug and Wires and Motor-End through Motor Hole (9a). 3.
  • Page 10 Installing the Left Rear Wheel Spanner Washer assembled already NOTE: With vehicle still upside down, remove nut and washer from axle. 1. Slide Washer (15) onto the rear axle. 2. Slide the Bushing (18) into the indent in the back of the Wheel (11) (it will sit even with the back of the wheel).

  • Page 11: Front Wheel Installation

    Installing the Front Wheels Spanner Front axle NOTE: Begin by removing nuts and washers from axles. 1. Slide Washer (15) onto the Front Axle. 2. Slide the Bushing (18) into the indent in the back of the Wheel (11) (it will sit even with the back of the wheel).

  • Page 12: Steering Rod Installation

    Installing the Steering Rod FRONT of Car Installation 1. Locate the Steering Rod Hole (A) and Steering Slot (B). 2. Place a Washer (23) over the long end of the Steering Rod (19) and slide up to rod Dimple (C). 3.

  • Page 13: Connecting The Drive Battery

    Connecting the Drive Battery to Drive Motor after Charging WARNING : Connect the red to red connectors, and white to white connectors. Connecting incorrectly can damage the battery and/ or motor. FRONT white of Car Connector Under Seat white motor connector 1.

  • Page 14: Motor Cover Installation

    Installing the Motor Cover Screw Driver FRONT of Car Under Seat Installation 1. Fit the Motor Cover (13) on the motor. 2. Install four Screws (A) securely.

  • Page 15: Seat Installation

    Installing the Seat Lock Tabs Installation 1. Align the Tabs (A) on the back of the seat with the slots in the back of the main body. 2. Align the Lock on the front of the seat with the hole in the middle of the main body hole.

  • Page 16: Steering Wheel And Sound Effect Batteries

    Installing the Steering Wheel and Batteries Installation 1. Remove the screw from the steering wheel (A). 2. Place the steering wheel over the steering column (B). 3. Align the holes on each side of steering wheel with the holes at the end of the steer- ing column.

  • Page 17: Side Mirror Installation

    Installing the Side Mirrors Installation 1. Insert the Right Mirror (A) into the slots of the mirror bracket (B) located on the door. 2. Insert a screw (C) through the top of the Screw Driver hole in the mirror and mirror bracket (the nut is captive inside the mirror bracket).

  • Page 18: Door Lock Operation

    Operation: Door Locks This vehicle is equipped with Door Locks (A) on each door. • To operate the Door Locks, close door completely and slide Door Lock DOWN into Frame Lock Slot (B) fully. Test by pulling outward gently on door. NOTE: Do not shut door with Door Lock extended.

  • Page 19: Operation And Features

    Operation and Features Steering wheel Sound buttons Shift lever Power switch Foot pedal To Operate the vehicle: 1. Power Switch: Turns the vehicle on and off. Rock the switch to “ON” position to turn the vehicle on, - “OFF” position to turn it off. Leave OFF when not in use. 2.

  • Page 20: General Information

    Maintenance - General Information The vehicle should be checked for damage, missing or badly worn parts before each use. • Check the tightness of the fasteners before each use. • Check the tightness of the wheels: • Note: If the drive wheel is not tight, it will not engage the gears and the vehicle will not run.

  • Page 21: Charging The Drive Battery

    Charging the Drive Battery connector Red battery connector Charger Red battery CAUTION: Do not operate vehicle Connector Connector without FUSE COVER in place! NOTE: Before first use, charge battery 15 to 18 hours. 1. Ensure power switch is OFF. Remove the seat (Refer to Seat Section) - use a coin or screwdriver to unlock the lock in front middle of the seat.

  • Page 22: Battery Re-Charge Interval And Time

    Re-charge Interval and Time Important! Check the drive battery and charger (supply cord, connector) for wear and damage before charging. Do not charge the battery if damage has occurred. Only replace with the same type 6V rechargeable battery and charger supplied by the manufacturer. •...

  • Page 23: Battery Storage

    Battery storage Do not leave the battery connected in the vehicle for long period of times while not being used. This may drain the battery completely and cause permanent damage. Disconnect the battery connectors from the battery when the vehicle is not going to be used for a long period of time.

  • Page 24: Troubleshooting Guide

    Troubleshooting Guide The following are examples of potential problems. Completely read through this manual and the troubleshooting guide table before calling. If you still need help resolving the problem please contact Customer Service. NOTE: Vehicle should be turned off and fully changed before doing troubleshooting. Problem Possible Cause Solution...

  • Page 25: Troubleshooting Guide

    Troubleshooting Guide - continued Problem Possible Cause Solution Vehicle will not Poor contact of wires or Check that the battery connectors run when Switch is connectors are fi rmly plugged into each other. If pressed. wires are loose around the motor call Customer Service.
  • Page 26 Limited Warranty General: • Used in a manner contrary to the instructions • Part or model specifi cations are subject to and warnings in this Owner’s Manual change without notice. • This Limited Warranty is the only warranty Huff y will not be liable for incidental or for the product.
  • Page 27 Notes...
  • Page 28 ANTES DE DEVOLVER EL RETOURNER AU MAGASIN, PRODUCTO A LA TIENDA, COMMUNIQUEZ AVEC LE SERVICE COMUNÍQUESE CON SERVICIO À LA CLIENTÈLE DE HUFFY. NOUS AL CLIENTE DE HUFFY. NOS VOUS AIDERONS VOLONTIERS AVEC COMPLACE AYUDARLO CON TOUT PROBLÈME CONCERNANT LES CUALQUIER PARTE O PROBLEMA PIÈCES OU LE MONTAGE!
