  • Page 1 APP-CONTROL User Manual...
  • Page 2 Contents 1 Scope of delivery3 2 Overview of the RaceChip  4 3 Installation 5 4 Operation 14 5 Trouble Shooting 16 6 Contact 23 Overview and explanation of symbols Warnings and important information – please read! General information on installation and use...

  • Page 3: Scope Of Delivery

    1 Scope of delivery RaceChip GTS Black Deactivation plug calibrated specifi cally for your returns your engine to stock tune vehicle Wiring harness User Manual automobile-grade, compatible installation and operation with your vehicle Cable ties Engine warranty 2 x long cable ties...
  • Page 4 2 Overview of the RaceChip Digital User Interface for controlling the RaceChip +/- buttons for changing the tuning stages (see Operation) Power ON light; lights only when the vehicle ignition is on and power is being supplied to the RaceChip...
  • Page 5 3 Installation Step 1 of 7 - Preparation Before installing the RaceChip, please wait for your engine to cool down. Otherwise there is a risk of sustaining burns. Open your vehicle’s bonnet, and close and lock the doors. Wait about 10 minutes before starting Step 2, as all current consumers must have switched themselves off Generally speaking, you do not require special tools to perform the installation.
  • Page 6 3 Installation Step 2 of 7 - Removing the engine cover The pictures on the following pages are for demonstration purposes only – details may be in your car’s engine bay. However, the installation process is identical. The engine cover is held in place by clips (A) or screws (B) •...
  • Page 7 The best way to fi nd the common rail itself is by following the injection lines. These always lead directly from the injection system to the cylinders, i.e. they can be traced back from the engine block. Setup illustration Common rail connection Common rail connection Cable with disconnected Cable from the stock plug RaceChip...
  • Page 8 If you experience diffi culties disconnecting the common rail sensor, see Detaching the Connector Correctly (separate document) for assistance • Now connect the end of the RaceChip wiring harness to the disconnected connector and the other end to the sensor •...
  • Page 9 Trouble Shooting for a solution Carrying out function test • Position the RaceChip and the wiring harness safely in the engine bay. Do not fi x anything in place yet. • Switch the ignition on DO NOT start the engine •...
  • Page 10 • Use the 360° fi xing clips included to fi x the RaceChip and thread the cable ties through the fi xing clips to hold the wiring harness in place.
  • Page 11 When selecting a fastening point, make sure that the RaceChip is protected from exposure to water, heat, and vibrations • Do not wrap the RaceChip in an airtight bag as this can lead to a built up of condensation •...
  • Page 12 Please fi nd the most important steps below. In general, you should follow the instructions given by your smartphone for the connection. • The connection between the RaceChip and your smartphone is set up in the last step of the installation process •...
  • Page 13 6 Go to your smartphone’s settings and view all discoverable Bluetooth devices. Select “RaceChip” 7 If “RaceChip” is not shown as a discoverable device or if it is shown but does not pair with your phone, please contact our Customer Service.
  • Page 14 Open the RaceChip app. You can fi nd the tuning stages offered by your RaceChip under the menu heading Tuning Stages. For safety reasons, you can select the tuning stage only when the car’s ignition is on but the motor is not running...
  • Page 15 4 Operation The RaceChip has been calibrated specifically for the engine in your car, and further adjustment is generally not necessary in order to get the best performance. However, performance tolerances or the condition of the engine sometimes mean that Fine tuning is needed after installing the RaceChip Engine runs roughly, or the extra performance is not detectable.

  • Page 16: Trouble Shooting

    5 Trouble Shooting If the RaceChip does not function as it should, you can find some initial assistance here. If the suggestions here do not solve the problem, please contact our Customer Service (see Contact) Description of problem What to do No extra performance •...
  • Page 17 • De-install the RaceChip wiring harness to the point that you can reconnect all the connections in your car as they were before you started installing the RaceChip. Lock the car and...
  • Page 18 • Please contact our Customer Service. We can update your RaceChip’s settings based on your description of the problem • You can update the settings of your RaceChip by going to Settings on the App (Search for updates for my car) Quality of gear shift •...
  • Page 19 If the SPORT tuning stage was not active when the fault light came on for the first time, please activate it now on the RaceChip App. If it was active, you can skip the next step and contact our Customer Service straight away.
  • Page 20 • Please contact our Customer Service. We can update your RaceChip’s settings based on your description of the problem • You can update the settings of your RaceChip by going to Settings on the App (Search for updates for my car) The car does not start •...
  • Page 21 • This means that our Customer Service can update your RaceChip’s settings and help you save fuel when you use an appropriate driving style. • You can update the settings of your RaceChip by going to Settings on the App (Search for updates for my car) No connection after •...
  • Page 22 Check if RaceChip and your phone will pair now. • Deactivate the Bluetooth connection and completely shut down the RaceChip App (iOS: push the home button twice and close the RaceChip App; Android: Open the task manager and close the RaceChip App) Activate the Bluetooth connection and open the RaceChip App again •...
  • Page 23 Please have your customer details close by when you contact us. Follow us on: /racechipchiptuning @racechipDE Legal notice RaceChip Chiptuning GmbH & Co. KG Ulmer Str 123 73037 Göppingen Germany Sales tax identifi cation number: DE 260672432 Registered at District Court of Ulm: HRA 721734...
