Bose FreeSpace DS 100SE Technical Data Sheet

Product Overview
The Bose ® FreeSpace ® DS 100SE loudspeakers are
high-performance, surface-mount loudspeakers
designed for foreground music and speech
reproduction in a wide range of commercial
applications, including retail, restaurant and
hospitality establishments.
These 100-watt loudspeakers can be installed up
to 30ft (10m) high, both indoors and outdoors.
The contemporary styling easily blends with a
wide variety of décors. Horizontal or vertical
mounting options offer installation flexibility.
The DS 100SE loudspeakers meet numerous
standards for combination music and evacuation
systems around the world when used with the
optional junction boxes.
Product Information
The FreeSpace DS 100SE surface-mount loudspeakers
are engineered for installation on walls and
other solid surfaces. Simple 1➞2➞3 installation: (1)
Wire and attach the wall bracket (2) Secure the
loudspeaker to the wall bracket with one screw
(3) Snap the wire connector into the wall bracket.
The included bracket allows for horizontal or
vertical mounting positions, each with either
pitch or yaw adjustment.
The DS 100SE loudspeakers can be used as
8-ohm, 100-watt loudspeakers or as 70/100V
loudspeakers. An easy-to-access thumb wheel
allows taps to be set quickly and simply without
the use of tools.
Two Twiddler drivers in a proprietary Articulated
®
Array ® loudspeaker design provide a 180° H x 75° V
dispersion pattern out of the box when loud-
speakers are mounted horizontally. The array can
be rotated easily to maintain this wide horizontal
dispersion pattern when the loudspeakers are
installed in the vertical orientation.
Performance of the FreeSpace DS 100SE loud-
speakers can be maximized through the use of
the recommended Bose loudspeaker equalization
resident in select Bose electronics or by using
other equipment with parametric equalization.
The loudspeakers can be used out of the box
with a 55-Hz high-pass filter when recommended
loudspeaker equalization is not used. The DS 100SE
loudspeakers are acoustically compatible with
DS 100F flush-mount loudspeakers and can be
integrated on the same loudspeaker line.
Bose Professional Systems Division
FreeSpace ®
Loudspeakers
Key Features
• Maximum SPL of 105 dB-SPL (peak 111 dB-SPL)
• Full-range performance from 65 Hz to 16 kHz
• 180° H x 75° V coverage pattern (out of the box,
when loudspeakers are mounted horizontally)
• Two 2.25" (57mm) Twiddler drivers in a
proprietary Articulated Array loudspeaker
design and a separate 5.25" (133mm) driver
• Simple 1➞2➞3 installation
• Pitch or yaw adjustment options:
Horizontal mount: maximum pitch 45° or
maximum yaw 30°
Vertical mount: maximum pitch 30° or
maximum yaw 45°
• Integrated multi-tap transformer provides
easy-to-change tap settings without tools:
70V – 12.5W, 25W, 50W, 100W
100V – 25W, 50W, 100W
• Can be used as an 8Ω, 100W loudspeaker
• Can be used indoors and outdoors and can
be painted
• Listed to ANSI/UL 1480-2005
Applications
The FreeSpace DS 100SE loudspeakers are
well-suited for permanent installations at:
• Retail stores
• Transportation facilities
• Hospitality venues
DS 100SE
• Concourses
• Restaurants
• Houses of worship
