12.

Setting the Reverse Function Switch

When the swash plate and the rail rotor react according
to the above movements, the function reversal switches
(1 - 6) are set correctly.
If the swash plate servos or the tail servo react precisely
opposite in one control movement, the respective func-
tion reversal switch must be switched.
The six switches (see figure 17) have the following functions:
Switches
1
2
3
4
5
6
To change the function, first disconnect the flight battery from the helicopter and then switch off the transmitter.
Then switch the respective switch from normal (= „NOR") to reverse (= „REV") or from „REV" to „NOR".
Then take the transmitter and the model into operation and test for correct control function.
76
Function
Roll function
Nod Function
Motor function
Tail Function
Gyro sensitivity
Pitch Function
Factory Setting
REV
REV
NOR
REV
REV
REV
Figure 17
