* The transmitter is technically able to control model helicopters and model planes. For this, the 5 DIP-switches
have the following functions:
DIP-
Switches
Model helicopter
1 Transmitter in model airplane mode
2 No mixer function
(normal mode)
3 Controller VA
Pitch trim
4
5 Control encoder calibration „OFF"
For the switch position „OFF", the DIP switch must be switched down and for the switch position „ON", the DIP switch
must be switched up. The input fields with a grey background show the factory settings for the DIP switches.
Attention!
The DIP switches 1 - 3 are pre-set ex works for the model helicopter „Beginner Falcon V2" (see grey marking
in the table) and usually do not need to be changed. If the control stick assignment at the transmitter is
changed (from mode 2 to mode 1), the DP switch 4 must be changed.
DIP switch 5 is used to calibrate the control stick. For more information on this, see the chapter „Mainte-
nance and Care".
** The simulator output socket can be used to tap the PWM signal for servo control, to also, e.g., control the interface
of a flight simulator or teacher transmitter with it. Further information on this can be found in the operating instruc-
tions of the simulator.
Switch position „OFF"
Model airplane
mode
Wing model
Standard tail unit
without mixer
Mode 1
Model helicopter
mode
Transmitter in model helicopter mode
Swash plate mixer
(CCPM-mode)
Controller VA
Gyro sensitivity
Switch position „ON"
Model airplane
mode
Delta model
V tail mixer
Mode 2
Steuergeber -Kalibrierung „ON"
mode
