- Page 1 Real Fires Classic Installation Instructions realfi res.co.nz...
- Page 2 Fireplace cavity and chimney inspection Real Fires are designed for installation into an existing masonry fireplace and chimney. Prior to installation the fireplace should be measured and a suitable size Real Fire selected. In most situations the fireplace will require masonry alteration to accommodate the firebox.
-
Page 3: Gas Supply
Gas supply A suitable gas supply needs to be provided at the right hand rear corner of the fireplace cavity. The pipe sizing should be calculated to supply gas to suit the megajoule rating of the fire. See rating chart. The gas supply should be reduced down to 10mm copper pipe at the fireplace location and left with a 10mm coil of approx 1 metre to feed into the firebox. - Page 4 Installation instructions - Firebox Once the fireplace cavity has been prepared and the gas supply pipe is positioned at the rear right hand side. The firebox can be installed. Note - Electrical options The firebox will have two electrical leads from the rear of the firebox. All fireboxes are pre wired for electrical options, Fan and Electric On/Off.
-
Page 5: Burner Commissioning
Installation instructions - Burner into firebox The burner is supplied boxed complete with, firebox reflectors, grate, ash cover, vermiculite, logs, & coals. To make the gas connection, place the burner in the firebox so that the back of the burner is touching the back of the firebox and is positioned central. -
Page 6: Optional Fan
Repeat on opposite side. Hang trim on brackets and check for level then push firmly onto Velcro pad. Instruct User Once the installation is complete, instruct the user on the operation of the fire and complete commissioning details in the Real Fires user manual. ALL INSTALLATIONS MUST BE CERTIFIED realfires.co.nz... - Page 7 realfires.co.nz...
- Page 8 realfires.co.nz...
- Page 9 Real Fires Log and Coal Layout This drawing is a typical example of the log and coal layout on a Real Fire 800. The layout is basically the same for Real Fires Log and Coal Layout all models with logs and coals decreased or increased in width to suit the size of fire. (The pilot ignition assembly has been omitted from the drawing).
-
Page 10: Framing Details
Model 800 Installation Into Timber Framing And New Masonry Block Construction New Masonry Block The following instructions are for installation into timber frame. The method of installation is the same for New Masonry Block. See Masonry Block Drawing Ventilation Ventilation to the room that houses the fire must meet the requirements of NZS5261. Framing Details Prior to installation, timber framing needs to be provided to suit the selected Real Fire. - Page 11 When installed into timber framing the Real Fire must be installed with an insulation kit. This must be ordered with the fire and fitted in the factory by Real Fires. The insulation kit allows the firebox to be installed with minimal timber clearances: 10mm clearance on sides of firebox and 25mm clearance from rear and top of firebox The timber clearance from the twin wall flue is also 25mm.
-
Page 12: Flue Requirements
2 metre horizontal clearance from any part of the building see cowl clearance drawing. Flue and Cowl Size Model Flue Cowl Size Real Fire 650 150mm inner flue/ 200mm outer flue 150/200 Cowl Real Fire 700 150mm inner flue/ 200mm outer flue... - Page 13 The Firebox and flue should be secured by fixing with seismic strapping and/or brackets to framing. Flue bends are available from Real Fires if the flue needs to be offset. Appropriate weatherproof roof flashing/ chimney capping must be used to comply with NZS 5261.
- Page 14 Natural Gas burner Fill the burner tray with the vermiculite supplied ensuring the burner tube is completely covered. Lay logs and coals on top of the vermiculite as shown in the log/coal layout drawing. Note that the shelf at the back of the burner is also used.
- Page 15 Repeat on opposite side. Hang trim on brackets and check for level then push firmly onto Velcro pad. Instruct User Once the installation is complete, instruct the user on the operation of the fire and complete commissioning details in the Real Fires user manual. ALL INSTALLATIONS MUST BE CERTIFIED realfires.co.nz...
- Page 16 realfires.co.nz...
- Page 17 realfires.co.nz...
- Page 18 realfires.co.nz...
- Page 19 Real Fires Log and Coal Layout This drawing is a typical example of the log and coal layout on a Real Fire 800. The layout is basically the same for Real Fires Log and Coal Layout all models with logs and coals decreased or increased in width to suit the size of fire. (The pilot ignition assembly has been omitted from the drawing).
