Dimensions and weights

Dimensions

Dimensions, WISE Parasol EX 690
Dimensions (mm)
A
B
C
D
570
567
178
70
* When the sensor module WISE SMB is installed in the face plate the height meas-
urement (H) increases by 12 mm
Dimensions, WISE Parasol EX 1290
Dimensions (mm)
A
B
C
D
1170
567
198
70
* When the sensor module WISE SMB is installed in the face plate the height meas-
urement (H) increases by 12 mm

Weight

Weight, WISE Parasol EX 690
Size
Type
Dry weight
690
690-A
690
690-B
Weight incl. design module but excl. sensor module WISE SMB (0.1 kg).
Weight, WISE Parasol EX 1290
Size
Type
Dry weight
1290
1290-A
1290
1290-B
Weight incl. design module but excl. sensor module WISE SMB (0.1) kg.
E
F
G
H *
280
690
690
230
E
F
G
H *
280
1290
690
230
Water volume (l)
(kg)
cooling
heating
21.9
1.1
23.2
1.1
0.2
Water volume (l)
(kg)
cooling
heating
34.7
1.4
39.7
1.4
0.9
23/11/2017
Ø
125
Dimensions base module
Ø
125
F
Dimensions with installed design module
Swegon reserves the right to alter specifications.
WISE Parasol EX
A
C
H
3
