Assembly Introduction

1.Key Parts

a. Slots:
The slot is a groove in components, which usually appears on connectors and servos. When a component has multiple slots,
the "ABCDE" naming method will be used to distinguish them.
b. Rudders:
c. Plugs:
Plugs on components come in different shapes and sizes, and are compatible with different fasteners.
Rudders are rectangular structures projecting from components. The symbols "△□☆○" are used to indicate the
different directions.
圆孔位
十字孔位
8
